Periodic Motion

1
Chapter 13

• Periodic Motion

2
Special Case

• Simple Harmonic Motion (SHM)

3
Simple Harmonic Motion (SHM)

• Only valid for small oscillation amplitude
• But SHM approximates a wide class of periodic
  motion, from vibrating atoms to vibrating tuning
  forks...

4
Starting Model for SHM mass m attached to a
spring
Demonstration
5
Simple Harmonic Motion (SHM)

• x displacement of mass m from
  equilibrium
• Choose coordinate x so that x 0 is the
  equilibrium position
• If we displace the mass m, a restoring force F
  acts on m to return it to equilibrium (x0)

6
Simple Harmonic Motion (SHM)

• By SHM we mean Hookes Law holdsfor small
  displacement x (from equilibrium), F
  k x ma k x
• negative sign F is a restoring force(a and x
  have opposite directions)

Demonstration spring with force meter
7
(No Transcript)
8
What is x(t) for SHM?

• Well explore this using two methods
• The reference circlex(t) projection of
  certain circular motion
• A little mathSolve Hookes Law

9
The Reference Circle

• P mass on spring x(t)
• Q point on reference circle
• P projection of Q onto the screen

10
The Reference Circle

• P mass on spring x(t)
• Q point on reference circle
• A amplitude of x(t)
• (motion of P)
• A radius of reference circle (motion of Q)

11
The Reference Circle

• P mass on spring x(t)
• Q point on reference circle
• f oscillation frequency of P 1/T
  (cycles/sec)
• w angular speed of Q 2p /T
  (radians/sec)
• w 2p f

12
What is x(t) for SHM?

• P projection of Q onto screen.
• We conclude the motion of P is

See additional notes or Fig. 13-4 for q
13
Alternative A Little Math

• Solve Hookes Law
• Find a basic solution

Solve for x(t)
14
See notes on x(t), v(t), a(t)

• v dx/dt v 0 at x A v max
  at x 0
• a dv/dta max at x A a 0
  at x 0

15
Show expression for f
16

• going from 1 to 3,increase one of A, m, k
• (a) change A same T
• (b) larger m larger T
• (c) larger k shorter T

Do demonstrations illustrating (a), (b), (c)
17
Summary of SHMfor an oscillator of mass m

• A amplitude of motion, f phase angle
• A, f can be found from the values of x and dx/dt
  at (say) t 0

18
Energy in SHM

• As the body oscillates, E is continuously
  transformed from K to U and back again

See notes on vmax
19
E K U constant
Do Exercise 13-17
20
Summary of SHM

• x displacement from equilibrium (x 0)
• T period of oscillation
• definitions of x and w depend on the SHM

21
Different Types of SHM

• horizontal (have been discussing so far)
• vertical (will see acts like horizontal)
• swinging (pendulum)
• twisting (torsion pendulum)
• radial (example atomic vibrations)

22
Horizontal SHM
23
Horizontal SHM

• Now show a vertical spring acts the same,if we
  define x properly.

24
Vertical SHM
Show SHM occurs with x defined as shown
Do Exercise 13-25
25
Swinging SHM Simple Pendulum
Derive w for small x
Do Pendulum Demonstrations
26
Swinging SHM Physical Pendulum
Derive w for small q
Do Exercises 13-39, 13-38
27
Angular SHMTorsion Pendulum (fiber-disk)
28
Application Cavendish experiment (measures
gravitational constant G). The fiber twists when
blue masses gravitate toward red masses
29
Angular SHMTorsion Pendulum (coil-wheel)
Derive w for small q
30
Radial SHMAtomic Vibrations
Show SHM results for small x (where r R0x)
31
Announcements

• Homework Sets 1 and 2 (Ch. 10 and 11) returned
  at front
• Homework Set 5 (Ch. 14)available at front, or
  on course webpages
• Recent changes to classweb accesssee HW 5 sheet
  at front, or course webpages

32
Damped Simple Harmonic Motion
See transparency on damped block-spring
33
SHM Ideal vs. Damped

• Ideal SHM
• We have only treated the restoring force
• Frestoring kx
• More realistic SHM
• We should add some damping force
• Fdamping bv

Demonstration of damped block-spring
34
Damping Force

• this is the simplest model
• damping force proportional to velocity
• b damping constant (characterizes
  strength of damping)

35
SHM Ideal vs. Damped

• In ideal SHM, oscillator energy is constant
  E K U , dE/dt
  0
• In damped SHM, the oscillators energy decreases
  with time E(t) K
  U , dE/dt lt 0

36
Energy Dissipation in Damped SHM

• Rate of energy loss due to damping

37
What is x(t) for damped SHM?

• We get a new equation of motion for x(t)
• We wont solve it, just present the solutions.

38
Three Classes of Damping, b

• small (underdamping)
• intermediate (critical damping)
• large (overdamping)

39
underdamped SHM
40
underdamped SHMdamped oscillation, frequency
w
41
underdamping vs. no damping

• underdamping
• no damping (b0)

42
critical dampingdecay to x 0, no oscillation

• can also view this critical value of b as
  resulting from oscillation disappearing

See sketch of x(t) for critical damping
43
overdamping slower decay to x 0, no
oscillation
See sketch of x(t) for overdamping
44
Application

• Shock absorbers
• want critically damped (no oscillations)
• not overdamped(would have aslow response time)

45
Forced Oscillations

• (Forced SHM)

46
Forced SHM

• We have considered the presence of a damping
  force acting on an oscillator
  Fdamping bv
• Now consider applying an external force
  Fdriving Fmax coswdt

47
Forced SHM

• Every simple harmonic oscillator has a natural
  oscillation frequency
• (w if undamped, w if underdamped)
• By appling Fdriving Fmax coswdt we force the
  oscillator to oscillate at the frequency wd (can
  be anything, not necessarily w or w)

48
What is x(t) for forced SHM?

• We get a new equation of motion for x(t)
• We wont solve it, just present the solution.

49
x(t) for Forced SHM

• If you solve the differential equation, you find
  the solution (at late times, t gtgt 2m/b)

50
Amplitude A(wd)

• Shown (for f 0)A(wd) for different b
• larger b smaller Amax
• ResonanceAmax occurs at wR, near the natural
  frequency,w (k/m)1/2

Do Resonance Demonstrations
51
Resonance Frequency (wR)

• Amax occurs at wdwR (where dA/dwd0)

52
natural, underdamped, forcedw gt w gt wR

• natural frequency
• underdamped frequency
• resonance frequency

53
Introduction toLRC Circuits

• (Electromagnetic Oscillations)

See transparency on LRC circuit
54
Electric Quantity Counterpart

• charge Q(t) x(t)
• current I dQ/dt v dx/dt(moving
  charge)(generates a magnetic field, B)

55
Electrical Concepts

• electric charge Q
• current (moving charge) I dQ/dt
• resistance (Q collides with atoms) R
• voltage (pushes Q through wire) V RI

56
Voltage (moves charges)

• resistance R causes charge Q to lose energy
  V RI
• (voltage potential energy per unit charge)
• C and L also cause energy (voltage) changes

57
Circuit Element D(Voltage)

• R resistance VR RI(Q collides with atoms)

• C capacitance VC Q/C(capacity to store Q
  on plate)
• L inductance VL L(dI/dt)(inertia towards
  changes in I)

58
Change in Voltage Change in Energy

• voltage potential energy per unit charge
• recall, around a closed loop

59

• Which looks like

60
Circuit Element Counterpart

• 1/C 1/capacitance k
• L inductance m
• R resistance b
• (Extra Credit Exercise 31-35)
• Use this table to write our damped SHM as damped
  electromagnetic oscillations

61
In the LRC circuit, Q(t) acts just like
x(t)!underdamped, critically damped, overdamped
62
Driven (and resonance) Vdriving Vmax coswdt
