Landforms Geography

1
Landforms Geography
Glaciers
2
Glacial Geomorphology

• Development of a glacier
• Types of glaciers
• Glacial landforms
• History of glaciers
• What causes glaciation?
• Impact of global climate change on glaciers
• Periglacial processes and landscapes

3
Development of a Glacier

• Glacier slowly moving mass of dense ice formed
  by gradual thickening, compaction, and refreezing
  of snow water over time
• After summer melt, some snow left over
• With weight and partial melting, snow turns to
  Firn, crunchy transition from snow to ice
• Further compaction, ice crystals align, become
  dense glacial ice which flows slowly downslope
• At least 40-m thick to become glacier

4
Glacial Mass Budget

• Glacial input Snow
• Glacial output ice, meltwater or water vapor
• Zone of Accumulation top of glacier where temps
  are cooler - input gt output
• Zone of Ablation lower part of glacier where
  temps are higher output gt input
• Equilibrium line point on glacier where input
  output

5
Glacial Formation
6
Glacial Mass Budget
7
Glacial Mass Budget
8
Glacial Movement

• Glaciers move through internal deformation
• Interior of glacier like malleable plastic

9
Glacial Movement
10
Glacier Types

• Mountain Glaciers
• Ice Cap Continuous sheet of ice covering entire
  landscape
• Ice Field Buries all but tallest mountains
  can be very thick
• Alpine Glacier Flows down valleys away from
  high country
• Cirque - Bowl-shaped depression on mountain flank
  due to glacial erosion snow source

11
(No Transcript)
12
Alaskan Glaciers
Hubbard Glacier
13
Continental Glaciers

• Huge ice masses covering a large part of a
  continent or large island also called ice
  sheets
• More than 3000 m deep in places
• Covers most of Antarctica and Greenland
• Weight of ice presses lithosphere down into
  asthenosphere, called isostatic depression

14
Continental Glaciers
15
Glacial Landforms

• Rock debris picked up by glaciers, transported
  in direction of movement deposited
• Glacial erosion
• Glacial Abrasion scratch and gouge bedrock
• Glacial Striations caused by glacial abrasion
• Glacial Grooves deep striations
• Glacial Plucking boulders ripped from ground by
  glacier deposited by retreating glacier, called
  Glacial Erratics

16
Glacial Erosional Landforms

• Roche Moutonnée rounded hill, gradual on side
  toward direction from which glacier comes

Glacial Erratic
Glacial Striations
17
Alpine Erosional Landforms

• Glacial Erosion
• Cirque bowl-like feature on mountain flanks
• Tarn small lake in bottom of cirque
• Arête narrow, steep ridges between cirques
• Horn mountain with 3 or more arêtes at summit
• Glacial Trough u-shape valley eroded by glacier
• Hanging Valley side trough above main trough
  possible waterfall

18
Alpine Erosional Landforms
Cirque
Horn Matterhorn
Glacial Trough
19
Glacial Depositional Landforms (Till)

• Glacial Till sediment directly deposited by
  glacier many particle sizes
• Moraine winding ridge formed by till at the
  front or side of glacier Moraine types
• Lateral along former edges of glacier
• Terminal along front of former glacier
• Recessional formed as glacier recedes
• Medial between 2 glaciers
• Ground irregular deposition as glacier recedes

20
Glacial Depositional Landforms (Till)
21
Glacial Depositional Landforms (outwash)

• Glacial Outwash sediments deposited by water
  out under a glacier as it melts forms Outwash
  Plain, flat feature in front of former glacier
• Kame large mound deposited near glacier front
• Esker winding ridge from water flowing in
  tunnel through ice under glacier
• Kettle Lake big ice block fallen off glacier
  front is buried by outwash, melts later forming
  lake

22
Glacial Depositional Landforms
23
Glacial Depositional Landforms
24
History of Glaciation

• As early as 2.3 B years ago, ice covered much of
  Earth, and off and on since then
• Most important Ice Age was Pleistocene Epoch, 1.8
  M years ago till 10K years ago
• Glacial period when glaciers expand from poles
  cooler temps, lower sea level,
• Interglacial period when glaciers recede
  warmer temps, higher sea level

25
Pleistocene Glaciations

• Named for southern extent of ice sheet in North
  America
• Nebraskan 1 million yrs ago
• Kansan 625 K yrs ago
• Illinoisan 300 K yrs ago
• Wisconsin 35 K to 10 K yrs ago
• Laurentide Ice Sheet eastern North America
• Cordilleran Ice Sheet western North America

26
Maximum Extent of Pleistocene Glaciation
30 of earths surface covered by ice sheets
(Only 11 coverage today)
27
Oxygen Isotopes
28
Evidence of More Glaciations?

• Ice core samples suggest more than the known 4
  glaciations show more cool, glacial periods
• Oxygen isotopes O-16 O-18 both in water, but
  O-18 evaporates more in warmer climate, so ratio
  of O-16 to O-18 in ice cores can indicate
  relative warmth of climates over 1 million yrs
  ago!

29
Great Lakes
30
Causes of Glaciation

• Summer temp (melting) is key to glaciation
• Possible Factors1. Variations in solar
  radiation (dust, sunspots)
• 2. Reduced carbon dioxide (escaping heat)
• 3. Increased volcanic activity (reflective dust)
• 4. Variations in Earth-Sun geometry (axial tilt,
  shape of orbit, rotation)
• 5. Plate Tectonics

31
Milankovitch Theory

• Dominant theory of causes of glaciation, based on
  Earth-Sun geometry
• Orbital eccentricity strongly elliptical orbit
  puts Earth farthest from Sun in summer, cooling
  it
• Tilt obliquity Earths tilt varies from 22.1º
  to 24.5º - less tilt means lower angle Sun and
  less insolation at poles, thus cooler summers
• Orbital precession wobbles of Earths axis -
  North Pole may point toward Sun at farthest point
  of orbit, creating a cool summer

32
Milankovitch Theory
Orbital Eccentricity
Axial Tilt
Orbital Precession
When three factors coincide, high probability of
glaciation
Glacial Geomorphology Processes and Landforms
33
Climate Change and Glaciers

• Since mid-1800s glaciers have been receding, both
  alpine and continental
• Alps, Parts of Andes, Mt. Kilimanjaro melting
• Thousands of sq miles of Antarctica Greenland
  ice sheet lost over last 30 years due to warming
• Melting area of Greenland has increased rapidly
  since early 1990s

34
Climate Change and Glaciers
35
Climate Change and Glaciers
36
Periglacial Processes and Landscapes

• In near-glacial environments constant
  freeze/thaw cycle effects on landscape
• Permafrost ground that is permanently frozen
• Continuous poleward of -7ºC mean annual
  isotherm all surfaces frozen exp under water
  avg 400 m thick, up to 1000 m thick
• Discontinuous poleward of -1ºC mean annual
  isotherm thinner than continuous, esp. on south
  facing slopes

37
Extent of Permafrost
38
Permafrost Processes

• Active Layer soil that melts refreezes daily
  or seasonally as thin as 10 cm in continuous
  permafrost, up to 2 m thick in discontinous
• Dramatic warming in arctic is making active layer
  much thicker releasing tons of CO2
• Talik body of unfrozen ground within
  permafrost, e.g. under a lake, important for
  movement of groundwater
