Title: CNC Tooling


1
CNC Tooling
  • Lab 3
  • Basics Calculations

2
Vertical Mill Cutting Tools
  • Identify each cutting tool found on the milling
    machine. (Attempt to be specific)
  • In teams of 3, compete to find the most
    information about each cutting tool
  • One person in the text book
  • One person on the internet
  • One person in a machinery handbook
  • Limit the entire exercise to 30 minutes
  • The winning team will have the most individual
    pieces of information about each cutting tool
  • Winning teams will have first access to the CNC
    Vertical Mill
  • Instructor Stop Here for Students

3
Carbide Inserts
  • How would you characterize the carbide insert
    used on the Vertical Mill?
  • In teams of 3, compete to find the most
    information about that specific carbide insert
  • One person in the text book
  • One person on the internet
  • One person in a machinery handbook
  • Limit the entire exercise to 15 minutes
  • The winning team will have the most individual
    pieces of information about the carbide insert
  • Winning teams will be team captains for the team
    projects
  • Instructor Stop Here for Students

4
Vertical Mill Spindle Speed
  • Feed rate for a cutting tool is dependent upon
    spindle speed. As 3 member teams, create lists
    to answer the following (limit time to 15
    minutes)
  • In manual mode, how is spindle speed controlled
    on the VMC190xi?
  • What options does the operator have for
    controlling/monitoring spindle speed?
  • What are the anticipated differences in torque
    and the resulting stalling of the tool bit, with
    relation to driving horsepower of the mill?
  • What do you anticipate would happen if the mill
    is in CNC automatic mode and the tool bit stalls
    while cutting?
  • Instructor Stop Here for Students

5
Answers
  • Spindle speed on the VMC190xi can not be
    accurately controlled by using the manual
    pushbuttons. Therefore, the only manual method
    of controlling spindle speed is through the
    Boxford software.
  • Optionally, an instrument that reads out in RPM
    can be mounted to display spindle speed
  • As horsepower increases, the variation in spindle
    speed due to cutter loading decreases. Also, for
    machines with geared or belt driven spindles, the
    slower spindle speeds at the same motor speed
    will have more torque and less speed variation.
  • When in CNC automatic mode and the tool bit
    stalls while cutting, the table will further bind
    the tool into the work piece and may break the
    tool, damage the work piece, stall the x-y table
    movements,

6
Vertical Mill - Tapping
  • When tapping using a vertical mill, how is torque
    on the tap limited to reduce breakage?
  • Instructor Stop Here for Students

7
Answer
  • Recommended Drill Bit size is chosen for tap
  • A cutting fluid is specified for the material
  • Taps are discarded when worn
  • Taps are matched to the materials machined
  • Spiral fluted taps help minimize the torque while
    cutting threads by keeping shavings from binding
    within the cutting edges
  • A tap clutch accessory can be purchased for about
    500 which can be programmed to slip at specific
    torques
  • A reversing motion is needed by some taps to
    clear metal shavings to prevent binding
  • Some milling machines have torque sensors that
    allow feedback to reverse the spindle when a
    preset torque is exceeded

8
Calculating Spindle Speed
  • Each material has recommended cutting speeds
    listed in sfpm.
  • Sfpm 3.14 x tool diameter x RPM
    12
  • Solve for RPM

9
Calculating Spindle Speed
  • If a material calls for an optimal cutting rate
    of 250 feet per minute, what should the spindle
    speed be set at?
  • Assume
  • ¼ end mill
  • Aluminum stock
  • Instructor Stop Here for Students

10
Calculating Spindle Speed
  • RPM SFPM x 12
    Tool Diameter 3.14
  • RPM 250 x 4 x 12 1
    3.14
  • RPM 3822 or about 3800 rpm

11
Calculating Spindle Speed
  • Using Appendix C, what size of end mill and
    spindle speed should be used when milling
    aluminum?
  • As a 3 member team, determine the appropriate
    relationships
  • Limit this exercise to not more than 15 minutes
  • Instructor Stop Here for Students

12
Calculating Spindle Speed
  • Aluminum sfpm 250 when using HSS
  • Sfpm (tool diameter) x RPM x 3.14 / 12
  • Solving for variables on one side and constants
    on the other
  • RPM x tool diameter SFPM x 12 / 3.14
  • Therefore, for any tool diameter there is a
    unique spindle speed, but there is no ideal tool
    diameter and speed combination
  • tool diameter is restricted by available power,
    clamping of the material, the smallest radius
    feature of a machined object, and other criteria

13
Calculating Tap Feed Rate
  • Given the requirement to tap a ¼-20 prepared
    hole in a ½ aluminum plate what 2 pieces of
    information are necessary to manually control the
    tap operation along the z-axis?
  • How many seconds will it take to tap each hole
    using spindle speed calculations?

14
Hint
  • Aluminum sfpm 250
  • 1/4x20 tap 1/4 diameter cutting surface
  • RPM 250 x 4 x 12 4000 rpm
    1 3.14
  • 20 threads per inch or 10 threads per ½
  • 1 revolution per thread
  • Instructor Stop Here for Students

15
Answer
  • 10 revolutions x min x 60 sec 0.15 sec
    4000 rev 1 min
  • Therefore, such operations can only be performed
    using CNC equipment
  • Slower manual operations can be performed at a
    cost of labor
  • Always check the tool manufacturers
    recommendations for determining best spindle
    speeds, appropriate cutting fluids,

16
Calculating Feed Rates
  • Associated with Feed Rates are the actual table
    positions in the X and Y axis
  • Using full size manual vertical mills, how are
    the actual positions of the X and Y axis
    controlled/measured?
  • Go to the next page for a picture of a full size
    manual vertical mill

17
Full Size Vertical Mill
18
Manual Feed Rates
  • What are the options for manual feed rate
    control/monitor of the x-y axis on the VMC190xi?
  • Setup the Boxford Software to display the manual
    control of x-y axis feed rates
  • Each team should be splitting the tasks
  • There are 4 computers with identical software,
    hooked to different types of machines
  • The Boxford manuals can be accessed on all of the
    lab computers, and also from the NSF sponsored
    Wiki website

19
Team Problems
  • Youve had several opportunities thus far to
    operate as a TEAM
  • List your insights as to why you believe the team
    suffers in certain areas
  • Separately list what benefits you achieved by
    working as a team
  • As a class, create a comprehensive list of rules
    for operating as a team
  • Limit this exercise to not more than 20 minutes

20
Evolved List of Team Rules
  • Every semester the class has been asked to do
    this exercise, and the following is a compiled
    list of rules that students have cited that are
    believed to contribute to team productivity
  • use the Result Management tool cited earlier if
    there is a conflict

21
CNC machining from CAD Drawings
  • Capturing the specific features of a design in a
    binary file provides the opportunity to machine
    parts in an automated mode
  • Remove the tooling from the VMC190xi and put the
    mill in the Home Position
  • See Lab 2

22
Selecting a sample CAD drawing
  • Video for CAM implementation of a sample CAD
    drawing goes here

23
Run the CAM software without tooling
  • For the remainder of the lab, every student
    should
  • remove all tooling and work pieces from the 4 CNC
    machines
  • Start each CNC machine
  • Put each machine manually in the Home Position
  • then mock machine a sample CAD file
  • Be ready to hit the Emergency Stop Button to
    prevent a collision between the spindle, vise,
    x-y table, chuck, walls of the enclosure,
  • If time permits, introduce precision orientation
    of the bench vise
