Urinary System

1
Urinary System
2
KIDNEY
3
Renal capsule
Outer layer of kidney
4
Renal cortex
Superficial reddish area
5
Renal medulla
Deep darker area containing the pyramids and
columns
6
Renal column
Area between the pyramids
7
Renal pyramid
2
3
1
4
5
6
7
8
Minor calyx
Each kidney contains 8-18
9
Major calyx
Each kidney contains 2-3
10
Renal pelvis
11
Renal hilum
12
Ureter
13
Bladder
14
trigone
Contains the 2 ureteral openings
15
Detrusor muscle
16
Transitional epithelium
17
Urethra
18
Prostatic urethra
Portion of the urethra that passes through the
prostate
19
Membranous urethra
Intermediate and shortest section of the male
urethra
20
Penile urethra
Portion of the urethra that passes through the
penis
21
Internal urethral sphincter
22
External urethral sphincter
23
RENAL BLOOD SUPPLY
24
Renal artery
25
Segmental artery
Renal artery divides and each segmental artery
supplies one renal region
26
Interlobar artery
Blood vessels that pass through the columns
between the pyramids
27
Arcuate artery
Blood vessels that form an arc between the cortex
and the medulla
28
Interlobular artery
Branch from arcuate arteries to enter the cortex
29
Afferent arteriole
Branches from interlobular arteries and is where
blood enters glomerulus
30
Glomerulus
31
Efferent arteriole
Blood exits glomerulus
32
Peritubular capillaries
efferent arterioles divide to surround portions
of the nephron in the cortex
33
Vasa recta
Some efferent arterioles have long loop-shaped
capillaries that surround portions of the nephron
in the medulla
34
Interlobular vein
Peritubular capillaries reunite to form
interlobular veins Interlobular veins also
receive blood from the vasa recta
35
Arcuate vein
Receives blood from the interlobular veins
36
Interlobar vein
Pass through the renal columns and receives blood
from arcuate veins
37
Segmental vein
Receives blood from the interlobar veins
38
Renal vein
39
Nephron
Contains one renal corpuscle and its renal tubule
40
Renal corpuscle

• Lies in the cortex and contains
• Glomerulus
• Bowmans Capsule

41
Glomerulus
42
Glomerular (Bowmans) capsule
Double walled epithelial cup that surrounds the
glomerulus
43
Visceral layer of Bowmans capsule
Nucleus of podocyte
44
Proximal convoluted tubule (PCT)
(orange twisted)
Portion of renal tubule that lies in the cortex
and is attached to the glomerulus and coiled
45
Loop of Henle
Also called a nephron loop Extends into the
medulla, makes a hairpin turn, and returns to the
cortex
46
Descending limb
(orange straight)
Portion of the nephron loop that descends from
the PCT into the medulla
47
Ascending limb
(purple straight)
Portion of the nephron loop that ascends from
medulla and returns to the cortex, attaching to
the DCT
48
Distal convoluted tubule (DCT)
(purple twisted)
Portion of renal tubule that lies in the cortex
and is attached to the collecting duct and coiled
49
Collecting tubule (duct)
Several DCTs drain into one collecting duct
50
Juxtaglomerular apparatus (JGA)
Distant Convoluted Tubule
Afferent arteriole
Regulates arterial blood pressure and the rate of
blood filtration by the kidneys
51
Macula densa
Tall crowded cells on the wall of the distal
convoluted tubule that monitor ion concentration
of the fluid passing through
52
Juxtaglomerular cells
In the wall of the afferent arteriole These are
modified smooth muscle fibers
53
Types of nephrons
54
cortical
80-85 of nephrons
Nephrons that have a short loop of Henle and
glomeruli in the superficial region of the cortex
Cortex Medulla
55
juxtamedullary
15-20 of nephrons
Cortex Medulla
Nephrons that have glomeruli in the cortex close
to the medulla and a long loop of Henle that
spans the medulla
