Tier I: Mathematical Methods of Optimization

1
(No Transcript)
2
Tier I Mathematical Methods of Optimization

• Section 2
• Linear Programming

3
Linear Programming (LP)

• Linear programming (linear optimization) is the
  area of optimization problems with linear
  objective functions and constraints
• Example
• minimize f(x) 6x1 5x2 2x3 7x4subject
  to 2x1 8x3 x4 20
• x1 5x2 2x3 3x4 -5

4
Linear Programming cont

• None of the variables are multiplied by another
  variable, raised to a power, or used in a
  nonlinear function
• Because the objective function and constraints
  are linear, they are convex. Thus, if an optimal
  solution to an LP problem is found, it is the
  global optimum

5
LP Standard Form

• LP Standard form
• minimize f cx
• subject to Ax b
• xi 0 i 1, , n
• where c is called the cost vector (1 by n), x is
  the vector of variables (n by 1), A is the
  coefficient matrix (m by n), and b is a m by 1
  vector of given constants.

6
Standard Form Basics

• For a maximization problem, we can transform
  using
• max(f(x)) ? min(-f(x))
• For inequality constraints, use slack
  variables 2x1 3x2 5 ? 2x1 3x2 s1
  5 where s1 0

7
Using Slack Variables

• When we transform the equation
• 2x1 3x2 5 to 2x1 3x2 s1 5
• If the left-hand side (LHS) (2x1 3x2) is less
  than the right-hand side (RHS) (5), then s1 will
  take a positive value to make the equality true.
  The nearer the value of the LHS is to the RHS,
  the smaller the value of s1 is. If the LHS is
  equal to the RHS, s1 0. s1 cannot be negative
  because the LHS cannot be greater than the RHS.

8
Standard Form Example

• Example
• Write in Standard Form
• maximize f x1 x2
• subject to 2x1 3x2 6
• x1 7x2 4
• x1 x2 3
• x1 0, x2 0
• Define slack variables x3 0 x4 0

9
Example Problem Rewritten

• The problem now can be written
• minimize g x1 x2
• subject to 2x1 3x2 x3 6
• x1 7x2 x4 4
• x1 x2 3
• x1 0, x2 0, x3 0, x4 0

10
Linear Algebra Review

• The next few slides review several concepts from
  linear algebra that are the basis of the methods
  used to solve linear optimization problems

11
Vectors Linear Independence

• Vectors
• A k-vector is a row or column array of k numbers.
  It has a dimension of k.
• Linear Independence (LI)
• A collection of vectors a1, a2, , ak, each of
  dimension n, is called linearly independent if
  the equation means that for j1, 2,
  , k

12
Linear Independence cont

• In other words, a set of vectors is linearly
  independent if one vector cannot be written as a
  combination of any of the other vectors.
• The maximum number of LI vectors in a
  n-dimensional space is n.

13
Linear Independence cont

• For example, in a 2-dimension space
• The vectors are not
• linearly independent because x2 5x1.
• are LI because there is
• no constant you can multiply one by to get the
  other.

14
Spanning Sets

• A set of vectors a1, a2, , ak in a n-dimensional
  space is said to span the space if any other
  vector in the space can be written as a linear
  combination of the vectors
• In other words, for any vector b, there must
  exist scalars l1, l2, , lk such that

15
Bases

• A set of vectors is said to be a basis for a
  n-dimensional space if
• The vectors span the space
• If any of the vectors are removed, the set will
  no longer span the space
• A basis of a n-dimensional space must have
  exactly n vectors
• There may be many different bases for a given
  space

16
Bases cont

• An example of a basis is the coordinate axis of a
  graph. For a 2-D graph, you cannot remove one of
  the axes and still form any line with just the
  remaining axis.
• Or, you cannot have three axes in a 2-D plot
  because you can always represent the third using
  the other two.

17
Systems of Equations

• Linear Algebra can be used to solve a system of
  equations
• Example
• 2x1 4x2 8 3x1 2x2 11
• This can be written as an augmented matrix

18
Systems of Equations cont

• Row operations may be performed on the matrix
  without changing the result
• Valid row operations include the following
• Multiplying a row by a constant
• Interchanging two rows
• Adding one row to another

19
Solving SOEs

• In the previous example, we want to change the A
  matrix to be upper triangular
• multiply top
• row by ½
• add -3 times the
• top row to the
• bottom row

20
Solving SOEs cont

• multiply bottom
• row by -1/8
• From the upper triangular augmented matrix, we
  can easily see that x2 1/8 and use this to get
  x1
• x1 4 2 . 1/8 15/4

21
Matrix Inversion

• The inverse of a matrix can be found by using row
  operations
• Example
• Form the augmented matrix (A, I)
• Transform to (I, A-1)
• using row operations

22
Optimization Equations

• We have seen that the constraints can be written
  in the form .
• We should have more variables than equations so
  that we have some degrees of freedom to optimize.
• If the number of equations are more than or equal
  to the number of variables, the values of the
  variables are already specified.

23
General Solution to SOEs

• Given a system of equations in the form
• Assume m (number of equations) lt n (number of
  variables) ? underspecified system
• We can split the system into (n-m) independent
  variables and (m) dependent variables. The
  values of the dependent variables will depend on
  the values we choose for the independent
  variables.

24
General Solution cont

• We call the dependent variables the basic
  variables because their A-matrix coefficients
  will form a basis. The independent variables
  will be called the nonbasic variables.
• By changing the variables in the basis, we can
  change bases. It will be shown that this allows
  examining different possible optimum points.

25
General Solution cont

• Separate the A matrix in the following way
• Or,

26
General Solution cont

• Define matrices B N as the following
• where B is a m by m matrix, N is a m by (n-m)
  matrix, aj is the jth column of the A matrix
• B is called the basic matrix and N is called
  the nonbasic matrix

27
General Solution cont

• The B matrix contains the columns of the A-matrix
  that correspond to the x-variables that are in
  the basis. Order must be maintained.
• So, if x4 is the second variable of the basis, a4
  must be the second column of the B-matrix
• The N matrix is just the columns of the A-matrix
  that are left over.

28
General Solution cont

• Similarly, define
• We will see later how to determine which
  variables to put into the basis. This is an
  important step to examine all possible optimal
  solutions.

29
General Solution cont

• Now, we have
• Multiply both sides by B-1
• So,

30
Basic Solution

• We can choose any values for (n-m) variables (the
  ones in xN) and then solve for the remaining m
  variables in xB
• If we choose xN 0, thenThis is called a basic
  solution to the system
• Basic Solution

31
Basic Feasible Solutions

• Now we have a solution to Ax b. But that was
  just one of two sets of constraints for the
  optimization problem. The other was xi 0, i
  1, , n (non-negativity)
• A basic feasible solution (BFS) is a basic
  solution where every x is non-negative
• A BFS satisfies all of the constraints of the
  optimization problem

32
Extreme Points

• A point is called an extreme point (EP) if it
  cannot be represented as a strict (0 lt l lt 1)
  convex combination of two other feasible points.
• Remember a convex combination of two points is a
  line between them.
• So, an EP cannot be on a line of two other
  feasible points.

33
Extreme Points (Graphical)

• Given a feasible region, an extreme point cannot
  lie on a line between two other feasible points
  (it must be on a corner)
• In a n-dimensional space, an extreme point is
  located at the intersection of n constraints

Not Extreme Points
FeasibleRegion
Extreme Point
34
Optimum Extreme Points
c
Starting Point

• We have a maximization problem, so we want to go
  as far in the direction of the c (objective
  function) vector as we can
• Can we determine anything about the location of
  the optimum point?

35
Optimum Extreme Points
c

• If we start on a line, we can move along that
  line in the direction of the objective function
  until we get to a corner
• In fact, for any c vector, the optimum point will
  always be on a corner

36
Basic Feasible Solutions

• In a n-dimensional space, a BFS is formed by the
  intersection of n equations.
• In 2-D

Basic Feasible Solution
Constraint 1
Constraint 2

• But, we just saw that an extreme point is also
  a corner point. So, a BFS corresponds to an EP.

37
Tying it Together

• We just saw that a basic feasible solution
  corresponds to an extreme point.
• This is very important because for LP problems,
  the optimum point is always at an extreme point.
• Thus, if we can solve for all of the BFSs
  (EPs), we can compare them to find the optimum.
• Unfortunately, this takes too much time.

38
Simplex Method Introduction

• The simplex method is the most common method for
  solving LP problems.
• It works by finding a BFS determining whether it
  is optimal and if it isnt, it moves to a
  better BFS until the optimal is reached.
• This way, we dont have to calculate every
  solution.

39
Simplex Method Algebra

• Recall

Sum over all non-basic variables
Objective Function
substitute
into above equation
40
Simplex Method Algebra
Multiply through and collect xj terms
where
41
Simplex Method Equations

• So, minimize
• If (cj zj) 0 for all j ? N, then the current
  BFS is optimal for a minimization problem.
• Because, if it were lt 0 for some j, that nonbasic
  variable, xj, could enter the basis and reduce
  the objective function.

Subject to
42
Entering Variables

• A nonbasic variable may enter the basis and
  replace one of the basic variables
• Since xN 0, and we have non-negativity
  constraints, the entering variable must increase
  in value.
• The entering variables value will increase,
  reducing the objective function, until a
  constraint is reached.

43
Entering Variable Equation

• The equation to determine which variable enters
  is . Calculate for all nonbasic indices j
• For a minimization problem, choose the index j
  for which cj - zj is the most negative
• If cj - zj 0 for all j, the solution is optimal
• For a maximization problem, choose the index j
  for which cj - zj is the most positive
• If cj - zj 0 for all j, the solution is optimal

44
Leaving Variables

• As the value of the entering variable increases,
  the value of at least one basic variable will
  usually decrease
• If not, the problem is called unbounded and the
  value of the minimum objective function is -?
• The variable whose value reaches zero first will
  be the variable that leaves the basis

45
Entering Leaving Variables

• Example x1 is entering the basis while x2, x3
  x4 are the current basic variables
• As soon as x2 reaches zero, we must stop because
  of the non-negativity constraints. But, now x2
  0, so it is a nonbasic variable and x1 gt 0, so
  it is a basic variable. So, x2 leaves the basis
  x1 enters the basis.

x4
x3
x2
x1
46
Leaving Variable Equation

• Let j be the index of the variable that is
  entering the basis and i be the index of the
  variable that is leaving the basis
• Meaning, for every index i that is in the basis
  and has , calculate .
  The index of the value that is the minimum is the
  index of the leaving variable.

47
Leaving Variable Equation

• The previous expression is obtained from the
  equation
• which applies when a constraint is reached

48
The Example Revisited

• x2, x3, x4 start out at (B-1b)i (i2, 3, 4)
  and have slopes of (B-1aj)i (i2, 3, 4) where
  j1 because 1 is the index of the entering
  variable (x1)
• Thus, the distance we can go before a basic
  variable reaches zero is for B-1a1 gt
  0. But, if (B-1a1)i lt 0 (like x3), it wont ever
  reach zero.

49
The Example Revisited
x4
x3
x2
x1

• We can also see how if none of the variables
  decreased, we could keep increasing x1 and
  improving the objective function without ever
  reaching a constraint This gives an unbounded
  solution

50
Example Problem

• Minimize f -x1 x2
• Subject to x1 x2 5
• 2x1 x2 4
• x1 3 x1, x2 0
• Given The starting basis is x1, x2, x3.
• Insert slack variables x3, x4, x5.

51
Example

• Minimize f -x1 x2
• Subject to x1 x2 x3 5
• 2x1 x2 x4 4
• x1 x5 3
• x1, x2, x3, x4, x5 0

52
Example

• 1st Iteration

53
Example

• Now, check optimality
• x4
• x5

lt 0
gt 0
54
Example

• So, x4 enters the basis since its optimality
  indicator is lt 0.

55
Example

• So, x3 is the leaving variable

56
Example
a4 has been substituted for a3

• 2nd Iteration

57
Example

• Optimality Indicators
• x3
• x5

58
Example Solution

• All of the optimality indicators are 0, so this
  is the optimal solution.
• So,

59
Simplex Algorithm Steps

• With the chosen basis, get B and solve xB B-1b
  and f cBxB.
• Calculate cj zj for all nonbasic variables, j.

• For a min. problem, if all cj zjs are 0, the
  current solution is optimal. If not, choose the
  index with the most negative cj zj.
• For a max. problem, if all cj zjs are 0, the
  current solution is optimal. If not, choose the
  index with the most positive cj zj.

60
Simplex Algorithm Steps

• Using the equation choose the leaving variable.
• If all (B-1aj)is are 0, then the solution is
  unbounded
• Let xj enter the basis and xi leave the basis.
  Obtain the new B matrix and start again with step
  1.

61
Choosing A Starting Basis

• In the example, we were given a starting basis.
  How to come up with one on our own?
• Case 1 max (or min) problem with
• Ax b (all inequalities) and
• all entries of the b vector 0.
• Insert slack variables into constraint equations
  and use the resulting identity matrix as the
  starting basis

62
Choosing A Starting Basis

• Let s vector of slack variables
• The problem will become

Subject to
Where I The Identity Matrix
. . .
. . .
. . .
63
Choosing A Starting Basis

• Choose the slack variables to be the starting
  basis
• The starting basis matrix (B) is the coefficients
  of the slack variables. This happens to be the
  identity matrix.
• We can see that the starting basis is feasible
  (xB 0)

64
Example Problem 2

• Minimize -x1 3x2
• Subject to 2x1 3x2 6
• -x1 x2 1 x1, x2 0
• Insert slack variables
• 2x1 3x2 x3 6
• -x1 x2 x4 1
• x1, x2, x3, x4 0

65
Example 2

• Use the slacks as the starting basis

66
Example 2

• Optimality Indicators
• j1
• j2

c2 - z2 is the most negative, so x2 enters the
basis
67
Example 2
x2 is entering the basis
68
Example 2
So, x4 is the leaving variable.
69
Example 2

• 2nd Iteration

x2 replaced x4
70
Example 2

• Optimality Indicators
• j1
• j4
• So, x1 enters the basis

71
Example 2

• Leaving Variable
• So, x3 leaves the basis and x1 replaces it.

72
Example 2

• 3rd Iteration

73
Example 2

• Optimality Indicators
• j3
• j4
• Both cj-zjs are 0, so the current solution is
  optimal

74
Example 2

• This graph shows the path taken.
• The dashed lines are perpendicular to the cost
  vector, c.

x2
Increasing c
x1
75
Example 2

• Since we were minimizing, we went in the opposite
  direction as the cost vector

x2
Increasing c
x1
76
More on Starting Bases

• Case 2 max (or min) problem with
• Ax b (at least some constraints)
• All entries of the b vector 0
• Add slacks to make the problem become
• Ax Is b x, s 0.
• We cannot do the same trick as before because now
  we would have a negative identity matrix as our B
  matrix.

77
Case 2 cont

• 2-Phase Method
• Introduce artificial variables (y) where needed
  to get an identity matrix. If all constraints
  were , the problem will become
• Ax Is Iy b x, s, y 0

78
Artificial Variables

• Artificial variables are not real variables.
• We use them only to get a starting basis, so we
  must get rid of them.
• To get rid of them, we solve an extra
  optimization problem before we start solving the
  regular problem.

79
2-Phase Method

• Phase 1
• Solve the following LP starting with B I and xB
  y b
• Minimize y
• Subject to Ax Is Iy b x, s, y 0
• If y ? 0 at the optimum, stop the problem is
  infeasible. If y 0, then use the current basis
  and continue on to phase 2.

80
2-Phase Method cont

• Phase 2
• Using the objective function from the original
  problem, change the c vector and continue solving
  using the current basis.
• Minimize (or Maximize) cx
• Subject to Ax Is b x, s 0

81
Artificial vs. Slack Variables

• Slack variables are real variables that may be
  positive in an optimum solution, meaning that
  their constraint is a strict (lt or gt) inequality
  at the optimum.
• Artificial variables are not real variables.
  They are only inserted to give us a starting
  basis to begin the simplex method. They must
  become zero to have a feasible solution to the
  original problem.

82
Artificial Variable Example 1

• Consider the constraints
• x1 2x2 4
• -3x1 4x2 5
• 2x1 x2 6 x1, x2 0
• Introduce slack variables
• x1 2x2 x3 4
• -3x1 4x2 x4 5
• 2x1 x2 x5 6

83
AV Example 1

• We can see that we cannot get an identity matrix
  in the coefficients and positive numbers on the
  right-hand side. We need to add artificial
  variables
• x1 2x2 x3 y1 4
• -3x1 4x2 x4 y2 5
• 2x1 x2 x5 6

84
AV Example 1

• Now we have an identity matrix, made up of the
  coefficient columns of y1, y2, x5.
• We would solve the problem with the objective of
  minimizing y1 y2 to get rid of the artificial
  variables, then use whatever basis we had and
  continue solving, using the original objective
  function.

85
Artificial Variable Example 2

• Consider the constraints
• x1 2x2 5x3 -4
• 3x1 x2 3x3 2
• -x1 x2 x3 -1 x1, x2, x3 0
• Introduce slack variables
• x1 2x2 5x3 x4 -4
• 3x1 x2 3x3 x5 2
• -x1 x2 x3 -1

86
AV Example 2

• We dont have to add an artificial variable to
  the 1st constraint if we multiply by -1.
• When we multiply the last constraint by -1 and
  add an artificial variable, we have
• -x1 2x2 5x3 x4 4
• 3x1 x2 3x3 x5 2
• x1 x2 x3 y1 1
• x1, x2, x3, x4, x5, y1 0

87
Constraint Manipulation

• So, after adding slacks, we must make the
  right-hand side numbers positive. Then we add
  artificial variables if we need to.

88
Artificial Variable Example 3

• Consider the problem
• Maximize -x1 8x2
• Subject to x1 x2 1
• -x1 6x2 3
• x2 2 x1, x2 0

89
AV Example 3

• Insert slacks
• x1 x2 x3 1
• -x1 6x2 x4 3
• x2 x5 2
• So, we need an artificial variable in the 1st
  constraint.

90
AV Example 3

• Insert artificial variable
• x1 x2 x3 y1 1
• -x1 6x2 x4 3
• x2 x5 2

91
AV Example 3

• So, Phase 1 is
• Minimize y1
• Subject to x1 x2 x3 y1 1
• -x1 6x2 x4 3
• x2 x5 2
• Our starting basis is y1, x4, x5.

92
AV Example 3

93
AV Example 3

• Optimality Indicators
• j1
• j2
• j3

94
AV Example 3

• Its a tie between x1 x2 pick x1 to enter the
  basis

x1 is entering the basis
95
AV Example 3
So, x1 replaces y1 in the basis
96
AV Example 3
97
AV Example 3

• Optimality Indicators
• j2
• j3
• j6

98
AV Example 3

• All of the optimality indicators are 0, so this
  is an optimum solution.
• So, we keep this basis and change the objective
  function to the original one
• Maximize x1 8x2
• Our basis is still x1, x4, x5.

99
AV Example 3

• Back to original problem

The basis remains the same
100
AV Example 3

• Optimality Indicators
• j2
• j3

Since we are maximizing now, we want the most
positive. So, x2 enters the basis.
101
AV Example 3
x2 is entering the basis
102
AV Example 3
Minimum
So x4 leaves the basis
103
AV Example 3
104
AV Example 3

• Optimality Indicators
• j3
• j4

105
Artificial Variable Example 3

• All of the optimality indicators are 0, so this
  is the optimum solution

106
KKT Conditions

• The Karush-Kuhn-Tucker (KKT) Conditions can be
  used to see optimality graphically
• We will use them more in nonlinear programming
  later, but we can use a simplified version here

107
KKT Conditions for LP

• Change the constraints so that they are all
  constraints.
• The optimum point is the point where the gradient
  of the objective function lies within the cone
  formed by the vectors normal to the intersecting
  constraints.

108
KKT Conditions

• Reminder
• The gradient (?) of a function f with n variables
  is calculated

Example
109
KKT Constraints Example

• Example In the example problem 2, we had the
  problem
• Minimize f -x1 3x2
• Subject to 2x1 3x2 6
• -x1 x2 1
• x1, x2 0
• The gradient of the cost function, -x1 3x2 is

110
KKT Example

• Previously, we saw that this problem looks like

x2
Constraint 2
(3/5, 8/5)
Extreme Points
(0, 1)
Constraint 1
(3, 0)
(0, 0)
x1
111
KKT Example

• Change to constraints to all
• g1 -2x1 3x2 -1
• g2 x1 x2 -1
• g3 x1 0
• g4 x2 0

112
KKT Example

• The gradients of the four constraints (counting
  the non-negativity constraints), g1, , g4 are

113
KKT Example

• The graph of the problem with the normals of the
  constraints becomes

x2
Constraint 2
The gradient corresponding to each constraint
(?gi) is perpendicular to the constraint i.
(3/5, 8/5)
?g2
?g1
?g3
(0, 1)
Constraint 1
?g2
?g4
?g4
(3, 0)
(0, 0)
x1
?g3
?g1
114
KKT Example

• c (-1, -3) looks like this
• So, whichever cone this vector fits into
  corresponds to the optimal extreme point.

115
KKT Example
x2
(3/5, 8/5)
?g2
?g1
?g3
(0, 1)
?g2
?g4
?g4
(3, 0)
x1
(0, 0)
?g3
?g1
116
KKT Example

• So, we get the same optimal point as when we used
  the simplex method
• This can also be done for problems with three
  variables in a 3-D space
• With four or more variables, visualization is not
  possible and it is necessary to use the
  mathematical definition

117
Mathematical Definition of KKT Conditions for LP

• Given a LP minimization problem
• Modify the constraints so that we have

Where gi(x) is the linear constraint equation i.
The bi that was on the right side of the
inequality sign is moved to the left side and
included in gi.
118
Mathematical Definition of KKT Conditions for LP

• If there exists a solution for x the lis for
  the conditions below, then x is the global
  optimum

Equation 1
Equation 2
Equation 3
Equation 4
119
Explanation of Equation 1

• Equation 1 mathematically states that the
  objective function vector must lie inside the
  cone formed by the vectors normal to the active
  constraints at the optimal point

120
Explanation of Equation 2

• Equation 2 forces li to be zero for all of the
  inactive constraints called the complementary
  slackness condition
• If the constraint is active, gi(x) 0, so li
  may be positive and ?gi will be part of the cone
  in Equation 1.
• If the constraint is inactive, gi(x) ? 0, so li
  must be zero. ?gi will not be included in the
  cone in Equation 1 because it will be multiplied
  by zero.

121
Explanation of Equations 3 4

• Equation 3 ensures that x is feasible
• Equation 4 ensures that the direction of the cone
  is correct.
• If the lis were negative, the cone would be in
  the opposite direction. So, this equation
  prevents that from happening.

122
KKT Conditions Summary

• The KKT Conditions are not very useful in solving
  for optimal points, but they can be used to check
  for optimality and they help us visualize
  optimality
• We will use them frequently when we deal with
  nonlinear optimization problems in the next
  section

123
Automated LP Solvers

• There are many software programs available that
  will solve LP problems numerically
• Microsoft Excel is one program that solves LP
  problems
• To see the default Excel examples for
  optimization problems, search for and open the
  file solvsamp.xls (it should be included in a
  standard installation of Microsoft Office)

124
Excel LP Example 1

• Lets solve the first example problem in this
  chapter with Excel
• The problem was
• Minimize f -x1 x2
• Subject to x1 x2 5
• 2x1 x2 4
• x1 3 x1, x2 0

125
Excel LP Example 1

• Here is the Excel spreadsheet with the necessary
  data

In the spreadsheet, A2 is the cell reference for
x1 B2 is the reference for x2
126
Excel LP Example 1

• You can see that under the value heading for
  the constraints objective function, we simply
  use the given functions to calculate the value of
  the function

127
Excel LP Example 1

• On the right side of the constraints, in the
  limit column, we write the value of the bi
  for that constraint
• Obviously, the objective function doesnt have a
  limit

128
Excel LP Example 1

• So, the spreadsheet looks like this

129
Excel LP Example 1

• Now, we need to use the Excel solver feature
• Look under the Tools menu for solver
• If it is not there, go to Add-Ins under Tools
  and select the Solver Add-In

130
Excel LP Example 1

• The Solver toolbox should look something like
  this

131
Excel LP Example 1

• This is a minimization problem, so select Min
  and set the target cell as the objective function
  value
• The variables are x1 x2, so in the By Changing
  Cells box, select A2 B2

132
Excel LP Example 1

• Now add the constraints
• For the Cell Reference, use the value of the
  constraint function and for the Constraint, use
  the number in the Limit column
• The constraints are all , so make sure that lt
  is showing between the Cell Reference and
  Constraint boxes

133
Excel LP Example 1

• Now, the Solver window should look like this

134
Excel LP Example 1

• Finally, click the Options button
• All of the variables are specified as being
  positive, so check the Assume Non-Negative box

135
Excel LP Example 1

• Since this is an LP problem, check the Assume
  Linear Model box
• Finally, the default tolerance of 5 is usually
  much too large. Unless the problem is very
  difficult, a tolerance of 1 or even 0.1 is
  usually fine

136
Excel LP Example 1

• Click Solve and the Solver Results box should
  appear
• Under Reports, select the Answer Report and
  click OK
• A new worksheet that contains the Answer Report
  is added to the file

137
Excel LP Example 1

• The spreadsheet with the optimum values should
  look like this

138
Excel LP Example 1

• The values for x1 x2 are the same as when we
  solved the problem using the simplex method
• Also, if you look under the Answer Report, you
  can see that all of the slack variables are equal
  to zero, which is also what we obtained with the
  simplex method

139
Excel Example 2

• Lets solve one more LP problem with Excel
• Maximize 5x1 2x2 x3
• Subject to 2x1 4x2 x3 6
• 2x1 x2 3x3 2
• x1, x2 0
• x3 unrestricted in sign

140
Excel Example 2

• Entering the equations into the spreadsheet
  should give

141
Excel Example 2

• Unlike last time, all the variables are not
  specified as being positive, so we cannot use the
  Assume Non-negative option for all of the
  variables.
• So we have to manually specify x1 x2 to be
  non-negative by adding two more constraints

142
Excel Example 2

• Now, the formulas in the spreadsheet should look
  like this

143
Excel Example 2

• Now, open the solver toolbox and specify
• The Target Cell,
• The range of variable cells,
• Maximization problem
• The constraints
• The first is and the rest are constraints.

144
Excel Example 2

• Click the Options button and check the Assume
  Linear Model box.
• Remember, since x3 is unrestricted in sign, do
  not check the Assume Non-negative box
• You can reduce the tolerance if you would like

145
Excel Example 2

• The Solver window should look like this

146
Excel Example 2

• After solving, the spreadsheet should look like
  this

147
Excel Example 2

• Notice that because x3 was unrestricted in sign,
  it was able to have a negative value and this
  improved the solution
• To see how much of a difference this made in the
  solution, re-solve the problem with the Assume
  Non-negative option selected

148
Solving LP Problems With Excel

• From these examples, you can see that Excel can
  be an efficient tool to use for solving LP
  optimization problems
• The method for solving the problems that was
  outlined here is obviously just one way and the
  user should feel free to experiment to find their
  own style

149
References

• Linear Programming and Network Flows Bazaraa,
  Mokhtar John Jarvis Hanif Sherali.
• Optimization of Chemical Processes 2nd Ed.
  Edgar, Thomas David Himmelblau Leon Lasdon.
• Pollution Prevention Through Process Integration
  El-Halwagi, Mahmoud
