1A Scalable Semantic Indexing Framework for
Peer-to-Peer Information Retrieval
Zhichen Xu
Yan Chen
Chengxiang Zhai
Northwestern University
- University of Illinois
- at Urbana-Champain
Yahoo! Inc.
ACM SIGIR HDIR 2005
2Motivation
- Rapid information growth requires scalable and
robust retrieval architecture - Problems with centralized retrieval architecture
- Hard to maintain freshness of information
- Single-point-of-failure
- Peer-to-Peer IR may be a possible solution
- No need for centralized indexing
- Easy to maintain freshness of information
- Resistant to single-point-of-failure
- Challenge P2P IR architecture?
3Term Index vs. Document Index
- Term index
- Fast query execution
- Insufficient for supporting sophisticated
algorithms such as feedback - Hard to update (e.g., adding a doc) in a
distributed environment - Document index
- Easy to update
- Support advanced retrieval algorithms
- Slow query matching
4What is the Right Indexing Architecture for P2P
IR?
5Previous Work pSearch Tang et al. 03
- Based on document indexing
- Address the problem of slow query execution by
- Dimension reduction (using LSI)
- Exploiting distributed hash tables (DHT)
- Problems
- Lack of semantic locality (semantically similar
documents may be stored in quite different nodes) - Slow index generation
- Hard to add a new concept
6Proposed Solution P2PIR, Scalable Semantic
Indexing Framework for IR
- Semantic locality
- Achieved through a novel two-phase distributed
semantic indexing - Documents with similar semantics will have
indices stored on nearby nodes - Flexible tradeoff between search accuracy and
efficiency - Support of sophisticated retrieval methods
- E.g., feedback and personalized search
- Adaptation to document dynamics
- Incrementally incorporate new documents/concepts
7Background on Sample DHTContent-Addressable
Network
- Two key operations
- Put (key, object)
- Object get (key)
- Partition Cartesian space into zones
- Each zone is assigned to a computer
- Neighboring zones are routing neighbors
- Object lookup is done through routing
8Routing and Location Properties on DHT
- Log(N) hops need to route a key where N is the
number of nodes in the overlay - Log(N) maintenance overhead for routing
- Guaranteed success
- Fault-tolerant and robust
- DoS attack resilient
- Becoming increasingly practical for serious use
9P2PIR Architecture
Applications
structure -aware feature vector
feature extraction
XML doc
index placement on DHT
concept vector construction
index locator construction
P2PIR
term vector
text doc
P2P DHT system
Results to user
Index locator generation
search on DHT
Relevance Ranking
Internet
query
query refinement
- Two stage document indexing
- Concept vector generation
- Index locator generation and placement
- Open for plugging in feature extraction,
relevance ranking and query refinement
10Assumptions about the Retrieval Models
- Documents and queries are both represented as
vectors - Naturally occurring in the vector-space model
- Probabilistic models can be computed as vector
matching as well - Euclidean distances are reasonably accurate in
capturing document topic similarity - Euclidean distances are only used to prune
non-promising documents - Final relevance ranking can be based on more
accurate retrieval functions
11Concept Vector Construction
- Group document into k clusters based on the
feature vectors - The centroid of each cluster corresponds to a
concept - Given a document d, the similarity between its
feature vector and a concept c (e.g., cosine
value between them) defines the weight of d on
concept c - The concept vector of d is composed of its
weights on all the concepts
12Two-Stage Semantic Indexing
- Stage 1 Fast dimension reduction
- Document clustering to identify nd clusters (d
DHT dimension) - Represent each document with a vector on this nd
dimensional space - Stage 2 Semantic index locator construction
- Further partition the nd clusters into n
equal-size semantically coherent groups, each
with size d - Each group forms an index locator (key for
searching DHT)
13Fast Dimension Reduction
- Regular k-means clustering
- Randomly start with k centroids
- Iteratively re-assign documents to each cluster
and re-compute the centroids - Can stop at anytime to obtain rough clusters
- Modification
- Start with k relatively different centroids
- Complexity at each iteration O(kN), where
N gtgtk is the number of documents - Can be run on a sample of documents
- Vector(D) (sim(D,C1), , sim(D,Ck))
14Index Locator Construction
- Motivation the dimensionality of concept vectors
(e.g., a few hundreds) may be much larger than
that of DHT, so hard to place index directly with
concept vector - Basic idea break the concept vector into
multiple chunks with the same dimensionality as
that of DHT, and each chunk contains related
concepts - With such division, each document only has a
small number of chunks with non-negligible
weights for indexing - Such chunks are called index locators
15Index Placement on DHT
- For each index locator of a document d
- If its norm (i.e., length of the vector) is over
certain threshold, we put the index locator of d
along with its feature vector on the peer node
whose DHT address vector matches best with the
index locator.
16Illustration of Two-Stage Indexing
Semantic Chunk 1
Semantic Chunk k
C1 C2
CM
D1 D2
DN
Concepts C1 C2
CM Doc Di (x1, x2, ,
xd, xd1, , x2d, . . xM)
Locator 1
Locator 2 .
(x1, x2, , xd ) ? Original vector(D)
In DHT
(x1, x2, , xd ) ? Original vector(D)
17Querying
- Contact any node on the DHT
- Project the query vector to find related
concepts, and form the index locators - Use index locators to route to DHT nodes with the
indices and feature vectors of related documents - Use original query vector and document vectors to
perform relevance ranking - This local retrieval process can expand to
neighboring DHT nodes until enough relevant
results have been identified
18Adaptation to Corpus Dynamics
- Basic idea Incrementally add new
documents/concepts without affecting existing
indices, and periodically (very infrequently)
rebuild index locators for all documents - When a set of new documents emerge, we check
- whether they contain new frequently-used terms or
new heavy weighted terms - whether their concept vectors belong to any
existing cluster in the existing semantic space
19Adaptation to Corpus Dynamics (II)
- To add and index a new concept c
- If c belongs to an existing concept chunk whose
size is less than that of the underlying DHT, we
can add c to that cluster by using the next
available entry of the index locator. - Otherwise, we generate a new concept group and a
new set of index locators to represent c - Generate the index locators for the new
documents, and deploy their indices on DHT - Finally, multicast the addition of the new
concept c, and the addition of new concept group
to all DHT nodes, so that they can route queries
about c
20Example for Corpus Dynamics
- When new documents on Bin Larden appear, we
detect it as a new concept relating to the
concept group terrorism. - If the dimensionality of DHT is 20, and the size
of terrorism concept group is 17 - Just add Bin Larden to that group as dimension
18 of the index locator. - The corresponding index locators of existing
documents have weight zero as default on
dimension 18, and thus remain the same. - Otherwise, the terrorism concept group already
full, we generate a new concept group for Bin
Larden (i.e., a new set of index locators).
21Summary
- Propose a scalable semantic indexing framework
for peer-to-peer information retrieval P2PIR - Index placement with good semantic locality,
leading to good retrieval accuracy and efficiency - Tunable framework and flexibility
- Incremental adaptation to document/concept
dynamics - Prototype and evaluation of P2PIR in progress
