File input and output

1
File input and output
2
Interactive vs. file I/O

• All of the programs we have seen or written thus
  far have assumed interaction with a user, who
  types in data at a keyboard and sees output on a
  screen
• We can also receive data from, or send data to,
  the secondary storage devices on the computer
• This type of input and output is called file I/O

3
File I/O

• The action of saving, or writing, data to a file
  is called file output.
• The action of reading data from a file is called
  file input.
• Both of these actions involve interacting with
  the operating system and its file structure

4
The file concept

• We can envision a file as a special kind of
  container that can hold a collection of data or
  instructions
• A file can also contain a collection of other
  files such a file is called a directory or
  folder
• An important point to remember is that Java
  considers a folder to be just another file

5
File system organization

• Under Windows and most other modern operating
  systems, information is stored on disk in a
  hierarchically ordered structure consisting of
  directories, subdirectories, and files
• Disks are designated using letters for example,
  C is typically the computers hard drive (or its
  primary partition), while A is traditionally a
  floppy disk
• The Windows GUI portrays directories as folders,
  which can contain other folders or files

6
Windows file system example
The illustration below depicts a typical file
system structure under Windows
7
Opening a file for input or output

• Before we can read data from a file, we must
  create a File object and associate it to the file
  from which we wish to read.
• When a valid association is established, we say a
  file is opened.
• A file must be opened before we can do any input
  and output to the file.
• We do this by calling a File constructor

8
Opening a file

• The simplest syntax for opening a file is
• File aFile new File (filename)
• The String argument designates the name of the
  file (as seen by the operating system)
• This syntax assumes that the argument is the name
  of a file (not a folder), and that the file is
  located in the same folder as the programs code
  file

9
Opening a file

• Slightly more complicated syntax is necessary if
  the file to be opened is in a different folder
• File aFile new File (path, file)
• The first argument specifies the disk and file
  system hierarchy that contains the file
• For example, if the file is in directory
  G\shared\cate\cs1, you would write
• File aFile new File (g/shared/cate/cs1,
  file)
• Note the use of the forward slash you can use
  either this format or
• File aFile new File (g\\shared\\cate\\cs1,
  file)

10
Opening a file

• A File object may also be associated to a
  directory.
• As far as Java is concerned, a directory is just
  a special kind of file
• The code on the next slide illustrates the use of
  a File object to open a directory, then list the
  names of all the files in the directory

11
Example
File directory new File (C/JavaPrograms/Ch12)
String filename directory.list() //
Returns an array of strings naming the files and
// directories in the directory denoted by this
pathname for (int i0 iltfilename.length
i) System.out.println(filenamei)
12
File methods

• The previous slide illustrated the use of the
  list() method, which returns an array of Strings
  containing the names of files within a directory
• Several other useful methods of the File class
  are listed in the Java API we will examine a few
  of these

13
File methods

• We can check if a File object is associated
  correctly to an existing file by calling its
  exists method
• if (inFile.exists())
• // inFile is associated correctly to an
  existing file
• else
• // inFile is not associated to any existing
  file
• It is particularly useful to check input files to
  see if they actually exist before we try to read
  from them

14
File methods

• To determine if a File object is associated to a
  file or directory, we call its boolean method
  isFile.
• A similar method, isDirectory, returns true if
  the File object is associated with a folder
  instead of an ordinary file.

15
Choosing a file from a list

• A javax.swing.JFileChooser object allows the user
  to select a file from a list of available files.
• The code fragment below illustrates how this is
  done
• JFileChooser chooser new JFileChooser()
• ...
• chooser.showOpenDialog(null)

16
A JFileChooser object displayed with the
showOpenDialog method
17
JFileChooser Object methods

• The getSelectedFile method retrieves the desired
  file.
• The getName and getAbsolutePath methods retrieve
  the name and full path of a selected file
  (similar methods exist for File objects).
• The showSaveDialog method displays a JFileChooser
  with a Save button.

18
A JFileChooser object displayed with the
showSaveDialog method
19
JFileChooser Example

• The next couple of slides display a program that
  uses JFileChooser objects to display a list of
  files, then allow the user to choose which file
  should be open for output
• Note the use of File and JFileChooser methods in
  the code

20

• import java.io.
• import javax.swing.
• public class TestJFileChooser
• public static void main (String args)
• JFileChooser chooser
• File file, directory
• int status
• chooser new JFileChooser( )
• status chooser.showOpenDialog(null)
• if (status JFileChooser.APPROVE_OPTION)
• file chooser.getSelectedFile()
• directory chooser.getCurrentDirectory()

• System.out.println("Directory "
  directory.getName())
• System.out.println("File selected to
  open " file.getName())
• System.out.println("Full path name "
  file.getAbsolutePath())
• else
• JOptionPane.showMessageDialog(null, "Open
  File dialog canceled")

21

• System.out.println("\n\n")
• status chooser.showSaveDialog(null)
• if (status JFileChooser.APPROVE_OPTION)
• file chooser.getSelectedFile()
• directory chooser.getCurrentDirectory()
• System.out.println("Directory "
  directory.getName())
• System.out.println("File selected for saving
  data " file.getName())
• System.out.println("Full path name "
  file.getAbsolutePath())
• else
• JOptionPane.showMessageDialog(null, "Save
  File dialog canceled")

22
Sample output from running the TestJFileChooser
program
23
Reading and Writing Files

• Once a file is opened by associating a File
  object to it, we can access the file.
• To read data from or write data to a file, we
  must create one of the Java stream objects and
  attach it to the file.
• A stream is a sequence of data items, usually
  8-bit bytes.
• Java has two types of streams an input stream
  and an output stream.

24
Reading and Writing Files

• An input stream has a source from which the data
  items come, and an output stream has a
  destination to which the data items are going.
• FileOutputStream and FileInputStream are two
  stream objects that facilitate file access.
• FileOutputStream allows us to output a sequence
  of bytes values of data type byte.

25
Writing Data to a File

• To send output to a file, do the following
• Create and open a File object
• File output new File(C/datafiles, stuff)
• Associate a new FileOutputStream object with the
  File object
• FileOutputStream outs new FileOutputStream(outpu
  t)
• Write the desired data to the FileOutputStream
  object
• byte snacks 0, 1, 2, 3, 4, 5, 6, 7, 8, 9
• outs.write(snacks)
• Close the File stream
• outs.close()

26
The importance of closing a file

• If the stream object is not closed, then data may
  get lost due to data caching
• Data is saved in blocks of bytes to reduce the
  time it takes to save all of our data.
• The operation of saving data as a block is called
  data caching.
• To carry out data caching, part of memory is
  reserved as a data buffer or cache, which is used
  as a temporary holding place.

27
The importance of closing a file

• Data are first written to a buffer. When the
  buffer becomes full, the data in the buffer are
  actually written to a file.
• If there are any remaining data in the buffer and
  the file is not closed, those data will be lost.

28
Reading Data from a File

• To read data into a program, we reverse most of
  the steps in the output routine.
• We use the read method of FileInputStream to read
  in an array of bytes.
• First we create a FileInputStream object
• File inFile new File(sample1.data)
• FileInputStream inStream new FileInputStream(inF
  ile)
• Then we must declare and create an array to hold
  the data
• int filesize (int) inFile.length()
• byte byteArray new bytefilesize

29
Reading Data from a File

• We use the length method of the File class to
  determine the size of the file.
• This allows us to create an array of bytes whose
  size is the size of the file.
• Finally, we read the data into the array of
  bytes
• inStream.read(byteArray)

30
Low-level File I/O

• The read and write methods of the FileInputStream
  and FileOutputStream classes read and write
  entire arrays of bytes, as we have seen
• We can output data other than bytes if we can
  type cast them into bytes.
• To read the data back, we use the read method.
• Depending on the data type we converted the data
  from, we may need to type cast back into the
  original data type.

31
High-level File I/O

• Using DataOutputStream allows us to output Java
  primitive data type values by converting the
  values into a sequence of bytes.
• The argument to the DataOutputStream constructor
  is a FileOutputStream object.
• A DataOutputStream object does not get connected
  to a file directly instead, its role is to
  provide high-level access to a file by handling
  the data type conversions.

32
Relationship between File and output Stream
objects
33
High-Level File I/O

• To read data back from the file, we reverse the
  operation.
• We use three objects File, FileInputStream, and
  DataInputStream.
• Data must be read in the order in which it was
  written otherwise, the results will be
  unpredictable.

34
Relationship between File object and input Stream
objects
35
High-Level File I/O

• FileOutputStream and DataOutputStream objects
  produce a binary file in which the contents are
  stored in the format (binary format) in which
  they are stored in the main memory.
• Data may be stored in ASCII format instead of
  binary format this requires the use of a
  different set of objects

36
High-Level File I/O

• With ASCII format, all data are converted to
  string data.
• A file whose contents are stored in ASCII format
  is called a text file.
• To generate a textfile we use a PrintWriter is an
  object .
• PrintWriter supports only two output methods,
  which should look familiar
• print
• println (for print line)

37
High-Level File I/O

• An argument to the methods may be any primitive
  data type.
• The methods convert the parameter to string and
  output this string value.
• The constructor of PrintWriter, like that of
  DataOutputStream, requires an output stream as
  its argument.

38
High-Level File I/O

• To read data from a text file, we use the
  FileReader and BufferedReader objects.
• We first associate a BufferedReader object to a
  file.
• File inFile new File(sample3.data)
• FileReader fileReader new FileReader(inFile)
• BufferedReader brdr new BufferedReader(fileRea
  der)
• Then we read data, using the readLine method of
  BufferedReader.
• String str bufReader.readLine()
• Finally, we convert the String to a primitive
  data type as necessary (using wrapper classes as
  weve done before).

39
File I/O and Objects

• To write objects to a file, we use
  ObjectOutputStream.
• To read objects from a file, we use
  ObjectInputStream.

40
File I/O and Objects

• In this example, we will write Person objects to
  a file.
• The first step is to modify the Person class
  definition to allow ObjectOutputStream and
  ObjectInputStream to perform object I/O.
• We modify the definition by adding the phrase
  implements Serializable to it.
• import java.io.
• class Person implements Serializable
• // the rest is the same

41
File I/O and Objects

• To save objects to a file, we first create an
  ObjectOutputStream object
• File outFile new File(objects.dat)
• FileOutputStream outFileStream new
  FileOutputStream(outFile)
• ObjectOutputStream outObjectStream new
  ObjectOutputStream(outFileStream)

42
File I/O and Objects

• To save a Person object, we execute
• Person person new Person(Mr. Man, 20, M)
• outObjectStream.writeObject (person)
• Different types of objects may be saved to a
  single file.
• We can also mix objects and primitive data type
  values in the same file.

43
File I/O and Objects

• To read objects from a file, we use
  FileInputStream and ObjectInputStream.
• We use the method readObject to read an object.
• Because we can store any types of objects to a
  single file, we must type cast the object read
  from the file.

44
File I/O and Objects

• The readObject method can throw a
  ClassNotFoundException (wrong type casting) in
  addition to an IOException.
• Either exception may be caught or propagated.
• If a file contains objects from different
  classes, they must be read in the correct order
  and the matching type casting must be applied.
