Functional renormalization group for the
effective average action
2
physics at different length scales

• microscopic theories where the laws are
  formulated
• effective theories where observations are made
• effective theory may involve different degrees of
  freedom as compared to microscopic theory
• example the motion of the earth around the sun
  does not need an understanding of nuclear burning
  in the sun

3
QCD Short and long distance degrees of freedom
are different ! Short distances quarks
and gluons Long distances baryons and
mesons How to make the transition?
confinement/chiral symmetry breaking
4
collective degrees of freedom
5
Hubbard model

• Electrons on a cubic lattice
• here on planes ( d 2 )
• Repulsive local interaction if two electrons are
  on the same site
• Hopping interaction between two neighboring sites

6
Hubbard model
Functional integral formulation
next neighbor interaction
External parameters T temperature µ chemical
potential (doping )
U gt 0 repulsive local interaction
7
In solid state physics model for everything

• Antiferromagnetism
• High Tc superconductivity
• Metal-insulator transition
• Ferromagnetism

8
Antiferromagnetism in d2 Hubbard model
U/t 3
antiferro- magnetic order parameter
µ 0
Tc/t 0.115
T.Baier, E.Bick,
temperature in units of t
9
antiferromagnetic order is finite size effect

• here size of experimental probe 1 cm
• vanishing order for infinite volume
• consistency with Mermin-Wagner theorem
• dependence on probe size very weak

10
Collective degrees of freedom are crucial !

• for T lt Tc
• nonvanishing order parameter
• gap for fermions
• low energy excitations
• antiferromagnetic spin waves

11
effective theory / microscopic theory

• sometimes only distinguished by different values
  of couplings
• sometimes different degrees of freedom
• need for methods that can cope with such
  situations

12
Functional Renormalization Group

• describes flow of effective action from small to
  large length scales
• perturbative renormalization case where only
  couplings change , and couplings are small

13
How to come from quarks and gluons to baryons and
mesons ?How to come from electrons to spin waves
?

• Find effective description where relevant
  degrees of freedom depend on momentum scale or
  resolution in space.
• Microscope with variable resolution
• High resolution , small piece of volume
• quarks and gluons
• Low resolution, large volume hadrons

14
(No Transcript)
15
Wegner, Houghton
/
16
effective average action
17
Unified picture for scalar field theorieswith
symmetry O(N) in arbitrary dimension d and
arbitrary N

• linear or nonlinear sigma-model for
• chiral symmetry breaking in QCD
• or
• scalar model for antiferromagnetic spin waves
• (linear O(3) model )
• fermions will
  be added later

18
Effective potential includes all fluctuations
19
Scalar field theory
20
Flow equation for average potential
21
Simple one loop structure nevertheless (almost)
exact
22
Infrared cutoff
23
Partial differential equation for function U(k,f)
depending on two ( or more ) variables
Z k c k-?
24
Regularisation

• For suitable Rk
• Momentum integral is ultraviolet and infrared
  finite
• Numerical integration possible
• Flow equation defines a regularization scheme (
  ERGE regularization )

25
Integration by momentum shells

• Momentum integral
• is dominated by
• q2 k2 .
• Flow only sensitive to
• physics at scale k

26
Wave function renormalization and anomalous
dimension

• for Zk (f,q2) flow equation is exact !

27
Scaling form of evolution equation
On r.h.s. neither the scale k nor the wave
function renormalization Z appear
explicitly. Scaling solution no dependence on
t corresponds to second order phase transition.
Tetradis
28
decoupling of heavy modes
threshold functions vanish for large w large
mass as compared to k Flow involves
effectively only modes with mass smaller or
equal k
unnecessary heavy modes are eliminated
automatically effective
theories addition of new collective modes still
needs to be done
29
unified approach

• choose N
• choose d
• choose initial form of potential
• run !

30
Flow of effective potential

• Ising model

CO2
Critical exponents
Experiment
T 304.15 K p 73.8.bar ? 0.442 g cm-2
S.Seide
31
Critical exponents , d3
ERGE world
ERGE world
32
derivative expansion

• good results already in lowest order in
  derivative expansion one function u to be
  determined
• second order derivative expansion - include field
  dependence of wave function renormalization
  three functions to be determined

33
apparent convergence of derivative expansion
from talk by Bervilliers
34
anomalous dimension
35
Solution of partial differential equation
yields highly nontrivial non-perturbative
results despite the one loop structure
! Example Kosterlitz-Thouless phase transition
36
Essential scaling d2,N2

• Flow equation contains correctly the
  non-perturbative information !
• (essential scaling usually described by vortices)

Von Gersdorff
37
Kosterlitz-Thouless phase transition (d2,N2)

• Correct description of phase with
• Goldstone boson
• ( infinite correlation length )
• for TltTc

38
Running renormalized d-wave superconducting order
parameter ? in doped Hubbard model
TgtTc
?
Tc
TltTc
- ln (k/?)
C.Krahl,
macroscopic scale 1 cm
39
Renormalized order parameter ? and gap in
electron propagator ?in doped Hubbard model
100 ? / t
?
jump
T/Tc
40
Temperature dependent anomalous dimension ?
?
T/Tc
41
convergence and errors

• for precise results systematic derivative
  expansion in second order in derivatives
• includes field dependent wave function
  renormalization Z(?)
• fourth order similar results
• apparent fast convergence no series resummation
• rough error estimate by different cutoffs and
  truncations

42
Effective average actionand exact
renormalization group equation
43
Generating functional
44
Effective average action
Loop expansion perturbation theory
with infrared cutoff in propagator
45
Quantum effective action
46
Exact renormalization group equation
47
Proof of exact flow equation
48
Truncations

• Functional differential equation
• cannot be solved exactly
• Approximative solution by truncation of
• most general form of effective action

49
non-perturbative systematic expansions
50
(No Transcript)
51
Exact flow equation for effective potential

• Evaluate exact flow equation for homogeneous
  field f .
• R.h.s. involves exact propagator in homogeneous
  background field f.

52
many models have been studied along these lines

• several fields
• complicated phase structure ( e.g. 3He )
• replica trick N0
• shift in critical temperature for Bose-Einstein
  condensate with interaction ( needs resolution
  for momentum dependence of propagator )
• gauge theories

53
disordered systems
Canet , Delamotte , Tissier ,
54
including fermions

• no particular problem !

55
Universality in ultra-cold fermionic atom gases

• with
• S. Diehl , H.Gies , J.Pawlowski

56
BEC BCS crossover

• Bound molecules of two atoms
• on microscopic scale
• Bose-Einstein condensate (BEC ) for low T
• Fermions with attractive interactions
• (molecules play no role )
• BCS superfluidity at low T
• by condensation of Cooper pairs
• Crossover by Feshbach resonance
• as a transition in terms of external magnetic
  field

57
chemical potential
BCS
BEC
inverse scattering length
58
BEC BCS crossover

• qualitative and partially quantitative
  theoretical understanding
• mean field theory (MFT ) and first attempts beyond

concentration c a kF reduced chemical
potential s µ/eF Fermi momemtum
kF Fermi energy eF binding energy
T 0
BCS
BEC
59
concentration

• c a kF , a(B) scattering length
• needs computation of density nkF3/(3p2)

dilute
dilute
dense
non- interacting Fermi gas
non- interacting Bose gas
T 0
BCS
BEC
60
different methods
Quantum Monte Carlo
61
QFT for non-relativistic fermions

• functional integral, action

perturbation theory Feynman rules
t euclidean time on torus with circumference
1/T s effective chemical potential
62
parameters

• detuning ?(B)
• Yukawa or Feshbach coupling hf

63
fermionic action

• equivalent fermionic action , in general not local

64
scattering length a
a M ?/4p

• broad resonance pointlike limit
• large Feshbach coupling

65
collective di-atom states

• collective degrees of freedom
• can be introduced by
• partial bosonisation
• ( Hubbard - Stratonovich transformation )

66
units and dimensions

• c 1 h 1 kB 1
• momentum length-1 mass eV
• energies 2ME (momentum)2
• ( M atom mass )
• typical momentum unit Fermi momentum
• typical energy and temperature unit Fermi
  energy
• time (momentum) -2
• canonical dimensions different from relativistic
  QFT !

67
rescaled action

• M drops out
• all quantities in units of kF if

68
effective action

• integrate out all quantum and thermal
  fluctuations
• quantum effective action
• generates full propagators and vertices
• richer structure than classical action

69
gap parameter
?
T 0
BCS
BEC
70
limits
BCS for gap
condensate fraction for bosons with scattering
length 0.9 a
71
temperature dependence of condensate
72
condensate fraction second order phase
transition
c -1 1
free BEC
c -1 0
universal critical behavior
T/Tc
73
changing degrees of freedom
74
Antiferromagnetic order in the Hubbard model

• A functional renormalization group study

T.Baier, E.Bick,
75
Hubbard model
Functional integral formulation
next neighbor interaction
External parameters T temperature µ chemical
potential (doping )
U gt 0 repulsive local interaction
76
lattice propagator
77
Fermion bilinears
Introduce sources for bilinears Functional
variation with respect to sources J yields
expectation values and correlation functions
78
Partial Bosonisation

• collective bosonic variables for fermion
  bilinears
• insert identity in functional integral
• ( Hubbard-Stratonovich transformation )
• replace four fermion interaction by equivalent
  bosonic interaction ( e.g. mass and Yukawa terms)
• problem decomposition of fermion interaction
  into bilinears not unique ( Grassmann variables)

79
Partially bosonised functional integral
Bosonic integration is Gaussian or solve
bosonic field equation as functional of fermion
fields and reinsert into action
equivalent to fermionic functional integral if
80
fermion boson action
fermion kinetic term
boson quadratic term (classical propagator )
Yukawa coupling
81
source term
is now linear in the bosonic fields
82
Mean Field Theory (MFT)
Evaluate Gaussian fermionic integral in
background of bosonic field , e.g.
83
Effective potential in mean field theory
84
Mean field phase diagram
for two different choices of couplings same U !
Tc
Tc
µ
µ
85
Mean field ambiguity
Artefact of approximation cured by inclusion
of bosonic fluctuations J.Jaeckel,
Tc
Um U? U/2
U m U/3 ,U? 0
µ
mean field phase diagram
86
Rebosonization and the mean field ambiguity
87
Bosonic fluctuations
boson loops
fermion loops
mean field theory
88
Rebosonization

• adapt bosonization to every scale k such that
• is translated to bosonic interaction

k-dependent field redefinition
H.Gies ,
absorbs four-fermion coupling
89
Modification of evolution of couplings
Evolution with k-dependent field variables
Rebosonisation
Choose ak such that no four fermion coupling is
generated
90
cures mean field ambiguity
Tc
MFT
HF/SD
Flow eq.
U?/t
91
conclusions

• Flow equation for effective average action
• Does it work?
• Why does it work?
• When does it work?
• How accurately does it work?

92
end
93
Flow equationfor theHubbard model
T.Baier , E.Bick ,
94
Truncation
Concentrate on antiferromagnetism
Potential U depends only on a a2
95
scale evolution of effective potential for
antiferromagnetic order parameter
boson contribution
fermion contribution
effective masses depend on a !
gap for fermions a
96
running couplings
97
Running mass term
unrenormalized mass term
-ln(k/t)
four-fermion interaction m-2 diverges
98
dimensionless quantities
renormalized antiferromagnetic order parameter ?
99
evolution of potential minimum
?
10 -2 ?
-ln(k/t)
U/t 3 , T/t 0.15
100
Critical temperature
For TltTc ? remains positive for k/t gt 10-9
size of probe gt 1 cm
?
T/t0.05
T/t0.1
Tc0.115
-ln(k/t)
101
Below the critical temperature
Infinite-volume-correlation-length becomes larger
than sample size finite sample finite k
order remains effectively
U 3
antiferro- magnetic order parameter
Tc/t 0.115
temperature in units of t
102
Pseudocritical temperature Tpc

• Limiting temperature at which bosonic mass term
  vanishes ( ? becomes nonvanishing )
• It corresponds to a diverging four-fermion
  coupling
• This is the critical temperature computed in
  MFT !

103
Pseudocritical temperature
Tpc
MFT(HF)
Flow eq.
Tc
µ
104
Below the pseudocritical temperature
the reign of the goldstone bosons
effective nonlinear O(3) s - model
105
critical behavior
for interval Tc lt T lt Tpc evolution as for
classical Heisenberg model cf.
Chakravarty,Halperin,Nelson
106
critical correlation length

c,ß slowly varying functions exponential
growth of correlation length compatible with
observation ! at Tc correlation length reaches
sample size !
107
critical behavior for order parameter and
correlation function
108
Mermin-Wagner theorem ?

• No spontaneous symmetry breaking
• of continuous symmetry in d2 !

109
crossover phase diagram
110
shift of BEC critical temperature
