User-session based Testing of Web Applications

1
User-session based Testing of Web Applications
2
Two Papers

• A Scalable Approach to User-session based Testing
  of Web Applications through Concept Analysis
• Uses concept analysis to reduce test suite size
• An Empirical Comparison of Test Suite Reduction
  Techniques for User-session-based Testing of Web
  Applications
• Compares concept analysis to other test suite
  reduction techniques

3
Talk Outline

• Introduction
• Background
• User-session Testing
• Concept Analysis
• Applying Concept Analysis
• Incremental Reduced Test Suite Update
• Empirical Evaluation (Incremental vs. Batch)
• Empirical Comparison of Concept Analysis to other
  Test Suite Reduction Techniques
• Conclusions

4
Characteristics of Web-based Applications

• Short time to market
• Integration of numerous technologies
• Dynamic generation of content
• May contain millions of LOC
• Extensive use
• Need for high reliability, continuous
  availability
• Significant interaction with users
• Changing user profiles
• Frequent small maintenance changes

5
User-session Testing

• User session
• A collection of user requests in the form of URL
  and name-value pairs
• User sessions are transformed into test cases
• Each logged request in a user session is changed
  into an HTTP request that can be sent to a web
  server
• Previous studies of user-session testing
• Previous results showed fault detection
  capabilities and cost effectiveness
• Will not uncover faults associated with rarely
  entered data
• Effectiveness improves as the number of sessions
  increases (downside cost increases as well)

6
Contributions

• View user sessions as use cases
• Apply concept analysis for test suite reduction
• Perform incremental test suite update
• Automate testing framework
• Evaluate cost effectiveness
• Test suite size
• Program coverage
• Fault detection

7
Concept Analysis

• Technique for clustering objects that have common
  discrete attributes
• Input
• Set of objects O
• Set of attributes A
• Binary relation R
• Relates objects to attributes
• Implemented as a Boolean-valued table
• A row for each object in O
• A column for each attribute in A
• Table entry o, a is true if object o has
  attribute a, otherwise false

8
Concept Analysis (2)

• Identifies concepts given (O, A, R)
• Concept is a tuple (Oi, Aj)
• Concepts form a partial order
• Output
• Concept lattice represented by a DAG
• Node represents concept
• Edge denotes the partial ordering
• Top element T most general concept
• Contains attributes that are shared by all
  objects in O
• Bottom element ? most special concept
• Contains objects that have all attributes in A

9
Concept Analysis for Web Testing

• Binary relation table
• User session s object
• URL u attribute
• A pair (s, u) is in the relation table if s
  requests u

10
Concept Lattice Explained

• Top node T
• Most general concept
• Contains URLs that are requested by all user
  sessions
• Bottom node ?
• Most special concept
• Contains user sessions that requests all URLs
• Examples
• Identification of common URLs requested by 2 user
  sessions
• us3 and us4
• Identification of user sessions that jointly
  request 2 URLs
• PL and GS

11
Concept Analysis for Test Suite Reduction

• Exploit lattices hierarchical use-case
  clustering
• Heuristic
• Identify smallest set of user sessions that will
  cover all URLs executed by original suite

12
Incremental Test Suite Update
13
Incremental Test Suite Update (2)

• Incremental algorithm by Godin et al.
• Create new nodes/edges
• Modify existing nodes/edges
• Next-to-bottom nodes may rise up in the lattice
• Existing internal nodes never sink to the bottom
• Test cases are not maintained for internal nodes
• Set of next-to-bottom nodes (user sessions) form
  the test suite

14
Web Testing Framework
15
Empirical Evaluation

• Test suite reduction
• Test suite size
• Replay time
• Oracle time
• Cost-effectiveness of incremental vs. batch
  concept analysis
• Program coverage
• Fault detection capabilities

16
Experimental Setup

• Bookstore Application
• 9748 LOC
• 385 methods
• 11 classes
• JSP front-end, MySQL backend
• 123 user sessions
• 40 seeded faults

17
Test Suite Reduction

• Metrics
• Test suite size
• Replay time
• Oracle time

18
Incremental vs. Batch Analysis

• Metric
• Space costs
• Relative sizes of files required by incremental
  and batch techniques
• Methodology
• Batch 123 user sessions processed
• Incremental 100 processed first, then 23
  incrementally

19
Program Coverage

• Metrics
• Statement coverage
• Method coverage
• Methodology
• Instrumented Java classes using Clover
• Restored database state before replay
• Wget for replaying user sessions

20
Fault Detection Capability

• Metric
• Number of faults detected
• Methodology
• Manually seeded 40 faults into separate copies of
  the application
• Replayed user sessions through
• Correct version to generate expected output
• Faulty version to generate actual output
• Diff expected and actual outputs

21
Empirical Comparison ofTest Suite Reduction
Techniques
22
Empirical Comparison of Test Suite Reduction
Techniques

• Compared 3 variations of Concept with 3
  requirements-based reduction techniques
• Random
• Greedy
• Harrold, Gupta, and Soffas reduction (HGS)
• Each requirements-based reduction technique
  satisfies program or URL coverage
• Statement, method, conditional, URL

23
Random and Greedy Reduction

• Random
• Selection process continues until reduced test
  suite satisfies some coverage criterion
• Greedy
• Each subsequent test case selected provides
  maximum coverage of some criterion
• Example
• Select us6 maximum URL coverage
• Then, select us2 most marginal improvement for
  all-URL coverage criterion

24
HGS Reduction

• Selects a representative set from the original by
  approximating the optimal reduced set
• Requirement cardinality of test cases
  covering that requirement
• Select most frequently occurring test case with
  lowest requirement cardinality
• Example
• Consider requirement with cardinality 1 GM
• Select us2
• Consider requirement with cardinality 2 PL and
  GB
• Select test case that occurs most frequently in
  the union
• us6 occurs twice, us3 and us4 once
• Select us6

25
Empirical Evaluation

• Test suite size
• Program coverage
• Fault detection effectiveness
• Time cost
• Space cost

26
Experimental Setup

• Bookstore application
• Course Project Manager (CPM)
• Create grader/group accounts
• Assign grades, create schedules for demo time
• Send notification emails about account creation,
  grade postings

27
Test Suite Size

• Suite Size Hypothesis
• Larger suites than
• HGS and Greedy
• Smaller suites than
• Random
• More diverse in terms of use case representation
• Results
• Bookstore application
• HGS-S, HGS-C, GRD-S, GRD-C created larger suites
• CPM
• Larger suites than HGS and Greedy
• Smaller than Random

28
Test Suite Size (2)
29
Program Coverage

• Coverage Hypothesis
• Similar coverage to
• Original suite
• Less coverage than
• Suites that satisfy program-based requirements
• Higher URL coverage than
• Greedy and HGS with URL criterion
• Results
• Program coverage comparable to (within 2 of)
  PRG_REQ techniques
• Slightly less program coverage than original
  suite and Random
• More program coverage than URL_REQ techniques,
  Greedy and HGS

30
Program Coverage (2)
31
Fault Detection Effectiveness

• Fault Detection Hypothesis
• Greater fault detection effectiveness than
• Requirements-based techniques with URL criterion
• Similar fault detection effectiveness to
• Original suite
• Requirements-based techniques with program-based
  criteria
• Results
• Best fault detection but low number of faults
  detected per test case - Random PRG_REQ
• Similar fault detection to the best PRG_REQ
  techniques
• Detected more faults than HGS-U

32
Fault Detection Effectiveness (2)
33
Time and Space Costs

• Costs Hypothesis
• Less space and time than
• HGS, Greedy, Random
• Space for Concept Lattice vs. space for
  requirement mappings
• Results
• Costs considerably less than PRG_REQ techniques
• Collecting coverage information for each session
  is the clear bottleneck of requirements-based
  approaches

34
Conclusions

• Problems with Greedy and Random reduction
• Non-determinism
• Generated suites with wide range in size,
  coverage, fault detection effectiveness
• Test suite reduction based on concept-analysis
  clustering of user sessions
• Achieves large reduction in test suite size
• Saves oracle and replay time
• Preserves program coverage
• Preserves fault detection effectiveness
• Chooses test cases based on use case
  representation
• Incremental test suite reduction/update
• Scalable approach to user-session-based testing
  of web applications
• Necessary for web applications that undergoes
  constant maintenance, evolution, and usage
  changes

35
References

• Sreedevi Sampath, Valentin Mihaylov, Amie Souter,
  Lori Pollock "A Scalable Approach to User-session
  based Testing of Web Applications through Concept
  Analysis," Automated Software Engineering
  Conference (ASE), September 2004.
• Sara Sprenkle, Sreedevi Sampath, Emily Gibson,
  Amie Souter, Lori Pollock, "An Empirical
  Comparison of Test Suite Reduction Techniques for
  User-session-based Testing of Web Applications,"
  International Conference on Software Maintenance
  (ICSM), September 2005.
