Chapter 9: Greedy Technique

1
Greedy Algorithms Technique Dr. M. Sakalli,
modified from Levitin and CLSR
2
Greedy Technique

• The first key ingredient is the greedy-choice
  property a globally optimal solution can be
  arrived at by making a locally optimal (greedy)
  choice.
• In a greedy algorithm, choice is determined on
  fly at each step, (while algorithm progresses),
  may seem to be best at the moment and then solves
  the subproblems after the choice is made. The
  choice made by a greedy algorithm may be depend
  on choices so far, but it cannot depend on any
  future choices or on the solutions to
  subproblems. Thus, unlike dynamic programming,
  which solves the subproblems bottom up, a greedy
  strategy usually progresses in a top-down
  fashion, making one greedy choice after another,
  iteratively reducing each given problem instance
  to a smaller one.

3

• Algorithms for optimization problems typically go
  through a sequence of steps, using dynamic
  programming to determine the best choices,
  (bottom-up) for subproblem solutions.
• But in many cases much simpler, more efficient
  algorithms are possible. A greedy algorithm
  always makes the choice for a locally optimal
  solution which seems the best at the current
  moment with the hope of a globally optimal
  solution. In the most cases does not always yield
  optimal solutions, but for many problems.
• The activity-selection problem, for which a
  greedy algorithm efficiently computes a solution,
  works well for a wide range of problems, i.e,
  minimum-spanning-tree algorithms, Dijkstra's
  algorithm for shortest paths form a single
  source, and Chvátal's greedy set-covering
  heuristic.
• Greedy algorithms constructs a solution to an
  optimization problem piece by piece through a
  sequence of choices that are
• feasible
• locally optimal
• Irrevocable (binding and abiding)

4
Applications of the Greedy Strategy

• Optimal solutions
• change making for normal coin denominations
• minimum spanning tree (MST)
• single-source shortest paths
• simple scheduling problems
• Huffman codes
• Approximations
• traveling salesman problem (TSP)
• knapsack problem
• other combinatorial optimization problems

5
Change-Making Problem

• Given unlimited amounts of coins of denominations
  d1 gt gt dm ,
• give change for amount n with the least number of
  coins
• Example d1 25c, d2 10c, d3 5c, d4 1c
  and n 48c
• Greedy solution d1 2 d2 3 d1
• Greedy solution is
• optimal for any amount and normal set of
  denominations
• may not be optimal for arbitrary coin
  denominations

6
Induced subgraph

• Let a graph be G V, E, we say that H is a
  subgraph of G and we write H?G if the vertices
  and edges of H V, E is a subset of the
  graph G, V'?V, E'?E.
• H need not to accommodate all the edges of G.
• If the vertices of H are connected and if its all
  the connecting edges overlay with the edges in G
  connecting the same adjacent vertices then, H is
  called induced subgraph. Edge induced, vertex
  induced, or neither edge nor vertex induced.
• Note if at least one path does exist between
  every pair of vertices, then this is a connected
  (but not directed yet) graph, directed one is the
  one whose every edge can only be followed from
  one vertex to another.

7
Directed acyclic grph, DAG

• Cycle definition seems to be ambiguous, two or
  three vertices, (only one vertex), if there is a
  path returning back to the same initial vertex
  again then there should be a cyclic case too.
  But!!
• A cyclic graph is a graph that has at least one
  cycle (through another vertex -at least one for
  bi-directional and at least two for
  uni-directional edged graphs) an acyclic graph
  is the one that contains no cycles. The girth is
  the number of the edges involved in the shortest
  cycle, ggt3 is triangle free graph.
• A source is a vertex with having no incident
  edges, while a sink is a vertex with no diverging
  edges from itself. A directed acyclic graph (DAG)
  is defined from a source to a vertex or from a
  vertex to a sink, or from a source to a sink,
  with no directed cycles.
• A finite DAG must have at least one source and at
  least one sink.
• The depth of a vertex in a finite DAG is the
  length of the longest path from a source to that
  vertex, while its height is the length of the
  longest path from that vertex to a sink.
• The length of a finite DAG is the length (number
  of edges) of a longest directed path. It is equal
  to the maximum height of all sources and equal to
  the maximum depth of all sinks. Wikipedia.

8
Minimum Weight Spanning Tree

• A spanning subgraph is a subgraph that contains
  all the vertices of the original graph. A
  spanning tree is a spanning subgraph that is of a
  acyclic graph of G (a connected acyclic
  subgraph) that includes all of vertices of G.
• Minimum spanning tree of a weighted, connected
  graph G a spanning tree of G of minimum total
  weight. Graph G V, E and the weight function
  w of a spanning tree T, that connects all V.
• w(T)?(E, V)?T w(u, v)
• All weights are distinct, injective

O(E lg V) using binary heaps. O(E V lg V),
using fib heap.
9
Partitioning V of G into A and V-A

• GENERIC-MST(G, w)
• A ? Empty set //Initialize
• while A does not form a spanning tree //Terminate
• do if edge (u, v) is safe edge for A
• A?A? (u, v) //Add safe edges
• return A

10
How to decide to the light edge

• Definitions a cut (S, V - S) of an undirected
  graph G (V, E) is a partition of V, and a light
  edge is the one, one of its endpoints (vertices)
  resides in S, and the other in V - S, with
  minimum possible weight, and a cut respects to A
  ifthere is no any edge of A crossing the cut.
• . do if edge (u, v) is safe for A
• In line 3 of the pseudo code given for generic
  mst(g, w), there must be a spanning tree T such
  that A ? T, and if there is an edge of (u, v)?T
  such that (u, v)?A, then (u, v) is the one said
  safe for A. The rule Theorem

11
How to decide to the light edge
y
x
V-S
T
u
S
Overlapping subproblems! DP. but MST leads to an
efficient algorithm.

• Theorem Suppose G (V, E) is a connected,
  undirected graph with a real-valued weight
  function w defined on E, and let A be a subset of
  E that is included in some MST in G, (S, V - S)
  be a cut that respects A, and (u, v) be a light
  edge crossing (S, V - S). Then, edge (u, v) is
  safe to be united to A.
• Proof by contradiction Let T be a mst of G, that
  A?T and suppose another mst T, with A?T and a
  light edge of u, v?T such that (u, v)?T. T'
  (of G) having A?(u, v) by using a cut-and-paste
  technique is possible, then (u, v) must be a safe
  edge for A. But we have another path of T, x, y
  crossing the cut S, V-S, (in which one side
  includes A), This generates a cycle (for which we
  are paying for two crossings and contradicts to
  the definition of mst). To minimize the cost we
  have to exclude the one with the heavier edge,
  and include the light one.
• T T - x, v ?(u, v)
• w(u, v) w(x, y). Therefore, w(T') w(T) -
  w(x, y) w(u, v) w(T)

T
S
v
12

• Both MST algorithms Kruskal, and Prim, determine
  a safe edge in line 3 of generic-mst.
• In Kruskal's algorithm, the set A is a forest.
• - The safe edge added to A is always a
  least-weight edge connecting two distinct
  components
• - many induced subtrees, and gradually merge
  into each other.
• In Prim's algorithm, the set A forms a single
  tree grows like a snowball as one mass. The safe
  edge added to A is always a least-weighted edge
  connecting the tree to a vertex not in the tree.
• Corollary
• Let
• G (V, E) be a connected, undirected graph,
  weight function w on E, let A be a subset of E
  that is included in some MST for G, and C be a
  connected component (tree) in the forest GA (V,
  A). If (u, v) is a light edge connecting C to
  some other component in GA, then edge (u, v) is
  safe for A.

13
Kruskal Algorithm

• It finds a safe edge to add to the growing
  forest
• A safe edge (u, v)
• connecting any two trees in the forest and
• having the least weight.
• Let C1 and C2 denote the two trees that are
  connected by (u, v). Since (u,v) must be a light
  edge connecting C1 to some other tree, from
  corollary it must be a safe edge for C1.
• Then the next step is union of two disjoint trees
  C1 and C2.
• Kruskal's algorithm is a greedy algorithm,
  because at each step it adds to the forest an
  edge of the least possible weight.
• Implementation of Kruskal's algorithm employs a
  disjoint-set data structure to maintain several
  disjoint sets of elements. Each set contains the
  vertices in a tree of the current forest. The
  operation FIND-SET(u) returns a representative
  element from the set that contains u.
• Thus, FIND-SET(u) FIND-SET(v), then vertices u
  and v belong to the same tree otherwise combine
  two trees, if u, v is a light edge - UNION
  procedure.

14

• MST-KRUSKAL(G, w)
• 1 A ? Empty set
• 2 for each v ?VG // for each vertex
• 3 do MAKE-SET (v) //create V trees,
• 4 sort the edges of E by nondecreasing weight w
• 5 for each e(u, v) ?E, in order by nondecreasing
  weight
• 6 do if FIND-SET(u) ? FIND-SET(v) //Check
  if
• 7 then A ? A ? (u, v) //if
  not in the same set
• 8 UNION (u, v) //merge two
  components
• 9 return A
• set A to the empty set and
• The running time for a G (V, E) depends on the
  implementation of the disjoint-set data
  structure.
• Assume the disjoint-set-forest implementation
  with the union-by-rank and path-compression
  heuristics, since it is the asymptotically
  fastest implementation known.
• Initialization O(V), time to sort the edges in
  line 4 O(E lg E).
• There are O(E) operations on the disjoint-set
  forest, which in total take O(E a(E, V)) time,
  where a is the functional inverse of Ackermann's
  function defined. Since (E, V) O(lg E), the
  total running time of Kruskal's algorithm is O(E
  lg E).

15
(No Transcript)
16
(No Transcript)
17
Prims MST algorithm

• Operates much like Dijkstra's algorithm for
  finding shortest paths in a graph. Prim's
  algorithm has the property that the edges in the
  set A always form a single tree.
• Starting from an arbitrary root vertex r (tree A)
  and expanding one vertex at a time, until the
  tree spans all the vertices in V. At each turn, a
  light edge connecting a vertex in A to a vertex
  in V - A is added to the tree.
• On each iteration, construct Ti1 from Ti by
  adding vertex not in Ti (A) that is closest to
  those already in Ti (this is a greedy step!)
• The same Corollary The rule allows merging of
  the edges that are safe for A therefore,
  Terminates when the all vertices are included in
  A, there the edges in A form a minimum spanning
  tree.
• This strategy is "greedy" since the tree is
  augmented at each step with an edge that
  contributes the minimum amount possible to the
  tree's weight.
• Needs priority queue for locating closest fringe
  vertex
• Next analysis rom the notes of CLRS, and listen
  from MIT

18

• Prim Algorithm Example

19
Notes about Kruskals algorithm

• Algorithm looks easier than Prims but is harder
  to implement (checking for cycles!)
• Cycle checking a cycle is created iff added edge
  connects vertices in the same connected component
• Union-find algorithms

20
Shortest paths Dijkstras algorithm

• Single Source Shortest Paths Problem Given a
  weighted
• connected graph G, find shortest paths from
  source vertex s
• to each of the other vertices
• Dijkstras algorithm Similar to Prims MST
  algorithm, with
• a different way of computing numerical labels
  Among vertices
• not already in the tree, it finds vertex u with
  the smallest sum
• dv
  w(v,u)
• where
• v is a vertex for which shortest path has been
  already found on preceding iterations (such
  vertices form a tree)
• dv is the length of the shortest path form
  source to v w(v,u) is the length (weight) of
  edge from v to u

21
Example
4
d
d
Tree vertices Remaining vertices
a(-,0) b(a,3) c(-,8) d(a,7) e(-,8)

4
b(a,3) c(b,34) d(b,32)
e(-,8)
b
c
3
6
5
2
a
d
e
7
4
4
d(b,5) c(b,7) e(d,54)
b
c
3
6
5
2
a
d
e
7
4
4
c(b,7) e(d,9)
b
c
3
6
2
5
a
d
e
7
4
e(d,9)
22
Notes on Dijkstras algorithm

• Doesnt work for graphs with negative weights
• Applicable to both undirected and directed graphs
• Efficiency
• O(V2) for graphs represented by weight matrix
  and array implementation of priority queue
• O(EVlogV) for graphs represented by adj.
  lists and min-heap implementation of priority
  queue
• Fib heap O(EVlogV, amertized.)
• Dont mix up Dijkstras algorithm with Prims
  algorithm!

23
Coding Problem

• Coding assignment of bit strings to alphabet
  characters
• Codewords bit strings assigned for characters of
  alphabet
• Two types of codes
• fixed-length encoding (e.g., ASCII)
• variable-length encoding (e,g., Morse code)
• Prefix-free codes no codeword is a prefix of
  another codeword
• Problem If frequencies of the character
  occurrences are
• known, what is the best binary
  prefix-free code?

24
Huffman codes

• Any binary tree with edges labeled with 0s and
  1s yields a prefix-free code of characters
  assigned to its leaves
• Optimal binary tree minimizing the expected
  (weighted average) length of a codeword can be
  constructed as follows
• Huffmans algorithm
• Initialize n one-node trees with alphabet
  characters and the tree weights with their
  frequencies.
• Repeat the following step n-1 times join two
  binary trees with smallest weights into one (as
  left and right subtrees) and make its weight
  equal the sum of the weights of the two trees.
• Mark edges leading to left and right subtrees
  with 0s and 1s, respectively.

25
Example

• character A B C D _
• frequency 0.35 0.1 0.2 0.2 0.15
• codeword 11 100 00 01 101
• average bits per character 2.25
• for fixed-length encoding 3
• compression ratio (3-2.25)/3100 25

26
(No Transcript)
