Network Analyzers From Small Signal To Large Signal Measurements

1
Network AnalyzersFrom Small SignalTo Large
Signal Measurements

• Doug Rytting

2
Agenda

• Small Signal Measurements Error Correction
• Compression and AM to PM
• Hot S22 Measurements
• Load Pull Measurements
• Pulse Measurements
• Large Signal Network Analyzer Measurements

3
Network Analyzer Block Diagram
4
Improvements with Correction
5
Improvements with Correction
6
Calibration Examples 8 Term Model
7
Agenda

• Small Signal Measurements Error Correction
• Compression and AM to PM
• Hot S22 Measurements
• Load Pull Measurements
• Pulse Measurements
• Large Signal Network Analyzer Measurements

8
Power Sweep - Compression
Saturated output power
Output Power (dBm)
Compression region
Linear region (slope small-signal gain)
Input Power (dBm)
9
Power Sweep -Gain Compression

• 1 dB compression input power resulting in 1 dB
  drop in gain
• Ratioed measurement
• Output power available (non-ratioed measurement)

10
Power Sweep - AM to PM Conversion
Ch1Mkr1 -4.50 dBm 20.48 dB
Ch2Mkr2 1.00 dB 0.86 deg

• Use transmission setup with a power sweep
• Display phase of S21
• AM - PM 0.86 deg/dB

2
Start -10.00 dBm
Stop 0.00 dBm
CW 900.000 MHz
1
Start -10.00 dBm
Stop 0.00 dBm
CW 900.000 MHz
11
Agenda

• Small Signal Measurements Error Correction
• Compression and AM to PM
• Hot S22 Measurements
• Load Pull Measurements
• Pulse Measurements
• Large Signal Network Analyzer Measurements

12
Hot S22 Measurement System
Small signal S-parameters of a nonlinear device
in the presence of a high power drive signal Df
away from test frequency.
High Power Combine
DUT A
13
Hot S22 Measurement System
S-parameters of a nonlinear device at a defined
input or output power.
14
Agenda

• Small Signal Measurements Error Correction
• Compression and AM to PM
• Hot S22 Measurements
• Load Pull Measurements
• Pulse Measurements
• Large Signal Network Analyzer Measurements

15
Load Pull Measurement
Need to measure nonlinear device behavior under
actual operating conditions
Parameter changes vesus output power level
16
Load Pull System
INPUT IMPEDANCE AND POWER MEASUREMENT SYSTEM
OUTPUT IMPEDANCE AND POWER MEASUREMENT SYSTEM
X
X
X
X
DUT
INPUT TUNER
OUTPUT TUNER
17
Types of Output Tuners
Harmonic load-pull
Passive load-pull
Active load-pull
Simultaneous Drive
OSC
DUT
18
Harmonic Load Pull System
Four Channel Frequency Converter HP 8510C/85110A
LO Synthesizer Can be Tuned to Harmonics
Port 3 Coaxial and power cals.
DUT
Reflectometer Mounted on Prober
Input Amplifier 1 - 50 GHz TWA
Port 1 Input Probe
Port 2 Output Probe
Port Drive PIN Switch
19
Agenda

• Small Signal Measurements Error Correction
• Compression and AM to PM
• Hot S22 Measurements
• Load Pull Measurements
• Pulse Measurements
• Large Signal Network Analyzer Measurements

20
High Power Device Pulse Measurements

• Control DUT Temperature
• Eliminate temperature as a variable
• Test high power devices on-wafer at full power
• Measure devices in "unsafe" DC operating area
• Test "pulsed" devices in a pulsed environment
• Test environment final application (GSM)
• Pulsed radars/phased array antennas/high power
  MMIC's
• Improve device characterization data
• Model power FET's at full power level
• Measure IV curves without temperature effects
• Investigate trapping effects in GaAs

21
Pulse System Capabilities

• Synchronization of pulses
• IV plane characterization
• Point in pulse vs Frequency or Pulse profile vs
  Time

22
Pulsed Bias/RF Meas System

RF Synthesizer
Measurement Controller
LO Synthesizer
Network Analyzer
Bias Network

Drain / Collector Bias Pulser
Gate / Base Bias Pulser

DC Power Supply
Digital Multimeter
Trigger
Pulse Generator
23
Agenda

• Small Signal Measurements Error Correction
• Compression and AM to PM
• Hot S22 Measurements
• Load Pull Measurements
• Pulse Measurements
• Large Signal Network Analyzer Measurements

24
Large Signal Network Analyzer
Complete Spectrum Waveforms Harmonics and
Modulation
25
Large Signal Network Analyzer

• Measures magnitude and phase of incident and
  reflected waves at fundamental, harmonic, and
  modulation frequencies.
• Calibrated for relative and absolute measurements
  for both linear and nonlinear components at the
  device under test.
• Calculate calibrated voltage and current in both
  the time and frequency domains.
• Combination of a vector network analyzer,
  sampling scope, spectrum analyzer and power
  meter.

26
LSNA System Block Diagram
Sampler Front End Requires high BW IF Requires
Harmonic LO
27
Sampling Converter Fundamentals
28
LSNA System Block Diagram
Mixer Front End Requires harmonic sync Can use
high BW IF for modulation Or low BW IF if no
modulation
29
Nonlinear Calibration - Model
30
Nonlinear Calibration

• Relative calibration at the fundamental and
  harmonic frequencies determines the 7 normal
  error terms.
• Power calibration at the fundamental and harmonic
  frequencies determines the magnitude of K.
• Phase reference generator calibration determines
  the phase of K relative to the fundamental
  frequency.
• Reference generator is an impulse that must be
  accurately modeled or measured.

31
Example 1

• Complete device measurement capability using a
  Large Signal Network Analyzer (LSNA).

32
Device Measurement
33
Example 2

• Device measurement verification and
  measurement-based model improvement.

34
Model Verification Improvement
35
Model Verification Improvement
36
Model Verification Improvement
37
Vector Network Analyzer References
38
Large Signal Network Analyzer References
