Glenair Company Overview

1
(No Transcript)
2
Glenair Company Overview

• An Interconnect Industry Leader Since 1956

• Privately ownedoriginal California location, no
  off-shore manufacturing
• 800,000 square feet of factory space in Glendale
  alone! Additional factories in Italy and the UK
• Primary Market military and aerospace
  interconnect systems
• Excellent customer service and technical product
  know-how
• Business culture fast turnaround, no minimums,
  no obsolete products, relentless focus on
  innovation

3
Circular Connector Series Summary
Nanominiature
Ultraminiature
Microminiature
Standard
Subminiature
Miniature
MIL-DTL-5015MIL-DTL-22992MIL-DTL-28840
MIL-DTL-26482MIL-DTL-26500MIL-DTL-83723
SERIES 80 MIGHTY MOUSE
SERIES 811 MIGHTY MOUSE HD
SERIES 88 SUPERFLY
MIL-DTL-38999 AND DERIVATIVE SPECIALS
Every Class and Duty Hermetic, Filter,
High-Temp, Ground Plane, Environmental,
High-Speed, etc.
4
Rectangular Connector Series Summary
Hiper-D
Micro-D
Micro-Crimp
Nano
Glenair Sr. 28 M24308 5 - 7.5 AMPs 11
Layouts 9-104 Positions
Glenair Sr. 79 N/A 5-23 AMP 31 Layouts 2-102
Positions
Glenair Sr. 17 M83513 3 AMP 8 Layouts 9-100
Positions
Glenair Sr. 89 M32139 1 AMP 7 Layouts 9-51
Positions
5
Summary of Contact Types
Signal Thermocouple
Coax/Twinax
EMI Filter
Optoelectronic
Pneumatic
Gas/Fluids
Nano/Micro TwistPin
Power and LouverBand
Hermetic
8 Quadrax
Fiber Optic

• From electrons to photons to fluids

6
Connector Accessory Series Summary
Protective Covers
Molded Shapes
Lightweight Composite
Shield Termination
Mechanical Strain-Relief
Environmental Sealing
Every AS85049 Slash Sheet Plus Thousands of
Commercial Designs All Manufactured in Glendale,
California
7
Glenair Connector Innovations
8
Glenair Connector Innovations
9
Glenair Connector Innovations
10
Glenair Accessory Innovations
11
Glenair Accessory Innovations
12
Glenair Accessory Innovations
13
Material and Plating Capabilities
Aluminum
Stainless Steel
Titanium
Plastic
Kovar
Composite
Marine Bronze
14
Interconnect Assemblies and Systems
Harsh-Environment
Lightweight/Flexible
Corrosion Proof
Fiber Optic
Field Repairable
Ultraminiature
Flex Circuitry
Media Conversion
15
