Title: Simulate LINC system in ADS


1
Simulate LINC system in ADS
  • Song Lin _at_ECE.UTK 03/30/2005

2
What is the LINC?
  • There are many linearization techniques.
  • Feed-forward
  • Pre-distortion
  • LINC
  • Linear amplification using nonlinear
    components
  • (LINC) is a technique whereby a linear
    modulation
  • signal is converted into two constant
    envelope signals
  • that are independently amplified by
    power-efficient
  • Class D amplifiers and then combined using
    a hybrid
  • coupler.

3
Fig1Simplified block diagram
for an outphasing power amplifier
  • The use of power efficient amplifiers can
    provide significant improvement in the PAE of
    the overall system.

4
Fig2Separation of two component
signals from the source signal
S1(t) and S2(t) are the modulated phase and
constant amplitude signals
5
The problem we want to solve
  1. The Class D Power amplifier.
  2. The reconfigurable Combiner.
  3. The phase detector.
  4. The phase shifter.
  5. The amplitude detector.
  6. The DSP part.

6
ADS simulation LINC at system level
7
ADS simulation results (ideal)
8
ADS simulation (non-ideal)
9
ADS simulation non-ideal results
10
The class D power amplifier
  • Use the Load-Pull technology to match the
    output port

11
  • Use S parameter to match the input port

To simplify the design, I chose the narrow band
system working around 850MHz. To design the
wideband PA, there is another way to go for
matching.
12
The phase detector
13
  • Use the MCU to control the comparing time, and
    then get the relationship of the phase different
    and the voltage. After getting the voltage, we
    can use the MCU to control the analogy phase
    shifter to balance the phase of the two branches

14
Phase shifter
15
Wide band 90 degree lumped hybrid
16
Reconfigurable transformer
17
  • For the reconfigurable transformer, we still
    have a long way to go. I think we can use the
    switch to make the transmission line transformer
    to be reconfigurable. Although this kind of
    reconfigurable transformer can get very high
    efficiency but it has very poor isolation between
    the two input port. So we should find the best
    point to meet the requirement.

18
Several Technology to improve the LINC
19
(No Transcript)
20
ELINC
21
(No Transcript)
22
Next stage
  • Combine the feedback technology and the ELINC
    technology.
  • Figure out the reconfigurable power combiner.

23
  • THANK YOU!
