Design and Building of

1

• Design and Building of
• 20 MGHz 2.5 Ghz SP4T RF Switches
• Soumo Ghosal
• BTech Final Year
• Institute of Radiophysics and Electronics
• University of Calcutta
• Under the Guidance of -
• Mr. A Praveen Kumar
• Engineer F
• GMRT, Khodad

2
RF/ Microwave Switches

• Switching is one of the most important function
  in control of microwave signals
• Microwave switch is a microwave circuit made up
  of high speed microwave devices.
• PIN diodes , GaAsFET MMIC are used extensively.
• The GMRT Receiver System also puts to use
  microwave switches at various stages such as
• (1) Band Selection
• (2) Swicthing Filter Banks
• (3) Attenuator Selection
• (4) Injection of various levels of noise for
  calibrating the
• receiver system

13/11/07 soumoghosal_at_gmail.com
2
3
Switch Design Configurations

• Series
• Series SPST

13/11/07 soumoghosal_at_gmail.com
3
4

• (2) Shunt

13/11/07 soumoghosal_at_gmail.com
4
5

• (3)Series Shunt

13/11/07 soumoghosal_at_gmail.com
5
6
Switching Parameters

• Insertion Loss

13/11/07 soumoghosal_at_gmail.com
6
7

• Isolation

13/11/07 soumoghosal_at_gmail.com
7
8

• VSWR

13/11/07 soumoghosal_at_gmail.com
8
9

• Switching Speed
• Trise
• Tfall
• Ton
• Toff

13/11/07 soumoghosal_at_gmail.com
9
10

• Switching Transients
• The transients are due to the DC shifts which
  occur internally in the switch during switching.
• RF Handling
• PIN diode switches are usually considered to
  be small signal devices and generally handle RF
  power levels upto 20dbm (100mW) with optimum
  performance below 5dBm.

13/11/07 soumoghosal_at_gmail.com
10
11
GaAsFET used as a RF Switch

• nanosecond order switching.
• minimal power consumption.
• minimal area occupied on the circuit.

13/11/07 soumoghosal_at_gmail.com
11
12

• Based on Metal Semiconductor Field Effect
  Transistors (MESFET) as the active elements.
• MESFETS are arranged in two mirror-image
  series-shunt configurations originating from a
  common RF node.
• The series MESFET provides a through path for the
  ON arm while the shunt MESFET provides an
  isolation for the OFF arm.

13/11/07 soumoghosal_at_gmail.com
12
13
MMIC Performance

• With less than 1dB insertion loss and about 30dB
  isolation at 1.5GHz the SW239 demonstrates
  impressive RF performance in a small package.
• High switching speeds of Trise/fall 2ns typical

• Input power for 1dB compression is 25dBm for
  standard 0/-5V DC control. Second and Third order
  Intermodulation Intercept points are 66 dBm and
  41 dBm typical, respectively.

13/11/07 soumoghosal_at_gmail.com
13
14

• PIN Configurations

13/11/07 soumoghosal_at_gmail.com
14
15
Controlling SW 239 using LM339 Comparator
Current WILL flow through the open collector when
the voltage at the PLUS input is lower than the
voltage at the MINUS input.
13/11/07 soumoghosal_at_gmail.com
15
16
The SP4T Design Layout
13/11/07 soumoghosal_at_gmail.com
16
17
Truth Table for Operation
13/11/07 soumoghosal_at_gmail.com
17
18
13/11/07 soumoghosal_at_gmail.com
18
19
RF Microstrip Line Calculation for PCB
imlementation

• For lowest cost, microstrip devices may be built
  on an ordinary FR4 (standard PCB) substrate.

13/11/07 soumoghosal_at_gmail.com
19
20
Measurements made using Network Analyser

• BSATR SP6T switch is operated over the frequency
  range 10 MHz-1 GHz and its VSWR,return loss and
  gain studied.
• The calibration
• has to be done.

13/11/07 soumoghosal_at_gmail.com
20
21

• The S11 and S21 are obtained and the VSWR, return
  loss and gain are obtained.
• We did it by choosing frequency paths 233MHz and
  610MHz were chosen.

13/11/07 soumoghosal_at_gmail.com
21
22

• Return loss plot (233MHz)
• VSWR (233MHz)
• Gain (in dB)

23
Conclusion and Future Scope for improvement

• SP4T PCB layout and logic circuitry successfully
  made on genesys software.
• Due to shortage of time the final PCB could not
  be made for the footprints in the design were too
  fine to be made at GMRT PCB Machine.
• Vector Network Analyser put to test BSATR module.

13/11/07 soumoghosal_at_gmail.com
23
24

• Thank You
