Title: Minnesota Wing Aircrew Training: Task O-2101


1
Minnesota Wing Aircrew Training Task O-2101
  • ELT Equipment and detection Procedures

2
Objectives
  • Discuss the various types of ELTs P 10.1.1
  • Describe how an ELT can be detected P 10.2
  • Describe how the aircraft DF works in both the
    Alarm and DF modes P 10.3.1
  • Discuss using the DF during a typical ELT search
    P 10.3.2
  • Response during initial phase, including signal
    fade
  • Response when getting close
  • Response as you pass over the beacon

3
Objectives
  • Describe the following ELT search methods
    P 10.4 10.7
  • Homing
  • Wing null
  • Aural
  • Signal
  • Discuss signal reflection and interference P
    10.9
  • Describe how to silence an ELT and the legal
    issues involved. P 10.10

4
Vocabulary
  • Glossary of terms
  • Direction Finder, DF.
  • Emergency Locator Transmitter, ELT.
  • Marine Emergency Position Indicating Radio
    Beacon, EPIRB.
  • Personal Locator Beacon, PLB.
  • Search And Rescue Satellite, SARSAT.

5
Beacons
  • 100 milliwatts of power
  • Roughly equal to that of a regular flashlight
  • Normally set off by the impact of an airplane
    crash can be set off by a hard landing--check
    121.5 before engine shutdown
  • Remember that the ELT may be attached to an
    aircraft or vessel in distress!
  • Line of sight Reception.
  • Subject to deflection and dispersion.

6
The ELT
  • Activated by g-force (when armed)
  • Some can be activated by the pilot in the cockpit
  • Three frequencies
  • 121.5 MHz (VHF emergency)
  • 243 MHz (UHF emergency military guard)
  • 406.025 MHz (third generation ELT/EPIRB)
  • General types
  • General aviation aircraft
  • Military (beepers or beacons)
  • Marine EPIRB
  • Test station (training practice beacon)
  • Advanced (406)

7
ELT Antenna
8
Most aircraft have ELTs installed
But they dont always survive a crash
9
Most aircraft have ELTs installed
But they dont always survive a crash
10
Military beacons
  • Most common type is the URT-33/C
  • Personnel ejecting/parachuting will have a 243
    MHz beacon
  • Some downed pilots may be able to communicate via
    two-way radio on 243 MHz using a PRC-90 or later
    military survival radio
  • Beacon mode transmits like an ELT on 243 MHz

11
Personal beacons
  • Personal Locator Beacon (PLB) or Personal
    Emergency Transmitter (PET)
  • Intended for hikers and other remote wilderness
    travelers
  • PLBs operate in the 406.0-406.1 MHz band

12
Marine EPIRB
  • Emergency Position Indicating Radio Beacon
  • Similar to an ELT, an EPIRB is used on ships and
    boats
  • Mandatory on certain commercial vessels
  • Some activate automatically and others are
    manually activated

13
Advanced ELTs
  • Most advanced are TSO C126
  • 406.025 MHz beacons have data burst encoding that
    identifies each (registered) individual beacon to
    the GOES SAR satellite system
  • Many have digital position reporting (GPS)
  • Still very expensive
  • Advantages of 406
  • Less chance of inadvertent activation.
  • Transmits identification.
  • Some transmits GPS position.
  • Higher power.
  • Cockpit indicator.
  • Will include weak 121.5 transmitter.
  • Self Test

14
Practice Beacon
  • Training Practice Beacons
  • Includes ones used by CAP
  • All should be converted from 121.6 to 121.775 MHz
    by now (if it isnt, dont use it)
  • During practice searches, avoid calling the
    practice beacon an ELT when communicating over
    the radio
  • May cause confusion
  • Always use the term Practice Beacon

15
Testing an Aircraft ELT
  • Can test the aircrafts ELT within the first five
    minutes after each hour
  • Only allowed up to three sweeps
  • When was the last time you tested the ELT in your
    aircraft?
  • Do you regularly monitor 121.5 MHz after you
    land?
  • Ensure your ELT didnt activate
  • This isnt considered a test, by the way, but you
    can try this excuse if you like

16
Inadvertent Activation
  • Excessively hard landings (Welcome aboard,
    Ensign!)
  • Inadvertent change of switch position
  • During removal/installation
  • Malfunction
  • Non-ELT source on 121.5 MHz (computers, broadcast
    stations, even pizza ovens!)
  • Monsieur Murphy

17
False Alarms
  • Approximately 97 of received ELT signals are
    false alarms
  • For 121.5 MHz ELTs abut 1 in 1000 are actual
    emergencies
  • For 406 MHz ELTs abut 1 in 8 are actual
    emergencies
  • Whats the big deal?
  • SARSAT can only monitor 10 ELTs at once
  • Easy to overload the system
  • They block emergency communications on 121.5 and
    243 MHz (guarded by towers, ARTCC, and the
    military)
  • BOTTOM LINE ELT Signals are calls For help, and
    FALSE ALARMS BLOCK REAL EMERGENCIES!

18
  • QUESTIONS?

19
Detection Timeline
20
Accuracy of SARSAT/COSPAS
  • For a regular 121.5 MHz beacon
  • Said to be a 12 nautical mile radius (452 square
    nm)
  • Actually an oval shape with a 50 probability of
    being 15 nm wide and 7 nm high
  • System is more accurate North to South (latitude)
  • Average six-hour notification
  • For a 406 MHz beacon its a 2 nm radius (12.4
    square nm) with an average one-hour notification
  • For a 406 MHz beacon with GPS its a 0.05 nm
    radius (0.008 square nm) with an average
    five-minute notification

21
OK, So How Should I Treat an ELT Mission?
  • AS AN EMERGENCY!
  • Its not possible to know whether an ELT signal is
    a distress signal or a false alarm
  • Although the statistics are against it, you must
    act as though it is a distress call
  • If you take advantage of them, every ELT mission
    allow you to keep your skills sharp!

22
Locating the ELT Signal
  • Route or parallel track to pick up the signal
  • If no SARSAT hits or definitive LKP
  • 4,000 to 10,000 AGL
  • Large track spacing (start at 60 nm, then do
    halves)
  • Once signal is located, DF the signal

23
Direction Finder (DF)
  • A direction finder compares signal strengths from
    two antenna patterns to let the user know
  • When you are centered on a signal
  • headed directly towards OR away from from the
    signal source
  • Which direction to turn when not centered
  • Similar to an ADF needle, but only points left or
    right, hence the term left-right homing

24
L-Tronics DF
25
DF Antenna
  • Most operate on VHF 121.5.
  • Some have additional UHF 243.0 Capability.
  • Two antennas, some UHF have three. All the
    aircraft in Minnesota wing are mounted on the
    bottom, but some wings may have aircraft with DF
    antennas on the top

26
Search Methods
  • DF Homing Method
  • Wing Shadow Method
  • Aural Search Method
  • Night and IFR Electronic Search

27
DF Homing Method
  • Understand the DF Controls.
  • Know the Search Procedures.
  • Practice, Practice, Practice.

28
Step 1 Acquire the Signal
  • To hear the signal you can use your L-Tronics Air
    DF or one of your comm radios.
  • To acquire with a comm radio, turn the squelch
    OFF (pull out the volume knob out or flip the
    appropriate switch)
  • The static you hear may be annoying, but it will
    allow you to hear the signal at the earliest
    possible time
  • Allows for a weak or distant signal to be heard

29
Done using Track Line or Parallel Track pattern
  • Proceed to the SARSAT composite hit, or to the
    point designated by your incident commander.
  • Initial altitude is normally 3,000 to 10,000 AGL
  • Use a search pattern (Track Line (route) search
    or Parallel Track) assigned by the Mission
    Coordinator

30
Beginning The Search Altitude Selection
  • Higher altitudes allow for reception of the ELT
    signal at greater distances.
  • ELTs transmit on 121.5 MHz and 243.0 MHz, both of
    which limit reception to line of sight.
  • Terrain will block ELT signals.
  • HIGHER is therefore usually BETTER to acquire a
    signal.
  • Medium altitude is generally better for searching
    (after signal heard)
  • 3,000 to 5,000 AGL

31
Beginning The Search Altitude Selection
Signal blocked by the curvature of the earth
Area of Reception
Area of Reception
32
Altitude Selection
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
New Search
37
(No Transcript)
38
(No Transcript)
39
Wing Shadow Method
40
Wing Shadowing
  • By flying the airplane in a circle, at some point
    the wing will block the ELT signal to the
    receiver antenna
  • This causes an audible decrease in volume, called
    a null
  • Almost any VHF-AM aircraft communications radio
    may be used with this method.

41
Wing Shadowing Antennas
  • To properly use the Wing Shadowing method, you
    MUST know where the antenna for the radio you are
    using is installed located on the aircraft
  • Communications radio antennas are usually, but
    not always, located above the wings
  • Can be above the fuselage, in the tail, etc.
  • L-Tronics Aircraft DF antennas may be above or
    below the aircraft
  • Below the aircraft is the preferred installation

42
Communications Antennas Above the Wing
43
DF Antennas Below the Wing
Antennas Belowthe Wing
44
How To DF by Wing Shadowing
  • Fly a constant bank angle 360 turn.
  • the audio will null,
  • or get significantly quieter,
  • when your wing blocks the antennas reception of
    the ELT signal.

45
Wing Shadowing Signal BlockingFor Antennas
Below the Wings
46
Wing ShadowingAntennas Below the Wing
  • Turn in a circle until you hear the null
    (significant decrease in volume)
  • The ELT is 90º to your RIGHT ADD 90º to your
    heading

47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
Antenna Location
  • Antenna on bottom, left turn, subtract 90
    degrees.
  • 220 - 90 130
  • Antenna on the top, left turn, add 90 degrees.
  • 040 90 130
  • Antenna on bottom, right turn add 90 degrees.
  • 355 90 085
  • Antenna on top, right turn subtract 90 degrees.
  • 175 - 90 085

53
Aural (Hearing) Search Method
  • Only Requires a Receiver.
  • This is based on the assumption that the area of
    equal beacon signal strength is circular
  • do NOT adjust volume during this search you will
    need it to determine equal levels of signal.

54
Aural (Hearing) Search Method (cont)
  • Begin by plotting your position as soon as you
    receive the ELT signal.
  • Fly that course for a short distance, then turn
    90º left or right and proceed until the signal
    fades.
  • Turn around (180º) and mark where the signal
    fades on the other side of the circle.
  • Plot chord lines similar to that of the diagram.
  • Bisect the chord lines at a perpendicular.
  • Plot a course to the location where the
    perpendicular lines intersect this should be the
    location of the target!

55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
Aural Metered Search
  • Must Have a Signal Strength Meter.
  • Assumes the Beacon Transmission Pattern is
    Circular.

59
Aural Metered Search
  • This search requires a signal strength meter
    (like that on the L-Tronics DF units-if the DF
    portion of the unit is inoperative you can still
    use this type of search as long as RECeive is OK.
  • Note your signal strength when beginning the
    search.
  • Fly a straight line until the signal gets lower,
    then increases to your original level.
  • Turn 180º and return to the lowest level of
    signal, then turn 90º left or right.
  • You should now be headed directly towards or away
    from the transmitter.
  • If the signal increases in strength, you are
    headed directly for the ELT.
  • If the signal decreases in strength, turn 180º

60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
Left-Right DF Homing
  • Most CAP corporate aircraft have L-Tronics
    LA-Series Left-Right Homing DF units.
  • These units operate virtually the same, but there
    are two major varieties
  • Single Meter Models
  • Dual Meter Models

65
L-Tronics DF Types
  • Single Meter Model
  • Dual Meter Model

66
Frequency Switch
  • Selects frequency to be used.
  • Use 121.5 MHz for actual ELTs/EPIRBs.
  • 243.0 MHz may also be used for all actual
    electronic searches.
  • Use 121.775 MHz for training (or 121.6 for
    non-CAP practices).
  • Refer to owners manual for use of the AUX
    position.

67
Alarm Toggle
  • Normal Alarm toggle in up position
  • DF toggle is down
  • DF is short for Direction Find
  • DF gives left-right homing to the ELT/EPIRB
    signal
  • ALARM is for NON-MISSION flights only
  • Use only during normal flying to alert the
    presence of an ELT or EPIRB

68
Volume Sensitivity
  • Volume controls the audio level to the speaker or
    headsets
  • Sensitivity controls the amount of signal that
    enters into the DF unit
  • It is critical that the proper amount of signal
    enters the DF half-scale, or the middle, is an
    optimum starting place
  • As the signal gets stronger, reduce SENSITIVITY,
    not volume
  • The DF will be unreliable as too much signal is
    received, so you must cut out part of it by
    reducing the sensitivity
  • More than three-quarters scale is too much

69
PREFLIGHT FUNCTIONAL CHECK
  • Just as you preflight the rest of the aircraft,
    you should preflight your DF when going on an ELT
    electronic search mission
  • These procedures are covered in the Mission
    Aircrew Reference Text.

70
DF SETTINGS FORDUAL METER MODELS
  • MISSIONS
  • Select 121.5 (or 121.775 for training missions)
  • Ensure Alarm Toggle Off
  • Turn Sensitivity to Maximum (Full Clockwise)
  • Turn Volume to About Mid-Scale
  • DF Should Stay About Centered
  • Strength Meter Will Move Up-Scale to Right
  • NON-MISSION FLIGHTS
  • Select 121.5
  • Turn Alarm Toggle On
  • Turn Sensitivity To Maximum

71
SIX STEPS
  • Use these 6 steps for locating ELTs and EPIRBs
    with L-Tronics LA- series airborne DF equipment
  • Use the full procedure every time for the best
    results
  • RECeive
  • HALF
  • DF
  • TURN
  • CHECK
  • SHOOT
  • Each of these steps will be described in detail
    in the slides to follow

72
Step 1 RECeive
  • Once you have started to receive the ELT or EPIRB
    signal on the proper frequency.
  • If you have a single-meter unit, turn the mode
    selector to RECeive and turn the volume to a
    comfortable level.
  • If you have a dual meter unit, refer to the
    STRENGTH window (no need to change modes).

73
RECeive Mode/STRENGTH Window
  • In receive mode or in the strength window, the
    unit measures signal strength
  • Left needle is low, right is high
  • Values are relative depending on the sensitivity
    you have selected.
  • You may still be able to use the strength meter
    even if the DF is not functioning perfectly
  • It is possible to locate an ELT using only the
    Receive Mode
  • Utilize Aural Search/Metered Search methods to
    accomplish
  • If the unit isnt completely operable, try wing
    shadowing using one of the aircrafts
    communications radios and use the DF units
    strength meter as a backup using the
    aural/metered methods

74
Step 2 HALF
  • Now that the unit is in RECeive mode and you have
    a good signal, turn the Sensitivity Knob to HALF
    SCALE
  • This is in the center of the window
  • If you are flying with a dual-meter unit, turn
    the Sensitivity Knob so the needle reads HALF
    SCALE in the STRENGTH window
  • A half-scale strength reading will prevent too
    much signal (oversense) from entering the unit
    and will provide you with a good starting point
  • It is also the optimum for the DF homing antennas

75
Step 3 DF
  • For signal meter units, turn the mode selector
    know to DF.
  • In DF mode, you can think of the needle as always
    pointing Direct to the Flipping target.
  • For dual meter models, simply refer to the DF
    window (no need to change modes).

76
DF Antenna
  • The aircraft DF unit has a 2 or 3 element
    antenna
  • Commonly, we might call this two or three
    antennas
  • It just means there are two or three rods!
  • This antenna setup is directional
  • One element actually receives the signal
  • The other elements (rods) reflect the signal away
    from the first rod

Antenna Elements
77
Antenna Reception Pattern
  • When viewed from the bottom, an antenna setup
    like the one pictured on the previous slide
    produces a reception pattern like the one shown
    here
  • This pattern is called carotid, which means
    heart-shaped
  • The pattern is the same even if the antennas are
    mounted above the wing

78
Direction Finding Mode/Window
  • The DF mode rapidly alternates the receiving and
    reflecting antenna elements
  • It chooses one element as the receiver and the
    other two as the reflectors, then switches to the
    other set
  • This produces a carotid pattern each time the
    unit switches
  • one is shown in red, the other in yellow
  • By comparing the two patterns, the unit will
    determine when they are equal
  • When theyre equal, the needle centers!
  • When the needle is centered, the target is
    either directly ahead or behind you!

79
Step 4 TURN
  • Turn at least one FULL circle, noting where the
    DF needle centers.
  • Under ideal conditions, the needle will center
    twice
  • When facing directly at the source of the signal
  • When facing 180º away from the target
  • You will solve this problem (called ambiguity) in
    the next step.

80
DF CENTERS
ELT (Possibility 1)
Alternating Antenna Patterns
WHEN THE PATTERNS ARE EQUAL, THE DF NEEDLE
CENTERS!
Alternating Antenna Patterns
ELT (Possibility 2)
81
Step 5 CHECK
  • Use Turn to Tell
  • Remembering that in DF mode the needle always
    points Direct to the Flipping target
  • When you have the needle centered, turn left or
    right
  • If you turn left and the needle goes left, the
    ELT is 180º from your present heading
  • If you turn left and the needle turns right, the
    ELT is dead ahead

82
AMBIGUITY
ELT (Possibility 1)
  • When Needle Centers
  • ELT is Directly Ahead or Behind
  • This situation is called ambiguity
  • To Solve ambiguity
  • Use Turn to Tell
  • Make a turn left or right
  • The needle always points Direct to the Flipping
    Target (DF!)

ELT (Possibility 2)
83
DF NEEDLE
ELT
  • Compare the YELLOW (LEFT) and the RED (RIGHT)
    antenna patterns
  • In this case, the LEFT pattern is stronger than
    the RIGHT
  • In DF mode, the needle would thenpoint LEFT
  • The needle always points Direct to the Flipping
    Target!

84
SOLVING AMBIGUITY
ELT (Possibility 1)
  • Actual ELT positionis unknown to user
  • Make a small turn left or right
  • As a teachingreminder, Use aTURN to TELL

ELT (Possibility 2)
85
SOLVING AMBIGUITY
ELT (Possibility 1)
  • Actual ELT positionis unknown to user
  • Make a small turn left or right
  • As a teachingreminder, Use aTURN to TELL
  • Example
  • TURN LEFT
  • needle goes left

ELT (Possibility 2)
86
SOLVING AMBIGUITY
  • Actual ELT positionis unknown to user
  • Make a small turn left or right
  • As a teachingreminder, Use aTURN to TELL
  • Example
  • TURN LEFT
  • If needle goes left
  • ELT is to your left (behind you)

ELT (Possibility 2)
ELT (Possibility 2)
87
SOLVING AMBIGUITY
ELT (Possibility 1)
  • If you turn Left and theneedle moves Right
  • The ELT is inFront of you!

ELT (Possibility 2)
88
SOLVING AMBIGUITY
ELT (Possibility 1)
  • If you turn Left and theneedle moves Right
  • The ELT is inFront of you!
  • Example
  • Turn left
  • Needle goes right

ELT (Possibility 2)
89
SOLVING AMBIGUITY
ELT (Possibility 1)
  • Solution
  • If you turn Left and the needle moves Right
  • The ELT is inFront of you!

90
Step 6 SHOOT
  • Use your DG to determine a bearing to the target
    follow it
  • You may need to fly through a zone of signal
    dropout
  • Be watchful for signs of signal passage
  • If you get signal passage, consider using the
    pinpointing the target techniques listed in
    this presentation
  • Frequently repeat the full six steps to ensure
    you are heading in the right direction and that
    you didnt inadvertently overfly the ELT

91
How A DF Unit Works Summary
  • Two Main Modes of Operation
  • RECeive
  • DF
  • RECeive Mode is a Strength Meter
  • Left is low, right is high
  • DF Mode Centers on Signal
  • Always points to the signal
  • Use a Turn to Tell when solving ambiguity
  • Aircraft and ground units work the same way

92
Reflections
  • Reflections of an ELT signal work just like a
    flashlight off of a mirror
  • Any flat, hard, or wet object can cause signal
    reflections
  • Mountains, especially cliff faces
  • Hangars and other metal structures
  • Wet grass or snow
  • Large bodies of water or ice
  • Powerlines can also have a large effect on a
    low-powered signal such as an ELT

93
Beating Reflections
  • Check your sensitivity at half-scale or lower
  • But ensure that its high enough to receive
    adequate signal
  • Reflections will generally be weaker than the
    most direct path to the target
  • Following reflections will generally take your
    closer to the target
  • If sensitivity is set to minimum, try DFing on a
    different frequency
  • For example, if you are trying to locate an
    actual ELT on 121.5 MHz, try locating it on 121.6
    or 121.775 MHz when you get close
  • When all else fails, fly somewhere else to get a
    good DF bearing-or try that at the first sign of
    problems!

94
Carrier-Only Signals
  • You dont always need to hear the ELT or EPIRB to
    find it
  • A carrier-only signal may be broadcasting with no
    audible sweep
  • This is especially true with low or old
    batteries, damaged ELTs, or spurious
    transmissions
  • You can identify a carrier-only signal by
    DEFLECTION
  • Good needle deflection generally indicates a
    signal that is strong enough to DF
  • Compare your deflection to another frequency
  • If you are using 121.5 MHz, try it on 121.775 MHz
  • If deflection is the same in both frequencies,
    you DONT have a signal, just random noise
  • If deflection is different, keep at it! You have
    the signal.

95
Vertical Reflections Signal Dropout
  • The transmission pattern (similar to the
    reception pattern of the DF antennas, only for
    transmission) of an ELT is not a perfect circle
    or sphere
  • It has lobes, or, stronger and weaker points
  • This is accentuated when the ELT is transmitting
    from a location above the surrounding ground
  • When you get a good DF heading and the signal
    fades or drops out completely you may just be
    outside of one of the signal lobes
  • When you reacquire the signal, it should be
    stronger than when you lost it

96
Signal Dropout
  • If you encounter a signal dropout, continue to
    fly on your last good DF heading
  • You should reacquire the signal in a few minutes
  • Actual time will depend upon your distance to the
    target
  • If you are unable to reacquire, return to where
    you last heard the signal and re-DF

97
Signal Strength
  • The rate of change in signal strength increases
    as you get closer to the transmitter, and RECeive
    mode or the STRENGTH window measures signal
    strength
  • This is due to Maxwells inverse square law.
  • When you double the distance from an object, the
    energy it you receive from it is 1/4 of what you
    originally received, or the inverse square
    1/(22) 1/4
  • After Scottish Physicist James Clerk Maxwell,
    1831-1879
  • You will therefore need to turn down the
    sensitivity to keep the unit at half scale in the
    RECeive mode or STRENGTH window much more often
    as you get close to the source of the signal
  • This should let you know that youre getting close

98
Signal Strength Rate of Change
SENSITIVITY KNOB DEACREASES EXPONENTIALLY
ASDISTANCE DECREASES
99
Cone of Confusion
  • Antennas receive best when the pole is
    perpendicular to the signal
  • When you approach the directly overhead position
    on an ELT, your DF will become unreliable
  • It may swing left and right
  • It may center regardless of your heading
  • You should practice to see what this station
    passage reading looks like
  • It is similar to crossing a VOR

100
Reception in the Cone of Silence
  • You may also get a significant drop in ELT signal
    since the antennas dont receive well directly
    off of their tips
  • Although called a cone of silence, you will
    probably only see hear a large decrease in
    signal instead of complete silence

101
Pinpointing the ELT
  • If you get a station passage indication, make an
    approximate 180 degree turn and DF back to the
    target
  • Repeat this process using different approach
    angleseach time, remembering that your path may
    be curved due to wind (like uncorrected NDB
    holding)
  • The point where station passage is received
    several timesshould be the location of the
    target

102
Pinpointing the ELT
  • After you think you have the target located
  • make a low pass over the suspected location and
    visually scan
  • if signal strength decreases significantly or
    drops out, climb back and try again
  • this is not the target sometimes false targets
    will appear due to reflections or other
    interference
  • If you hear the ELT at low altitude, you probably
    have the right place
  • a low pass down a runway might be a good idea if
    you suspect a particular airport

103
Night and IFR Electronic Search
  • Observe Altitudes Closely.
  • Ensure Clearance from Towers.
  • Electronic Search Only (No Visual).
  • Maintain Contact With FAA Facility (If Possible).

104
Coordination with ATC
  • Monitor and Advise Traffic if Searching Near an
    Uncontrolled Airport.
  • Advise Approach Control and/or Tower Near a
    Controlled Airport.
  • Advise ATC if You Hear an ELT.
  • Advise ATC if You No Longer Hear the ELT.

105
  • QUESTIONS?

106
After Locating The ELT
  • After location, coordinate with ground teams to
    bring them on-scene.
  • Use radio communication and relay GPS
    coordinates.
  • Pick up the ground team at a predetermined
    location and lead them to the target.
  • Alternately, coordinate a pick up point on the
    radio.
  • Practice your air to ground coordination skills
    often
  • try it both with and without radio communication
  • Air-to-Ground is CAPs best unique ES skill!

107
DF upon Landing
  • Many times the ELT is located at an airfield
    where it is easier for you to land and locate the
    ELT than it is to get a ground team to the scene
  • You can use a hand-held radio or hand-held DF
    unit
  • The most commonly used in CAP is the Little L-Per
  • You did remember to put one of these (with
    charged batteries) in the aircraft before you
    left, didnt you?

108
Little L-Per
  • Six Steps
  • Receive
  • Half
  • DF
  • Center
  • Turn
  • Shoot

109
OK, which of these planes is it in?
  • You land at an airport with multiple hangers and
    each hanger is full of aircraft
  • This can make it difficult to find the ELT
  • Two methods can help
  • Signal-offset
  • Using a hand-held radio without its antenna

110
OK, which of these planes is it in?
  • Signal-offset reflected signals are generally
    weaker so by tuning your radio further away from
    the primary frequency you can isolate the signal
  • Assume ELT transmitting on 121.5 set to 121.55
  • As you home in set in 121.6 (you may even work up
    to 121.7)
  • As you get further away from 121.5 the area where
    the signal will break through the squelch becomes
    smaller and smaller (you can even turn up the
    squelch to get further isolation)

111
OK, which of these planes is it in?
  • Using a hand-held radio without its antenna
  • Once youve narrowed the suspects down to one or
    two aircraft (usually side-by-side), remove the
    radios antenna and hold it next to one of the
    ELT antennas
  • Turn the volume down until you just hear the
    signal
  • Move to the other aircrafts ELT antenna
  • If the signal is stronger you probably have it
    if weaker, its probably the other aircraft
  • Can also combine this with the signal-offset
    method
  • Dont key the radios transmitter with the
    antenna removed!

112
OK, where is the thing?
  • ELTs are usually located in or near the rear of
    the aircraft. Also look for remote switches.
  • Single-engine Cessna right side of the upper
    baggage area immediately aft of the baggage door
  • Multi-engine Cessna left side of the fuselage
    just forward of the horizontal stabilizer.
    Accessed through a small push-plate on the side
    of the fuselage.
  • Single- and multi-engine Piper in the aft
    fuselage. Accessed through a small access panel
    on the aft bulkhead of the baggage compartment.
  • Single- and multi-engine Bonanza in the aft
    fuselage. Accessed through a small access plate
    on the right side of the fuselage.
  • Large piston twins (e.g., King Air) and small
    jets if installed its probably in the rear
    section. No visible antenna. May have a small
    round push-plate that lets you manipulate the ELT
    switch.

113
Silencing the ELT
  • The preferred method is to have the owner (or
    someone designated by the owner) turn it off and
    disconnect the battery
  • Second best is to just turn it off
  • The owner may take the switch to Off and then
    back to Armed
  • If this is done, stick around and monitor 121.5
    to ensure it doesnt go off again
  • If you cant find the owner, you may have to
    build a foil tent (refer to CAPP-2)

114
Silencing the ELT
  • Foil Tent
  • 1 x 5
  • Encloses antenna
  • Flaps at least 18 beyond antenna on fuselage
  • Securely taped (masking tape preferred)

115
Silencing the ELT
  • Ensure that the owner is notified that the ELT
    was disabled
  • If you cant get a phone number, you can place a
    note on the aircraft (not the window)

116
Legal Issues
  • Per CAPR 60-1 Chapter 1, CAP members will not
    enter private property and should not do anything
    that could cause harm or damage to the distress
    beacon or aircraft/boat
  • Entry to the ELT should be made by the owner or
    operator or law enforcement
  • A transmitting ELT is under the legal authority
    of the FCC, and federal law requires that it be
    deactivated ASAP (a crashed aircraft is under the
    authority of the NTSB)

117
Legal Issues
  • CAP members do not have the authority to trespass
    onto private property, either to gain access to
    the aircraft or to enter the aircraft to gain
    access to the ELT
  • Besides the owner/operator, some owners give FBO
    personnel permission to enter their aircraft

118
Legal Issues
  • While entry upon private property may be
    justified if such an act is for the purpose of
    saving life, every effort should be made to
    obtain the controlling agency's and/or the
    property owner's consent
  • If you need entry onto private property in order
    to search for an ELT, law enforcement authorities
    such as local police, the county sheriff's office
    or game wardens may be contacted for assistance.

119
Legal Issues
  • Normally, local law enforcement officials are
    happy to assist you if they are not familiar
    with CAP and your responsibilities, a simple
    explanation often suffices
  • If this doesn't work, try calling AFRCC and have
    them explain the situation

120
Legal Issues
  • The most important aspect is the manner in which
    you approach the matter
  • The local civil authorities are in charge, but if
    the AFRCC tasks you to search, you go search and
    offer assistance to the civil authorities when
    the opportunity presents itself
  • If they tell you go home, then phone the IC
    and/or AFRCC and close the mission

121
Where to get more information
  • CAP Emergency Services Training and Operational
    Missions, CAPR 60-3.
  • Operational and Maintenance Practices for
    Emergency Locator Transmitters and Receivers,
    AC91-44A.
  • ELT/EPIRB Search, CAPP2.

122
QUESTIONS?Good Hunting!
Write a Comment
User Comments (0)
About PowerShow.com
