Verifying high-resolution forecasts

1
Verifying high-resolution forecasts

• Advanced Forecasting Techniques
• Forecast Evaluation and Decision Analysis METR
  5803
• Guest Lecture Adam J. Clark
• 3 March 2011

2
Outline

• Background
• Clark, A. J., W. A. Gallus, M. L. Weisman, 2010
  Neighborhood-based verification of precipitation
  forecasts from convection-allowing NCAR-WRF model
  simulations and the operational NAM.
• Clark, A. J., and Coauthors, 2011 Probabilistic
  precipitation forecast skill as a function of
  ensemble size and spatial scale in a
  convection-allowing ensemble.

3
Why is verifying high-resolution forecasts
challenging?

• Scale/predictability issues
• As finer scales are resolved, time lengths for
  predictability shorten. Was first shown
  mathematically by Ed Lorenz
• Lorenz, E. N., 1969 The predictability of a flow
  which possesses many scales of motion. Tellus,
  21, 289307.

4
Challenges (cont.)

• Observations many fields are not directly
  observed at high-resolution. Thus, models and
  data assimilation systems needed to create
  analysis datasets at high-resolution. Of course,
  this introduces uncertainties that should be
  accounted for when doing model evaluation.
• At fine scales, forecasts with small errors can
  still be extremely useful. For example

5
Challenges (cont.)
OBS
Most subjective evaluations would say forecast 2
was better, although all objective metrics
indicate forecast 1 was better. How can we
develop metrics consistent with human subjective
impressions?
1
2
Credit Baldwin et al. 2001
6
Non-traditional approaches

• Purely subjective good, fair, poor, ugly scale
  of 1 to 10, etc.
• Combination of subjective and objective
• MCS example manually categorize possible
  forecast outcomes into 2x2 contingency tables and
  then compute objective metrics
• Objective methods (Casati et al. 2008) has nice
  review.
• Feature-based (Ebert and McBride 2000 Davis et
  al. 2006). Involves defining attributes of
  objects
• Scale Decomposition (e.g., Casati et al. 2004)
  evaluates skill as function of amplitude and
  spatial scale of the errors.
• Neighborhood-based approaches (e.g., Ebert 2009)
  consider values at grid-points within a
  specified radius (i.e. neighborhood of an
  observation.

7
References so far

• Casati, B., G. Ross, and D. B. Stephenson, 2004
  A new intensity-scale approach for the
  verification of spatial precipitation forecasts.
  Meteor. Appl., 11, 141-154.
• Casati and Coauthors, 2008 Forecast
  verification Current status and future
  directions. Meteor. Appl., 15, 3-18.
• Baldwin, M. E., S. Lakshmivarahan, and J. S.
  Kain, 2001 Verification of mesoscale features in
  NWP models. Preprints, Ninth Conf. on Mesoscale
  Processes, Fort Lauderdale, FL, Amer. Meteor.
  Soc., 255-258.
• Ebert, E. E., and J. L. McBride, 2000
  Verification of precipitation in weather systems
  Determination of systematic errors. J. Hydrol.,
  239, 179202.
• Ebert, E. E., 2009 Neighborhood verification A
  strategy for rewarding close forecasts. Wea.
  Forecasting, 24, 1498-1510.
• Davis, C. A., B. Brown, and R. Bullock, 2006
  Object-based verification of precipitation
  forecasts. Part II Application to convective
  rain systems. Mon. Wea. Rev., 134, 17851795.

8
Neighborhood ETS applied to CAMs

• What was done and why
• Examined a large set of convection-allowing
  forecasts run by NCAR 2004-2008 and compared them
  to operational NAM.

• Earlier work (e.g., Done et al. 2004) showed
  skill scores between coarser models ( 10 km) and
  convection-allowing NCAR-WRF almost identical.
• This contradicted other findings

Done et al. 2004 Fig 5
9
Neighborhood ETS (cont)

• Perhaps lack of differences was simply a result
  of inadequate traditional metrics.
• When forecasts contain fine-scale and
  high-amplitude features slight displacement
  errors cause double penalties
  observed-but-not-forecast and forecast-but-not-obs
  erved
• Thus, many recent studies have developed
  alternative metrics
• Feature based (Ebert and McBride 2000 Davis et
  al. 2006)
• Scale-decomposition (Casati et al. 2004)
• Neighborhood-based (Roberts and Lean 2008 Ebert
  2009)

10
Neighborhood ETS (cont)

• To compare the NCAR-WRF and NAM forecast a
  neighborhood-based Equitable Threat Score (ETS)
  was developed.
• Traditional ETS is formulated in terms of
  contingency table elements

and is interpreted as fraction of correctly
predicted observed events, adjusted for hits
associate with random chance.

• Neighborhood ETS is computed in terms of
  specified radii this study uses 20 to 250 km.

11
r 100 km, 81 total grid-points
Open circles observed events Crosses
forecast events Grey shading - hits
12
Neighborhood ETS (cont)

• To compute neighborhood ETS
• Simply redefine contingency table elements in
  terms of r
• Hits (traditional) correct forecast of an event
  at a grid-point
• Hits (neighborhood) an event is forecast at a
  grid-point and observed at any grid-point within
  r, or an event is observed at a grid-point and
  forecast at any grid-point within r.
• Misses (traditional) event is observed at a
  grid-point but not forecast
• Misses (neighborhood) event is observed at a
  grid-point but not forecast at any grid-point
  within r.
• False Alarms (traditional) event is forecast at
  a grid-point but not observed
• False Alarms (neighborhood) event is forecast
  at a grid-point but not observed at any
  grid-point within r.
• Correct negatives (traditional and neighborhood)
  event is neither forecast nor observed at a
  grid-point

13
Neighborhood ETS (cont)

• Domain and cases

14
Neighborhood ETS (cont.)

• Model configurations

15
Neighborhood ETS (cont.)

• Results 2004-2005

16
Neighborhood ETS (cont.)

• Results 2007-2008

17
Neighborhood ETS (cont.)

• Time series at constant radii

18
An aside computing statistical significance for
categorical metrics

• First, what are the ways to compute averages of
  categorical metrics over a set of cases?
• 1) Compute the metric for each case and then
  average over all cases.
• 2) Sum contingency table elements over all cases,
  and then compute the metric from the summed
  elements.

19
Hamill, T. M., 1999 Hypothesis tests for
evaluation numerical precipitation forecasts.
Wea. Forecasting, 14, 155-167.

• You have to be very careful computing statistical
  significance for precipitation forecasts! Key
  quote Precipitation forecast errors are often
  non-normally distributed and have spatially
  and/or temporally correlated error the effective
  number of independent samples is much less than
  the total number of grid-points.
• What does this mean??
• Hamill outlines several potential approaches for
  computing significance for threat scores. He
  finds a rather involved resampling approach is
  most appropriate for non-probabilistic forecasts.


20
Resampling
Forecast 1 Forecast 2
Case 1 a, b, c, d a, b, c, d
Case 2 a, b, c, d a, b, c, d
Case 3 a, b, c, d a, b, c, d
Case 4 a, b, c, d a, b, c, d
Case 5 a, b, c, d a, b, c, d
Case 6 a, b, c, d a, b, c, d
Case 7 a, b, c, d a, b, c, d
ETS ETS
Forecast 1 Forecast 2
Case 1 a, b, c, d a, b, c, d
Case 2 a, b, c, d a, b, c, d
Case 3 a, b, c, d a, b, c, d
Case 4 a, b, c, d a, b, c, d
Case 5 a, b, c, d a, b, c, d
Case 6 a, b, c, d a, b, c, d
Case 7 a, b, c, d a, b, c, d
ETS ETS
Randomly shuffle the sets of contingency table
elements for each case and recompute ETS
difference. Repeat 1000 x. Construct a
distribution of ETS differences and test whether
test statistic falls within distribution. Dont
forget about bias!!
Difference between unshuffled ETS is test
statistic
21
Neighborhood ETS Compositing

• OFi is observed frequency for each grid-point
  within a conditional distribution of observed
  events.
• N is of grid-points in domain
• n is of grid-points in radius-of-influence

22
Neighborhood ETS (cont) Compositing

• Composite observations relative to forecasts.

23
Neighborhood ETS (cont) compositing
24
Neighborhood ETS (cont)

• Composite animations from SE2010 SSEF members
  with different microphysics

25
Neighborhood ETS (cont)

• Conclusions
• Computing ETS on raw grids gave small
  differences. When criteria for hits was relaxed
  using neighborhood approach, more dramatic
  differences were seen that better reflected
  overall subjective impressions of forecasts.

26
Probabilistic Precipitation Forecast Skill as a
function of ensemble size and spatial scale in a
convection-allowing ensemble

• Adam J. Clark NOAA/National Severe Storms
  Laboratory
• John S. Kain, David J. Stensrud, Ming Xue, Fanyou
  Kong, Michael C. Coniglio, Kevin W. Thomas,
• Yunheng Wang, Keith Brewster, Jidong Gao, Steven
  J. Weiss, and Jun Du
• 13 October 2010
• 25th Conference on Severe Local Storms, Denver, CO

27
Introduction/motivation

• Basic idea
• Convection-allowing ensembles ( 4km
  grid-spacing) provide added value relative to
  operational systems that parameterize convection.

• Precipitation forecasts are improved,
• diurnal rainfall cycle is better depicted,
• ensemble dispersion is more representative of
  forecast uncertainty, and
• explicitly simulated storm attributes can provide
  useful information on potential
  convection-related hazards
• However, convection-allowing models are very
  computationally expensive relative to current
  operational mesoscale ensembles.
• EXAMPLE Back of the envelope calculation for
  expense to make SREF convection-allowing
• 32 km to 4 km is decrease in grid-spacing by a
  factor of 8. To account for 3D increase in of
  grid-points and time-step reduction, take 83
  which gives increase in computational expense by
  factor of 500. Then take 500 times 21 members
  10,500.

28
Introduction/motivation (cont)

• Given computational expense, it would be useful
  to explore whether point of diminishing returns
  is reached with increasing ensemble size, n.
• 2009 Storm-scale ensemble forecast (SSEF) system
  provides good opportunity to examine the issue
  because it is relatively large
• 20 members 17 members used herein
• Decent number of warm season cases (25).

29
Data and Methodology

• 2009 SSEF system configuration

10 WRF-ARW members
8 WRF-NMM members
2 ARPS members
30
Data and Methodology (cont)

• Domain and cases examined

SSEF domain
analysis domain
31
Data and Methodology (cont)

• 6-hr accumulated rainfall examined for forecast
  hour 6-30.
• Stage IV rainfall estimates used for rainfall
  observations.
• Forecast probabilities for rainfall exceeding
  0.10-, 0.25-, 0.50-, and 1.00-in were computed by
  find the location of the verification threshold
  within the distribution of ensemble members.
• Area under the relative operating characteristic
  curve (ROC area) used for objective evaluation.
• 1.0 is perfect, 0.5 is no skill, and below 0.50
  is negative skill
• ROC areas were computed for 100 unique
  combinations of randomly selected ensemble
  members for n 2 to 15. For n 1, 16, and 17
  all possible combinations of members used.

32
Data and Methodology (cont)

• Examination of different spatial scales.
• Observed and forecast precipitation averaged over
  increasingly large spatial scales. Why do this?
  Not all end users require accuracy at 4-km
  scales

- For the verification, constant quantiles were
used to compare across different scales. Cannot
compare constant thresholds because precipitation
distribution changes.
33
Results

• Panels show ROC areas as function of n.
• Different colors of shading correspond to
  different scales. Areas within each color show
  the inter-quartile range for the distribution of
  ROC areas (recall, for each n, ROC areas were
  computed for 100 unique combinations of members).
• For each color, the darker shading denotes ROC
  areas that are less than those of the full 17
  member ensemble with differences that are
  statistically significant.

• Main result More members are required to reach
  statistically indistinguishable ROC areas
  relative to the full ensemble as forecast lead
  time increases and spatial scale decreases (and
  ROC areas arent bad).

34
RESULTS (cont)

• Interpretation
• Rise in ROC area reflects gain in skill as
  forecast PDF is better sampled.
• More members are required to effectively sample a
  wider forecast PDF, so the n at which we see
  skill flatten should increase with a broadening
  PDF. Two variables in the analysis are
  associated with a widening of the PDF
• 1) increasing forecast lead time (because
  model/analysis errors grow)
• 2) decreasing spatial scale (because errors grow
  faster at smaller scales)
• Caveats
• 1) Averages are presented. Specific cases with
  lower than average predictability (higher spread)
  should require more members to reach point of
  diminishing returns. Low probability events
  require more members to achieve reliable
  forecasts (e.g. Richardson 2001).

35
RESULTS (cont)

• More Caveats
• Ensemble is under-dispersive.

• A reliable ensemble with more spread would
  require more members to effectively sample the
  forecast PDF.

36
CONCLUSIONS

• Spatial scale and forecast lead time needed for
  end users should be carefully considered in
  future convection-allowing ensemble designs.
• Future work needed to improve reliability of
  convection-allowing ensembles, and further
  evaluations are needed for weather regimes with
  varying degrees of predictability.
• QUESTIONS??
