Nursing of Adult Patients with Medical

1
Nursing of Adult Patients withMedical
Surgical Conditions

• Cardiovascular
• Disorders

2
Diagnostic Tests

• Diagnostic Imaging
• Radiographic exam to assess heart size, shape and
  position and outline of shadows.

3
Diagnostic Tests

• Computed Axial Tomography (CT/CAT Scan)
• Three dimensional view of the structure

4
Diagnostic Tests

• Angiogram
• radiographs are taken after injection of dye into
  an artery
• Aortogram
• visualizes the abdominal aorta and the major leg
  arteries with injection of dye into the femoral
  artery

Iliac Artery
5
Diagnostic Tests

• Fluoroscopy
• action-picture

Fluoroscopy Demo
6
Diagnostic Tests

• Cardiac Catherterization and Angiography
• Visualizes the hearts chambers, valves, great
  vessels, and coronary arteries
• Catheter is inserted into the heart chambers to
  measure pressure, and blood-volume.
• Contrast dye may be used for better visualization
• Post-procedure
• supine, with sandbag over pressure dressing at
  insertion site

7
Cardiac Catheterization
8
Cardiac Catheterization Lab
9
Cardiac Catheterization with Contrast
10
Diagnostic Tests

• Electrocardiogram
• Graphic study of the electrical activities of the
  myocardium

11
Review of Cardiac Electrical Activity
12
Diagnostic Tests

• Electrocardiogram
• P-wave
• contraction (depolarization) of the atria
• QRS complex
• contraction (depolarization) of the ventricles
• relaxation (repolarization) of the atria is
  covered by the QRS complex
• T-wave
• relaxation (repolarization) of the ventricles

13
Relationship of EKG to cardiac muscle activity
(SA Node fires)
Atrial Depolarization
(Impulse to AV node)
(Impulse moves through Bundle of His Perkinje
fibers)
Ventricular Depolarization
Ventricular Repolarization
14
Electrocardiogram
15
Diagnostic Tests

• Cardiac Monitors
• Continual monitoring of the cardiac electrical
  activity on a video monitor
• Telemetry
• electronic transmission of data to a distant
  location

16
Diagnostic Tests

• Thallium Scanning
• Thallium 201 is injected and the patient
  exercises on a treadmill
• Thallium is transported into normal cells, but
  not ischemic or infarcted cells

17
Thallium Scanning
18
Diagnostic Tests

• Echocardiography
• Ultrasound is used to record size, shape, and
  position of cardiac structures
• Detects
• pericardial effusion
• ventricular function
• cardiac chamber size and contents
• ventricular muscle and septal motion and
  thickness
• cardiac output
• cardiac tumors
• valvular function
• congenital heart disorders.

19
Echocardiography
Echocardiogram Demo
20
Echocardiography
21
Diagnostic Tests

• Positron Emission Tomography (PET)
• Computerized radiographic technique that uses
  radioactive substances to examine the metabolic
  activity of various body structures
• Used to study dementia, stroke, epilepsy, tumors,
  and cardiac tissue

PET Demonstration
22
Diagnostic Tests

• Laboratory Exams
• Blood cultures
• Culture and sensitivity
• Compete Blood Count (CBC)
• RBC (erythrocytes) 4-6 million/cu.mm
• Hemoglobin 10-20 gm/100ml
• Hematocrit 40-50 percent
• WBC 5,000-10,000/mm
• Platelets 150,000-400,000/mm
• Coagulation Studies
• Prothrombin Time (PT) 11-12.5 seconds
• Partial thromboplastin time (PTT) 60-70 seconds
• Erythrocyte sedimentation rate (ESR)
• Up to 20mm/minute

23

• Serum electrolyte tests
• sodium - maintains fluid balance (135-145mEq/L)
• potassium - relaxes heart muscle (3-5 mEq/L)
• calcium - contraction of cardiac muscle
  (9-11mg/dl)
• magnesium - maintain level of electrical
  excitability in the nerves and muscles (1-2
  mEq/L)
• Serum lipids
• Total Cholesterol (140-200 mg/dl)
• High Density Lipoprotein (HDL) (35-85 mg/dl)
• Low Density Lipoprotein (LDL) (below 100mg/dl)
• Triglycerides (35-135 mg/dl)
• Arterial blood gases
• pH 7.35-7.45
• PaCO2 35-45 mm Hg
• PaO2 80-100 mm Hg
• HCO 21-28 mEq/L
• SaO2 95-100

24
Diagnostic Tests

• Cardiac Enzyme Studies
• CPK isoemzyme II (MB)
• enzyme is released when the heart muscle is
  damaged or necrosis occurs
• levels rise in 3-6 hours, peak in 12-18 hours,
  and may remain elevated for 3-4 days
• Normal Value 40-170 U/L
• LDH
• Rises within the first 24-72 hours, peaks in 3-4
  days, and returns to normal in approx 14 days
• Normal Value 100-200 U/L

25
Risk Factors forCardiovascular Disorders

• Nonmodifiable Factors
• Family History
• Parent or sibling who has CV disorder before 50
  yrs
• Age
• Normal physiological changes
• Approx 50 of all MI occur after 65 yrs
• Sex (Gender)
• Men are at greater risk than women
• Race
• African Amer. males are at higher risk of
  hypertension

26
Risk Factors forCardiovascular Disorders

• Modifiable Factors
• Smoking
• 2-3 times greater risk
• Hyperlipidemia
• Diet high in saturated fat, cholesterol, and
  calories
• Cholesterol levels above 200 mg/dl
• Hypertension
• B/P higher than 140/90

27
Risk Factors forCardiovascular Disorders

• Diabetes Mellitus
• Damage to vessels due to high glucose levels
• High cholesterol levels (abnorm. lipid
  metabolism)
• Obesity
• Increases workload of the heart
• Sedentary Lifestyle
• Exercise improves the hearts efficiency, lowers
  glucose cholesterol levels, lowers B/P, reduces
  weight, and reduces stress levels

28
Risk Factors forCardiovascular Disorders

• Stress
• Catecholamines are released which cause increased
  heart rate and damage to myocardial cells
• Oral Contraceptives
• Not clearly defined
• Older high dose contraceptives made women at
  higher risk for cardiovascular disorders esp.
  smokers
• Newer low dose contraceptives dont seem to cause
  that risk
• Psychosocial Factors
• Type A personality
• aggressiveness, competitiveness, perfectionism,
  compulsiveness

29
Cardiac Dysrhythmias

• Normal Sinus Rhythm
• Originates in the SA node
• Rate 60-100 beats/min
• Rhythm regular

30

• Sinus Tachycardia
• Originates in the SA node
• Rate 100-150
• Rhythm regular
• Causes
• exercise, anxiety, fever, shock, medications,
  hypothermia, heart failure, excessive caffeine,
  and tobacco
• Not usually caused by cardiac problems
• Treatment
• Directed at cause

31

• Sinus Bradycardia
• Originates SA node
• Rate less than 50-60 beats per min
• Rhythm regular
• Cause
• sleep, vomiting, intracranial tumors, MI, drugs,
  vagal stimulation, endocrine disturbances, and
  hypothermia
• Treatment
• Directed toward cause
• Atropine to increase heart rate
• Temporary or permanent pacemaker

32

• Supraventricular Tachycardia (SVT)
• Premature Atrial Contraction (PAC)
• Originates atria
• Rate 150-250 beats/min
• Rhythm regular
• Causes
• drugs, alcohol, mitral valve prolapse, emotional
  stress, smoking, and hormone imbalance
• usually not caused by heart disease
• Treatment
• Eliminate underlying cause
• Decrease heart rate
• carotid sinus pressure, ocular pressure,
  digitalis, calcium channel blockers, propranolol,
  quinidine, and cardioversion

33

• Atrial Fibrillation
• Originates atria
• Rate 350-600
• Rhythm irregular may be unable to count
• Causes
• atherosclerosis, mitral valve disease, CHF,
  cardiomyopathy, congenital abnormalities, COPD,
  and thyrotoxicosis
• Treatment
• digitalis, calcium channel blockers (verapamil),
  antidysrhythmics (procainamide), quinidine,
  anticoagulants (heparin, coumadin) and
  cardioversion

34

• Atrioventricular Block (1st, 2nd, 3rd degree)
• Originates SA node impulse is slowed at the AV
  junction due to a defect
• Rate
• 1st degree - 60-100 beats/min
• 2nd degree - 30-40 beats/min
• 3rd degree - may be no heart beat
• Cause
• atherosclerotic heart disease, MI, CHF, digitalis
  toxicity, congenital abnormality, drugs, and
  hypokalemia
• Treatment
• directed at cause
• atropine and isoproterenol
• pacemaker for 3rd degree

35

• Premature Ventricular Contractions (PVC)
• Originates ventricles
• Rate 60-100 beats/min
• Rhythm
• regular with an occasional extra beat
• may occur as a single event or may occur several
  times in a minute, or in pairs or strings
• Cause
• irritability of the ventricules, exercise,
  stress, electrolyte imbalance, digitalis
  toxicity, hypoxia, and MI
• Treatment
• Treat the cause
• antidysrhythmics (lidocaine, procainamide, or
  bretylium

36

• Ventricular Tachycardia
• Originates ventricles 3 or more successive
  PVCs
• Rate 140-240 beats/min
• Rhythm regular to slightly irregular
• Cause
• hypoxemia, drug toxicity, electrolyte imbalance,
  and bradycardia
• Treatment
• IV procainamide (decrease excitability of cardiac
  muscle)
• Lidocaine with MI
• Cardioversion

37

• Ventricular Fibrillation
• Originates ventricles
• Rate none
• Rhythm none
• Cause
• untreated ventricular tachycardia, electrolyte
  imbalances, digitalis or quinidine toxicity, and
  hypothermia
• Treatment
• Emergency care
• CPR
• defibrillation (15-20 seconds of the onset)
• medications
• lidocaine, bretylium, or procainamide

38
Artificial Cardiac Pacemakers

• Pacemaker
• Battery-operated generators that initiate and
  control the heart rate by delivering an
  electrical impulse to the myocardium
• Temporary
• Used for cardiac support following some MIs or
  open-heart surg.
• Permanent
• Used when other measures have failed to convert
  the dysrhythmia or conduction problem
• 2nd 3rd degree AV block, bradydysrhythmias,
  tachydysrhythmias

39
Internal Pacemaker
Catheter-like electrode is placed in the area to
be paced and generator is embedded under the skin
40
External Pacemaker
Electrode pad is placed on the chest wall and is
attached to a generator place in a pocket or pouch
41
Artificial Cardiac Pacemakers

• Nursing Interventions
• Post-op
• monitor heart rate and heart monitor
• assess vital signs and level of consciousness
• assess insertion site for erythema, edema, and
  tenderness
• bed rest with arm immobilized for first few hours
• Patient Teaching
• continued medical care is very important
• medical-alert ID
• report signs symptoms of pacemaker failure
• weakness, vertigo, chest pain, pulse changes
• avoid electrical equipment
• hairdryers, battery-operated toothbrushes, etc.
• avoid high-output electrical genterators and
  large magnets (MRI)
• teach patient or family member to check pulse
  rate
• notify physician if heart rate drops below 70
