6. Optoelectronic Devices
2
Optical Waveguides
(a) A buried-in rectangular waveguide, (b) a
buried-in rib waveguide, (c) a strip-loaded
waveguide, and (d) a diffused waveguide
3
Some Fabrication Processes of Optical Waveguides
4
Basic Theory of Waveguides
5
Theory of Planar Optical Waveguides
6
Approximate Theory of Rectangular Optical
Waveguides Surrounding by a Uniform Medium
7
Approximate Theory of Rectangular Optical
Waveguides Surrounding by a Uniform Medium (Cont)
8
Approximate Theory of Rectangular Optical
Waveguides Surrounding by a Uniform Medium (Cont)
9
Applications of Y-Branches and Bends of
Conventional Optical Waveguides
10
Multimode Interference (MMI) Devices
11
Example of Optical Performance of MMI Device
12
1n MMI Optical Splitters
13
All-optical Logic Gate Based on MMI Waveguide
14
All-optical Logic Gate Based on MMI Waveguide
(Cont)
15
All-optical Logic Gate Based on MMI Waveguide
(Cont)
16
Photonic Crystals
17
Square-lattice and Triangular-lattice Photonic
Crystals
18
Band Structures of Photonic Crystals
Eg. The band structures of the 2D square-lattice
photonic crystal with the lattice constant is
a0.5µm. The radius of the pillar is Rc225nm.
And the refractive index of the pillar is
3.16227766.
19
Photonic Crystals Improving LED Efficiency

• Incorporating a photonic crystal into an
  indium-gallium-nitride (InGaN) LED increases both
  the internal quantum efficiency and the amount of
  light extracted. The light is produced in the
  quantum-well (QW) active region.

20
Photonic Crystals Improving LED Efficiency (Cont)
Far-field emission patterns from a conventional
(left) and a photonic-crystal LED (right) are
very different. The latter has a
strongly-modified emission pattern due to the
scattering of waveguided modes out of the LED
chip.
21
Photonic Crystal Waveguides (PCWGs)
22
Comparison between the Conventional Waveguides
and the PCWGs

• The conventional optical waveguides are weakly
  guided. There exist large power losses in the
  wide-angle bends/branches. However, the same
  structures made of line-defect photonic crystals
  give little losses because the lights were
  trapped by the defects of the photonic crystals.
• Most of the conventional optical waveguide
  devices can be easily modulated by EO effect, AO
  effect, and so on. But only a few photonic
  crystal waveguide devices can be modulated.

23
Periodical Dielectric Waveguides (PDWGs)
24
Electro-Optic (EO) Effect

• The electro-optic (EO) effect is a nonlinear
  optical effect that results in a refractive index
  that is a function of the applied electric field
  (voltage)
• Examples of Pockels effect Ammonium dihydrogen
  phosphate (ADP), Potassium dihydrogen phosphate
  (KDP), Lithium Niobate, Lithium Tantalate, etc.
• Examples of Kerr effect Most glasses, gases, and
  some crystals

Pockels effect
Kerr effect
25
Phase Modulators

• Phase shift
• , where Vp (the half-wave voltage) is the voltage
  applied to achieve a phase shift of p radians.

26
Mach-Zehnder Modulator to Modulate Amplitude of
Light
Output Intensity
Consider the case of f00. If VVp, then PoutPin
is the maximum, else if V0, then Pout0 is the
minimum.
27
Characteristics of Optical Modulators/Switches

• Extinction Ratio ?(I0-Im)/I0 if Im?I0 and
  ?(Im-I0)/Im if Im?I0, where Im is the optical
  intensity when the maximum signal is applied to
  the modulator and I0 is the optical intensity
  with no signal applied.
• Insertion Loss Li10log(It/Im), where It is the
  transmitted intensity with no modulator and Im is
  the transmitted intensity when the maximum signal
  is applied to the modulator.
• Bandwith ?f2p/T, where T is the switching time.

28
Optical Directional Coupler as a Channel Switch
29
A Complicated Optical Directional Coupler
30
3dB-Directional Coupler as a Beam Splitter

31
Coupled-Mode Equations to Analyze Directional
Coupler
32
Coupled-Mode Equations (Cont)

• The coupling length is Lcp/2?. Both Lc and ?
  depend on the refractive index distribution of
  guide.
• While the waveguiding mode traverses a distance
  of odd multiple of the coupling length (Lc, 3Lc,
  , etc), the optical power is completely
  transferred into the other waveguide. But it is
  back to the original waveguide after a distance
  of even multiple of the coupling lengths (2Lc,
  4Lc, , etc). If the waveguiding mode traverses a
  distance of odd multiple of the half coupling
  length (Lc/2, 3Lc/2, , etc), the optical power
  is equally distributed in the two guides.

33
Acousto-Optic (AO) Modulators
Bragg-type Width gtgt ?2/? Raman-Nath-type Width
ltlt ?2/? ? wavelength of light ? wavelength of
acoustic wave
Bragg-type AO modulator sin?B?/2?
Raman-Nath type AO modulator sin?mm?/2?, m
integer
34
Bragg-type AO Modulator as Spectrum Analyzer
Acousto-optic materials Visible and NIR Flint
glass, TeO2, fused quartz Infrared Ge High
frequency LiNbO3, GaP
Operations of Bragg-type AO modulator Bragg
diffraction effect Driving frequency 1MHz
1GHz Rise time 150 ns (1-mm diameter laser)
35
Direct Coupling from Laser/Fiber to Waveguide

• Direct Coupling Efficiency

where is the laser/fiber mode and
is the waveguide mode.
36
Coupling Efficiency from Laser/Fiber to Waveguide
37
Coupling Efficiency from Laser/Fiber to Waveguide
(Cont)
38
Coupling Efficiency from Laser/Fiber to Waveguide
(Cont)
39
Simulation Results Coupling Efficiency from
Laser/Fiber to Waveguide
For given waveguides fundamental mode, one can
obtained the optimal coupling efficiency by
selecting the values of w and c.
40
Typical Optical Disks
41
DVD Disks
42
Lasers in DVD Players
43
Optoelectronic Devices in DVD Players
44
Band Theory of Semiconductor Devices

• Metal The conduction band and the valence band
  may overlap.
• Semiconductor The bandgap between the conduction
  band and the valence band is very small. The
  electron can be easily excited into the
  conduction band to become a free electron.
• Insulator The bandgap between the conduction
  band and the valence band is very large. The
  electron is hardly excited into the conduction
  band to become a free electron.

45
Semiconductor
Fermi energy level, EF the highest energy level
which an electron can occupy the valance band at
0k
46
Bandgap Theory of Diode
47
Bandgap Theory of Tunnel Diode
48
Bandgap Theory of n-p-n Transistor
49

• Radiation from a Semiconductor Junction

50
Homojunction Laser Diode
51
Formation of Cavity in Laser Diode
52
Threshold Current
53
Heterostructure Laser Diodes
54
Stripe AlGaAs/GaAs/AlGaAs LD

• Advantages of stripe geometry
• 1. reduced contact area ? Ith?
• 2. reduced emission area, easier coupling
  to optical fibers
• Typical W a few µm, Ith tens of mA
• Poor lateral optical confinement of photons

55
Buried Double Heterostructure LD

• Good lateral optical confinement by lower
  refractive index material ?stimulated emission
  rate ?
• Active region confined to the waveguide defined
  by the refractive index variation ? index guided
  laser diode
• Buried DH with right dimensions compared with the
  ? of radiation ? only fundamental mode can exist?
  single mode laser diode
• DH AlGaAs/GaAs LD
• ? 900 nm LD
• DH InGaAsP/InP LD ? 1.3/1.55 µm LD

56
Output Modes of LD

• Output spectrum depends on
• 1. optical gain curve of the active medium

• 2. nature of the optical resonator
• L decides longitudinal mode separation. W H
  decides lateral mode separation
• With sufficiently small W H?only TEM00 lateral
  mode will exist ( longitudinal modes depends on L
  )
• Diffraction at the cavity ends ?laser beam
  divergence ( aperture ??diffraction ?)

57
Current Dependence of Power Spectrum in LD

• Output spectrum depends on
• 1. optical gain curve of the active
  medium, and
• 2. nature of the optical resonator
• Output spectrum from an index guided LD
• low current ?multimode
• high current ?single mode

58
Light Detectors

• Classification by spectral response
• wide spectral response
• narrow spectral response

• Principles of photodetection
• ? External photoelectric effect
• Eg. vacuum photodiode
• photomultiplier
• Internal photoelectric effect
• Eg. p-n junction photodiode
• PIN photodiode
• avalanche photodiode

59

• Characteristics of Light Detectors

60

• External Photoelectric Detector ? Vacuum
  Photodiode

61

• External Photoelectric Detector? Photomultiplier

62

• Internal Photoelectric Detector (Semiconductor
  Photodiode)

P-N photodiode
63

• PIN and Avalanche Photodiodes

Operating modes (1) photoconductive mode
(reverse biased) (2) Photovoltaic mode (forward
biased)
64
Typical Characteristics of Photodetectors
65

• Principle of OP Circuit for Photodiodes

66
Light Emitting Diode (LED)
Construction
Optical design
67
Choice of LED Materials
68
Typical Choice of Materials for LEDs
69
Radiative Transition Through Isoelectronic
Centers

• For indirect band-gap semiconductors?use
  recombination of bound excitons at isoelectronic
  centers to generate radiative recombination
• Isoelectronic center produced by replacing one
  host atom in the crystal with another kind of
  atom having the same number of valence electrons
• Isoelectronic center attract electron and hole
  pair ? exciton radiative recombination can occur
  without phonon assistance ? h?slightly smaller
  than bandgap energy Eg
• Common isoelectronic centers
• N in GaP ? 565 nm
• N in GaAs0.35P0.65 ? 632 nm
• N in GaAs0.15P0.85 ? 589 nm
• ZnO pair in GaP ( neutral molecular center ) ?
  700 nm

70
Choice of Substrates for Red and Yellow LEDs
71
Material System for High Brightness Red/Yellow
LEDs
72
Choice of Substrates for Blue LEDs

• Choices of light emitting material for blue LEDs
  ( before 1994 ) GaN system, ZnSe system, SiC,
  etc. And the winner is GaN

73
Earlier LED Structures
74
Basic Structures of High Brightness Visible LEDs
75
High Brightness Blue LEDs
76
Output spectra
Radiation pattern
Note response time 90ns (yellow
and red LED) 500ns (green LED)
