KOMPAS-3D V11

1
KOMPAS-3D V11
Key features overview
2
More than50 novelties
3
Software protection
4
Software protection system

• New version of software protection system - HASP
  SRM by Aladdin Knowledge Systems Ltd.
• Trial period during 30 days since the software
  has been started first time.
• Demo mode automatically switches on after trial
  mode finishing.

5
Public access
6
Add-Ons Novelties
7
Steel Structures 3D New Add-On!!!
8
Steel Structures 3D
Steel Structures 3D application, which is
intended for automation of design process of
metal constructions from metal rolling profiles.
The library is a perfect solution first of all
for using in the area of machine building and
designing of steel frameworks
9
Steel Structures 3D

• The frameworks can be set as trajectories
• straight-line segments of sketches,
• polyline segments,
• straight-line edges of solids.

10
Steel Structures 3D

• Template container contains a set of standard
  assortments
• Predefined set of profiles
• User defined profiles parameters

11
Steel Structures 3D

• Steel structure can be orientated by the
  following ways
• Changing the anchor point
• Mirroring
• Rotating
• Moving

12
Steel Structures 3D

• Various combination of Trim/Extend features
• Trim/Extend by plane,
• Angular splicing,
• Butt splicing,
• Trim by indent.

13
Steel Structures 3D

• Report command.
• Creates BOM lists on selected objects. The report
  can be saved as
• KOMPAS-Drawing (.cdw),
• KOMPAS-Fragment (.frw),
• KOMPAS-Table (.tbl),
• Open Office Spreadsheet (.ods),
• Microsoft Excel 97/2000/XP (.xls),
• Text document (.txt).
• Set Properties command.
• Allows changing object properties.

14
Standard Parts library New Add-On!!!
15
Standard part library

• Catalogues of fasteners according to DIN and ISO
  standards
• Bolts
• Nuts
• Pins
• Rivets
• Screws
• Split pins
• Washers

16
Standard part library
Various holes catalogues
17
Unwrap library New Add-On!!!
18
Unwrap library
The application is intended to automate the
design of dust, gas and air flues, pipelines and
similar parts of sheet material.
19
Unwrap library

• Various shapes can be unwrapped by the library

20
Pipelines 3D New improvements
21
Pipelines 3D

• Path from library
• Object Info
• Create pipe template

22
Pipelines 3D

• Joint segments
• Diagnostics

23
Pipelines 3D

• Set properties
• Report

24
Mathematical core improvements
25
Mathematical core

• Mathematical core of KOMPAS-3D is completely
  development of ASCON company.
• Mathematical core of KOMPAS-3D developed on ?
  in Microsoft Visual Studio

r1(u1,v1) p r cosu1ix r sinu1iy h v1iz 0
? u1 ? 2?, 0 ? v1 ? 1. r2(u2,v2) p u2ix
v2iy. r3(u3,v3) p u3ix v3iy h
iz. Parameters (u2, v2), (u3, v3) inside of
circle u2(t) u3(t) r cost, v2(t) v3(t)
r sint, 0?t?2?.
26
More faster

• Windows XP Pro SP2
• View creation faster 2-4 times.
• View update faster 2-4 times.

Punch AETZ Record, Russia 331 details
Machining center NIPTI Micron, Russia 4283 details
Barrel-type magnetic direct-flow separator OAO
Uchalinsky Ore Mining and Processing Enterprise
, Russia 1292 details
27
Accelerate 3D designing
Fast loading of an assembly Rotation 10 times
faster Adding new components 5-7 times faster
User type of loading
28
3D Curves

• Arc of Circle 3D
• Join Curves
• Round Curves
• Trim Curves
• Intersectional curve of surfaces
• Spline by Objects

29
Even easier learning
30
Easy learning
Easy-Learning with KOMPAS-ABC Built-in
interactive learning system
31
Easy learning
Start Learning of Drawing process with
KOMPAS-Graphic ABC
32
More intuitive Interface
33
Increase usability of designing

• Context toolbar
• Extended command toolbars
• Hide commands toolbar
• Pop-up Messages

34
High resolution supporting
Four sizes of icons are available
35
Accelerate 3D designing
36
New features for 3D modeling
37
3D Scaling
38
Multiportions in 3D
Select the portions to be saved
39
More flexible

• Assembly structure editing
• Merge in sub-assembly
• Explode Sub-assembly
• Copying and moving components

40
Local Coordinate System
41
Mechanical mates
Rotation rotation
Rotation move
Cam pusher
42
Enhanced Functionality
Tangent mate improving
43
Up to down design

• Bodies to part
• Part to assembly,
• Assembly to part
• Properties (MP, color, optical) for separate
  bodies

Project PLOTER FREZUJACY Author MICHAL PRECH,
Poland
44
Sheet metal functional Bend by sketch
45
Collaboration
46

• Collaboration

• Easy collaboration and integration
• All basics CAD formats supported
• Free data exchange with 3D Model Recognition
  System

2D user 3D user Text documentation, BOM
Import DXF, DWG, IGES, TIFF, GIF, JPEG, BMP, PNG, TGA IGES, SAT, Parasolid, STEP ASCII (DOS), ANSI (Windows) text file, RTF files, TIFF, GIF, JPEG, BMP, PNG, TGA
Export DXF, DWG, 2D IGES, e-drawing, TIFF, GIF, JPEG, BMP, PNG, TGA IGES, SAT, Parasolid, STEP, VRML, STL, e-drawing, TIFF, GIF, JPEG, BMP, PNG, TGA ASCII (DOS), ANSI (Windows) text file, RTF, DBF, Microsoft Excel, TIFF, GIF, JPEG, BMP, PNG, TGA
47
Improved collaboration

• Direct 3D-DWG models import
• Export to STL format
• Improved Import/Export SAT, STEP, IGES, XT,
  Parasolid

48
Drawings and 2D documents
49
Hyperlinks
50
Hyperlinks

• Links to variables

51
Enhanced Functionality
Multilanguage spell checking
52
Enhanced Functionality
Advanced Color and Transparency Management of
Fill
53
Thank you!
