Title: How Do I Get Into Phase 1 Trials With My Compound?
1How Do I Get Into Phase 1 Trials With My Compound?
Greg Ruppert Director, North American Sales May
9, 2013
2Preface and Disclaimer
- This presentation is in regard to nonclinical
animal studies provided to support an
investigational new drug (IND) application (21
CFR 312) for various scenarios and approaches.
There are a number of other aspects to the drug
development process that are not covered. - There isnt a one size fits all approach to
designing a nonclinical IND package. Rather,
nonclinical studies in support of an IND must be
tailored to the specific investigational agent
and the proposed clinical trials.
3Preface and Disclaimer
- FDA's guidance documents, including this
guidance, do not establish legally enforceable
responsibilities. Instead, guidances describe the
Agency's current thinking on a topic and should
be viewed only as recommendations, unless
specific regulatory or statutory requirements are
cited. The use of the word should in Agency
guidances means that something is suggested or
recommended, but not required. - Before submitting the application, the applicant
should submit a plan to the appropriate new drug
evaluation division identifying the types of
bridging studies that should be conducted. The
applicant should also identify those components
of its application for which it expects to rely
on FDAs finding of safety and effectiveness of a
previously approved drug product. The division
will critique the plan and provide guidance.
4What You Need To Do Before You Start Animal
Studies
- Species selection
- Metabolic profiles
- Pharmacology
- Vehicle
- Solution vs. suspension
- Concentration
- Methods
- Formulation
- Bioanalytical
- Immunological for biopharmaceuticals
- Clinical plan
5How Many Approaches To An IND Standard
Approach
- NCE Small Molecule or Traditional Approach
- DRF and repeat toxicology in rodents nonrodent
with TK - Dosing regimen
- Recovery?
- Genotoxicity battery
- Ames
- Mammalian Cell Mutation (Chromosomal Aberration)
- in vivo Micronucleus (optional)
- Safety Pharmacology battery
- CV nonrodent
- in vitro hERG
- CNS rodent
- Respiratory rodent
- In general, the differences from this standard
approach is presented for the following IND
approaches.
6How Many Approaches To An IND Biopharmaceuticals
- What is a biopharmaceutical?
- Product derived from characterized cells
(bacteria, yeast, insect, plant, mammalian). - Includes growth factors, recombinant proteins,
antibodies, endogenous proteins, enzymes etc. - Does not include antibiotics, heparin, vitamins,
vaccines, cellular and gene therapy etc. - Oligonucleotides
7How Many Approaches To An IND Biopharmaceuticals
- Species selection Needs to be the most relevant
- Sequence homology
- Cell based assays for binding affinities
- Functional activity - in vivo or in vitro
- If no orthologous target consider homologous
molecules, transgenic animals or animal models of
disease. - Monoclonal antibodies directed against foreign
targets
8How Many Approaches To An IND Biopharmaceuticals
- How many species?
- If pharmacologically active in two species, then
2 are needed for initial studies. - Single species based on well understood
pharmacology. - For novel antibody-drug conjugates (ADC) two
species are recommended - Dose selection
- High dose should be the highest of
- Maximum pharmacological effect.
- Up to 10-fold exposure over expected clinical
levels. - .
9How Many Approaches To An IND Biopharmaceuticals
- Immunogenicity
- Assessment of anti-drug antibodies (ADAs) not
needed if evidence of sustained pharmacology, no
unexpected changes is PK/TK, no evidence of
immune-mediated reactions. - Take blood samples for analysis of ADAs, analyze
if needed. - If ADAs detected characterize impact on
exposure, pharmacology, toxicity. - Neutralizing antibody assays generally not
needed if there is adequate understanding of
PK/PD relationship.
10How Many Approaches To An IND Biopharmaceuticals
- Differences in nonclinical approach for IND
- Species selection
- Pharmacology not metabolism
- Number of species
- One or two
- Safety pharmacology
- Separate or incorporated
- Genetic toxicology
- Not needed except for special situations
- Toxicology
- Dose selection
11How Many Approaches To An IND Vaccines
- Single species - generally rabbit
- Single dose toxicity
- Adjuvant toxicity study if novel adjuvant is
used - Repeat dose toxicity
- Include local tolerance and evaluation of
immunogenicity in repeat-dose study - Biodistribution and Integration study may be
required - Safety Pharmacology and genotoxicity battery
generally not required
12How Many Approaches To An IND Oncology
- Cancer advanced vs. palliative care
- The investigation does not significantly
increases the risks (or decreases the
acceptability of the risks) associated with the
use of the drug product. - Pharmacology (mechanism of action, resistance,
schedule dependencies, and anti-tumor activity). - Safety Pharmacology battery generally included in
general toxicology studies. - Reversibility (in at least one of the repeat-dose
studies). - Genotoxicity battery generally not required.
13How Many Approaches To An IND Animal
Rule
- Compounds where conducting a clinical trial in
humans is not feasible radiation sickness,
neurotoxic gas exposure - For an IND a standard approach is used along with
a Phase 1 in humans, but the clinical trials for
efficacy are carried out in animals not humans.
14How Many Approaches To An IND Excipients
- Excipients- anything other than GRAS requires
additional work - Studies required will vary from no additional
work required (GRAS) to conducting all studies in
the Traditional Approach (Novel). - Use in previously approved products or GRAS
status? - Indication - lifesaving therapies vs. low
morbidity indications. - Novel - adequate prior human exposure has not
been documented. - The sponsor is encouraged to contact the
appropriate review division to receive specific
guidance when necessary.
15How Many Approaches To An IND
Reformulated/Repurposed Drugs
- 505(b)(2)
- Bridging studies may substitute Safety
Pharmacology battery and General Toxicology
studies if they are found to provide an adequate
basis for reliance upon FDAs finding of safety
and effectiveness. - Particular toxicities associated with the new
route of administration should be
considered/evaluated. - May require additional nonclinical work based on
the composition of the formulation and known
toxicities. - May be required in two species (ocular,
intrathecal, or epidural) or one species (all
other routes). - Additional nonclinical work may be required
depending on the alternate route being utilized
(i.e. hypersensitivity and phototox for dermal,
blood compatibility for IV, etc.).
16How Many Approaches To An IND Biosimilar
- Generic form of a biopharmaceutical.
- Not as straightforward as for small molecules
where you synthesize the exact same structure. - For biopharmaceuticals, the process by which they
are created does not lend itself to duplication
many processes are proprietary. - Need to establish the biosimilar is equivalent to
the innovator compound.
17How Many Approaches To An IND Biosimilar
- Proving equivalency.
- First step is characterizing the product for
structure and activity, typically done in vitro. - Guidance documents
- Nothing much from the FDA yet.
- Guidance form Canada, WHO, as well as multiple
documents from EMEA. - Could involve animal studies prior to IND.
- Typically single species.
- Goal is comparison of biosimilar to innovator
are there any differences in the tox profile?
18How Many Approaches To An IND Exploratory IND
- Obtain human data on exposure and distribution,
no efficacy or safety. - Should only be considered when planning limited,
early exploratory IND studies in man. - Early Phase I studies, limited human exposure, no
therapeutic or diagnostic intent. - Conducted prior to the traditional dose
escalation, safety, and tolerance studies
generally conducted in Phase I trials. - Generally are used to determine if MOA can be
achieved in man, provide PK information in man,
select most promising lead, and/or explore
biodistribution characteristics.
19How Many Approaches To An IND Exploratory IND
- Reduced scope of the Exploratory IND results in
reduced nonclinical need - Expanded acute toxicology studies may suffice if
supporting a microdose study (less than 1/100th
of the dose that produces pharmacologic effect). - Single species may be used if supported by in
vitro metabolism and in vivo PD effects. - Safety Pharmacology and genotoxicity battery
generally not required.
20How Many Approaches To An IND Exploratory IND
- 14-Day Repeat-Dose toxicology studies may suffice
if supporting a study designed to evaluate
pharmacologic effect of up to 14 days. - Two species with standard designs.
- Dose selection based on anticipated clinical
exposures. - Safety Pharmacology evaluations can be evaluated
in the toxicology studies. - Genotoxocity limited to Ames assay in specific
scenarios
21How Many Approaches To An IND Imaging Agents
- FDA encourages meeting due to uniqueness of each
agent - Biological products should be evaluated similar
to biopharmaceuticals described previously - Generally single lifetime exposure, or only a few
exposures used to diagnose or monitor diseases or
conditions, therefore results in reduced
nonclinical need. - Need to consider dose (e.g. mass dose), route,
frequency of exposure, and kinetics. - Studies should be conducted to evaluate effects
of a large mass dose (or maximum feasible dose). - NOAEL in acute toxicology and safety pharmacology
studies should be at least 100X and NOAEL in
repeat-dose toxicology be at least 25X the
maximal mass dose in man.
22How Many Approaches To An IND Botanical Products
- Definition - products that contain vegetable
matter as ingredients, may be a food (including
dietary supplement), drug (including
biopharmaceuticals), device, or cosmetic. - For the guidance, botanical includes plant
materials, algae, macroscopic fungi and
combinations thereof does not include materials
from genetically engineered species, fermentation
products (even if already approved for other uses
in US), or highly purified/chemically modified
substances derived from botanical substances. - Unique situation in that many of the products in
development have been taken/sold for many years
with no nonclinical support.
23How Many Approaches To An IND Botanical Products
- Nonclinical approach
- If legally available already and there are no
known safety issues (serious or life
threatening), additional toxicology may not be
needed. - If contains multiple components from different
plant, algae, or fungal species it would be
subject to the requirements of a combination drug
product, although this may be changing. - For compounds marketed outside the US, dependent
on route of administration - For compounds that have never been marketed such
as traditional herbal medicines dependent on
preparation and dosing
24How Many Approaches To An IND Drug
Combinations
- Combinations 3 scenarios
- New new- Nonclinical combination studies
recommended. - Marketed new
- If no cause of concern, additional nonclinical
studies generally not required to support POC
studies up to 1 month. - Marketed marketed
- If clinical experience with co-administration
available, additional nonclinical studies
generally not required unless there is a
significant toxicological concern. - If no clinical experience with co-administration
available, but no cause of concern based on
available data, nonclinical studies generally not
required to support short duration clinical
trials (up to 3 months), however are recommended
for longer durations.
25How Many Approaches To An IND Drug
Combinations
- Nonclinical development programs should be
conducted on the individual entities. - Duration of combination studies should be
equivalent to duration of clinical trial (not to
exceed 90 days) and take into account the
characteristics of the combination. - Should be limited to single relevant species,
unless unexpected toxicity is identified. - If complete nonclinical development programs are
not available for the individual entities, a
complete program with the combination will
suffice as long as the individual agents are only
planned to be used in combination. - Combination Safety Pharmacology and genotoxicity
battery generally not recommended.
26How Many Approaches To An IND Juvenile
Indications
- If starting in humans and expanding into
juveniles - Review of the data from standard toxicology
studies to determine if additional studies are
needed - If Juvenile is the target population
- Design of juvenile animal toxicology studies
- Consider intended use in children, timing of
dosing relative to growth and development phases
in intended population, differences in
pharmacological and toxicological profiles
between mature and immature systems. - Should be designed to evaluate effects on organ
systems that develop postnatally ( nervous,
reproductive, pulmonary, renal, skeletal, and
immune) and measurements of growth.
27How Many Approaches To An IND Cellular and
Gene Therapies
- Design of nonclinical study package should take
into consideration the population of cells to be
administered or the class of vector the animal
species and physiologic state most relevant for
clinical indication and product class and the
intended doses, route of administration, and
treatment regimens. - Follow same rules as for biopharmaceuticals.
- Species specificity, permissiveness for infection
by viral vectors, comparative physiology, etc.
should be considered in study design. - Single species (most appropriate,
pharmacologically relevant) should be employed. - Other non-standard endpoints may be required
such as cell fate, functional, product-dependent,
or disease-dependent endpoints. - Generally difference lies in stricter
manufacturing regulations and controls.
28Which Path Do I Take
- Depends on test article type, indication, route,
clinical plan - Review the guidelines (FDA/EMEA/ICH)
- Pre-IND Meeting
- Propose what makes scientific sense, along with
the data to support your approach - Ask if the Agency agrees with this approach
29Where Do I Go To Get The Work Done
- What to look for in a CRO
- Inspections how often, any 483s, if so what
were they for (not all 483s indicate issues) - Experience SD and technical
- Capacity are they overbooked
- Historical data needed to discern background
from test article-related - Communication if they are hard to contact
during proposal process, will that carry through
to the study - Reporting history can they follow through on
commitments - What the CRO needs from you
- Test article
- Understanding of project scope
- Communication
30Where Do I Go To Get The Work Done (Continued)
- Common issues that arise
- No material available, insufficient material
available - Protocol approval
- Veterinary intervention
- Communication
- Background information on compound and possible
toxicities
31Summary
- How do I get an IND for my compound depends on
- Indication
- Compound class
- Clinical plan
- Numerous guidance documents to help
- Hire a consultant as needed
- Work with your CRO as appropriate
- Take advantage of a pre-IND meeting with the
Agency
32Horizontal Bar Chart
Study Traditional Biopharmaceuticals Vaccines Cancer
Single dose/DRF Yes Yes (1 or 2 species) Yes (1 species) Yes
Repeat dose Yes Yes (1 or 2 species) Yes (1 species) Yes
Genotoxicity Yes No No No
Safety Pharmacology Yes Yes in Tox studies No Yes in Tox studies
Study Animal Rule Excipients Reformulated or Repurposed Biosimilar
Single dose/DRF Yes Yes or No Yes or No Yes (1 species)
Repeat dose Yes Yes or No Yes or No Yes (1 species)
Genotoxicity Yesa Yes or No Yes or No No
Safety Pharmacology Yesa Yes or No Yes or No No
a - dependent on type of test article
33Horizontal Bar Chart
Study Exploratory Imaging Agents Botanicals Combinations b
Single dose/DRF Yes Yes Yes or No Yes or No
Repeat dose Yes or No Yes Yes or No Yes or No
Genotoxicity No Yes Yes or No No
Safety Pharmacology Yes in Tox studies Yes Yes or No No
b May or may not be needed on the combination.
Traditional studies should be completed on
individual entities.
Study Juvenile c Orphan Cellular and Gene Therapeutics
Single dose/DRF Yes or No Yes Yes (1 or 2 species)
Repeat dose Yes or No Yes Yes (1 or 2 species)
Genotoxicity Yes or No Yes No
Safety Pharmacology Yes or No Yes Yes in Tox studies
c May or may not be needed in the juvenile
animal. Traditional studies should be
completed in the adult animals.
34The FDA And Their Divisions
- Center for Drug Evaluation and Research (CDER)
- Conventional synthetic chemicals
- Antibiotics, natural and recombinant hormones
- Novel drugs such as antisense oligonucleotides
and synthetic peptides (lt 40 AA)
35The FDA And Their Divisions
- Center for Biologic Evaluation and Research
(CBER) - Blood and blood products
- Vaccines and allergenics
- Conventional biotechnology-derived products
- Recombinant proteins, monoclonal antibodies,
antigenic peptides - Novel biotechnology-derived products
- Center for Devices and Radiological Health (CDRH)
- Center for Veterinary Medicine (CVM)
36Guidelines
- ICH
- Q3A (R2) Impurities in New Drug Substances
- Q3B (R2) Impurities in New Drug Products
- Q3C (R4) Impurities Guidelines for Residual
Solvents - S1A Need for Carcinogenicity Studies for
Pharmaceuticals - S1B Testing for Carcinogenicity of
Pharmaceuticals - S1C (R2) Dose Selection for Carcinogenicity
Studies of Pharmaceuticals - S2 (R1) Guidance on Genotoxicity Testing and Data
Interpretation for Pharmaceuticals Intended for
Human Use - S3A Note for Guidance on Toxicokinetics The
Assessment of Systemic Exposure in Toxicity
Studies - S3B Pharmacokinetics Guidance for Repeat Dose
Tissue Distribution Studies
37Guidelines
- ICH (Continued)
- S4 Duration of Chronic Toxicity Testing in
Animals (Rodent and Nonrodent Toxicity
Testing) - S5 (R2) Detection of Toxicity to Reproduction for
medicinal Products Toxicity to Male Fertility
- S6 (R1) Preclinical Safety Evaluation of
Biotechnology-Derived Pharmaceuticals - S7A Safety Pharmacology Studies for Human
Pharmaceuticals - S7B The Non-Clinical Evaluation of the Potential
for Delayed Ventricular Depolarization (QT
interval prolongation) by Human
Pharmaceuticals - S8 Immunotoxicology Studies for Human
Pharmaceuticals - S9 Nonclinical Evaluation of Anticancer
Pharmaceuticals - S10 Photosafety Evaluation
- M3 (R2) Guidance on Nonclinical Safety Studies
for the Conduct of Human Clinical Trials and
Marketing Authorization for Pharmaceuticals
38Guidelines
- EMEA
- 3BS11A Pharmacokinetics and metabolic studies
in the safety evaluation of new medicinal
products in animals - CHMP/SWP/302413/08 Need for revision of the
guideline single dose toxicity (3BS1A) - CHMP/SWP/488313/07 Repeated dose toxicity
- CPMP/SWP/1042/99 Repeated dose toxicity
- CPMP/SWP/5199/02 Limits of genotoxic impurities
- CHMP/QWP/251344/2006
- CHMP/SWP/199726/04 Reflection Paper on the
assessment of the Genotoxic Potential of
Antisense Oligodeoxynucleotides - EMEA/194898/2006 Carcinogenicity Evaluation of
Medicinal Products for the Treatment of HIV
Infection - CPMP/SWP/2592/02 Rev 1 CHMP SWP Conclusions and
recommendations on the use of genetically
modified animal models for carcinogenicity
assessment
39Guidelines
- EMEA (Continued)
- CPMP/SWP/2877 /00 Carcinogenic potential
- CPMP/SWP/372/01 Points to consider on the
Non-clinical assessment of the carcinogenic
potential of human insulin analogues - EMEA/CHMP/203927/05 Risk Assessment of Medicinal
Products on Human Reproduction and Lactation
From Data to Labeling - CHMP/SWP/169215/05 Need for Non-Clinical Testing
in Juvenile Animals on Human Pharmaceuticals
for Pediatric Indications - CPMP/SWP/2600/01 Points to consider on the Need
for assessment of reproduction toxicity of
human insulin analogues - CPMP/SWP/2145/00 Non-clinical local tolerance
testing of medicinal products - CHMP/SWP/150115/06 Non-clinical guideline on
drug-induced hepatotoxicity
40Guidelines
- EMEA (Continued)
- CHMP/SWP/94227/04 Non-Clinical Investigation of
the Dependence Potential of Medicinal
Products - CPMP/SWP/398/01 Need for revision of the Note
for Guidance on photosafety testing - CPMP/SWP/728/95 Replacement of animal studies by
in vitro models - CHMP/SWP/28367/07 Strategies to identify and
mitigate risks for first- in-human clinical
trials with investigational medicinal
products - CHMP/GTWP/125459/2006 Non-clinical studies
required before first clinical use of gene
therapy medicinal products - EMEA/CHMP/SWP/91850/06 Development of a CHMP
Guideline on the Non- Clinical Requirements to
Support Early Phase I Clinical Trials with
Pharmaceutical Compounds - EMEA/CHMP/94526/05 Annex Guideline on Similar
Biological Medicinal Products containing
Biotechnology-Derived Proteins as Active
Substance Non-Clinical and Clinical Issues -
Guidance on Similar Medicinal Products
containing Recombinant Erythropoietins
41Guidelines
- EMEA (Continued)
- EMEA/273974/05 Quality, Preclinical and Clinical
aspects of Gene Transfer Medicinal Products -
Annex on Non- Clinical testing for Inadvertent
Germline transmission of Gene Transfer
Vectors - CPMP/SWP/799/95 Non-Clinical Documentation for
Mixed Marketing Authorization Applications - CHMP/SWP/258498/05 Non-Clinical Development of
Fixed Combinations of Medicinal Products - CPMP/SWP/1094/04 Evaluation of Control Samples
for Non - clinical Safety Studies Checking
for Contamination with the Test Substance - CPMP/SWP/2599/02 Position Paper on the
non-clinical safety studies to support
clinical trials with a single micro dose - CPMP /3097/02 Comparability of medicinal
products containing biotechnology-derived
proteins as active substance -annex on
non-clinical and clinical issues
42Guidelines
- EMEA (Continued)
- CPMP/SWP/997/96 Pre-clinical evaluation of anti-
cancer medicinal products - CPMP/SWP/465/95 Pre-clinical pharmacological and
toxicological testing of vaccines - EMEA/HMPC/107079/07 Assessment of genotoxicity of
herbal substances/preparations - EMEA/HMPC/32116/05 Non-Clinical Documentation
for Herbal Medicinal Products in Applications
for Marketing Authorization (Bibliographical
and Mixed Applications) and in Applications
for Simplified Registration
43Guidelines
- CDER
- Animal Models - Essential elements to Address
Efficacy under the Animal Rule - Developing Medical Imaging Drugs and Biological
Products - Part 1 Conducting Safety Assessments - Estimating the Maximum Safe Starting Dose in
Initial Clinical Trials for Therapeutics in Adult
Healthy Volunteers - Genotoxic and Carcinogenic Impurities in Drug
Substances and Products Recommended Approaches - Immunotoxicology Evaluation of Investigational
New Drugs - Nonclinical Evaluation of Late Radiation Toxicity
of Therapeutic Radiopharmaceuticals - Nonclinical Safety Evaluation of Drug or Biologic
Combinations - Nonclinical Safety Evaluation of Reformulated
Drug Products and Products Intended for
Administration by an Alternate Route - Nonclinical Safety Evaluation of Pediatric Drug
Products
44Guidelines
- CDER (Continued)
- Nonclinical Studies for the Safety Evaluation of
Pharmaceutical Excipients - Photosafety Testing
- Recommended Approaches to Integration of Genetic
Toxicology Study Results - Reference Guide for the Nonclinical Toxicity
Studies of Antiviral Drugs Indicated for the
Treatment of N/A Non-Life Threatening Disease
Evaluation of Drug Toxicity Prior to Phase I
Clinical Studies - Safety Testing of Drug Metabolites
- Single Dose Acute Toxicity Testing for
Pharmaceuticals - Statistical Aspects of the Design, Analysis, and
Interpretation of Chronic Rodent Carcinogenicity
Studies of Pharmaceuticals - Content and Format of Investigational New Drug
Applications (INDs) for Phase 1 Studies of Drugs - Exploratory IND Studies
- Codevelopment of Two or More Unmarketed
Investigational Drugs for Use in Combination - Applications covered by Section 505(b)(2)
