The Planck Satellite Mission

1
The Planck Satellite Mission

• Pekka Heinämäki
• Tuorla Observatory,Finland

Tartu Workshop August, 15-19, 2005
2
PlanckThe Cosmic Background Anisotropy Mission

• Planck is a space observatory designed to image
  the temperature anisotopies of the CMB over the
  whole sky, with unprecedented sensitivity DT/T2
  x 10-6 and angular resolution lt 10
• ? allow the determination of fundamental
  cosmological parameters with a few percent
  uncertainty
• - Mapping of Cosmic Microwave Background
  anisotropies with improved sensitivity and
  angular resolution
• - Testing inflationary models of the early
  universe
• - Measuring amplitude of structures in Cosmic
  Microwave Background

3
Mission Overview

• Very wide frequency coverage
• Extreme attention to suppression of systematic
  effects

4
Mission Overview

• 1.5 m aperture Gregorian telescope with carbon
  fibry technology (Danish Consortium)
• Field of view offset by 85 degrees from
  spin-axies maitaind in antisun direction to cover
  full sky in half year

5

• Guiana Space Centre, Kourou, French Guiana, in
  July 2007 by an Ariane-5 launcher.
• together with ESA's Herschel spacecraft.
• After a journey lasting between four and six
  months, Planck will make a major manoeuvre to
  enter its operational orbit, a small Lissajous
  orbit around L2, 1.5 million kilometres away from
  the Earth.

6

• The two vehicles will separate shortly after
  launch and proceed independently to different
  orbits about the second Lagrange point of the
  Earth-Sun system (L2).

7
Herschel (FIRST)

• It will performe imaging photometry and
  spectroscopy in the far-Infrared and
  Submillimetre part of the spectra
• HIFI (high resolution spectrographs), PACS
  (Photoconductor Array Camera and Specrometer),
  SPIRE (Spectral and Photometric Imaging Receiver)
• ? will cover the 60 670 micron waveband
• Formation and evolution of galaxies and stars,
  ISM physics and chemistry, solar system bodies

8
Worlds largest space mirror polished at Tuorla
The mirror will be unique in many ways. When the
mission is launched in 2007, it will be the
largest ever sent to space. It will be the first
SiC mirror used in a telescope, and of course
the first to be used in space as well. It will be
the first mirror polished to operate at both
short radio wavelengths and long infra-red
wavelengths. Herschel will be the first entirely
European space telescope.
9
The High Frequency Instrument or HFI

• 48 bolometers sensitive to 100-850 GHz (split
  into 6 channels)
• Actively cooled to 0.1K
• Best angular resolution 5 and temperature
  sensitivity 5 microK

10
The High Frequency Instrument The High Frequency
Instrument (HFI) is an array of 48 bolometric
detectors which will be placed in the focal
plane of the Planck telescope, and will image the
sky in six frequency channels between 100 and
857 GHz. The HFI is being designed and built by a
Consortium of scientists led by Jean-Loup Puget
(PI) of the Institut d'Astrophysique Spatiale in
Orsay (France), and Francois Bouchet (Deputy PI)
of the Institut d'Astrophysique de Paris. The
other main institutes involved in the HFI
Consortium are California Institute of
Technology, in Pasadena (USA) Canadian Institute
for Theoretical Astrophysics, in Toronto (Canada)
Cardiff University, in Cardiff (UK) Centre
d'Etudes Spatiales des Rayonnements, in Toulouse
(F) Centre de Recherche sur les tres Basses
Temperatures, in Grenoble (F) College de France,
in Paris (F) Commissariat a l'Energie Atomique,
in Gif-sur-Yvette (F) Danish Space Research
Institute, in Copenhagen (DK) Imperial College,
in London (UK) Institut d'Astrophysique de
Paris, in Paris (F) Institut des Sciences
Nucleaires, in Grenoble (F) Institute of
Astronomy, in Cambridge (UK) - Planck page
Jet Propulsion Laboratory, in Pasadena (USA)
Laboratoire de l'Accelerateur Lineaire, in Orsay
(F) Laboratoire d'Etude du Rayonnement et de la
Matiere en Astrophysique, in Paris, (F)
Max-Planck-Institut fuer Astrophysik, in
Garching (D) - Planck Page Mullard Radio
Astronomy Observatory, in Cambridge (UK)
National University of Ireland, in Maynooth (IR)
Rutherford Appleton Laboratory, in Chilton (UK)
Space Science Dpt of ESA, in Noordwijk (NL)
Stanford University, in Stanford (USA)
Universite de Geneve , in Geneva (CH)
Universidad de Granada, in Granada (E)
University La Sapienza, in Rome (I)
11
The Low Frequency Instrument or LFI

• Consists of four arrays of 56 HEMT-based radio
  receivers, between 30 and 100 GHz
• Operated at 20K
• Best angular resolution 10 and temperature
  sensitivity 12 microK

12
The Low Frequency Instrument The Low Frequency
Instrument (LFI) is an array of 56 tuned radio
receivers which will be placed in the focal plane
of the Planck telescope, and will image the sky
in three frequency channels between 30 and 70
GHz. The LFI will be designed and built by a
Consortium of scientists led by Reno Mandolesi of
the Istituto Fisica Spaziale e Fisica Cosmica
(IASF) in Bologna (Italy) - Planck Page. The
other main institutes involved in the LFI
Consortium are Chalmers University of
Technology, in Goteborg (S) Danish Space
Research Institute , in Copenhagen (DK) - Planck
Page Instituto de Astrofisica de Canarias, in
La Laguna (E) Instituto de Fisica de Cantabria,
in Santander (E) Istituto CAISMI, in Firenze (I)
Istituto IASF (CNR), in Milano (I) Istituto di
Fisica del Plasma IFP (CNR), in Milano (I)
Istituto IFSI, in Roma (I) Jet Propulsion
Laboratory , in Pasadena (USA) Max-Planck-Institu
t fuer Astrophysik , in Garching (D) - Planck
Page Millimetre Wave Laboratory, in Espoo (FI)
Jodrell Bank Observatory, in Macclesfield (UK)
Osservatorio Astronomico di Padova, in Padova
(I) Osservatorio Astronomico di Trieste, in
Trieste (I) - LFI's DPC home page SISSA, in
Trieste (I) Space Science Dpt of ESA , in
Noordwijk (NL) Theoretical Astrophysics Center,
in Copenhagen (DK) University of California
(Berkeley), in Berkeley (USA) University of
California (Santa Barbara), in Santa Barbara
(USA) Universite de Geneve, in Geneva (CH)
University of Oslo, in Oslo (N) Universita Tor
Vergata, in Roma (I)
13
Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals Estimated Planck Instrument Performance Goals


Instrument LFI LFI LFI HFI HFI HFI HFI HFI HFI HFI HFI HFI HFI HFI
Center Frequency (GHz) 30 44 70 100 100 143 143 217 217 353 353 545 545 857
Detector Technology HEMT radio receiver arrays HEMT radio receiver arrays HEMT radio receiver arrays Bolometer arrays Bolometer arrays Bolometer arrays Bolometer arrays Bolometer arrays Bolometer arrays Bolometer arrays Bolometer arrays Bolometer arrays Bolometer arrays Bolometer arrays
Detector Temperature 20 K 20 K 20 K 0.1 K 0.1 K 0.1 K 0.1 K 0.1 K 0.1 K 0.1 K 0.1 K 0.1 K 0.1 K 0.1 K
Cooling Requirements H2 sorption cooler H2 sorption cooler H2 sorption cooler H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution H2 sorption 4K J-T stage Dilution
Number of Unpolarised Detectors 0 0 0 0 4 4 4 4 4 4 4 4 4 4
Number of Linearly Polarised Detectors 4 6 12 8 8 8 8 8 8 8 0 0 0 0
Angular Resolution (arcmin) 33 24 14 9.5 7.1 7.1 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
Bandwidth (GHz) 6 8.8 14 33 47 47 72 72 116 116 180 180 283 283
Average DT/T per pixel 2.0 2.7 4.7 2.5 2.2 2.2 4.8 4.8 14.7 14.7 147 147 6700 6700
Average DT/T per pixel 2.8 3.9 6.7 4.0 4.2 4.2 9.8 9.8 29.8 29.8
Sensitivity (1 ) to intensity (Stokes I)
fluctuations observed on the sky, in
thermodynamic (x10-6) temperature units, relative
to the average temperature of the CMB (2.73 K),
achievable after two sky surveys (14 months).
14

• ?Maximize the ability to discriminate between
  different cosmologial models, substract
  foregrounds minimize the susceptibility to
  systematic errors pointing strategy, frequency
  coveragy

? Instrument noise
etc. TOD ? HEALPIX also "electric" and
"magnetic" parts of the the polarization field ?
To remove contaminating foreground signals
Secondary anisotropies! Show how much T
varies from to point to point on the sky ?Values
of cosmological parameters can be determined by
comparing model and observed temperature power
spectra
http//space.mit.edu/home/tegmark/cmb/pipeline.htm
l
15
A simulation of the CMB anisotropies at an
angular resolution and sensitivity level typical
of what can be achieved by Planck.
16
German Astrophysical Virtual Observatory

• The Planck Simulator
• The Planck Simulator provides synthetic sky maps
  of the Cosmic Microwave Background. The Planck
  Simulator allows to enter a variety of parameters
  which describe the assumed cosmology and allows
  to include a number of foreground emission
  processes. A detailed description of the
  available options can be found here.

http//www.g-vo.org/portal/tile/products/services/
planck/index.jsp
17

• WOMBAT is dedicated to understanding sources of
  microwave foreground emission and providing the
  cosmology community with estimates of foreground
  emission as well as uncertainties in those
  estimates. http//astron.berkeley.edu/wombat/

18

• Analysis Packages
• HEALPix
• SpICE
• MADCAP Microwave Anisotropy Dataset Computational
  Analysis Package
• CMBFit CMBfit is a software package for
  ultra-fast calculation of likelihoods from the
  Wilkinson Microwave Anisotropy Probe (WMAP) data
• GLESP Gauss-Legendre Sky Pixelization for CMB
  analysis
• C(l) Computation
• CMBFAST The CMBfast software can be used
  for the computation of the theoretical spectra of
  CMB anisotropy. The HEALPix synfast program reads
  in the output of this routine to allow one to
  generate random realisations of the observable
  CMB sky.
• CAMB Code for Anisotropies in the Microwave
  Background
• CMBEASY CMBEASY is a software package for
  calculating the evolution of density fluctuations
  in the universe
• DASh CMBEASY is a software package for
  calculating the evolution of density fluctuations
  in the universe

Hierarchical Equal Area isoLatitude Pixelisation
of the sphere
19
Characterizing the microwave background sky

• Cosmological information is encoded in the
  statistical properties of the maps, hot and cold
  spots
• To find out how much anisotropy is there on
  different spatial scales -gt a map of temperature
  fluctuations on a sphere conventionally described
  in terms of spherical harmonics.
• IF fluctuations in the early Universe obey
  Gaussian statistics, as expected in most theories
  each of the coefficients alm is independent and
  so the power spectrum provides a complete
  statistical description of the temperature
  anisotropies

20

• The shape of the angular power spectrum is very
  sensitively dependent on fundamental
  cosmological parameters
• First peak (position) shows the universe is close
  to spatially flat total energy density
• First peak (hight) depends upon the matter and
  baryon density (both depend on the Hubble
  constant)
• Constraints on the second peak indicate
  substantial amounts of dark baryons
• Third peak will measure the physical density of
  the dark matter
• Damping tail will provide consistency checks of
  underlying assumptions
• curvature of the universe the position of the
  peaks
• Ilt100 plateau indicate Scale-invariant density
  fluctuations, tilting the primordial power
  spectrum raising the right side relative to the
  left side

(taken from W. Hu's web page)
21

• Temperature (TT) results are consistent with
  ACBAR and CBI measurments
• Cross-power spectrum (TE) ? adiapatic initial
  conditions, isocurvature models predict a dominat
  peak at l 330 and subdominant peak at l 110.
• Defect models do not have multiple acoustic peaks
  ? no vector component

22

• And
• Wb consistent with abundance measurments
• Wm clusters dark matter estimates
• WD supernova data
• H0 HST Cepheid measurments
• Concordance model (built up last few years using
  many different data sets)
• Inflation predicts Universe is flat ? requires
  cosmological constant
• Inflation predicts Gaussian fluctuations and
  scale-invariant scalar
• spectral index n_s1
• Baryon density and dark matter densities, Hubble
  constant are defined with 5
• accurarcy
• BUT t/n_s degeneracy !

23
?Precision cosmology

• Planck has the ability
• Detect much smaller temperature variations
  (about ten times WMAP) in the CMB than previous
  missions
• Perform CMB measurements with a higher
  angular resolution than ever before (about twice
  better than WMAP)
• Measure over a wider band of frequencies to
  enhance the separation of the CMB from
  interfering foreground signals
• (ifrequency coverage about ten times larger
  than WMAP)

(taken from W. Hu's web page)
24
Hu's web page

• The main difference between Planck and MAP lies
  in the quality of the CMB data taken, and
  therefore, in the accuracy with which the
  cosmological parameters can be determined
  polarization properties

25
Polarization

• Thomson scattering of temperature anisotropies on
  the last scattering surface generates a linear
  polarization pattern on the sky. Polarisation
  pattern can be separated into electric' (E) and
  magnetic' (B) components.
• USEFUL BECAUSE
• As polarization is generated only at last
  scattering, it probes last scattering in a more
  direct way than anisotropies alone
• Observations of polarization provide an important
  tool for reconstructing the model of the
  fluctuations from the observed power spectrum ?
  breaking the degeneracy between certain parameter
  combinations
• Different sources of temperature anisotropies
  (scalar, vector and tensor) give different
  patterns in the polarization both in its
  intrinsic structure and in its correlation with
  the temperature fluctuations themselves.
• Polarization power spectrum provides information
  complementary to the temperature power spectrum.
  This can be of use in breaking parameter
  degeneracies and thus constraining cosmological
  parameters more accurately.
• Timing of reionization

26
Reionization

• The absence of a Lyman alpha abrorbtion
  trought in the spectra of high redshift quasars z
  gt 6 shows that the intergalactic medium must have
  been reionoized
• BUTThe re-ionization could not have been
  earlier than z 30, or there would be a
  suppression of the first Doppler peak in the
  angular fluctuation spectrum of the Cosmic
  Microwave Background (Tegmark Zaldarriaga 2000
  De Bernardis et al. 2000).
• WMAP led to the estimate tau 0.17-0.04.
  WMAP accuracy is not enough for discrimination
  between models (Naselsky, Chiang 2004).
• Double reionization models Cen 2003, Wythe,
  Loeb 2003, period of extended reionization Haima
  n, 2003, but more complex pictures are possible

27

• Tau is only mildly constrained by Cl_t. WMAP
  ET-correlation spectrum and the E-polarization
  spectrum Cl_E contain independent information on
  tau. The majority of this information is conveyed
  by the spectral components with llt30.
• Cosmic variance.
• Large angles polarization data can be used to
  discriminate between different reionization
  histories. CMB (polarization) experiments will be
  indispensable for shedding light on those details
  of the reionization process that can be inspected
  through this observational window (Colombo 2004).

http//background.uchicago.edu/whu/polar/webversi
on/
28

• Contraining inflation Initial peturbations
  comprise a contribution from tensor modes
  (gravity waves) in addition to scalar modes
  (density peturbations)? contribute on lasrge
  scales (rT/S).
• Differentiating between tensor and scalar
  modes
• Scalar perturbations produce a pure E-mode
  polarisation pattern
• Vector perturbations (generated in
  topological defect models) generate mainly a
  B-mode polarisation pattern
• Tensor modes (gravity wave) generate an
  admixture of E- and B-modes

29

• The E-mode polarization greatly exceeds the
  B-mode then scalar fluctuations dominate the
  anisotropy. Conversely if the B-mode is greater
  than the E-mode, then vectors dominate. If
  tensors dominate, then the E and B are
  comparable.These statements are independent of
  the dynamics and underlying spectrum of the
  perturbations themselves

http//background.uchicago.edu/whu/polar/webversi
on/
30
Secondary effects Broad frequency coverage
(from 30 to about 900 GHz) ? detailed nature of
various astrophysical foregrounds -gt must be
corrected -gt but also byproducts

• Cluster of galaxies kSZ-effect and tSZ-effect
• Extragalactic sources
• Galactic studies dust properties, magnetic
  field, distrb. Of the ionized vs. interstellar
  medium

31
1.In the low frequency channels ( 30 to 90 GHz),
are expected to detect mainly radio-loud,
flat-spectrum radiogalaxies and QSOs, blazars,
and possibly some inverted-spectrum radiosources.
2. In the millimetre channels (90 to 300 GHz),
the predominant extragalactic sources will be
rich clusters of galaxies detected via the SZ
effect. 3.In the sub-millimetre channels (300 to
900 Ghz), are expect to detect many thousands of
infra-red luminous galaxies (both normal and
starbursting) and (mostly radio-quiet) AGNs, and
a few high-redshift galaxies and QSOs. 4. In
sub-mm and mm wavelengths maps of the emission
from Galactic
32
Some scientific areas addressed by Planck Some scientific areas addressed by Planck Some scientific areas addressed by Planck

Component Area Highlights
CMB Cosmology origin of structure Initial conditions for structure evolution Origin of primordial fluctuations Testing and characterizing inflation Testing and characterizing topological defects Constraints on the nature and amount of dark matter Determination of fundamental parameters  0, H0,   to 1  b, Qrms, ns to a few
Sunyaev-Zeldovich Cosmology structure evolution Measurement of y in gt104 clusters Estimate of H0 from y and X-ray measurements Cosmological evolution of clusters Bulk velocities (scales gt300 Mpc) out to z1 with  v 50 km/s
Extragalactic sources Cosmology structure formation Source catalogues of IR and radio galaxies AGNs, QSOs, blazars inverted-spectrum radio sources Far-infrared background fluctuations Evolution of galaxy counts
Dust emission Galactic studies Dust properties Cloud and cirrus morphology Systematic search for cold cores
Free-free and synchrotron Galactic studies Determination of spectral indices Cosmic ray distribution Magnetic field mapping
All Channels Solar System studies Asteroids Planets Comets Zodiacal emission
33
Sunyaev-Zeldovich Effect

• The thermal Sunyaev-Zeldovich effect arises from
  the frequency shift when CMB photons are
  scattered by the hot electrons in the
  intra-cluster gas. Observations of the SZ effect
  provide information on the hot intra-cluster gas
  that is complementary to that derived from
  observations at X-ray wavelengths
• The kinematic Sunyaev-Zeldovich effect Peculiar
  velocities of the hot intra-cluster gas lead to a
  Doppler shift of the scattered photons which is
  proportional to the product of the radial
  peculiar velocity and the electron density
  integrated along the line of sight through the
  cluster -gt possible to measure cluster peculiar
  velocities
• The frequency dependence of the TSZ distortion is
  characterised by three distinct frequencies 217
  GHz, where TSZ vanishes 150 GHz which gives the
  minimum decrement of the CMB intensity and 350
  GHz which gives the maximum distortion.

34
The Thermal SZ effect
High signal to noise and angular resolution are
essential to studying higher order effects and
cross-correlating CMB maps with observations at
other wavelengths.
Input SZ simulation
WMAP 4yr
Planck 1yr
From Martin White talkConstrainning Cosmology in
the Planck Era
35

• The SZ effect probes the intra-cluster gas
  temperature whereas the X-ray emission is more
  sensitive to the density distribution.

From Planck-HFI page
36

• Maps of the sum of primary CMB and secondary SZ
  anisotropies. YSZ is for the thermal SZ effect
  and KSZ is for the kinetic effect. The maps are
  obtained from hydrodynamical simulations of
  structure formation. The SZ effect anisotropies
  induce additional power at small angular scales.

From Planck-HFI page
37

• The combination of spatially resolved X-ray
  temperature and flux profiles, and measurements
  of the thermal SZ effect in the CMB, can be used
  to estimate the true spatial dimensions of rich
  clusters of galaxies and hence to estimate the
  Hubble constant
• Observations of the SZ effect provide information
  on the hot intra-cluster gas that is
  complementary to that derived from observations
  at X-ray wavelengths
• Rich cluster survay (104 entries)

38
So we need Planck and others..

• If we know Hubble parameter to about 5 is it
  good enough?
• We still know nothing about Lamba and dark matter
  - most of the Universe
• How about Gaussianity?
• n_s1 and Gaussianity do not distinguish between
  inflatoniary models (we have only upper limits on
  tensor to scalar ratio rT/S)
• Timing of reionization

39
others
40

• SPOrt is an Astrophysical Project aimed at
  observing the polarization of the sky in the
  microwave range 20-100 GHz, with angular
  resolution of 7. Primary goals are
• tentative detection of CMB Polarization on
  large angular scales maps of Galactic synchrotron
  emission at the lowest frequencies (22-32 GHz)
• SPOrt is carried on under the scientific
  responsibility of an International collaboration
  of Institutes headed by the IASF-CNR in Bologna
  and is fully funded by the Italian Space Agency
  (ASI).It has been selected by ESA to be flown on
  board the International Space Station (ISS) for a
  minimum lifetime of 18 months.

41
Suborbital Experiments

• http//lambda.gsfc.nasa.gov/product/suborbit/su_ex
  periments.cfm

42
Links to Project Website DataAtLAMBDA Year Status l-min l-ma Freq. (GHz) Detectors Polariz Type
ACBAR DATA Arcminute Cosmoloy Bolometer Array Receiver 2001-date continues 60 2700 150, 219, 274 Bolometer No Ground
ACME/ HACME - Advanced Cosmic Microwae Explorer/ HEMTACME 1988-1996 completed 10 180 26-35 and 38-45 HEMT No Ground
ACT - Atacama Cosmoloy Telescope - future - - 145, 225, 265 Bolometer No Ground
AMI - Arcminute MicroKelvin Imager - future - - 12-18 Interferometer No Ground
AMiBA - Array for Microwae Backgroud Anisotropy - future - - 90 - Yes Ground
APACHE - Antarctic Plateau Anisotropy CHasing Experimet 1995-1996 completed - - 100, 150, 250 Bolometer No Ground
APEX - Atacama Pathfinder EXperiment - future - - 150, 217 Bolometer No Ground
Archeops DATA N/A 1999-date continues 15 350 143, 217, 353, 545 Bolometer Yes Balloon
Full name
l- min
l - max
43
ARGO - N/A 1988, 1990, 1993 completed 53 180 150-600 Bolometer No Balloon
ATCA - Australia Telescope Compact Array 1991-1997 completed 3350 6050 8.7 HEMT No Ground
BAM - Balloon- borne Anisotropy Measurement 1995 completed 30 100 110-250 Liquid-helium cooled, Fourier transform spectromete No Balloon
BEAST - Background Emission Anisotropy Scanning Telescope 2000-date continues 10 1000 25-35 and 38-45 HEMT No Balloon, Ground
BICEP - Background Imaging of Cosmic Extragalactic Polarization - future - - - Bolometer - Ground
BOOMERanG - Balloon Observations Of Millimetric Extragalactic Radiation and Geophysics 1997-date continues 25 1025 90-420 Bolometer Yes Balloon
CAPMAP - Cosmic Anisotropy Polarization MAPper 2002-date continues 500 1500 90 and 40 MMIC/ HEMT Yes Ground
CAT - Cosmic Anisotropy Telescope 1994-1997 completed 339 722 13-17 Interferometer/ HEMT No Ground
CBI DATA Cosmic Background Imager 2002-date continues 300 3000 26-36,in 10 channels Interferometer/ HEMT No Ground
44
CG - Cosmological Gene 1999-date continues 100 1000 0.6 to 32 HEMT No Ground
DASI - Degree Angular Scale Interferometer 1999-date continues 200 900 26-36,in 10 bands HEMT Yes Ground
FIRS - Far Infra- Red Survey 1989 completed 3 29 170-680 Bolometer No Balloon
MAT - Mobile Anisotropy Telescope 1997, 1998 completed 30 1100 30-140 HEMT/SIS No Ground
MAXIMA DATA Millimeter Anisotropy eXperiment Imaging Array 1995, 1998, 1999 completed 50 700 150-420 Bolometer No Balloon
MBI-B - Millimeter-Wave Bolometric Interferometer - future - - 90 Bolometer Yes Ground
MINT - Millimeter INTerferometer - future 1000 3000 150 SIS No Ground
MSAM - Medium Scale Anisotropy Measurement 1992-1997 completed 69 362 150-650 Bolometer No Ballon
PIQUE - Princeton I, Q, and U Experiment 2002 completed 69 362 90 Bolometer Yes Ballon
POLAR - Polarization Observations of Large Angular Regions 2000 continues 2 30 26-46 HEMT Yes Ground
Polatron - N/A - future 200 2000 100 Bolometer Yes Ground
45
Python - N/A 1992-1997 completed 55 240 30-90 Bolometer/ HEMT No Ground
QMAP - N/A 1996 completed 30 850 30-140 HEMT/SIS No Balloon
SK - Saskatoon 1993-1995 completed 52 401 26-46 HEMT Yes Ground
SPT - South Pole Telescope - future - - - Bolometer - Ground
Tenerife - N/A 1984-2000 completed 13 30 10, 15, 33 HEMT No Ground
TopHat - N/A 2002-date continues 10 700 150-720 Bolometer No Balloon
VSA DATA Very Small Array 2002 continues 130 1800 26-36 Interferometer/ HEMT No Ground
Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments Sunyaev-Zeldovich Effect Experiments
SuZIE - Sunyaev- Zeldovich Infrared Experiment 1996-date continues 1000 3700 150, 220, 350 Bolometer No Ground
SZA - Sunyaev- Zeldovich Array - future - - 26-36 and 85-115 Interferometer No Ground
