Quick Sort

1
Quick Sort

2
Quicksort

• Quicksort is a well-known sorting algorithm
  developed by C. A. R. Hoare. The quick sort is an
  in-place, divide-and-conquer, massively recursive
  sort. It's essentially a faster in-place version
  of the merge sort. The quick sort algorithm is
  simple in theory, but very difficult to put into
  code (computer scientists tied themselves into
  knots for years trying to write a practical
  implementation of the algorithm, and it still has
  that effect on university students).

3
Quick Sort

• The recursive algorithm consists of four steps
  (which closely resemble the merge sort)
• If there are one or less elements in the array to
  be sorted, return immediately.
• Pick an element in the array to serve as a
  "pivot" point. (Usually the right-most element in
  the array is used.)
• Split the array into two parts - one with
  elements larger than the pivot and the other with
  elements smaller than the pivot.
• Recursively repeat the algorithm for both halves
  of the original array.

4
Quick Sort

• function quicksort(q)
• var list less, pivotList, greater
• if length(q) 1return q
• select a pivot value pivot from q
• for each x in q except the pivot element
• if x lt pivot then add x to less
• if x pivot then add x to greater
• add pivot to pivotList
• return concatenate(quicksort(less), pivotList,
  quicksort(greater))

5
Quick Sort Visualization
6
Quick Sort Visualization
7
Quick Sort Visualization
85
96
63
8
Quick Sort Visualization
85
96
63
9
Quick Sort Visualization
85
96
63
45

31
96
10
Quick Sort Visualization
85
96
63
45

31
96
11
Quick Sort Visualization
85
96
63
45

31
96

24
17

85
63
12
Quick Sort Visualization
85
96
63
45

31
96
13
Quick Sort Visualization
63
96
85
14
Quick Sort Visualization
15
Efficiency
n 8
Assuming the divide steps and the conquer steps
take time proportional to n, then the runtime of
each level is proportional to n. With logn 1
levels, the runtime is O(nlogn).
16
Efficiency

• Best Case Situation
• Assuming that the list breaks into two equal
  halves, we have two lists of size N/2 to sort. In
  order for each half to be partitioned,
  (N/2)(N/2) N comparisons are made. Also
  assuming that each of these list breaks into two
  equal sized sublists, we can assume that there
  will be at the most log(N) splits. This will
  result in a best time estimate of O(Nlog(N)) for
  Quicksort.

17
Efficiency

• Worst Case Situation
• In the worst case the list does not divide
  equally and is larger on one side than the other.
  In this case the splitting may go on N-1 times.
  This gives a worst-case time estimate of O(N²).
  Average Time
• The average time for Quicksort is estimated to
  be O(Nlog(N)) comparisons.

18
Efficiency

• The disadvantage of the simple version
  previously stated is that it requires extra
  storage space. The additional memory allocations
  required can also drastically impact speed and
  cache performance in practical implementations.
  There is a more complicated version which uses an
  in-place partition algorithm.

19
In-Place Quick Sort

• Sorting in place
• Instead of transferring elements out of a
  sequence and then back in, we just re-arrange
  them.
• Uses a constant amount of memory
• Efficient space usage
• Algorithm inPlaceQuickSort
• Runs efficiently when the sequence is implemented
  with an array

20
In-Place Quick Sort Visualization
21
In-Place Quick Sort Visualization
Pivot p element at the right bound index l
leftBound index r rightBound 1
r
l
p
while l lt r
22
In-Place Quick Sort Visualization
Pivot p element at the right bound index l
leftBound index r rightBound 1
r
l
p
while l lt r
r
l
p
r
l
p
23
In-Place Quick Sort Visualization
Pivot p element at the right bound index l
leftBound index r rightBound 1
r
l
p
while l lt r
l while its value lt p AND l lt r r-- while
its value gt p AND r gt l
r
l
p
swap l and r (as long as l lt r)
r
l
p
l while its value lt p AND l lt r r-- while
its value gt p AND r gt l
r
l
p
when l gt r swap l and p
r
l
p
sort(left leftBound, right l 1) sort(left
l 1, right rightBound)
r
l
p
r
l
p
24
Randomized Quick Sort

• Variation of the quick sort algorithm
• Instead of selecting the last element as the
  pivot, select an element at random
• Expected runtime efficiency will always be
  O(nlogn)
