Title: Terminology in Chest XRays


1
(No Transcript)
2
Terminology in Chest XRays
  • PA view- chest close to xray plate
  • xray tube 6 feet from patient
  • Pt erect
  • AP view- back close to plate
  • xray tube 3 feet from pt
  • pt supine
  • PA sharper
  • less magnified
  • Both generally taken in full inspiration
  • Oblique- taken with pt standing obliquely. Right
    oblique is with right chest against the plate
  • Lateral decubitus side of supine pt on the
    plate with xray tube horizontal
  • Apical Lordotic- xray tube angled at 45
  • Sternal rib views

3
HOW TO READ A CHEST X-RAY
  • Switch off all unnecessary lights.
  • 1.Identify patient name,age,sex,hosp . Date of
    xray and side marker (R or L)?
  • 2.. Check the adequacy and tech quality of film
  • Exposure- mid thoracic intervertebral disc should
    be clearly visible or a finger held behind the
    black part of the film should be just visible.
    Underexposed film is pale- lung appears
    consolidated/pulm edema. Overexposed film is
    black suggest emphysema
  • Position Supine or erect. PA,APor lat
  • Rotation (centered)- Spinous process of upper
    thoracic vertebrae should be central Medial
    ends of clavicles must be equidistant from the
    central spinous process
  • Lung volume (Degree of inspiration)- Right
    hemidiaphragm should reach the anterior end of
    6th / 7th rib or the 9th / 10th rib posteriorly
    on full inspiration
  • gt 6th rib in expiration indicates
    hyperinflation( emphysema)?
  • lt 5th rib indicates underinflation (
    crying infant)?
  • Film taken in expiration may simulate
    disease cardiomegaly, pulmonary congestion
  • 1

4
(CONTD.)?
  • 3. Check the extrathoracic soft tissue-
  • Start at the top with the supraclavicular areas,
    neck, shoulder,- look for subcutaneous
    emphysema., calcified glands Continue down each
    side of the chest Assess breast shadows. Finally
    check under the diaphragm for air
  • 4.. Check the bony cage Ribs,clavicles,
    scapulae,shoulder jts,thoracic spine
  • 5..Check for medical equipment
  • like ET tube, CVP line -Tip of ET tube should be
    about 2 cm from carina
  • 6. F. Check the superior mediastinum for widening
    or abnormal masses and identify the trachea
  • thymus causes widening upto 2yrs
  • 7. Check the heart- its positioned with 1/3 of
    its diameter to the right and 2/3 to the left of
    the spinous process. A low diaphragm will cause a
    right shift and a high d a left shift. The
    hearts full dia should be less than ½ of the
    internal thoracic dia at its widest point (
    cardiothoracic ratio)?
  • 8.Check the diaphragms, Cp Cp angles.
  • R dia 3 cm higher than left. Outline should
    be smooth with highest point medial to the
    midline of the hemithorax
  • Gastric bubble seen under L diaphragm
  • 9.. Hilum
  • Hilar shadows- made up of pulm art and large
    veins. Left hilum normally 2 cm higher than right
  • 10.Lungs
  • Lung pattern- all the markings in a normal lung
    are vascular. They disappear 2 cm or less from
    the lung margin
  • Lung zones- Upper apex to 2nd costal
    cartilage,
  • Middle -2-4 cartilage
  • lower below 4th cartilage

5
Features of Anatomy seen on PA VIEW
6
LATERAL VIEW
7
Normal PA view
8
PA VIEW
  • Each lobe is covered by visceral pleura.The
    visceral pleura bordering adjacent surfaces of 2
    lobes form the septa,which separates the lobes.
  • The space between 2 adjacent septae is called the
    interlobar fissure- a fissure is a narrow space
    a septa is a divider. The 2 terms are used
    interchangeably
  • Right lung has 3 lobe-RUL,RML,RLL separated by
    septa or fissures
  • R major fissure runs obliquely downwards from 5th
    thoracic vertebra to the diapraghm to a point
    just behind the ant cp angle.
  • Not normally seen in PA view as it is not
    parallel to the x-ray beam
  • The Right minor fissure intersects the lateral
    chest wall at the level of anterior portion of
    4th rib(/_2)?
  • RUL made up of apical ,anterior posterior
    bronchopulmonary segments
  • RML made up of lateral and medial segments
  • RLL made of superior, medial basal, ant basal,
    lateral basal and post basal

9
PA view
  • Left lung is made of
  • LUL LLL
  • The LUL is made up of apicoposterior and anterior
    segments
  • The lower or lingular division of the LUL is made
    up of sup inf seg
  • The LLL is made up of the sup, medial basal, ant
    basal, lat basal and postbasal

10
NORMAL CXR
  • Trachea is central
  • Dome of R diapraghm is at the level of 6th rib
  • L hemidiapraghm is 3cm lower than the R
  • Heart size is lt 50 of the thoracic diameter. 2/3
    of the heart lies to the L and 1/3 to the R of
    the spine
  • Cardiac apex gastric bubble are to the left
  • Horizontal fissure lies at the level of the 4th
    costal cartilage.
  • Mediastinum is lt 25 of the chest width

11
HEART BORDERS
1.Aortic knuckle 2.Pulm. Artery 3.L.atrial
appendage 4.L ventricle 5.R atrium 6.trachea
7.R dome of diaphragm 8.gas bubble in stomach
9.horizontal fissure
12
CT ratio
  • MRDmaximum R
    diameter

  • MLD maximum L diameter.

  • ID internal diameter

13
USEFUL RULES SIGNS
  • The Silhouette Sign
  • Contiguous objects of the same density are not
    seen separately
  • The 4 basic densities are air, fat, water and
    metal
  • The silhouette sign is seen when a border of the
    heart, aorta, or diaphragm is obliterated
  • The heart and ascending aorta are anterior
    structure

14
Causes of confluent opacification of a hemithorax
  • There are four main causes of confluent
    opacification of a hemithorax -
  • consolidation (that is, material within the
    air-spaces and
  • pleural effusion - that is, material within the
    pleural space, which could be serous fluid,
    blood, or pus.
  • Complete collapse of one lung with the
    mediastinum shifting over the the abnormal side
    can also cause a "white out" on the abnormal
    side.
  • Finally, after a pneumonectomy the mediastinum
    shifts to the empty hemithorax and the residual
    pleural space fills with fluid and fibrotic
    material leaving the patient with a complete
    "white out" on the side that has been operated
    on. Consolidation and pleural effusion are the
    two most common, and it can be difficult to
    distinguish between them - of course, they can
    coexist.

15
Collapse-RML
  • Silhouette sign

16
RML COLLAPSE-LATERAL
17
RML collapse..graphic
18
Collapse
  • Collapse of a lobe is caused by proximal
    obstruction
  • for example, by a neoplasm, mucus plug, such as
    in a postoperative patient, or foreign body, such
    as in a child.

19
AIR BRONCHOGRAM
  • The bronchi are not normally seen on the xray as
    they are thin walled, contain air and are
    surrounded by air in the alveoli
  • Visualisation of air in the bronchi is known as
    an air bronchogram
  • Air- filled bronchi can be seen if surrounded by
    diseased lung which contains no air (eg
    pneumonia, hyaline membrane disease,RDS)?

20
RDS
21
SAIL SIGN
  • The normal thymus lies in the sup, ant
    mediastinum. In the infant , it may appear to
    widen the mediastinum in a PA view, being largest
    at about 2 years of age
  • The inferior border of the R thymic lobe is a
    straight line. When it rests on the R horizontal
    fissure it produces an appearance referred to as
    the sail sign

22
sail sign
23
RUL collapse..graphic
24
(No Transcript)
25
LLL COLLAPSE
26
LLL COLLAPSE
27
(No Transcript)
28
Medial segment of R middle lobe CONSOLIDATION
29
(No Transcript)
30
RMLL PNEUMONIA
31
TB HILAR ADENOPATHY
32
APICAL TB
33
MILIARY TB
34
Pl. effusion R
35
(No Transcript)
