The aLife Home System

1
The aLife Home System
2
The aLife Home System

• Home automation with a different approach
• Market flooded
• They all take the same approach GUIs that wait
  for user input
• aLife is event driven based on
• Temperatures
• Security
• Energy

3
aLife Example Event
4
Project Goals And Objectives

• 1 goal Embedded Android
• Create a smart and customizable system
• Little to no learning curve
• Focus on active user interface
• Easy integration with any home
• Integrate with 3rd party devices
• Low cost

5
Project Block Diagram
ZigBee Base
Base Station
6
Remote Module
7
Remote Modules - Communications

• Module Communication Network Wireless ZigBee
• More reliable, robust than wired
• Flexibility in module installation location
• Acceptable data rate (up to 250kbps)
• Acceptable transmission range (up to 75m)
• Open source, abundance of cheap hardware and
  software available

8
Remote Modules Block Diagram
9
Remote Modules Schematic pg1
10
Remote Modules Schematic pg2
11
Remote Modules Schematic pg3
12
Remote Modules Power Supply

• Power Supply Requirement Specifications
• 3.3VDC output, lt 20mV peak to peak ripple
• Source gt 250mA
• Efficiency gt 80
• Work off of both 120VAC and battery
• Implementation National Semi LM2841XMK-ADJL
  switching buck DC-DC converter
• 3.3VDC output, 2mV peak to peak ripple
  (simulated)
• 300mA max
• 83 efficiency (simulated)

13
Remote Modules Power Supply
14
Remote Modules MCU

• MCU Requirement Specifications
• Built in ZigBee transceiver
• Available ZigBee Consumer protocol stack
• Operate at gt 15MHz
• gt 32kB built in FLASH, gt 2kB built in RAM
• Features digital I/O, PWM, ADCs, UART, 12C

15
Remote Modules MCU

• MCU Design Implementation
• Freescale MC13213R2
• Built in ZigBee transceiver
• 20 MHz
• 60kB FLASH, 4kB RAM
• 8x ADC, 2x UART, 1x I2C, 5x PWM, 22x GPIO
• BeeStack Zigbee 2007 compliant protocol stack
• Program firmware in C using CodeWarrior IDE

16
Remote Modules MCU
17
Remote Modules Base Comms

• Communication with Android Base Requirement Specs
• Must use a standard that is compatible with both
  Android base and remote module hardware
• Implementation
• RS232 using TI SN65C3221EPWR transceiver
• Up to 1M baud rate
• 15kV ESD protection
• No hardware handshaking

18
Remote Modules Base Comms
19
Remote Modules Type 1 Functions

• 120VAC Power Sensor Requirement Specifications
• Measure up to 1800W (max power rating for a
  standard wall outlet)
• Resolution down to 5W at 3 accuracy
• lt 10m Ohms AC impedance
• gt2kV electrical isolation between AC and digital
  side
• Ability to disconnect AC output to save appliance
  power

20
Remote Modules Type 1 Functions

• Power Sensor Design
• Allegro Micro ACS709LLFTR-20BB-T Hall effect
  based AC current sensor exceeds specs
• AC peak detector circuit for current sensor
  output
• On Semi MC33072ADR2G instrumentation amplifier
• Gain controlled via ADI AD5241BRZ1M 1M Ohm, 256
  step digital Pot for power ranging from 3W up to
  1700W
• Theoretical resolution down to 3W at 2 accuracy
  (still needs to be tested)
• In series software controlled relay

21
Remote Modules Type 1 Functions
22
Remote Modules Type 1 Functions

• Temperature Sensor Requirement Specs
• Accurate to within /- 2 degrees Celsius
• Range of -30 to 100 degrees Celsius
• I2C interface
• Remote temperature sensor loop (type 2 function)
• Implementation
• NXP SA56004ED,118 temperature sensor
• Meets the above requirements

23
Remote Modules Type 1 Functions
24
Remote Modules Type 2 Functions

• Type 2 Requirement specifications
• 2 DAC and digital outputs Lighting, motor
  control
• 2 ADC inputs Remote current sensor input
• 1 Temperature sensor loop measure outdoor temp
• 1 Software controlled relay garage door control
• Surge and short circuit protection for all I/O

25
Remote Modules Type 2 Functions

• Type 2 Function Implementation
• Digital and DACs outputs- PWM fed into low pass
  op amp circuits using Micron MCP665-E/UN dual op
  amp chip
• Can change from gnd to 3.3V in 3ms
• Output can drive /- 90mA
• 2 ADC inputs
• Surge protection - 400W TVS, clamp at 7.3V
• Short protection - 70mA hold, 130mA trip PTCs
• 10A relay

26
Remote Modules Type 2 Functions
27
Remote Modules Type 2 Functions
28
Remote Modules ZigBee Transceiver

• ZigBee Transceiver Requirement Specifications
• Transmission range of gt 30m
• ZigBee 2007 compliant protocol
• ZigBee Transceiver Design
• Single port antenna design to minimize components
• Transmission range still unknown pending antenna
  development
• Will use Freescales BeeStack Zigbee 2007
  protocol, specifically designed for this MCU

29
Remote Modules ZigBee Transceiver
30
Remote Modules PCB

• PCB implementation
• We will generate a layout from our schematic in
  Altium and manufacture our own custom PCBs with
  the following target specs
• 2-4 layer boards
• 3x3 or smaller outside dimensions
• Double sided component placement to minimize
  board area

31
Base Station Hardware
32
Design decision - Functionality

• Need a board to be able to run the android
  operating system.
• Has to be able to handle multiple clients
  accessing it at the same time (up to 5).
• Supports serial communication to interact with
  the ZigBee devices on the network

33
Design decision - Practicality

• Its a wall mounted unit, so the overall weight
  should be less than 5 pounds
• Should be able to be wall mounted
• Needs to be powered off a wall outlet
• LCD should be bigger than 2 inches to be
  considered easy to interact with

34
Processor

• i.MX51processor board

35
i.MX51 Specifications

• Processor ARM Cortex A8
• Runs anywhere from 600 MHz over 1GHz
• Meets the minimum android system requirements of
  200 MHz
• Supports Ethernet Connectivity
• Contains multiple interfaces that we needed to
  interact with our system

36
Picture of Complete System

• Included in this picture
• Processor board
• LCD Screen
• Expansion board

37
Communication Scheme

• Serial Communication is the main way this board
  talks to the network
• Problem Android OS doesnt support
  communication over serial ports!
• After some difficulty implementing serial comm.,
  we decided on using some lower level C code as an
  intermediary

38
Format for the C code
39
Base Station Software
40
Specifications and Requirements

• Functional
• Base station must be able to accept up to 5
  simultaneous service request on a first come
  first serve basis
• Multiple request to service the same notification
  must only be serviced once
• Must be able to add/remove/update a row in
  database with 98 reliability
• Security
• All user must have unique login Allowed 5
  unsuccessful attempts before lockout
• Only registered remote client devices may have
  service request fulfilled by the base station
• Notifications
• All notifications must have a unique notification
  ID
• Users shall only receive notifications that they
  are registered to receive

41
Design Approach and Implementation

• V-Model
• Proven and well structured
• Allows for redesign
• Android Operation System
• Supports notifications
• Supports secure socket communication
• Database support
• Eclipse IDE w/ Android Development Tools (ADT)
  Plug-in
• Free
• Best support for Android Development

V Model
42
Design Decision Database Management System (DBMS)

• SQLite
• Needed the use of a database for our software
• Had several choices, but implemented SQLite
• Extensive native support provided by Android
  platform.
• Will run on Base Station, no need for additional
  hardware
• No need for purchase server space.
• Relatively fast compared to other DBMS

43
Software Block Diagram
44
Software Block Diagram Background Services

• Fields
• PowerNotif (Boolean)  Field tells whether a
  powered device notification is set up
• SecurityNotif (Boolean)  Field tells whether a
  security device notification is set up
• ControlNotif (Boolean)  Field tells whether a
  control device notification is set up
• ActiveDevices(Device )  Array of active
  devices in the network
• RequestedService (String)  String representation
  of a request
•
• Methods
• BaseStation ()Constructor to create the GUI
  interface for our system.
• getActiveDevices()  Takes in no parameters.
   Returns all active devices in database.
• addDevice(Device X)  Adds specified device to
  network and database.  No return.
• removeDevice(Device X)   Removed specified
  device from network and database.  No return.
• setNotifications()  Takes no parameters.  Sets
  all initial notifications booleans.  These will
  dictate which notifications will be checked for
  continuously throughout the program.
• pollDevices(ActiveDevices)   Takes in all active
  devices and updates their information in the
  database tables.  Returns nothing.
• socketParser (ByteStream)  Takes in a socket
  byte stream and returns the requested service in
  string format.
• requestService (Device X, RequestService)  This
  method will take in a device and service request
  and will fulfill the said service.  Returns
  nothing.

45
Software Block Diagram Devices Class

• Fields
• ID (Int)  Device's ID
• Name (String) Name provided by user for device
• Status (Boolean)  Provides status of device, on
  or off
• Methods
• getID() Takes in no parameters.  Returns an Int,
  the value of the devices ID.
• setID(Int ID)  Takes in an Int and updates ID
  field.  Does not return anything.
• getName()  Takes in no parameters.  Returns a
  String, the value of the devices Name.
• setName(String name)  Take in a String and
  update Name field.  Does not return anything.
• getStatus()  Takes in no parameters.  Returns
  Status of device
• setStatus(Boolean Status)  Takes in a boolean
  and updates Status of device.  Does not return
  anything.

46
Software Block Diagram PowerDevice

• Fields
• TotalWatts (Int)  Provides total watts used by
  device
• SetWatts (Int)  Provides user defined limit for
  watt usage
• CurrentTemp (Int)  Provides current temperature
  information
• SetTemp (Int)  Provides user defined limit for
  temperature
• PollTime (Int)  Time the information was polled
• SetTime (Int)  Set time for notification
  purposes
• Timeframe (Int)  Timeframe for power information
  i.e. 7 days or 30 days
• Methods
• PowerDevice()  Constructor to create object.
   Will have generic and specific constructors.
• turnOn()  Takes in no parameters.  Sends message
  to ZigBee device to turn on
• turnOff()  Takes in no parameters.  Sends
  message to ZigBee device to turn on
• getTemp()  Takes no parameters.  Polls ZigBee
  device for temperature.
• setTemp(Int Temp)  Sets ZigBee device with
  provided temperature.  Does not return anything.
• getWatt()  Takes no parameters.  Polls ZigBee
  device for wattage.
• getTimeframe()  Takes in no parameters.  Returns
  the timeframe field.
• setTimeframe(Int Timeframe)  Sets the timeframe
  field.  Does not return anything.

47
Software Block Diagram SecurityDevice

• Fields
• SetTime(Int)  Provides set time for any
  notifications
• Methods
• SecurityDevice()  Constructor to create object.
   Will have generic and specific constructors.
• isOpen()  Takes in no parameters.  Returns true
  if ZigBee device is open.
• IsLocked()  Takes in no parameters.  Returns
  true if ZigBee device is locked.

48
Software Block Diagram ControlDevice

• Fields
• SetTime(Int)   Set time for notification
  purposesMethods
• ControlDevice()  Constructor to create object.
   Will have generic and specific constructors.
• turnOn()  Takes in no parameters.  Sends message
  to ZigBee device to turn on
• turnOff()  Takes in no parameters.  Sends
  message to ZigBee device to turn on

49
Database Structure

• The SQLite database will be utilized to store
  information about current users, devices, power
  history, notification history, and notification
  set ups.  Each of these elements will be have
  their own table in our database with their own
  specified fields.

50
Remote Client Device (RCD)
51
Specifications and Requirements

• Reliability
• No crashes
• 90 Notification Rate with connection
• Usability
• Easy to answer notifications
• Unobtrusive
• Notifications only when needed

52
Specifications and Requirements

• Android Phone
• Secure Connection
• Seamless transition between WiFi and Cell Network
• Fast notifications
• lt10 sec with a connection

53
Research and Design Decisions

• Minimal focus on control
• Prevent detraction from the standard practices
• Notifications based on events
• Untapped market
• Cost savings

54
Notifications Packet Structure
Type 1 (Power) Type 2(Power) Type (Power) Type 4 (Temperature) Type 5 (Temperature)
Notification type Notification type Notification Type Notification Type Notification Type
Notification Level Notification Level Notification Level Notification Level Notification Level
Notification ID Notification ID Notification ID Notification ID Notification ID
Button 1 Text Button 1 Text
Button 2 Text Button 2 Text
Button 3 Text Button 3 Text
Current Temp
Current Set Point
Current HVAC Mode
Page Flip Page Flip Page Flip Page Flip Page Flip
Display State with Control Options Display History with Notification Options Display History with Notification Options Display State with Control Options Display History with Notification Options
55
Class Structures

• Android
• Notification
• Service

56
Class Structures

• aLife
• Menu
• System

57
Design Approach and Implementation

• GUI

58
Testing Base Station

• Hardware
• Verified communication serially
• Could interact with the screen and it be user
  friendly
• Software
• Tested the adding of users and devices to the DB.
• Checked for concurrency issues among multiple
  clients
• Tested that the software would generate a
  notification whenever it received a signal to do
  so

59
Testing Remote Client and Wireless Network

• Remote Client
• Showed that we can populate information from the
  Base Stations database
• Can interact with the Base Station through
  notifications
• Maintain TCP/IP connection with the system
• Wireless Network
• No real testing, unable to get the protocol stack
  configured correctly

60
Budgeting

• Base Station
• Freescale i.MX51 0.00 (on loan from Advantor
  Systems)
• Remote Client
• HTC Dream Android smartphone 0.00 (owned by a
  group member)
• Samsung Captivate Android smartphone 0.00
  (owned by a group member)
• Remote Modules per module costs on following
  table

61
Budgeting Per Remote Module
Item Type Manufacturer Part Number Cost/1 Multiple
MCU Freescale MC13213R2 0.00
Dual op amps Micron MCP665-E/UN 1.46
Temp Sensor NXP SA56004ED,118 0.85
Relay Tyco PB114006 1.18 2
Terminal Block Tyco 1-284093-0 2.21
DC-DC Converter National LM2841XMK-ADJL 3.90
Transformer Pulse BV030-7136.0 3.36
Current Sensor Allegro ACS709LLFTR-20BB-T 4.46
Instrum Amps On Semi MC33072AD 1.10
Digital Pot ADI AD5241BRZ1M 2.33
Balun Murata LDB212G4005C-001 0.42
Crystal AVX CX3225SB16000E0FPZ25 3.30
Misc 5.00

• Remote Modules
• Freescale MC13213 0.00 (sampled from
  Freescale)

62
Budgeting Remote Module Component Costs

• Total per module 100.00
• Additional costs for ZigBee base module
• RS232 transceiver TI SN65C3221EPWR, 2.63
• DB9 connector - Norcomp 171-009-113R911, 3.00
• No terminal block -2.21
• Bare PCBs (6 sq inch) 60.00 each
• Total cost of 4 remote modules 640.00

63
Budgeting - Summary

• Total budge allowance - 600
• Base Station - 0.00
• Remote Client - 0.00
• Remote Modules - 640
• Total 640
• Slightly over budget, but we had a good
  estimation from the start

64
Milestone
65
Successes/Difficulties

• Successes
• Working high level product from the base station
  to user notification
• Successfully manipulated our embedded platform to
  handle the requests that we wanted
• Difficulties
• Zigbee
• Serial Port Communication

66
Questions

• Any questions or comments?
