Title: Chapter 30: Plant Diversity II: The Evolution of Seed Plants
1Chapter 30Plant Diversity IIThe Evolution
ofSeed Plants
2Free-Living Gametophytes
3Reduced Gametophytes
4Some Seed-Bearing-Plant Anatomy
Gender Female Male
Sporangia Megasporangia Microsporangia
Spores Megaspores Microspores
Gametophyte Megagametophyte Microgametophyte
Gametangia Archegonia Antheridia
Gametes Egg Sperm
5Ovules
- Megasporangium gives rise (meiotically) to
megaspores - Integument envelopes, protecting the
megasporangium - An ovule consists of integument surrounding a
megasporangium which in turn surrounds a
megaspore - The female gametophyte develops mitotically from
the megaspore - The female gametophyte gives rise mitotically to
the female gamete, the egg - Once fertilized the egg develops into an
embryonic sporophyte - The sporophyte embryo surrounded by the parental
megagametophyte which, in turn, is surrounded by
grandparental sporophyte tissue is a seed
6Seeds (are complicated)
Gametophyte (haploid parent)
Sporophyte (next generation)
Sporophyte (grandparent)
7Gymnosperms
Gymnosperms have seeds and vasculature but not
flowers nor fruit
8Gymnosperms
Gymnosperms are plants that have naked seeds
that are not enclosed in ovaries. Their seeds are
exposed on modified leaves that usually form
cones. p. 593, Campbell Reece (2005)
9Gymnosperm
10Pollen Heterospory
This is pollen!
11Pollen Pollen Tube
Pollen freed plants from flagellated sperm so no
more need for water for fertilization to take
place
12Grains of Pollen
Seed-bearing plants disseminate their sperm/male
gametophyte as pollen
Pine pollen
13Gymnosperm Life Cycle
Overall this life cycle takes about three years
(not including growth to sexual maturity of the
resulting tree)
14Angiosperms
Angiosperms are vascular plants that produce
seeds via flowers and distribute those seeds via
fruit
15A Flower
Male part
Female part
16Flower Cross Section
17Pigmented Sepals
18Flying Penises!
One of the great advantages of flowering is the
potential for pollination by animals
19Origin of Flower Structure
20Primitive Flowers
21Fruit
A fruit typically consists of a mature ovary,
although it can include other flower parts as
well
22Various Fruits
As seeds develop from ovules after
fertilization, the wall of the ovary thickens. A
pea pod is an example of a fruit, with seeds
(mature ovules, the peas)
23Even More Fruits
encased in the ripened ovary (the pod). Fruit
protects dormant seeds and aid in their
dispersal. p. 598, Campbell Reece (2005)
24Angiosperm Life Cycle
25Embryo Sac 7-Cell Gametophyte
Synergids
antipodal cells
Egg
Double fertilization is of these two cells
Formation of embryo sac the angiosperm female
gametophyte
Polar Nuclei
26Double Fertilization
27Monocots vs. Eudicots
28Monocots vs. Eudicots
29Monocots vs. Eudicots
30Overview Bryophytes (moss)
name? sporophyte? spores? gametophyte? gamete?
terminating event? meiosis? mitosis? mitosis? syngamy?
ploidy? diploid haploid haploid haploid
Bryophyta inconspicuous wind dispersed conspicuous germinates apart from parental sporophyte sperm is motile egg stays in association with gametophyte
31Overview Pterophytes (ferns)
name? sporophyte? spores? gametophyte? gamete?
terminating event? meiosis? mitosis? mitosis? syngamy?
ploidy? diploid haploid haploid haploid
Pterophyta conspicuous wind dispersed inconspicuous germinates apart from parental sporophyte sperm is motile egg stays in association with gametophyte
32Overview Coniferophytes (pines)
name? sporophyte? spores? gametophyte? gamete?
terminating event? meiosis? mitosis? mitosis? syngamy?
ploidy? diploid haploid haploid haploid
Conifero-phyta Conspic-uous embryos disperse, packaged associated with grand-parental sporophyte tissue (seeds) megaspore not dispersed microspore is wind dispersed with/as pollen inconspicuous microspore germinates as pollen tube, once associated with female sporophyte tissue, associated with ovule megaspore germinates in parental sporophyte sperm is non-motile both gametes stay in close association with parental gameto-phytes
33Overview Anthophytes (flowering)
name? sporophyte? spores? gametophyte? gamete?
terminating event? meiosis? mitosis? mitosis? syngamy?
ploidy? diploid haploid haploid haploid
Antho-phyta conspicuous seeds plus seeds packaged within grand-parental-sporophyte tissue (fruit) megaspore not dispersed microspore is wind dispersed with/as pollen inconspicuous same as pines except ovule is surrounded by a grandparental-sporophyte ovary (i.e., ovary and ovule are of same generation) sperm is non-motile both gametes stay in close association with parental gameto-phytes
34The End
