Air Traffic Management, Adacel Inc.

1
TRAINRO/1-PPT/31
New Technologies in ATM SYSTEM ICAO, Montreal
23 November 2009
Air Traffic Management, Adacel Inc.
2
AURORA is the Most Advanced ATM System in
Operation Today
3
Topics

• Developments in Air Traffic Management Automation

• Scope of the automated ATM system
• Surveillance systems integration
• Air Traffic Management Automation
• Automated Flight/Surveillance Data processing
• Surveillance systems
• Conflict detection
• Coordination
• Demo
• Overview on a demo platform and meeting with
  engineers

4
Evolution

• In 1971, in a typical control tower
• 100 movements a day (400 passengers)
• One man operation
• Three frequencies HF, VHF, UHF
• Traffic sheet
• Binoculars, Light gun, Map.
• In 2009, in a busy tower
• 3000 movements a day (250,000 passengers)
• 6 to 8 ATCO operation
• 16 frequencies and data link
• Radar/ADS-B, (ASD, A-SMGCS)
• IDS, (Information Display System)
• Electronic (EFS) or Paper Flight Strips

5
Scope of the automated ATM system

• OCS (Oceanic )
• ASD, EFS, IDS
• Non-surveillance airspace or satellite based
  surveillance
• Procedural control (time based separation)
• 4-D, flight plan based, profile
• Conflict detection and reporting
• Conformance monitoring functions (Route, FL, EST)
• Surveillance (ADS-C, CPDLC)
• VCCS (HFRO), data link

6
Scope of the automated ATM system

• ENR (Enroute)
• ASD, EFS, IDS
• Non or Surveillance based separation
• Mixed surveillance (Radar, ADS-B/MLAT, ADS-C,
  CPDLC)
• Conflict detection and reporting
• Conformance monitoring (Route, FL, EST)
• Safety nets (STCA, MSAW, APW )
• VCCS, data link

7
Scope of the automated ATM system

• Approach or TMA
• ASD, EFS, IDS
• Surveillance based separation (radar standards)
• Mixed surveillance (Radar, ADS-B/MLAT)
• Conflict detection and reporting (-)
• Safety nets (STCA, MSAW, APW, WTC) ()

8
Aircraft Situation Display (ASD)
9
OCS, ENR, APP Electronic Flight Strips
Eastbound
RVSM
Fixes
Next sector
Clearance
Control
10
Conflict Reporting
Conflict Type
Required Separation
Loss of separation time
Actual Separation
Active
Conflict Segment
Intruder
Draw
11
Scope of the automated ATM system

• Tower
• ASD
• A-SMGCS (ADS-B) Runway Incursion
• Flight strips (EFS)
• VCCS , Data link for PDC
• IDS, (Information Display System)
• Weather (actual Wind and QNH, TAF, SIGMET's)
• Runways in use
• Procedures (Runway change, emergencies etc)

12
Tower EFS (Electronic Flight Strip)
13
Scope of the automated ATM system

• Common requirements for all sectors
• HD screen, color coded and icons
• Automatic or manual coordination
• Selection of Tools and Maps
• Sectorization on line by supervisor
• Users preference at log-on

14
Conclusion

• We will demonstrate what a modern integrated ATM
  ( FDPS and SDPS/RDPS) system can and must do to
  meet today's ATS requirements
• ATM Analyses and Processes Airspaces
  Surveillance
• ATM Analyses and Processes Aircrafts CNS
  capabilities
• ATM generates a 4-D profile
• ATM generates Conflict Detection and Safety Nets
• ATM generates ASD, EFS

15
End Part I
16
Air Traffic Management Automation

• Automated Flight Data/Surveillance Data
  processing
• Surveillance systems
• Conflict detection
• Coordination

17
Automated FDPS and SDPS/RDPS

• Incorporate latest CNS technologies of airborne
  systems,
• Incorporate all available surveillance sources
  Radar, ADS-B, ADS-C, CPDLC and pilot voice
  position reports (UHF-VHF-HF),
• Processes route and intent information to
  generate internal 4-D profiles
• Process weather data
• Processes and displays Automatic Conflict
  Detection by applying the required separation
  based on Airspace and Aircraft data
• Support automatic and manual exchange of data
• Provides the controllers with adapted system
  displays and tools
• ASD
• EFS auto or manual update

18
Automated FDPS and SDPS/RDPS

• BENIFITS
• Update internal 4-D flight profiles with
  surveillance data and perform conformance
  monitoring.
• Improve safety with automated conflict
  detection-safety nets
• Reduce the potential for errors by eliminating
  manual tasks
• Aircrafts fly preferred routes saving fuel and
  reducing
• CO2 emission

19
Aircraft Situation Display (ASD)
20
Aircraft Position Symbol (APS)
21
OCS, ENR, APP Electronic Flight Strips
22
OCS, ENR, APP Electronic Flight Strips
Eastbound
RVSM
Fixes
Next sector
Clearance
Control
23
Conflict Prediction Reporting
24
Conflict Reporting
Conflict Type
Required Separation
Loss of separation time
Actual Separation
Active
Conflict Segment
Intruder
Draw
25
Conflict Reporting
Conflict Segment
Intruder
Start and end time
Active
26
Clearance widows
Complexe
Dynamic Reroute
FL
Probe
27
Automatic Coordination
Expanded Boundary
FIR Boundary
Notification
Transfer
Coordination
?

• Full AIDC Message Protocol
• OLDI
• Dialogues Adaptable

?
Current
Previous
Next
FIR Boundary
28
Coordination window
Inbound Message
Inbound coord. profile
Outbound Coord. profile
Next Sector Button
Response Area
Coord. Message Buttons
Annotations Restrictions
Manual, Send, Other Buttons
29
Safety Nets

• ATM processes
• the Surveillance Data
• Radar
• ADS-B
• MLAT
• the Flight Data
• RVSM status
• CFL
• WTC
• the Environment Data
• Reserved Airspace

STCA MSAW APW WTC
30
OCS, ENR and APP Summary

• Provides surveillance
• Improves communications and coordination
• Provides conflict free trajectories
• Provides all Safety Nets
• Reduces aircraft separation
• Reduces controller workload

31
TOWER

• Air Situation Display (ASD)
• Electronic Flight Strip (EFS)

32
TOWER ASD
Lists
Localizer dots
SIDs
Runways
Satellite airport
Fixes
Obstacle
33
Tower EFS (Electronic Flight Strip)
34
TOWER Summary

• Same ASD functionalities as in the ACC
• Advanced EFS using touch screen technology

35
Architecture
36
Conclusion

• Supports all ATC domains OCS, ENR, APP, TWR
• Flight Data and Surveillance Data Processing
  incorporating all available surveillance sources
  (Radar, ADS/B, ADS-B, CPDLC)
• 4 D profile
• Conflict detection and Safety Nets
• ASD and EFS
• Automatic or Manual Coordination

37
