LOWER EXTREMITY

1
LOWER EXTREMITY
Francis Neuffer, MD USC SOM Gross Anatomy /
Radiology
2
OUTLINE

• Hip Trauma
• Knee Degeneration
• Ankle Vascular Injury
• Foot Sports Injury

3
FEMORAL HEAD
ACETABULUM
FEMORAL NECK
AP HIP
GREATER TROCHANTER
FOVEA CAPITIS
LESSER TROCHANTER
CORTICAL BONE
MEDULLARY BONE
4
RT. HIP
Pediatric
Adult
5
CORONAL MRI
RT. HIP
6
INTERTROCHANTERIC FRACTURE
7
BONE DENSITY MEASUREMENT NUCLEAR MEDICINE
8
POST OPERATIVE REPAIR
9
ACETABULAR FRACTURE Dashboard fracture
CT SCAN OF THE PELVIS SHOWS FRACTURE
10
AVASCULAR NECROSIS
Bone scan
X-ray
MRI
11
FRACTURED LT. FEMUR
LAT
AP
12
DESCRIBE THE FRACTURE
AP

• BONE AND WHICH PART
• FRACTURE ORIENTATION AND PARTS
• DISPLACEMENT AND ANGULATION
• JOINT / SOFT TISSUE INVOLVEMENT

LAT
13
EXAMPLE
There is an oblique fracture through the
diaphysis of the femur with approximately 1cm of
lateral and anterior displacement of the distal
fragments relative to the proximal fragments.
There is no angulation at the fracture margin.
There is some shortening due to unopposed muscle
pull. The fracture does not extend into the joint.
14
DISTAL FEMUR KNEE
Medial epicondyle
Lateral epicondyle
Lateral tibial condyle
Intercondylar eminence
Medial tibial condyle
Head of fibula
Tibial tuberosity
15
KNEE
LATERAL
AP
16
Tendon Rupture Which One?
17
MRI RIGHT KNEE
coronal section
anterior
Scan level
18
-
MEDIAL
Sagittal sections
MEDIAL MENISCI
PCL
LATERAL MENISCI
ACL
PATELLA TENDON
LATERAL
19
SAGITAL MR KNEE (MID JOINT)
QUADRICEPS TENDON
POSTERIOR CRUCIATE LIGAMENT
Scan level
PATELLA
ANTERIOR CRUCIATE LIGAMENT
PATELLAR TENDON
20
PATELLA FRACTURE
NORMAL
21
NORMAL
QUADRACEPS TENDON INJURY
PATELLA TENDON INJURY
22
PATELLA TENDON RUPTURE
23
ANTERIOR CRUCIATE LIGAMENT INJURY
Normal
24
POST OPERATIVE LIGAMENT REPAIR
Stabilization of ligament by surgical graft and
screws
25
POSTERIOR CRUCIATE LIGAMENT INJURY
Normal
26
MENISCUS
NORMAL
TORN
27
WHAT IS MY AGE?
28
POST OP KNEE REPLACEMENT
Degenerative arthritis
POST-OP
29
LOWER LEG
TIBIAL TUBEROSITY
HEAD OF FIBULA
FIBULA
TIBIA
FIBULA
LATERAL MALLEOLUS
MEDIAL MALLEOLUS
AP
LATERAL
30
Tibial fracture shows spiral orientation
31
AP ANKLE
Tibial shaft
Fibular shaft
Medial malleolus of the tibia
Lateral malleolus of the fibula
Talus
32
LATERAL ANKLE
tibia
fibula
talus
navicular
cuboid
calcaneus
33
FRACTURES THROUGH THE MEDIAL AND LATERAL
MALLEOLI.
34
THIS CT SCAN SHOWS FRACTURES THROUGH THE MEDIAL
AND LATERAL MALEOLI.
35
SALTER INJURY TO GROWTH PLATE
36
AP FOOT
DIP
PIP
DISTAL PHALANX MIDDLE PHALANX PROXIMAL PHALANX
PHALANGES
MTP
CUNIFORMS
3RD
SESAMOID BONES
METATARSALS
1ST
2ND
I
II
III
IV
V
SCAPHOID
CUBOID
TALUS
TARSALS
CALCANEUS
37
LATERAL FOOT
(NAVICULAR)
(3) CUNEIFORMS
TALUS
METATARSALS
PHALANGES
SUSTENTACULUM TALI
CALCANEUS
CUBOID
SESAMOID BONE
CALCANEAL TUBEROSITY
38
CALCANEAL FRACTURE
PATIENT FELL OFF OF A LADDER
39
DIABETIC OSTEOMYLITIS
Note air in soft tissues on right due to
bacterial growth.
40
BONE SCAN OSTEOMYELITIS
Increased activity on bone scan supports
osteomylitis in metatarsal
41
GOUT
Urate crystal deposits cause inflammation and
erosion.
42
VASCULAR STRUCTURES
43
AP PELVIC ARTERIOGRAM
1
6

1. ABDOMINAL AORTA
2. COMMON ILLIAC ARTERY
3. INTERNAL ILLIAC ARTERY
4. EXTERNAL ILLIAC ARTERY
5. COMMON FEMORAL ARTERY
6. LUMBAR ARTERY

2
3
4
5
44
CONVENTIONAL ANGIOGRAM 1 Common femoral
artery 2 Superficial femoral artery 3 Profunda
femoral artery (Deep artery of the thigh) 4
Lateral femoral circumflex artery
CALCIFICATION outlines superficial femoral
artery.
1
4
2
3
45
ARTERIAL CALCIFICATION
46
LOWER EXTREMITY ARTERIOGRAM
1
1
2
2
3
3

1. COMMON FEMORAL ARTERY
2. PROFUNDA FEMORIS ARTERY (Deep artery of the
   thigh)
3. SUPERFICIAL FEMORAL ARTERY

47
LOWER EXTREMITY ARTERIOGRAM
POPLITEAL ARTERY
4
Subtraction image
48
LOWER EXTREMITY ARTERIOGRAM

• 4. POPLITEAL ARTERY
• ANTERIOR TIBIAL ARTERY
• POSTERIOR TIBIAL ARTERY
• 7. FIBULAR ARTERY

4
5
6
7
49
SUPERFICIAL FEMORAL ARTERY ARTERIOGRAM
50
BALLOON ANGIOPLASTY OF SFA
51
INFERIOR VENA CAVAGRAM
52
LEFT LOWER LEG VENOGRAM
4
2

• POPLITEAL VEIN
• FEMORAL VEIN
• PROFUNDA FEMORAL VEIN
• GREAT SAPHENOUS VEIN

3
4
2
1
53
VENOGRAM AP projection
Popliteal vein
Calf veins
54

CALF VEIN THROMBUS
PULMONARY EMBOLUS
55
Summary

• Hip Trauma
• Knee Degeneration
• Ankle Vascular Injury
• Foot Sports Injury

56
