Netronics Wireless Solutions for Video Surveillance

1
Netronics Wireless Solutions for Video
Surveillance
2
Video Surveillance Market
2
Post 9/11, video surveillance is becoming an
integral part of most security projects, and more
common than before
3
Video Surveillance Market
3
Solutions becoming more demanding, covering all
types of locations and terrains, high quality of
video and applications
4
Video Surveillance Market
4
Transmission networks receive high focus in
quality projects
5
Netronics SolutionWireless Video Surveillance
without Boundaries
5

• Netronics provides leading wireless transmission
  solutions for quality video surveillance projects
• The Right Products
• The Best Cost Structure
• Worldwide Experience

6
Video Surveillance Market
6
Market Size
2007
2013
2008
2009
2010
2011
2012
7
Video Surveillance Market
7
Market Size
Expected to grow from 4.5B in 2007 to 46B by
2013
46B
4.5B
2007
2013
2008
2009
2010
2011
2012
ABI Research, June 2008
8
Video Surveillance Market
8
Market Size
Growth is stable through the financial crisis
Financial crisis
2007
2013
2008
2009
2010
2011
2012
IMS Research, Nov 2008
9
Video Surveillance Market
9
Verticals
Many verticals with different requirements and
solution types
10
Video Surveillance Market
10
Technology
Evolving to IP-based cameras, higher resolution
and frame-rates, advanced video analytics
11
Video Surveillance Projects Types
11
Low-end
High-end

• City surveillance (low scale)
• Enterprise
• Campuses
• Plants
• Gas stations
• ATMs

• City surveillance (high scale)
• Border control
• Railways security
• Gas/Oil pipeline security
• Facilities
• Airports, seaports
• Traffic surveillance

12
High-End Video Surveillance
12

• Video applications require high resolution and
  high quality
• High Capacity - Mega-Pixel cameras consuming high
  bandwidth
• Advanced Applications - License-plate or face
  recognition (e.g. as an applicable evidence in
  court)
• Real Time - Focused alerts, maximum information
  for manned patrols
• Mission-critical - No tolerance for system
  downtime or quality degradation
• Requires higher capacity for video streaming, and
  higher robustness and reliability of the wireless
  transport infrastructure

13
Why Wireless Transport?
13
Border Control
Remote Facilities
City Surveillance

• No cabling through walls, trenching for fiber
  between buildings, or drilling holes for cables
  in buildings.
• Low deployment and operational costs (CAPEX
  OPEX)
• Flexible and dynamic network topology, locations
  of cameras, and network expansion

14
Netronics Wireless Transport Network for Video
Surveillance
14

• In high quality projects Netronics PtP solution
  fits best
• Dedicated high-capacity BW per camera
• Robust and high quality radio link
• Flexible and scalable architecture
• Simple to install and maintain
• Affordable

15
Netronics Wireless Transport Network for Video
Surveillance
15
16
Netronics Solution Overview
16
Max Throughput (Mbps) Max Range (Km) Freq. (GHz) Channel BW (MHz)
2 full duplex 20 2.4, 5.8 5
5 (5 uplink, 2 downlink) 20 2.4, 4.9-6 5/10/20
18 full duplex 80 2.4, 4.9-6 5/10/20
50 full duplex 120 2.4, 4.9-6 20

• Netronics Provides Broadband Wireless Solutions
• Variety of sub-6 GHz frequency bands
• OFDM technology enables operation in near/non
  line-of-sight
• Point-to-Point unique Multiple Point-to-Point
  architectures
• Netronics Network Management System (RNMS) to
  easily control a complex network
• Suitable for access and backhaul in diverse
  scenarios

17
What Projects Fit Best for Netronics Solution ?
17

• High-End City Surveillance Projects
• Require high capacity per camera, dedicated
  robust link per camera
• Wide Area Projects
• e.g. borders, pipelines, railways, remote
  utilities
• Projects That Require Access and Backhaul
• Netronics is a one-stop-shop with a deep
  portfolio

18
City Surveillance Scenarios
18
19
City Surveillance Scenarios
19
Bypass obstacles, reach remote sites
20
City Surveillance Scenarios
20
Aggregate several cameras
21
City Surveillance Scenarios
21
High Resolution Camera
22
Case Study Safe City Argentina
22

• Municipal project, aimed to increase security in
  public places,monitor traffic, prevent
  vandalism, violence, crime, littering, and
  protect water facilities
• 40 cameras (of 1.5 Mbps) are wireless (several
  dozens more arewired)
• Multiple Point-to-Point Architecture, Hub site
  located at the control center

23
Case Study Sacred Site SecurityWest bank,
Palestine
23

• Video surveillance and security applications,
  securing residents and visitors in a historic
  site, in a sensitive area
• Netronics provides real-time, high-quality
  transmission of video streams from cameras
  installed throughout compound
• Seamless operation in extremely challenging
  environment(nLOS, rough mountain terrain,
  interferences)

24
Wide Area ScenariosGas/Oil Pipelines Protection
24
25
Wide Area ScenariosGas/Oil Pipelines Protection
25

• Cascading Topology
• Ring Topology
• a link is down, other cameras can still reach the
  control center

26
Case Study - Utility Surveillance
26

• Customer Water Company
• Data Video transmission of water levels to
  Water NOC (telemetry)
• Enable utility company to operate an
  Early-Warning System to alertlocal agricultural
  community to natural events that could result in
  floods.
• Real-time data and video transmission for
  mission-critical application
• Connects sites as far as 71 Km apart
• Operates at high altitude where other equipment
  failed (4611 m)

27
Case Study - Electricity Substations Surveillance
27

• Customer Power Grid, Power transmission
• Each site is covered by several IP cameras,
  aggregated traffic is sent via Netronics link to
  the control center
• Multiple Point-to-Point architecture, using
  collocated radios in central Hub sites
• High-quality, real time video transmission 24x7

28
Wide Area ScenariosTransportation/Railways
Security
28
29
Case Study Traffic control
29

• A large-scale Traffic Surveillance Emergency
  Response project in Canada
• Transmitting high quality video from cameras
  installed along highways to Traffic Control
  Centers throughout the city
• Netronics robust systems were deployed in record
  time, and are operating flawlessly even in
  extreme temperatures of 30 degrees below

30
Case Study - Highway Surveillance
30

• Traffic surveillance along highways. Netronics
  systems transmit high-quality video from Highway
  to Traffic Control Centers
• Netronics provides wireless access to camera
  sites, and backhauling from local to central
  headquarters
• Low power consumption enables operation on solar
  power

31
Case Study - Highway SurveillanceContinued
31

• Systems enable traffic monitoring and fast
  response to highway incidents
• High quality, real-time video transmission 24x7
• Systems operate in interference conditions
  (pirate radio stations in area)
• Better pricing structure than competing solutions

32
Wide Area ScenariosBorder Protection
32
33
Case Study Border Control
33

• Customer Defense Forces
• Video surveillance along the border in long
  conflicted borders
• Netronics provides wireless access to camera
  sites, and backhauling from local to central
  headquarters
• Requirements included TDM interfaces, high
  capacity, long ranges, extreme environmental
  conditions

34
Summary Netronics Solution
34
Simple
Reliable Robust
High Capacity
Long Ranges
Flexible Scalable
Cost Effective

• Mission-critical, one problematic camera will
  not degrade other cameras
• Dedicated bandwidth per camera
• Support high-capacity consuming cameras
• Work in nLOS scenarios

35
Summary Netronics Solution
35
Simple
Reliable Robust
High Capacity
Long Ranges
Flexible Scalable
Cost Effective

• Variety of capacities, suitable for camera sites
  and backhaul

36
Summary Netronics Solution
36
Simple
Reliable Robust
High Capacity
Long Ranges
Flexible Scalable
Cost Effective

• suitable both for in-city short ranges and wide
  area long ranges

37
Summary Netronics Solution
37
Simple
Reliable Robust
High Capacity
Long Ranges
Flexible Scalable
Cost Effective

• Optional topologies star, ring, daisy-chain,
  cascading
• Support 4.9 GHz (public safety band) and
  multi-band
• Support 5/10/20 MHz channel bandwidth, maximum
  spectrum efficiency and flexibility in radio
  planning

38
Summary Netronics Solution
38
Simple
Reliable Robust
High Capacity
Long Ranges
Flexible Scalable
Cost Effective

• Competitive cost structure
• Pay as you grow model
• Reduced CAPEX

39
Summary Netronics Solution
39
Simple
Reliable Robust
High Capacity
Long Ranges
Flexible Scalable
Cost Effective

• Simple radio planning, training, installation
  maintenance
• Agnostic to camera and video applications levels
• Reduced OPEX

40
Thank you
41
What is Multiple Point-to-Point ?
41

• Single Hub site for multiple collocated radios
• Dedicated bandwidth per link
• Synchronized radio transmission reduces mutual
  interferences
• Unique architecture by Netronics

42
Multiple Point-to-Point Benefits Dedicated
Capacity
42

• New remote site requires high capacity
• Receives dedicated bandwidth
• No implication on service to other sites

43
Multiple Point-to-Point Benefits Robustness
43

• New remote site near or non line of sight harsh
  environment
• Rate and modulation for that link is reduced
• Directional Antenna - lower chances for
  interferenceto effect a specific link
• Other links are noteffected by theinterference

43
