An Introduction to adaptive filtering

1
An Introduction to adaptive filtering its
applications

• By
• Asst.Prof.Dr.Thamer M.Jamel
• Department of Electrical Engineering
• University of Technology
• Baghdad Iraq

2
Introduction

• Linear filters
• the filter output is a linear function of the
  filter input
• Design methods
• The classical approach
• frequency-selective filters such as
• low pass / band pass / notch filters etc
• Optimal filter design
• Mostly based on minimizing the mean-square
  value
• of the error signal

3
Wiener filter

• work of Wiener in 1942 and Kolmogorov in 1939
• it is based on a priori
• statistical information
• when such a priori
• information is not available,
• which is usually the case,
• it is not possible to design
• a Wiener filter in the first
• place.

4
Adaptive filter

• the signal and/or noise characteristics are often
  nonstationary and the statistical parameters
  vary with time
• An adaptive filter has an adaptation algorithm,
  that is meant to monitor the environment and vary
  the filter transfer function accordingly
• based in the actual signals received, attempts to
  find the optimum filter design

5
Adaptive filter

• The basic operation now involves two processes
• 1. a filtering process, which produces an
  output signal in response to a given input
  signal.
• 2. an adaptation process, which aims to adjust
  the filter parameters (filter transfer function)
  to the (possibly time-varying) environment
• Often, the (average) square value of the
  error signal is used as the optimization
  criterion

6
Adaptive filter

• Because of complexity of the optimizing
  algorithms most adaptive filters are digital
  filters that perform digital signal processing
• When processing
• analog signals,
• the adaptive filter
• is then preceded
• by A/D and D/A
• convertors.

7
Adaptive filter

• The generalization to adaptive IIR filters leads
  to stability problems
• Its common to use
• a FIR digital filter
• with adjustable
• coefficients

8
Applications of Adaptive Filters Identification

• Used to provide a linear model of an unknown
  plant
• Applications
• System identification

9
Applications of Adaptive Filters Inverse Modeling

• Used to provide an inverse model of an unknown
  plant
• Applications
• Equalization (communications channels)

10
Applications of Adaptive Filters Prediction

• Used to provide a prediction of the present value
  of a random signal
• Applications
• Linear predictive coding

11
Applications of Adaptive Filters Interference
Cancellation

• Used to cancel unknown interference from a
  primary signal
• Applications
• Echo / Noise cancellation
• hands-free carphone, aircraft headphones etc

12
ExampleAcoustic Echo Cancellation
13
(No Transcript)
14
(No Transcript)
15
LMS Algorithm

• Most popular adaptation algorithm is LMS
• Define cost function as mean-squared error
• Based on the method of steepest descent
• Move towards the minimum on the error
  surface to get to minimum
• gradient of the error surface estimated at
  every iteration

16
LMS Adaptive Algorithm

• Introduced by Widrow Hoff in 1959
• Simple, no matrices calculation involved in the
  adaptation
• In the family of stochastic gradient algorithms
• Approximation of the steepest descent method
• Based on the MMSE criterion.(Minimum Mean square
  Error)
• Adaptive process containing two input signals
• 1.) Filtering process, producing output signal.
• 2.) Desired signal (Training sequence)
• Adaptive process recursive adjustment of filter
  tap weights

17
LMS Algorithm Steps

• Filter output
• Estimation error
• Tap-weight adaptation

18
Stability of LMS

• The LMS algorithm is convergent in the mean
  square if and only if the step-size parameter
  satisfy
• Here ?max is the largest eigenvalue of the
  correlation matrix of the input data
• More practical test for stability is
• Larger values for step size
• Increases adaptation rate (faster adaptation)
• Increases residual mean-squared error

19
STEEPEST DESCENT EXAMPLE

• Given the following function we need to obtain
  the vector that would give us the absolute
  minimum.
• It is obvious that
• give us the minimum.
• (This figure is quadratic error function
  (quadratic bowl) )

20
STEEPEST DESCENT EXAMPLE

• We start by assuming (C1 5, C2 7)
• We select the constant . If it is too big,
  we miss the minimum. If it is too small, it would
  take us a lot of time to het the minimum. I would
  select 0.1.
• The gradient vector is

21
STEEPEST DESCENT EXAMPLE
As we can see, the vector c1,c2 converges to
the value which would yield the function minimum
and the speed of this convergence depends on .
22
LMS CONVERGENCE GRAPH
Example for the Unknown Channel of 2nd order
Desired Combination of taps
This graph illustrates the LMS algorithm. First
we start from guessing the TAP weights. Then we
start going in opposite the gradient vector, to
calculate the next taps, and so on, until we get
the MMSE, meaning the MSE is 0 or a very close
value to it.(In practice we can not get exactly
error of 0 because the noise is a random process,
we could only decrease the error below a desired
minimum)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
Adaptive Array Antenna
SMART ANTENNAS

• Adaptive Arrays

35
Adaptive Array Antenna
36
(No Transcript)
37

• Applications are many
• Digital Communications (OFDM , MIMO , CDMA, and
  RFID)
• Channel Equalisation
• Adaptive noise cancellation
• Adaptive echo cancellation
• System identification
• Smart antenna systems
• Blind system equalisation
• And many, many others

38
Adaptive Equalization
39
Introduction

• Wireless communication is the most
  interesting field of communication these days,
  because it supports mobility (mobile users).
  However, many applications of wireless comm. now
  require high-speed communications
  (high-data-rates).

40

• What is the ISI
• Inter-symbol-interference, takes place when a
  given transmitted symbol is distorted by other
  transmitted symbols.
• Cause of ISI
• ISI is imposed due to band-limiting effect of
  practical channel, or also due to the multi-path
  effects (delay spread).

41
(No Transcript)
42
(No Transcript)
43

• Definition of the Equalizer
• the equalizer is a digital filter that provides
  an approximate inverse of channel frequency
  response.
• Need of equalization
• is to mitigate the effects of ISI to decrease
  the probability of error that occurs without
  suppression of ISI, but this reduction of ISI
  effects has to be balanced with prevention of
  noise power enhancement.

44
(No Transcript)
45
Types of Equalization techniques

• Linear Equalization techniques
• which are simple to implement, but greatly
  enhance noise power because they work by
  inverting channel frequency response.
• Non-Linear Equalization techniques
• which are more complex to implement, but have
  much less noise enhancement than linear
  equalizers.

46
Equalization Techniques
Fig.3 Classification of equalizers
47

• Linear equalizer with N-taps, and (N-1) delay
  elements.
• Go

48
Table of various algorithms and their trade-offs
algorithm Multiplying-operations complexity convergence tracking
LMS Low slow poor
MMSE Very high fast good
RLS High fast good
Fast kalman Fairly Low fast good
RLS-DFE High fast good
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
Adaptive noise cancellation
54
Adaptive Filter Block Diagram
55
The LMS Equation

• The Least Mean Squares Algorithm (LMS) updates
  each coefficient on a sample-by-sample basis
  based on the error e(n).
• This equation minimises the power in the error
  e(n).

56
The Least Mean Squares Algorithm

• The value of µ (mu) is critical.
• If µ is too small, the filter reacts slowly.
• If µ is too large, the filter resolution is poor.

• The selected value of µ is a compromise.

57
LMS Convergence Vs u
58
Audio Noise Reduction

• A popular application of acoustic noise reduction
  is for headsets for pilots. This uses two
  microphones.

59
The Simulink Model
60
Setting the Step size (mu)

• The rate of convergence of the LMS Algorithm is
  controlled by the Step size (mu).
• This is the critical variable.

61
Trace of Input to Model

• Input Signal Noise.

62
Trace of LMS Filter Output

• Output starts at
• zero and grows.

63
Trace of LMS Filter Error

• Error contains
• the noise.

64
Typical C6713 DSK Setup
USB to PC
to 5V
Headphones
Microphone
65
Adaptive Echo Cancellation
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
Acoustic Echo Canceller
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
(No Transcript)
80
New Trends in Adaptive Filtering

• Partial Updating Weights.
• Sub-band adaptive filtering.
• Adaptive Kalman filtering.
• Affine Projection Method.
• Time-Space adaptive processing.
• Non-Linear adaptive filtering-
• Neural Networks.
• The Volterra Series Algorithm .
• Genetic Fuzzy.
• Blind Adaptive Filtering.

81
