MySQL

1
MySQL

• Would You Like Some Transactions With That Table?

2
Slides Are Available
3
What Is MySQL?

• Most popular open source RDBMS
• Open source means 'free'
• Really? No cost at all?
• Widely used
• Sabre airline reservations
• Google
• LinkedIn
• What does Oracle DBA need to know?
• Many differences...

4
Why Should I Care?

• I'm an Oracle DBA
• MySQL means nothing to me
• It isn't a 'real' RDBMS
• Why should I learn about MySQL?
• MySQL is being used by real businesses
• Can't hurt your employability
• Many jobs expect DBA to know multiple RDBMS
• Why not learn one that is widely used?
• And it's free you can download and install
  right now!

5
Oracle DBA Perspective

• What will we look at?
• Installing
• Start/stop
• How database/tables stored
• Backups
• Transactions
• Storage engines

6
My Message

• Compare MySQL to Oracle
• Not to be critical of MySQL
• Not to praise Oracle
• Make Oracle DBAs aware
• How much we assume about RDBMS
• Because Oracle does things a certain way
• MySQL is very different
• Assuming it is like Oracle can cause serious
  problems
• Does your business understand the differences?
• The cost of being 'free'?

7
MySQL Versions

• MySQL Enterprise
• Have to buy support
• MySQL Community Edition
• The 'free' version
• MySQL Community Edition Preview Release
• Available for download
• Ready for prime time?
• Oracle doesn't offer 12g for trial download...

8
MySQL Versions
9
MySQL Where Did It Come From?

• Used to store web site logs
• Transactions
• What's that?
• If we lose some records
• So what?
• Supported by an individual
• Do your own thing
• Recovery
• Not to worry, plenty more web logs every day

10
Some Differences MySQL/Oracle

• Oracle
• Database
• Schema
• a group of database objects
• Database user
• Maps to a database schema
• MySQL
• Server
• Databases
• Group of database objects
• Users don't map to database

11
Some Differences MySQL/Oracle

• Storage engines
• Transaction support
• Performance
• Hot backup
• Binary logging and recovery
• Table locking
• Corruption
• Misc.

12
Storage Engines

• MySQL gives you a choice
• Oracle, all transactional all the time (OATATT)
• MySQL storage engines
• MyISAM (IBM, Indexed Sequential Access Method)
• Very fast read
• InnoDB
• Transactional, like Oracle
• Separate software, owned by Oracle
• Many others
• See next chart

13
Storage Engines
14
InnoDB Storage Engine

• Imagine mixing
• MyISAM, InnoDB tables in a statement
• What does 'transactional' mean?
• What does recovery mean?

15
CSV Storage Engine

• CSV storage engine
• Stores data in text files
• Using comma-separated format

16
Blackhole Storage Engine

• My favorite

This is where we store all the data relating to
the Raiders and their 'Commitment to Excellence'
17
Yeah, But...

• No problem
• I'll just make all the tables InnoDB
• Cool, but
• MySQL catalog (system?) tables are MyISAM
• Can't change them
• Table storage engine can be changed at any time
• Privileged users
• No one should do this, but...stuff happens
• Create table syntax
• Supports overriding default storage engine

18
Transaction Support

• MyISAM
• Default table type
• Table type of system databases
• Does not support transactions
• Example
• Writing to MyISAM tables and server crashes
• Who know what was and wasn't written to tables
• No recovery

19
Performance

• Many large MySQL servers in use
• Performance must be good
• or good enough for 'free'
• Optimizer
• Different storage engines
• How to optimize statement that has
• MyISAM tables
• InnoDB tables
• Does it support all storage engines you are using?

20
Hot Backup

• MySQL does not have this
• Backup option 1
• Shutdown server, copy all files, startup server
• Backup option 2
• Lock all tables
• Dump all data to a dump file
• Dump file is set of SQL to recreate database
• Very slow to recover
• Backup option 3
• Buy hot backup software product
• Not free

21
Binary Logging and Recovery

• MySQL
• Default, no logging
• You can configure binary logging
• Three formats
• Statement-based
• Row-based
• Mixed
• Binary log filenames have format
• binlog.000001, binlog.000002, etc.
• You must apply them in correct order

22
MySQL Binary Logs

• MySQL does not have any way of knowing when
  replaying the binary logs which statements need
  to be executed and which are already committed.
• Oracle DBA doesn't worry about this
• Oracle checks and tells you which archived redo
  log is needed next
• Oracle won't allow archived redo logs to be
  applied out of order

23
Binary Logging Formats
24
Binary Log Issues
25
Table Locking

• MyISAM storage engine
• Does not support row level locking
• Table locks
• Performance?
• InnoDB storage engine
• Supports row level locking

26
Corruption

• Oracle
• I have rarely seen any cases
• But all tables support transactions
• MySQL
• What does it mean to rollback
• When different storage engines involved
• Some support transactions, some don't
• Some tables will be rolled back
• Others won't
• Is this corruption?

27
MySQL Corruption Issues

• Good read
• Discusses corruption issues in MySQL engines
• I'm not saying this happens often
• But you need to be aware of these issues
• Another difference from Oracle
• Different storage engines, different corruption
  mechanisms
• http//www.mysqlperformanceblog.com/2006/07/30/mys
  ql-crash-recovery/

28
MySQL Issues

• Misc
• Referential Integrity
• Some storage engines support
• Triggers
• Row-level, not statement-level
• Directload
• Not supported
• Parallel Query
• Not supported

29
MySQL Issues

• White Paper
• Compares MySQL to PostgreSQL
• PostgreSQL, another open source RDBMS
• More like Oracle than MySQL
• Discusses issues with MySQL
• I'm not endorsing PostgreSQL
• But the whitepaper is very good
• Google
• PostgreSQL vs. MySQL A Comparison of Enterprise
  Suitability

30
MySQL Table Storage

• MyISAM
• Each table has three files
• ltfilenamegt.frm Data dictonary information
• ltfilenamegt.MYD table data
• ltfilenamegt.MYI table indexes
• InnoDB
• Data and indexes in a tablespaces
• Made up of one or more datafiles
• Sound familiar?

31
Documentation Online
32
Documentation Online
33
Documentation Online
34
Talk Is Cheap

• A little less conversation
• A little more action
• Download and install MySQL to your laptop now
• Slides show the steps
• Windows
• You will have a fully functional MySQL server
• Start learning right now

35
Install MySQL Windows

• Windows Vista
• 6.0 Service Pack 1
• Screenshots shown
• Windows XP
• Professional Version 5.1
• Same steps
• Very minor differences in what you see

36
Downloads?
37
Downloads?
38
Enterprise Version
39
Community Version
40
Windows Downloads
41
Windows Installation
42
Windows Installation
43
Windows Installation
44
Windows Installation
45
Windows Installation
46
Windows Installation
47
Windows Installation
48
Windows Installation
49
Windows Installation
50
Windows Installation
Uncheck
51
Windows Installation
52
Windows Installation
Check
53
Windows Installation
54
Windows Installation
mysql
55
Windows Installation
56
Accessing MySQL Windows

• Click Start
• Programs
• MySQL
• MySQL Server 5.1
• MySQL Command Line Client
• Right-click
• Send to
• Desktop (Create Shortcut)
• Double-click desktop icon
• MySQL Command Line Client

57
Accessing MySQL Windows
Shortcut created at installation
mysql
58
mysql client utility

• Similar to SQLPlus

59
Now What?

• Stop, start MySQL server
• What databases are available
• show databases
• Set default database
• use ltdbnamegt
• What tables are in the database
• show tables

60
Windows Vista

• Stop/Start
• Services
• Start
• Settings
• Control Panel
• System and Maintenance
• Administrative Tools
• Services
• Scroll down to MySQL, highlight
• Upper left, options for Stop, Pause, Restart
• If MySQL is down, option to Start

61
Windows XP

• Stop/Start
• Command line
• net stop mysql, net start mysql
• Services
• Start
• Control Panel
• Administrative Tools
• Services
• Services window
• Scroll down to MySQL, highlight
• Upper left, options for Stop, Pause, Restart
• If MySQL is down, option to Start

62
(No Transcript)
63
(No Transcript)
64
System Databases

• INFORMATION_SCHEMA
• Catalog database
• MYSQL database
• User and privilege information
• TEST
• For you to play in...
• These databases are created at installation

65
MySQL Server Configuration

• Controlled by 'option' file(s)
• Similar to Oracle pfile or spfile
• SHOW VARIABLES
• See current values
• Standard location(s)
• Search order
• One of the most common problems
• Persons don't know where these files are
• Make changes that don't take affect
• Can't find the file or files

66
Option File(s)

• MySQL searches multiple locations
• Uses most recent value of each parameter
• How to know all files being scanned by MySQL?
• mysql help

Note dash dash help
67
Option File
68
Option File
69
Option File
70
Option File
71
Option File
72
MySQL Filesystem Layout

• From option file (my.ini)
• basedir
• Where software is stored
• datadir
• Where table data is stored

73
MySQL basedir
74
MySQL basedir/bin
75
MySQL datadir
76
MySQL Log Files

• General Query Log
• All client requests
• Binary Log
• Statements that modify data
• Slow Query Log
• Statements that take longer than 10 seconds
• Error Log
• Server messages

77
MySQL Log Files

• Find log file locations

78
Summary

• MySQL is 'free'
• May need other products to make it work for you
• Hot backup for example
• MySQL is widely used
• MySQL is very different from Oracle
• DBA tasks and issues will be different
• MySQL is not better or worse than Oracle
• Just very different

79
The End?

• You now have a MySQL server installed
• No excuses
• Learn it, live it, love it
• Update your resume
• Next?
• Multiple MySQL servers on same machine
• Replication
• etc.
