Bioinformatics, Data Integration and Machine Learning a Thesis Proposal

1
Bioinformatics, Data Integration and Machine
Learninga Thesis Proposal

• Kaushik Sinha
• Supervisors Prof. Gagan Agrawal and Prof.
  Mikhail Belkin

2
Roadmap

• Motivation
• Our Approach
• Current Work
• Learning Layouts of Flat-file Biological Datasets
• Exploratory Tools for Biological Data Analysis
• Proposed Work
• Deep Web Mining for Biological Data
• Semi-supervised Ranking
• Multiple-instance Learning
• Conclusion

3
Motivation

• Integration is hard
• Data explosion
• Data size number of data sources
• New analysis tools
• Autonomous resources
• Heterogeneous data representation various
  interfaces
• Frequent Updates
• New trend web and grid services

4
Motivation contd

• In recent years DNA microarry and other gene and
  protein assays have become essential tools for
  biologists
• Next step of biological enquiry is to find out
• What is known about these genes?
• How are these genes related to each other or
  other genes identified in similar studies?
• However, major difficulties are
• How do we extract key properties shared by a
  candidate genes?
• How do we generate reasonable hypothesis to
  explain them?
• How do we define and evaluate similarity between
  sets of genes?

5
Motivating Example

• Suppose after a micro array experiment a
  biologist suspects that a small set of genes are
  related to a disease
• This can be confirmed by searching existing
  literature
• One would expect related genes to appear together
  in literature
• Due to sheer volume
• Searching is time consuming and error prone
• Some complications could arise as well
• However, suppose Gene A and C are related and
  both of them are weakly related to gene B
• In literature, one would expect
• A,C appear together OR/AND
• A,B appear together
• B,C appear together
• How do we efficiently conclude that A,C are
  actually related?

6
Our Approach

• Using data mining / machine learning techniques
  to extract useful information from biological
  data
• Different forms of data
• Flat-file data
• Microarray data
• Online literature abstracts
• Develop different forms of tools
• Layout extractor
• Hypergraph mining
• Similarity measure among sets of genes

7
Roadmap

• Motivation
• Our Approach
• Current Work
• Learning Layouts of Flat-file Biological Datasets
• Exploratory Tools for Biological Data Analysis
• Proposed Work
• Deep Web Mining for Biological Data
• Semi-supervised Ranking
• Multiple-instance Learning
• Conclusion

8
Learning Layout of a Flat-File

• In general intractable
• Try and learn the layout, have a domain expert
  verify
• Key issue what delimiters are being used ?

9
Finding Delimiters

• Some knowledge from domain expert is required
  (Semi-automatic)
• Naïve approaches
• Frequency Counting
• Counts frequently occurring single tokens (word
  separated by space)
• Sequence Mining
• Counts frequently occurring sequence of tokens

10
Assumptions

• Biological datasets are written for humans to
  read
• It is very unlikely that delimiters will be
  scattered all around, in different places in a
  line
• Position of the possible delimiters might provide
  useful information
• Combination of positional and frequency
  information might be a better choice

11
Positional Weight

• Let P be the different positions in a line where
  a token can appear
• For each position i ? P, tot_seqji represents
  total of token sequences of length j starting
  at position i
• For each position i ? P, tot_unique_seqji
  represents total of unique token sequences of
  length j starting at position i
• For any tuple (i,j), p_ratio(i,j) is defined as
  shown above
• p_ratio(i,j) can be log normalized to get
  positional weight, p_wt(i,j) with the property
  p_wt(i,j) ? (0,1)

12
Delimiter score (d_score)

• Frequency weight for any token sequence sji with
  length j and starting at position i, f_wt(sji),
  is obtained by log normalizing frequency f(sji)
• Obviously, f_wt(sji) ? (0,1)
• Positional and frequency weight now can be
  combined together to get d_score as follows,
• d_score(sji) a p_wt(i,j) (1-a) f_wt(sji)
• Where a ?(0,1)
• Thus d_scrore has the following two properties,
• d_score(sji) ?(0,1)
• d_score(sji) gt d_score(sjk) implies sji is more
  likely to be a delimiter than sjk

13
Generating layout descriptor

• Once the delimiters are identified, an NFA can be
  built scanning the whole database where,
  delimiters are different states of the NFA
• This NFA can be used to generate a layout
  descriptor since it nicely represents optional
  and repeating states
• The following figures shows an NFA, where A, B,
  C, D, and E are delimiters with B being an
  optional delimiter and C D being a repeating
  delimiters

14
Results

• By suitably varying a, a tight superset of
  possible delimiters are found
• A domain expert can then help to identify the
  true delimiters
• Results from 3 different flat file datasets are
  as follows

15
Comparison with naïve approaches

• d_score based approach definitely does a better
  job as compared to the naïve approaches
• The following table clearly shows the improvement

16
Realistic Situation

• The task of identifying complete list of correct
  delimiters is difficult
• Most likely we will end up with getting an
  incomplete list of delimiters
• The delimiters which does not appear in every
  data record (optional) are the ones to be
  possibly missed

17
Identifying Optional Delimiters

• Given a list of incomplete delimiters how can we
  identify optional delimiters, if any?
• Build a NFA based on given incomplete information
• Perform clustering to identify possible crucial
  delimiters
• Perform contrast analysis

18
Crucial delimiter

• A delimiter is considered crucial, if missing
  delimiters will appear immediately following
  these delimiters
• The goal is to create two clusters,
• one having delimiters which are not crucial
• The other one having crucial delimiters

19
Identifying crucial delimitersA few definitions

• Succ(X) Set of delimiters that can immediately
  follow X
• Dist_App of groups of occurrences of X based
  on of text lines between X and immediately next
  delimiter
• Info_Tuple(nXi,fXi,tXi) Information for each
  Dist_App
• Info_Tuple_List Lx For any X, list of all
  possible Info_Tuple.

20
Metric for clustering

• rXf is likely to be low if an optional delimiter
  appears immediately after X, and high otherwise
• Choose a suitable cut-off value rc and assign
  delimiters to different groups as follows,-
• If rXf lt rc, assign X to a group containing
  possible crucial delimiters
• Else assign X to the group containing non crucial
  delimiters

21
Observations and Facts

• Missing optional delimiters can appear
  immediately after crucial delimiters ONLY
• Non-crucial delimiters can be pruned away
• Consider two Info_Tuples (nX1, fX1 ,tX1) and
  (nX2, fX2 ,tX2) in LX
• If a missing delimiter appears immediately after
  the appearance corresponding to the first tuple
  but not the second one,-
• nX1 gt nX2
• Missing delimiter will appear in tX1 but not in
  tX2

22
A hypothetical example illustrating Contrast
Analysis

• Suppose, X is a crucial delimiter having 2
  Info_tuples, L1 and L2 , as follows,
• L1(50, 20, l1 .txt)
• L2(20, 12, l2 .txt)
• Sequence mining on l1 .txt and l2 .txt yields two
  sets of frequently occurring sequences, S1 and
  S2 , as follows,
• S1 f1 , f5 , f6 , f8 , f13 , f21
• S2 f1 , f4 , f6 , f7 , f8 , f10 , f13 , f21
• Since but , f5 is a possible
  missing delimiter
• f5 is a missing delimiter only if it has a high
  d_score or is verified by a domain expert as a
  valid delimiter

23
Contrast Analysis

• For any i,j, if nXi gt nXj , look for frequently
  occurring sequences in tXi and tXj, call them
  fsXi and fsXj respectively
• If there exists a frequent sequence fs such
  that, but then, fs is quite
  likely to be a possible delimiter
• If fs has a fairly high d_score or identified by
  a domain expert as valid delimiter add it to the
  incomplete list as newly found delimiter

24
Generalized Contrast Analysis

• In case of more than two Info_Tuples, identify
  mean of all nXi values
• Form a group by appending text from all
  Info_Tuples, where
• Form another group by appending text from all
  Info_Tuples, where
• Perform contrast analysis among all such possible
  groups

25
Another example illustrating Generalized Contrast
Analysis

• Suppose, X is a crucial delimiter having 3
  Info_tuples, L1 , L2 , L3 , as follows,
• L1(50, 20, l1 .txt)
• L2(20, 12, l2 .txt)
• L3(15, 10, l3 .txt)
• Mean number of lines,
• Append l2 .txt and l3 .txt , call it t2 .txt
• Sequence mining on l1 .txt and t2 .txt yields two
  sets of frequently occurring sequences, S1 and
  S2 , as follows,
• S1 f1 , f5 , f6 , f8 , f13 , f21
• S2 f1 , f4 , f6 , f7 , f8 , f10 , f13 , f21
• Since but , f5 is a possible
  missing delimiter
• f5 is a missing delimiter only if it has a high
  d_score or is verified by a domain expert as a
  valid delimiter

26
Overall Algorithms
27
Results Optional delimiters

• Pruning

28
Results Non-optional Missing delimiters

• Even though designed for finding optional
  delimiters, our algorithms works, in some cases,
  for missing non-optional delimiters too
• If a missing non-optional delimiter appears
  exactly in the same location in each record, then
  our algorithm fails
• If a non-optional delimiter has a backward edge
  coming from a delimiter that appears later in a
  topologically sorted NFA then our algorithm works

29
Roadmap

• Motivation
• Our Approach
• Current Work
• Learning Layouts of Flat-file Biological Datasets
• Exploratory Tools for Biological Data Analysis
• Proposed Work
• Deep Web Mining for Biological Data
• Semi-supervised Ranking
• Multiple-instance Learning
• Conclusion

30
Hypergraph Mining

• Basic Motivation
• To find useful Transitive Relation
  (hypergraphs) among genes
• Example (Gene-Disease Relationship)
• Gene A is related to a gene B
• Gene B is related to a gene C
• Is Gene A related to Gene C ?
• Gene Source
• Microarray Experiments
• Information Source
• Online Literature abstracts

31
Formal Problem Definition

• Given
• A dictionary KT of keywords
• A dictionary KM of user provided key words
  (KT?KM)
• Collection of literature abstracts,- each
  abstract is represented as a set of keywords
• Task
• To find hyperedges exceeding user defined
  threshold, each of which involves a set of key
  words from KM and are potentially connected by
  another set of linking words from KT-KM

32
Modeling

• Purpose
• To use a similar approach as frequent itemset
  mining
• Define
• total weightsupport cross support
• Support set of keywords appear together in one
  document
• Cross support set of keywords can be partitioned
  so that each partition appears in different
  document
• Issues
• Since downclosure property does not hold for
  total weight modified downclosure property can be
  defined

33
Idea

• Support satisfies downclosure property
• Let X be a set, O be its power set. A function f
  O ?R satisfies downclosure property if for all
  A,B ? O , A ? B ,f(B)gtf(A)
• Cross support can be designed to be restricted
  below a particular value, i.e., it is bounded
• Form a function h as addition of two functions
  hfg
• f satisfies downclosure property
• g is bounded
• h satisfies modified down closure property
• For any ?0, if h(Kn) ? then f(Kn-1)
  max0,(?-sup(g))
• This property can be used to devise efficient
  algorithm

34
Results
35
Similarity Measure among sets of genes

• Each file containing gene names can be considered
  as a Discrete Random Variable (DRV)
• Each such DRV can take several values (gene
  names)
• For two such files X,Y and for any pair (x,y),
  x?X and y?Y, p(x,y) can be computed from online
  abstracts based on co-occurrence
• Now defining Zg(X,Y), Z is a RV
• Expectation of Z can be used as a similarity
  measure
• Different g gives rise to different similarity
  measure

36
Roadmap

• Motivation
• Our Approach
• Current Work
• Learning Layouts of Flat-file Biological Datasets
• Exploratory Tools for Biological Data Analysis
• Proposed Work
• Deep Web Mining for Biological Data
• Semi-supervised Ranking
• Multiple-instance Learning
• Conclusion

37
Query Planning for Deepweb Mining

• A huge source of online biological information is
  available in the form of deepweb
• An online query form query form needs to be
  filled out
• Required information is available by filling out
  may such forms from different websites
• There might be some dependency among these forms
• Requires Redundancy elimination

38
Roadmap

• Motivation
• Our Approach
• Current Work
• Learning Layouts of Flat-file Biological Datasets
• Exploratory Tools for Biological Data Analysis
• Proposed Work
• Deep Web Mining for Biological Data
• Semi-supervised Ranking
• Multiple-instance Learning
• Conclusion

39
Semi-supervised Ranking

• Ranking
• Given a training set of examples with labels/pair
  wise relationships
• Task is to rank an unseen test set, i.e. to get a
  permutation so that relevant examples are ranked
  higher than irrelevant ones
• This corresponds to learning a ranking function
• Semi-supervised Ranking
• Incorporating unlabeled examples to learn the
  ranking function
• Out of sample extension

40
Potential Application

• Following a microarray experiment it might be
  possible to guess if gene A is more important
  than gene B involved in the experiment
• However all possible order relationship is time
  consuming end error prone
• Thus, from a small set of order relationship and
  using other genes from the experiment as
  unlabeled data a semi-supervised ranking function
  can be learned

41
Roadmap

• Motivation
• Our Approach
• Current Work
• Learning Layouts of Flat-file Biological Datasets
• Exploratory Tools for Biological Data Analysis
• Proposed Work
• Deep Web Mining for Biological Data
• Semi-supervised Ranking
• Multiple-instance Learning
• Conclusion

42
Multiple Instance Learning

• Instead of instance-label pair (x,y), bag-label
  pair (B,y) is provided as training data
• A bag contains multiple instances
• A bag label is negative, if each instance in the
  bag has negative label
• A bag label is positive, if there exists at least
  one instance with positive label
• Given an unseen bag, the task is to predict its
  label

43
Potential Application

• Following a microarray experiment it might be
  possible to form bags of genes with appropriate
  labels
• From different biological labs doing similar
  experiments, many such bags can be obtained to
  use as training data
• Before, designing a new microarray experiment,
  gene set can be selected based on multiple
  instance learning

44
Summary

• Use of data mining /machine learning techniques
  to extract information for biological data
• Work done
• Learning layouts of flat-file biological datasets
• Hypergraph Mining
• Similarity Measure among sets of genes
• Proposed Work
• Study and application of machine learning
  techniques
