Chemical Bonding

1
Chemical Bonding

• Chapter 8 Sections 1 2

2

• A chemical bond is a force of attraction between
  any two atoms in a compound.
• Bonding between atoms occurs because it creates a
  more stable arrangement for the atoms.

3
Lewis Symbols Dot Diagrams

• Convenient way to show the valence electrons

4
Three types of bonding

• Metallic bonding results from the attraction
  between metal atoms and the surrounding sea of
  electrons
• Ionic bonding results from the electrical
  attraction between large numbers of cations and
  anions
• Covalent bonding results from the sharing of
  electron pairs between two atoms

5
Ionic Bonding

• Many atoms transfer electrons and other atoms
  accept electrons, creating cations (positive
  metal ions) and anions (negative nonmetal ions).
• The resulting ions are attracted to each other by
  electrostatic force.

6
Ionic bonding between Na and Cl
7
(No Transcript)
8
Covalent bonding

• In many cases electrons do not completely
  transfer from one atom to another.
• The electrons between atoms are shared.

9
Covalent bonding between H2

• Hydrogens electron configuration is 1s1
• Because both H atoms need 1 more electron to
  become isoelectronic with He, it is unlikely that
  either will give up an electron.

10
Covalent bonding between H2

• ?

1s
?
1s
They share the two electrons. H H ?
H H
11
Types of Covalent Bonds

• When electrons are shared equally the bond is
  called a NONPOLAR covalent bond. (i.e. H2)
• Sometimes the electrons between two atoms are NOT
  shared equally. The bond created is called a
  POLAR covalent bond.
• . . . .
• H Cl ? HCl
• . . . .

12
Polar Covalent Bonding

• An example of this would be HCl.

HCl molecule Hydrogen atom
? 1s
Ne ?? ?? ?? ? 3s
3p
Chlorine atom
13
How to classify bond types

• Electronegativity measure of the ability of an
  atom to attract electrons in a chemical bond
• Each element on the periodic table is assigned an
  electronegativity value (see page 353) that
  ranges from 0.7 to 4.0.
• The difference in the electronegativity
  determines the bonding type (ionic, polar
  covalent, or nonpolar covalent).

14
If the electronegativity difference is

• 1.7 and higher ionic
• 0.3 to 1.7 polar covalent
• 0.0 to 0.3 nonpolar covalent

15
What if I get an electronegativity difference
that is 0.3 or 1.7?

• These cut-off numbers are guidelines.
• It is a gradual change not stair-step.

16
Ionic Character

• As the electronegativity difference increases,
  the ionic character increases as well!

17
Practice Problems

• What type of bond will occur between iodine and
  the following elements cesium, iron, and sulfur?

Bonding between I and Electronegativity difference Bond Type
Cesium
Iron
Sulfur
18
Answers to problems
Bonding between I and Electronegativity difference Bond Type
Cesium 2.5 0.7 1.8 Ionic
Iron 2.5 1.8 0.7 Polar covalent
Sulfur 2.5 2.5 0.0 Nonpolar covalent
19
Determine the type of bond between the following
pairs.
Bonding between Electronegativity difference Bond type
Li Cl
S O
Ca Br
P H
Si Cl
S Br
20
Answers
Bonding between Electronegativity difference Bond type
Li Cl 3.0 1.0 2.0 Ionic
S O 3.5 2.5 1.0 Polar covalent
Ca Br 2.8 1.0 1.8 Ionic
P H 2.1 2.1 0.0 Nonpolar covalent
Si Cl 3.0 1.8 1.2 Polar covalent
S Br 2.8 2.5 0.3 Nonpolar covalent
