Control and Monitoring of Hydrogen Sulfide in Digester Gas

1
Control and Monitoring of Hydrogen Sulfide in
Digester Gas

• Steve Walker
• Craig Barnes
• Metro Wastewater Reclamation District

2

Metro Districts Central Treatment Plant
3
What to Use to Control H2S

• Equipment
• Iron vs. Aluminum Salts
• Dewatering Issues
• 503 Regulations Aluminum under scrutiny in
  Round 2
• Iron beneficial for crops and other plants

4
Districts Reasons to Reduce the Amount

• Potential offsite buyer for methane - gas
  contaminated with 3000 ppm H2S
• Tried ferrous chloride from suppliers
  recommendation
• Tried ferric chloride as an alternative

5
Reasons for Alternatives

• Cost Comparison
• Flexibility
• Impacts on Processes

6
Results

• Cost active pounds/digester loading Same
• Reaction time slower with ferrous
• Flexibility proven could use either product

7
Addition Points Impacts

• Primary Influent
• Ferrous
• Ferric
• DAF Conditioning Box
• Ferrous
• Ferric

8
Use of Ferric After Testing

• H2S impacts on cogeneration equipment
• Equipment reliability
• Destruction of yellow metal parts
• Acidification of engine oil
• Struvite reduction

9
12 cyl. Turbo 2000 hp w/1200 kW gen - 1 of 4
10
Engines required extensive maintenance
11
Trigens Turbine control panel with PLC
12
Trigens pride and joy - Centaur 40 Turbine
13
Current Usage and Why

• Goal Title V Air Permit Compliance
• Limit of 169 tons per year SO2 to atmosphere
• H2S ceiling of 2000 ppm with running 3 hour
  average of 1800 ppm
• Ferric onsite used for struvite control in
  dewatering process
• Handling one chemical vs. two - KISS

14
Current Dosing Points

• Digester Feed Line
• DAF Conditioning Box
• NSEC Influent Channel

15
Ni/Deni Aeration Basin - 1 of 12
16
Current Results

• Gas production remains at 4MSCFD
• Holding H2S levels at 900 ppm /- 100 with
  consistent feed rate
• Minimal Process Impacts
• Foaming
• Struvite

17
NOTE

• High flow in spring 2001 reduced sulfide
  generators in the collection system by flushing
  the piping. This made results seem better.
  Dosages are back to traditional levels now.

18
Dosage Rate

• Roughly 0.3 gpm ferric solution to 650 gpm
  digester feed or
• Roughly 2000 pounds/day to 340,000 pounds TS 12
  active lb/ton
• Digesters are fed sequentially so all get
  equivalent dose

19
Calculation

• 0.3 gal/min x 8.34 lb/gal x 1.4 (specific
  gravity) x iron in solution (40) x 1440
  min/day 2000 lb/day of iron
• Lb/day x 0.10/lb x 365 days/yr 73,000

20
Note the floating cover on Digester 6
21
Monitoring

• Effectiveness checked with GC Mass Spec twice
  per week from grab sample
• This would not meet the requirements of the
  current air permit
• APCD permit required installation of Continuous
  Monitoring System (CMS)

22
Digester Flares
23
Turbine Exhaust
24
Continuous Monitoring System (CMS) Requirements

• Continuous gas stream H2S monitoring
• Continuous data transmission and recording
• Instrument reliability
• Relative Accuracy Test Audit (RATA) compliant

25
LasIR Unit
26
Control Unit
27
Control Unit Display
28
Modifications Needed After Initial Installation

• Inability to meet accepted calibration protocol
• Extractive method required
• Water vapor in digester gas impacted reliability

29
White Cell
30
LasIR Reconfiguration

• Sensor upgrade - aka White Cell

31
Layout of the Multi-pass Extractive Monitor Head
Alak Chanda 04January 2001
32
LasIR Upgrades

• Laser modified for extractive analysis
• Nitrogen gas used for purge and zeroing
• H2S calibration gas incorporated

33
Cal and Purge Gas
34
Results

• Instrument has proven reliable
• Permit compliance achieved

35
Future Use

• Instrument will control ferric dosing
• ANY QUESTIONS?
