High Performance Linux Clusters

1
High Performance Linux Clusters

• Guru Session, Usenix, Boston
• June 30, 2004
• Greg Bruno, SDSC

2
Overview of San Diego Supercomputer Center

• Founded in 1985
• Non-military access to supercomputers
• Over 400 employees
• Mission Innovate, develop, and deploy technology
  to advance science
• Recognized as an international leader in
• Grid and Cluster Computing
• Data Management
• High Performance Computing
• Networking
• Visualization
• Primarily funded by NSF

3
My Background

• 1984 - 1998 NCR - Helped to build the worlds
  largest database computers
• Saw the transistion from proprietary parallel
  systems to clusters
• 1999 - 2000 HPVM - Helped build Windows clusters
• 2000 - Now Rocks - Helping to build Linux-based
  clusters

4
Why Clusters?
5
Moores Law
6
Cluster Pioneers

• In the mid-1990s, Network of Workstations project
  (UC Berkeley) and the Beowulf Project (NASA)
  asked the question

Can You Build a High Performance Machine
From Commodity Components?
7
The Answer is Yes
Source Dave Pierce, SIO
8
The Answer is Yes
9
Types of Clusters

• High Availability
• Generally small (less than 8 nodes)
• Visualization
• High Performance
• Computational tools for scientific computing
• Large database machines

10
High Availability Cluster

• Composed of redundant components and multiple
  communication paths

11
Visualization Cluster

• Each node in the cluster drives a display

12
High Performance Cluster

• Constructed with many compute nodes and often a
  high-performance interconnect

13
Cluster Hardware Components
14
Cluster Processors

• Pentium/Athlon
• Opteron
• Itanium

15
Processors x86

• Most prevalent processor used in commodity
  clustering
• Fastest integer processor on the planet
• 3.4 GHz Pentium 4, SPEC2000int 1705

16
Processors x86

• Capable floating point performance
• 5 machine on Top500 list built with Pentium 4
  processors

17
Processors Opteron

• Newest 64-bit processor
• Excellent integer performance
• SPEC2000int 1655
• Good floating point performance
• SPEC2000fp 1691
• 10 machine on Top500

18
Processors Itanium

• First systems released June 2001
• Decent integer performance
• SPEC2000int 1404
• Fastest floating-point performance on the planet
• SPEC2000fp 2161
• Impressive Linpack efficiency 86

19
Processors Summary
Processor GHz SPECint SPECfp Price
Pentium 4 EE 3.4 1705 1561 791
Athlon FX-51 2.2 1447 1423 728
Opteron 150 2.4 1655 1644 615
Itanium 2 1.5 1404 2161 4798
Itanium 2 1.3 1162 1891 1700
Power4 1.7 1158 1776 ????
20
But What You Really Build?

• Itanium Dell PowerEdge 3250
• Two 1.4 GHz CPUs (1.5 MB cache)
• 11.2 Gflops peak
• 2 GB memory
• 36 GB disk
• 7,700
• Two 1.5 GHz (6 MB cache) makes the system cost
  17,700
• 1.4 GHz vs. 1.5 GHz
• 7 slower
• 130 cheaper

21
Opteron

• IBM eServer 325
• Two 2.0 GHz Opteron 246
• 8 Gflops peak
• 2 GB memory
• 36 GB disk
• 4,539
• Two 2.4 GHz CPUs 5,691
• 2.0 GHz vs. 2.4 GHz
• 17 slower
• 25 cheaper

22
Pentium 4 Xeon

• HP DL140
• Two 3.06 GHz CPUs
• 12 Gflops peak
• 2 GB memory
• 80 GB disk
• 2,815
• Two 3.2 GHz 3,368
• 3.06 GHz vs. 3.2 GHz
• 4 slower
• 20 cheaper

23
If You Had 100,000 To Spend On A Compute Farm
System of Boxes Peak GFlops Aggregate SPEC2000fp Aggregate SPEC2000int
Pentium 4 3 GHz 35 420 89810 104370
Opteron 246 2.0 GHz 22 176 56892 57948
Itanium 1.4 GHz 12 132 46608 24528
24
What People Are Buying

• Gartner study
• Servers shipped in 1Q04
• Itanium 6,281
• Opteron 31,184
• Opteron shipped 5x more servers than Itanium

25
What Are People Buying

• Gartner study
• Servers shipped in 1Q04
• Itanium 6,281
• Opteron 31,184
• Pentium 1,000,000
• Pentium shipped 30x more than Opteron

26
Interconnects
27
Interconnects

• Ethernet
• Most prevalent on clusters
• Low-latency interconnects
• Myrinet
• Infiniband
• Quadrics
• Ammasso

28
Why Low-Latency Interconnects?

• Performance
• Lower latency
• Higher bandwidth
• Accomplished through OS-bypass

29
How Low Latency Interconnects Work

• Decrease latency for a packet by reducing the
  number memory copies per packet

30
Bisection Bandwidth

• Definition If split system in half, what is the
  maximum amount of data that can pass between each
  half?
• Assuming 1 Gb/s links
• Bisection bandwidth 1 Gb/s

31
Bisection Bandwidth

• Assuming 1 Gb/s links
• Bisection bandwidth 2 Gb/s

32
Bisection Bandwidth

• Definition Full bisection bandwidth is a network
  topology that can support N/2 simultaneous
  communication streams.
• That is, the nodes on one half of the network can
  communicate with the nodes on the other half at
  full speed.

33
Large Networks

• When run out of ports on a single switch, then
  you must add another network stage
• In example above Assuming 1 Gb/s links, uplinks
  from stage 1 switches to stage 2 switches must
  carry at least 6 Gb/s

34
Large Networks

• With low-port count switches, need many switches
  on large systems in order to maintain full
  bisection bandwidth
• 128-node system with 32-port switches requires 12
  switches and 256 total cables

35
Myrinet

• Long-time interconnect vendor
• Delivering products since 1995
• Deliver single 128-port full bisection bandwidth
  switch
• MPI Performance
• Latency 6.7 us
• Bandwidth 245 MB/s
• Cost/port (based on 64-port configuration) 1000
• Switch NIC cable
• http//www.myri.com/myrinet/product_list.html

36
Myrinet

• Recently announced 256-port switch
• Available August 2004

37
Myrinet

• 5 System on Top500 list
• System sustains 64 of peak performance
• But smaller Myrinet-connected systems hit 70-75
  of peak

38
Quadrics

• QsNetII E-series
• Released at the end of May 2004
• Deliver 128-port standalone switches
• MPI Performance
• Latency 3 us
• Bandwidth 900 MB/s
• Cost/port (based on 64-port configuration) 1800
• Switch NIC cable
• http//doc.quadrics.com/Quadrics/QuadricsHome.nsf/
  DisplayPages/A3EE4AED738B6E2480256DD30057B227

39
Quadrics

• 2 on Top500 list
• Sustains 86 of peak
• Other Quadrics-connected systems on Top500 list
  sustain 70-75 of peak

40
Infiniband

• Newest cluster interconnect
• Currently shipping 32-port switches and 192-port
  switches
• MPI Performance
• Latency 6.8 us
• Bandwidth 840 MB/s
• Estimated cost/port (based on 64-port
  configuration) 1700 - 3000
• Switch NIC cable
• http//www.techonline.com/community/related_conten
  t/24364

41
Ethernet

• Latency 80 us
• Bandwidth 100 MB/s
• Top500 list has ethernet-based systems sustaining
  between 35-59 of peak

42
Ethernet

• What we did with 128 nodes and a 13,000 ethernet
  network
• 101 / port
• 28/port with our latest Gigabit Ethernet switch

• Sustained 48 of peak

• With Myrinet, would have sustained 1 Tflop
• At a cost of 130,000
• Roughly 1/3 the cost of the system

43
Rockstar Topology

• 24-port switches
• Not a symmetric network
• Best case - 41 bisection bandwidth
• Worst case - 81
• Average - 5.31

44
Low-Latency Ethernet

• Bring os-bypass to ethernet
• Projected performance
• Latency less than 20 us
• Bandwidth 100 MB/s
• Potentially could merge management and
  high-performance networks
• Vendor Ammasso

45
Application Benefits
46
Storage
47
Local Storage

• Exported to compute nodes via NFS

48
Network Attached Storage

• A NAS box is an embedded NFS appliance

49
Storage Area Network

• Provides a disk block interface over a network
  (Fibre Channel or Ethernet)
• Moves the shared disks out of the servers and
  onto the network
• Still requires a central service to coordinate
  file system operations

50
Parallel Virtual File System

• PVFS version 1 has no fault tolerance
• PVFS version 2 (in beta) has fault tolerance
  mechanisms

51
Lustre

• Open Source
• Object-based storage
• Files become objects, not blocks

52
Cluster Software
53
Cluster Software Stack

• Linux Kernel/Environment
• RedHat, SuSE, Debian, etc.

54
Cluster Software Stack

• HPC Device Drivers
• Interconnect driver (e.g., Myrinet, Infiniband,
  Quadrics)
• Storage drivers (e.g., PVFS)

55
Cluster Software Stack

• Job Scheduling and Launching
• Sun Grid Engine (SGE)
• Portable Batch System (PBS)
• Load Sharing Facility (LSF)

56
Cluster Software Stack

• Cluster Software Management
• E.g., Rocks, OSCAR, Scyld

57
Cluster Software Stack

• Cluster State Management and Monitoring
• Monitoring Ganglia, Clumon, Nagios, Tripwire,
  Big Brother
• Management Node naming and configuration (e.g.,
  DHCP)

58
Cluster Software Stack

• Message Passing and Communication Layer
• E.g., Sockets, MPICH, PVM

59
Cluster Software Stack

• Parallel Code / Web Farm / Grid / Computer Lab
• Locally developed code

60
Cluster Software Stack

• Questions
• How to deploy this stack across every machine in
  the cluster?
• How to keep this stack consistent across every
  machine?

61
Software Deployment

• Known methods
• Manual Approach
• Add-on method
• Bring up a frontend, then add cluster packages
• OpenMosix, OSCAR, Warewulf
• Integrated
• Cluster packages are added at frontend
  installation time
• Rocks, Scyld

62
Rocks
63
Primary Goal

• Make clusters easy
• Target audience Scientists who want a capable
  computational resource in their own lab

64
Philosophy

• Not fun to care and feed for a system
• All compute nodes are 100 automatically
  installed
• Critical for scaling
• Essential to track software updates
• RHEL 3.0 has issued 232 source RPM updates since
  Oct 21
• Roughly 1 updated SRPM per day
• Run on heterogeneous standard high volume
  components
• Use the components that offer the best
  price/performance!

65
More Philosophy

• Use installation as common mechanism to manage a
  cluster
• Everyone installs a system
• On initial bring up
• When replacing a dead node
• Adding new nodes
• Rocks also uses installation to keep software
  consistent
• If you catch yourself wondering if a nodes
  software is up-to-date, reinstall!
• In 10 minutes, all doubt is erased
• Rocks doesnt attempt to incrementally update
  software

66
Rocks Cluster Distribution

• Fully-automated cluster-aware distribution
• Cluster on a CD set
• Software Packages
• Full Red Hat Linux distribution
• Red Hat Linux Enterprise 3.0 rebuilt from source
• De-facto standard cluster packages
• Rocks packages
• Rocks community packages
• System Configuration
• Configure the services in packages

67
Rocks Hardware Architecture
68
Minimum Components
Local Hard Drive
Power
Ethernet
OS on all nodes (not SSI)
X86, Opteron, IA64 server
69
Optional Components

• Myrinet high-performance network
• Infiniband support in Nov 2004
• Network-addressable power distribution unit
• keyboard/video/mouse network not required
• Non-commodity
• How do you manage your management network?
• Crash carts have a lower TCO

70
Storage

• NFS
• The frontend exports all home directories
• Parallel Virtual File System version 1
• System nodes can be targeted as Compute PVFS or
  strictly PVFS nodes

71
Minimum Hardware Requirements

• Frontend
• 2 ethernet connections
• 18 GB disk drive
• 512 MB memory
• Compute
• 1 ethernet connection
• 18 GB disk drive
• 512 MB memory
• Power
• Ethernet switches

72
Cluster Software Stack
73
Rocks Rolls

• Rolls are containers for software packages and
  the configuration scripts for the packages
• Rolls dissect a monolithic distribution

74
Rolls User-Customizable Frontends

• Rolls are added by the Red Hat installer
• Software is added and configured at initial
  installation time
• Benefit apply security patches during initial
  installation
• This method is more secure than the add-on method


75
Red Hat Installer Modified to Accept Rolls
76
Approach

• Install a frontend
• Insert Rocks Base CD
• Insert Roll CDs (optional components)
• Answer 7 screens of configuration data
• Drink coffee (takes about 30 minutes to install)
• Install compute nodes
• Login to frontend
• Execute insert-ethers
• Boot compute node with Rocks Base CD (or PXE)
• Insert-ethers discovers nodes
• Goto step 3
• Add user accounts
• Start computing

• Optional Rolls
• Condor
• Grid (based on NMI R4)
• Intel (compilers)
• Java
• SCE (developed in Thailand)
• Sun Grid Engine
• PBS (developed in Norway)
• Area51 (security monitoring tools)

77
Login to Frontend

• Create ssh public/private key
• Ask for passphrase
• These keys are used to securely login into
  compute nodes without having to enter a password
  each time you login to a compute node
• Execute insert-ethers
• This utility listens for new compute nodes

78
Insert-ethers

• Used to integrate appliances into the cluster

79
Boot a Compute Node in Installation Mode

• Instruct the node to network boot
• Network boot forces the compute node to run the
  PXE protocol (Pre-eXecution Environment)
• Also can use the Rocks Base CD
• If no CD and no PXE-enabled NIC, can use a boot
  floppy built from Etherboot (http//www.rom-o-ma
  tic.net)

80
Insert-ethers Discovers the Node
81
Insert-ethers Status
82
eKVEthernet Keyboard and Video

• Monitor your compute node installation over the
  ethernet network
• No KVM required!
• Execute ssh compute-0-0

83
Node Info Stored In A MySQL Database

• If you know SQL, you can execute some powerful
  commands

84
Cluster Database
85
Kickstart

• Red Hats Kickstart
• Monolithic flat ASCII file
• No macro language
• Requires forking based on site information and
  node type.
• Rocks XML Kickstart
• Decompose a kickstart file into nodes and a graph
• Graph specifies OO framework
• Each node specifies a service and its
  configuration
• Macros and SQL for site configuration
• Driven from web cgi script

86
Sample Node File
lt?xml version"1.0" standalone"no"?gt lt!DOCTYPE
kickstart SYSTEM "_at_KICKSTART_DTD_at_" lt!ENTITY ssh
"openssh"gtgt ltkickstartgt ltdescriptiongt Enable
SSH lt/descriptiongt ltpackagegtsshlt/packagegt
ltpackagegtssh-clientslt/packagegt ltpackagegtssh-s
erverlt/packagegt ltpackagegtssh-askpasslt/packagegt
ltpostgt ltfile name"/etc/ssh/ssh_config"gt Host
CheckHostIP no
ForwardX11 yes ForwardAgent
yes StrictHostKeyChecking
no UsePrivilegedPort no
FallBackToRsh no Protocol
1,2 lt/filegt chmod orx /root mkdir
/root/.ssh chmod orx /root/.ssh lt/postgt lt/kickst
artgtgt
87
Sample Graph File
lt?xml version"1.0" standalone"no"?gt lt!DOCTYPE
kickstart SYSTEM "_at_GRAPH_DTD_at_"gt ltgraphgt ltdescrip
tiongt Default Graph for NPACI Rocks. lt/descripti
ongt ltedge from"base" to"scripting"/gt ltedge
from"base" to"ssh"/gt ltedge from"base"
to"ssl"/gt ltedge from"base" to"lilo"
arch"i386"/gt ltedge from"base" to"elilo"
arch"ia64"/gt ltedge from"node" to"base"
weight"80"/gt ltedge from"node"
to"accounting"/gt ltedge from"slave-node"
to"node"/gt ltedge from"slave-node"
to"nis-client"/gt ltedge from"slave-node"
to"autofs-client"/gt ltedge from"slave-node"
to"dhcp-client"/gt ltedge from"slave-node"
to"snmp-server"/gt ltedge from"slave-node"
to"node-certs"/gt ltedge from"compute"
to"slave-node"/gt ltedge from"compute"
to"usher-server"/gt ltedge from"master-node"
to"node"/gt ltedge from"master-node"
to"x11"/gt ltedge from"master-node"
to"usher-client"/gt lt/graphgt
88
Kickstart framework
89
Appliances

• Laptop / Desktop
• Appliances
• Final classes
• Node types
• Desktop IsA
• standalone
• Laptop IsA
• standalone
• pcmcia
• Code re-use is good

90
Architecture Differences

• Conditional inheritance
• Annotate edges with target architectures
• if i386
• Base IsA grub
• if ia64
• Base IsA elilo
• One Graph, Many CPUs
• Heterogeneity is easy
• Not for SSI or Imaging

91
Installation Timeline
92
Status
93
But Are Rocks Clusters High Performance Systems?

• Rocks Clusters on June 2004 Top500 list

94
(No Transcript)
95
What We Proposed To Sun

• Lets build a Top500 machine
• from the ground up
• in 2 hours
• in the Sun booth at Supercomputing 03

96
Rockstar Cluster (SC03)

• Demonstrate
• We are now in the age of personal
  supercomputing
• Highlight abilities of
• Rocks
• SGE
• Top500 list
• 201 - November 2003
• 413 - June 2004
• Hardware
• 129 Intel Xeon servers
• 1 Frontend Node
• 128 Compute Nodes
• Gigabit Ethernet
• 13,000 (US)
• 9 24-port switches
• 8 4-gigabit trunk uplinks
