The Skeletal System

1
The Skeletal System
2
Skeletal System

• Bony tissues that form the bodys framework
  comprise the Skeletal System.
• In domesticated animals, the skeletal system is
  internal, called an endoskeleton, and are
  basically alike in most species.

3
Skeletal System

• The number of bones in a horses neck are the
  same as those in a rabbits, but the size and
  length vary.

4
Skeletal System

• The outer layers of bones are composed of hard
  mineral deposits. About 26 of total bone mass
  is composed of mineral matter.
• The remainder of the composition of bones
  includes 20 protein, 4 fat, and 50 water.

5
Skeletal System

• About 85 of the mineral matter is calcium
  phosphate.
• The remaining 15 is calcium carbonate.

6
Skeletal System

• The inner core of bones is soft tissue called
  bone marrow.
• Some of the bone marrow consists of yellow fat,
  called yellow marrow.
• The other portion is made of red tissue called
  red marrow, that is responsible for red blood
  cell formation.

7
Skeletal System

• As an animal grows, bones increase in size and
  length in the region of cartilage between the end
  and shaft of bones.
• As the animal matures, this cartilage ossifies
  (becomes bony material).

8
Skeletal System

• In mature animals, bone is continually being
  reabsorbed and replaced, but no new bone growth
  occurs.
• Osteoporosis occurs when the bone that is
  reabsorbed is not replaced.

9
Skeletal System

• As long bones grow in length, they also increase
  in diameter.
• This is caused by the production of new bony
  tissue in the periosteum that surrounds the
  outside of the bone.

10
Skeletal System

• Bone growth is affected by hormones, vitamins,
  and other nutrients.
• Therefore, bones can become fragile or distorted
  due to nutritional deficiencies.
• Breaks in bones repair when the ends fill with a
  fibrin clot, that becomes bony tissue.

11
Skeletal System

• The skeletal system provides body support and
  leverage for muscle movement, which is made
  possible by several types of joints.

12
Skeletal System

• Ball-and-socket joints can move in all directions
  (shoulder).
• Hinge joints move in only two directions (knee).
• Pivot joints allow for movement in several
  directions (neck)

13
Skeletal System

• Gliding joints allow for flexibility to move
  forward, backward, or sideways (vertebrae)

14
Skeletal System

• Joints are held together by ligaments and are
  enclosed by a capsule which contains synovial
  fluid to lubricate the joint and allow
  friction-free movement.

15
Skeletal System

• The skeletal system of animals of the phylum
  Chordata can be divided into three parts
• the axial (spine, ribs, sternum, skull)
• the pectoral limb (foreleg)
• the pelvic limb (pelvic girdle and hindlegs)

16
Skeletal System
Axial -
Pelvic -
Pectoral -
17
Skeletal System

• The vertebral column (spine) is divided into five
  regions
• Cervical (7 vertebrae)
• Thoracic (13 vertebrae)
• Lumbar (6 vertebrae)
• Sacral (5 vertebrae)
• Coccygeal (18-20 vertebrae)

18
Skeletal System - Axial
Skull
Lumbar Vertebrae
Thoracic Vertebrae
Sacral Vertebrae
Coccygeal Vertebrae
Ribs
Cervical Vertebrae
Xyphoid
Sternum
19
Skeletal System - Pectoral
Scapula
Humerus
Ulna
Radius
Metacarpal Bones
Carpus
Phalanges
20
Skeletal System - Pelvic
Ilium
Pelvis
Ischium
Femur
Patella
Tibia and Fibula
Tarsus
Metatarus
Phalanges
21
Skeletal System
22
Maxillar
Mandible
Clavicle
Scapula
Sternum
Humerus
Ribs
Lumbar Vertebrae
Radius
Pelvis
Coccyx
Ulna
Carpus
Metacarpus
Phalanges
Femur
Patella
Tibia
Fibula
Metatarsals
Tarsus
Phalanges
23
Skeletal System

• Bones are divided into four classes based on
  their shape and function
• Long bones (support)
• Flat bones (muscle attachment and organ
  protection)
• Short bones (help in movement and change the
  direction of tendons)
• Irregular bones (vertebrae)

24
Skeletal System

• Parts of the skeletal system protect vital
  organs.
• Skull (protects the brain)
• Rib cage (protects the heart, lungs, and certain
  abdominal organs)
• Vertebrae (protect the spinal column)
