Atomic Structure and the Periodic Table

1
Chapter 5

• Atomic Structure and the Periodic Table
• Milbank High School

2
Section 5.1Atoms

• Learning Target
• I can summarize Daltons atomic theory.

3
Section 5.1Atoms

• Learning Target
• I can describe the size of an atom.

4
First Ideas

• Aristotle - Famous philosopher
• All substances are made of 4 elements
• Fire - Hot
• Air - light
• Earth - cool, heavy
• Water - wet
• Blend these in different proportions to get all
  substances

5
Whos Next?

• Late 1700s - John Dalton- England.
• Teacher- summarized results of his experiments
  and those of others.
• Daltons Atomic Theory
• Combined ideas of elements with that of atoms.

6
Daltons Atomic Theory

• All matter is made of tiny indivisible particles
  called atoms.
• Atoms of the same element are identical, those of
  different atoms are different.
• Atoms of different elements combine in whole
  number ratios to form compounds.
• Chemical reactions involve the rearrangement of
  atoms. No new atoms are created or destroyed.

7
Just How Small Is an Atom?

• Think of cutting a piece of lead into smaller and
  smaller pieces
• How far can it be cut?
• An atom is the smallest particle of an element
  that retains the properties of that element
• Atoms-very small Fig. 5.2, p. 108
• still observable with proper instruments Fig.
  5.3, page 108

8
Section 5.2Structure of the Nuclear Atom

• Learning Target
• I can distinguish among protons, electrons, and
  neutrons in terms of relative mass and charge.

9
Section 5.2Structure of the Nuclear Atom

• Learning Target
• I can describe the structure of an atom,
  including the location of the protons, electrons,
  and neutrons with respect to the nucleus.

10
Parts of Atoms

• J. J. Thomson - English physicist. 1897
• Made a piece of equipment called a cathode ray
  tube.
• It is a vacuum tube - all the air has been pumped
  out.
• Determined the presence of electrons in atoms

11
Thomsons Experiment

-
Vacuum tube
Metal Disks
12
Thomsons Experiment

-
13
Thomsons Experiment

-
14
Thomsons Experiment

-
15
Thomsons Experiment

-

• Passing an electric current makes a beam appear
  to move from the negative to the positive end

16
Thomsons Experiment

-

• Passing an electric current makes a beam appear
  to move from the negative to the positive end

17
Thomsons Experiment

-

• Passing an electric current makes a beam appear
  to move from the negative to the positive end

18
Thomsons Experiment

-

• Passing an electric current makes a beam appear
  to move from the negative to the positive end

19
Thomsons Experiment

• By adding an electric field

20
Thomsons Experiment

-

• By adding an electric field

21
Thomsons Experiment

-

• By adding an electric field

22
Thomsons Experiment

-

• By adding an electric field

23
Thomsons Experiment

-

• By adding an electric field

24
Thomsons Experiment

-

• By adding an electric field

25
Thomsons Experiment

-

• By adding an electric field he found that the
  moving pieces were negative

26
Other particles

• Proton - positively charged pieces 1840 times
  heavier than the electron
• Neutron - no charge but the same mass as a proton

27
Rutherfords experiment

• Ernest Rutherford -English physicist. (1910)
• Wanted to see how big atoms are.
• Used radioactivity.
• Alpha particles - positively charged pieces-
  helium atoms minus electrons
• Shot them at gold foil which can be made a few
  atoms thick.

28
Rutherfords experiment

• When an alpha particle hits a fluorescent screen,
  it glows.
• Heres what it looked like (page 111)

29
Fluorescent Screen
Lead block
Uranium
Gold Foil
30
He Expected

• The alpha particles to pass through without
  changing direction very much.
• Because?
• the positive charges were thought to be spread
  out evenly. Alone they were not enough to stop
  the alpha particles.

31
How he explained it

• Atom is mostly empty.
• Small dense, positive piece at center.
• Alpha particles are deflected by it if
  they get close enough.

32
Density and the Atom

• Since most of the particles went through, it was
  mostly empty space.
• Because the pieces turned so much, the positive
  pieces were heavy.
• Small volume, big mass, big density.
• This small dense positive area is the nucleus.

33
Subatomic particles p.111
Actual mass (g)
Relative mass
Name
Symbol
Charge
Electron
e-
-1
1/1840
9.11 x 10-28
Proton
p
1
1
1.67 x 10-24
Neutron
n0
0
1
1.67 x 10-24
34
Section 5.3Distinguishing Between Atoms

• Learning Target
• I can explain how the atomic number identifies an
  element.

35
Section 5.3Distinguishing Between Atoms

• Learning Target
• I can use the atomic number and mass number of an
  element to find the numbers of protons,
  electrons, and neutrons.

36
Section 5.3Distinguishing Between Atoms

• Learning Target
• I can explain how isotopes differ, and why the
  atomic masses of elements are not whole numbers.

37
Section 5.3Distinguishing Between Atoms

• Learning Target
• I can calculate the average atomic mass of an
  element from isotope data.

38
Counting the Pieces

• Atomic Number number of protons in the nucleus
• of protons determines kind of atom (since all
  protons are alike!)
• the same as the number of electrons in the
  neutral atom.
• Mass Number the number of protons neutrons.
• These account for most of mass

39
Symbols

• Contain the symbol of the element, the mass
  number and the atomic number.

40
Symbols

• Contain the symbol of the element, the mass
  number and the atomic number.

Mass number
X
Atomic number
41
Symbols

• Find the
• number of protons
• number of neutrons
• number of electrons
• Atomic number
• Mass Number

19
F
9
42
Symbols

• Find the
• number of protons
• number of neutrons
• number of electrons
• Atomic number
• Mass Number

80
Br
35
43
Symbols

• if an element has an atomic number of 34 and a
  mass number of 78 what is the
• number of protons
• number of neutrons
• number of electrons
• Complete symbol

44
Symbols

• if an element has 91 protons and 140 neutrons
  what is the
• Atomic number
• Mass number
• number of electrons
• Complete symbol

45
Symbols

• if an element has 78 electrons and 117 neutrons
  what is the
• Atomic number
• Mass number
• number of protons
• Complete symbol

46
Isotopes

• Dalton was wrong.
• Atoms of the same element can have different
  numbers of neutrons.
• different mass numbers.
• called isotopes.

47
Naming Isotopes

• We can also put the mass number after the name of
  the element.
• carbon- 12
• carbon -14
• uranium-235

48
Atomic Mass

• How heavy is an atom of oxygen?
• There are different kinds of oxygen atoms.
• More concerned with average atomic mass.
• Based on abundance of each element in nature.
• Dont use grams because the numbers would be too
  small.

49
Measuring Atomic Mass

• Unit is the Atomic Mass Unit (amu)
• One twelfth the mass of a carbon-12 atom.
• Each isotope has its own atomic mass, thus we
  determine the average from percent abundance.

50
Calculating averages

• Multiply the atomic mass of each isotope by its
  abundance (expressed as a decimal), then add the
  results.
• Sample 5-5, p.120

51
Atomic Mass

• Calculate the atomic mass of copper if copper has
  two isotopes. 69.1 has a mass of 62.93 amu and
  the rest has a mass of 64.93 amu.

52
Atomic Mass

• Magnesium has three isotopes. 78.99 magnesium 24
  with a mass of 23.9850 amu, 10.00 magnesium 25
  with a mass of 24.9858 amu, and the rest
  magnesium 25 with a mass of 25.9826 amu. What is
  the atomic mass of magnesium?
• If not told otherwise, the mass of the isotope is
  the mass number in amu

53
Atomic Mass

• Is not a whole number because it is an average.

54
Section 5.4The Periodic Table Organizing the
Elements

• Learning Target
• I can describe the origin of the periodic table.

55
Section 5.4The Periodic Table Organizing the
Elements

• Learning Target
• I can identify the position of groups, periods,
  and the transition metals in the periodic table.

56
Development of the Periodic Table

• mid-1800s, about 70 elements
• Dmitri Mendeleev Russian chemist
• Arranged elements in order of increasing atomic
  mass
• Thus, the first Periodic Table

57
Mendeleev

• Left blanks for undiscovered elements
• When discovered, good prediction
• Problems?
• Co and Ni Ar and K Te and I

58
New way

• Henry Moseley British physicist
• Arranged elements according to increasing atomic
  number
• The arrangement today
• P.124 long form
• Symbol, atomic number mass

59
Periodic table

• Horizontal rows periods
• There are 7 periods
• Periodic law
• Vertical column group (or family)
• Similar physical chemical prop.
• Identified by number letter

60
Areas of the periodic table

• Group A elements representative elements
• Wide range of phys chem prop.
• Metals electrical conductors, have luster,
  ductile, malleable

61
Metals

• Group IA alkali metals
• Group 2A alkaline earth metals
• Transition metals and Inner transition metals
  Group B
• All metals are solids at room temperature, except
  _____.

62
Nonmetals

• Nonmetals generally nonlustrous, poor conductors
  of electricity
• Some gases (O, N, Cl) some are brittle solids
  (S) one is a fuming dark red liquid (Br)
• Group 7A halogens
• Group 8A noble gases

63
(No Transcript)
64
Division between metal nonmetal

• Heavy, stair-step line
• Metalloids border the line
• Properties intermediate between metals and
  nonmetals
• Learn the general behavior and trends of the
  elements, instead of memorizing each element
  property
