Mobile Development Microsoft Mobile Platforms Rob Miles Department of Computer Science

1
Mobile DevelopmentMicrosoft Mobile
PlatformsRob MilesDepartment of Computer
Science
2
Introduction

• A bit of history
• Where the Pocket PC came from
• Where the Smartphone came from
• Pocket PC Phone Edition
• At bit of architecture
• How the platforms run the programs
• Why managed code is wonderful
• A bit of construction
• The tools you will need

3
Pocket PC

• Originally called the wallet PC
• Launched in 1996 with Version 1.0 of Windows CE
• Superseded in the following year with Version 2.0
• Initially available in keyboard and keyboard-less
  versions

4
Breakthrough Pocket PCCompaq Ipaq

• This was the first device to deliver on
  performance, display and battery life
• 120MHz processor
• 32MB of RAM
• Flash ROM
• RS232 and IR ports
• 240x320 TFT colour display

5
State of the art Pocket PC

• Dell Axim V50s
• 624Mhz Processor
• 64MB RAM
• 480x640 colour display
• WIFI and Bluetooth
• 3D Graphics accelerator
• Windows Mobile 5 upgradeable
• 150 less than the original IPAQ!

6
Smartphone

• In 2001 Microsoft announced that it would be
  launching a range of Smarpthones (codenamed
  "Stinger")
• The Smartphones would be "Windows based"
• The version of Windows in question was Windows CE
  3.0
• Launched in October 2002 with Orange SPV

7
Breakthrough SmartphoneSPV E200

• First to deliver on performance and battery life
• 32MB user memory
• Built in Bluetooth support
• Built in camera
• Smartphone 2003 Operating System
• .NET Compact Framework

8
State of the art Smartphone SPV C500

• Launched in August 2004
• 64MB of internal memory
• Fast internal processor (200 MHz)
• Small form factor
• Runs Windows Mobile 2003 Second Edition
• Being replaced by the C550 which adds Media
  Player 10 for protected content

9
Pocket PC Phone Edition

• Combines PDA with phone
• Launched in July 2002
• 206-MHz Intel StrongArm processor
• 32MB RAM
• Based on Pocket PC 2002

10
Breakthrough Device XDA II

• Launched in April 2004
• 400MHz Processor
• 128MB RAM
• Camera
• Bluetooth
• Windows Mobile 2003

11
State of the Phone EditionXDA IIS

• Launched in April 2005
• Integrated Keyboard
• Improved performance

12
What you should be saving up for.

• First 3G Windows Mobile Device
• Branded as Orange M5000
• VGA resolution display (640x480)
• WIFI support
• Two cameras
• Windows Mobile 5.0
• Want one

13
Other devices of note

• Gizmondo
• Offers a Windows CE based gaming platform with
  GPS, GPRS and 3D Acceleration built in
• Licensed developers only (sadly)
• Imate JAM
• Very small Pocket PC phone edition
• New form factor for Pocket PC

14
The Future

• The development of the devices over the last few
  years has been amazing
• The systems are going to get more powerful and
  more connected
• Location based behaviour is now very easy to
  implement in systems

15
Architecture

• If you write programs for the mobile devices you
  should plan to work in the Compact Framework
  using managed code
• This makes your programs
• Portable
• Safe
• Easy to write

16
Managed and Native Code
Managed Code User Program
.NET Compact Framework Class Libraries
Native (Unmanaged Code) User Program
.NET Compact Framework Common Language Runtime
Processor and Operating System Services
17
Native (unmanaged) code

• Programs are compiled to machine code for the
  target processor
• Created in C or Visual Basic and compiled for
  the specific hardware in the device
• Has direct access to the processor instruction
  set
• Scary stuff for uber-geeks

18
Managed Code

• Programs execute within a managed environment
• Microsoft Intermediate Language (MSIL) is Just In
  Time compiled on the target device
• Code is not produced for a specific target
  hardware
• Code is validated before execution
• Helps programmers sleep at night

19
Managed Code is Best

• You should concentrate on managed code
  development
• it is easier and faster to create
• programs are inherently more reliable and easier
  to debug
• However, we need to be aware that there is a
  performance penalty for working this way
• the first time a method is called the run time
  system must "Just In Time" compile the MSIL code
  for that method into machine code
• this can lead to delays when programs start up
  and, sometimes during execution when new classes
  are loaded

20
Inside a Managed Code Program

• Because the executable is a .NET program you can
  use ILDASM and other tools to manipulate it
• You could even create MSIL applications for
  mobile devices if you wish

21
P/Invoke is your friend

• If you need to get down and dirty from managed
  code you use Platform Invoke (P/Invoke)
• This provides marshalling of data to and from
  calls to native methods
• You will use this to access some parts of the
  operating system the Compact Framework cannot
  reach
• Device Data Battery Life etc
• Placing Calls and SMS messages

22
So, Rules To Code By

• Use Managed Code wherever possible
• Good reasons to use Native Code
• You really want speed
• You really want to drive the hardware directly
• You are being paid really large sums of money
  to do it
• Compromise
• If you need native code, put it in a native code
  library and then talk to it via the Platform
  Invoke (P/Invoke) mechanism

23
Writing the Code

• You can use C if you like (in fact I insist)
• You can use Visual Studio
• A lot of the forms behaviours map directly across
  to the mobile platform
• You do not need a real device
• Unless you want to place phone calls or
  send/receive SMS messages

24
Visual Studio 2003

• Visual Studio 2003 as supplied will develop
  managed code applications for the Pocket PC
• By adding the Smartphone Developer kit to Visual
  Studio 2003 you can use this to develop
  Smartphone applications
• The Smartphone Developer Kit is a free download,
  but you need to have Visual Studio to make use of
  it

25
Visual Studio 2005

• This is a significant advance over Visual Studio
  2005
• The Forms editor now functions with a more
  complete emulation of the mobile device display
• The emulation of the devices is now at processor
  level rather than an 8086 version of the device
• You can pick up Beta 2 for free!

26
Deploying the Program

• When the program is executed from within Visual
  Studio it is copied into a directory on the
  target device and executed from there
• You can deploy the program just as an executable
  file if you wish, by copying it into a directory
  on the Smartphone using the ActiveSync
• Or you can build an installer

27
Debugging

• The debug tools are very powerful
• You can
• Pause an executing program
• Add a breakpoint to an executing program without
  stopping it
• These facilities work on the target device too
• You must however have used Debug mode to build
  the application
• The Remote Display Power tool can be useful here

28
Finding the Program

• The more recent mobile phones are shipped with
  file browser programs you can use to find and run
  the executable directly
• Pocket PC owners can use the built in file browser

29
Developers Toolkits

• To start to develop you need
• Visual Studio 2003
• Active Sync. 3.7 or better
• Smartphone 2003 tools
• Visual Studio 2005
• Active Sync. 4.0
• Powertoys
• You should also get the Power Toys

30
Call to Action

• The devices out there are getting really powerful
  and connected
• They are about as easy to write for as desktop
  machines
• This is a genuinely new area where the scope for
  innovation is huge
• So get out there and get started!
