POSTERIOR INTERSCALENE BLOCK Ercan KURT GÜLHANE
MILITARY MEDICAL FACULTY DEPARTMENT OF
ANESTHESIOLOGY AND REANIMATION ANKARA
2
INTERSCALENE BRACHIAL PLEXUS BLOCK

• ANTERIOR APPROACH
• SINGLE DOSE TECHNIQUE
• CATHETER TECHNIQUE
• POSTERIOR APPROACH
• SINGLE DOSE TECHNIQUE
• CATHETER TECHNIQUE

3
INTERSCALENE BRACHIAL PLEXUS BLOCK

• INDICATIONS
• Shoulder and upper arm surgery
• Immobility of shoulder joint
• Shoulder manipulations
• Chronic pain therapy
• Arthroscopic shoulder surgery
• ADVANTAGES
• Easily performed in any position of the arm
• DISADVANTAGES
• Ulnar nerve may not be blocked
• Serious complications may occur

4
ISB CONTRAINDICATIONS

• Skin infection
• Refusal of the procedure by the patient
• Haemorrhagic diathesis
• Contralateral phrenic nerve or recurrent nerve
  paralysis
• Known neuropathy involving the arm undergoing
  surgery
• Severe bronchopulmonary disease
• Known allergy to the trial drugs
• Previous neurologic damage to the brachial plexus

5
INTERSCALENE BLOCK

• ANATOMY OF BRACHIAL PLEXUS

6
V.J.Interna
A. C.Communis
Phrenic nerve
Subclavian a.
Subclavian v.
7
Anterior and middle scalene
Subclavian a-v
8
Vertebral a.
Phrenic nerve
Middle scalene m.
SCM muscle
Anterior scalene m.
Subclavian a.
9
ANATOMICAL LANDMARKS OF BRACHIAL PLEXUS

• Arteria carotis communis
• Apex of lung
• Phrenic nerve

10
LOCAL ANESTHETICS MAY SPREAD INTO SUBARACHNOIDAL
SPACE THROUGH THREE WAYS

• 1- INTERVERTEBRAL FORAMEN
• 2- DURAL SHEATH
• 3- INTRANEURALLY

11
SINGLE - DOSE ISB USING POSTERIOR APPROACH
12
ISB USING POSTERIOR APPROACH ANATOMICAL LAYERS
IN TRANSVERSE SECTION

• 1- Skin-subcutaneous tissue
• 2- M. trapezius
• 3- M. splenius capitis
• 4- M. semispinalis capitis
• 5- M. semispinalis cervitis
• 6- M. scaleneus posterior
• 7- M. scaleneus medius

13
ISB USING POSTERIOR APPROACH
BRACHIAL PLEXUS
C-7 SPINOUS PROCESS
14
POSTERIOR ISB
SITTING POSITION
LATERAL DECUBITIS POSITION
15
SINGLE - DOSE ISB USING POSTERIOR APPROACH
16
SINGLE - DOSE ISB USING POSTERIOR APPROACH
17
SINGLE - DOSE ISB USING POSTERIOR APPROACH
18
SINGLE - DOSE ISB USING POSTERIOR APPROACH
19
SINGLE - DOSE ISB USING POSTERIOR APPROACH
20
SINGLE - DOSE ISB USING POSTERIOR APPROACH
21
SINGLE - DOSE ISB USING POSTERIOR APPROACH
22
SINGLE - DOSE ISB USING POSTERIOR APPROACH
23
SINGLE - DOSE ISB USING POSTERIOR APPROACH
24
SINGLE - DOSE ISB USING POSTERIOR APPROACH
25
SINGLE - DOSE ISB USING POSTERIOR APPROACH
26
SINGLE - DOSE ISB USING POSTERIOR APPROACH
27
LOCAL ANESTHETICS FOR ISB

• A TOTAL VOLUME OF 40 50 ML
• 20 -25 ml 0,5 bupivacaine 20 - 25 ml 1
  prilocaine
• 20 - 25ml 0,5 bupivacaine 20 - 25 ml 1
  lignocaine
• 20 - 25ml 0,2 ropivacaine 20 - 25 ml 1
  lignocaine

28
INDICATIONS FOR CATHETER

• Acute pain therapy (postoperative)
• Management of chronic pain (CRPS)
• Supportive adjunct to physiotherapy/exercise
  therapy
• Sympatholysis (for improving wound healing)
• Preventive analgesia (phantom pain prophylaxis)

29
CONTINUOUS ISB USING POSTERIOR APPROACH
30
CONTINUOUS ISB USING POSTERIOR APPROACH
31
CONTINUOUS ISB USING POSTERIOR APPROACH
32
CONTINUOUS ISB USING POSTERIOR APPROACH
33
CONTINUOUS ISB USING POSTERIOR APPROACH
34
CONTINUOUS ISB USING POSTERIOR APPROACH
35
CONTINUOUS ISB USING POSTERIOR APPROACH
36
CONTINUOUS ISB USING POSTERIOR APPROACH
37
CONTINUOUS ISB USING POSTERIOR APPROACH
38
CONTINUOUS ISB USING POSTERIOR APPROACH
39
CONTINUOUS ISB USING POSTERIOR APPROACH
40
CONTINUOUS ISB USING POSTERIOR APPROACH
41
STIMULATING CATHETERS

• Precisely control catheter placement
• Improved onset of motor nerve block

• Does Interscalene Catheter Placement with
  Stimulating Catheters Improve Postoperative Pain
  or Functional Outcome After Shoulder Surgery?
• Regional Anest Vol 104(2) 2007
• Stevens M.F.

42
Brachial Plexus Block With Catheter Using The
Posterior Interscalene Approach
Decreased likelihood of catheter dislodgement
due to neck movement

• In The Management Of Neuropathic Cancer Pain (2
  Case Report)TÜRKER G.
• Uludag Üniversitesi Tip Fakültesi,
  Anesteziyoloji ve Reanimasyon AD, BURSA

43
ISB COMPLICATIONS

• Horner syndrome
• N. recurrens paralysis
• Phrenic nerve paralysis
• Bronchospasm
• Total spinal anesthesia
• Acute respiratory insufficiency
• Contralateral anesthesia
• Loss of consciousness and apnea
• Hematoma
• Nerve injury

44
ACCIDENTAL EPIDURAL CATHETERIZATION

• During continuous interscalene block via the
  posterior approach
• Gurbet A.
• 2005 Journal The Pain Clinic

• the patient should be awake and conscious during
  catheter placement
• radiographic confirmation of catheter position
  should be
• obtained before the first injection
• after each local anesthetic injection the patient
  should be monitored.

5 ml of contrast medium were injected and a C-arm
fluoroscopic imaging showed contrast medium in
the epidural space with catheter opacification
45
INTRACORD INJECTION

• Permanent Loss of Cervical Spinal Cord Function
  Associated with Interscalene Block Performed
  Under General Anesthesia
• Benumof Jonathan L
• Volume 93(6), December 2000, 1541- 4

46
How to Prevent Catastrophic Complications When
Performing ISB

• In our institution, we only perform interscalene
  blocks before or after surgery in awake patients

47
PRECAUTIONS IN ISB

• ISB should not be performed in patients with a
  history including contralateral hemidiaphragmatic
  paralysis, pneumothorax and pneumonectomy
• The patients who can not tolerate a 25
  reduction of FVC are not appropriate for ISB
• Pulse oxymetry should be used
• Supplemental nazal oxygen should be given

48
IN CASE OF DISPNEA AFTER ISB

• The patient should be closely observed
• Patient is positioned in reverse Trendelenburg or
  sitting position
• Breath sounds should be oscultated to evaluate
  diaphragmatic hemiparesis
• A chest radiogram is required to check
  pneumothorax
• Ventilatory support or endotracheal intubation is
  indicated, if necessary

49
AS A RESULT

• Prevention of these complications includes the
  proper selection of patients
• The performance of blocks either before or after
  anesthesia in patients who are awake or mildly
  sedated
