Laryngoscopy: Time to broaden our horizon.

1
Laryngoscopy Time to broaden our horizon.

• Dr Renu Devaprasath DNB (Anaesthesia)Dept of
  Anaesthesia Jeyasekharan HospitalNagercoilKanya
  kumari District

2
LARYNGOSCOPY

• A procedure wherein the larynx is visualized
• Performed for diagnostic, therapeutic
  intubation purposes by various specialists.

3
LARYNGOSCOPY IN ANESTHESIA

• Unique
• A means to an end
• Objective is usually intubation of the trachea.

4
RARELY

• Visualizing the upper airway movement of the
  vocal cords
• Removing a foreign body
• Placing a R.T. or TEE Probe

5
TODAYS PRESENTATION

• Techniques, devices manouvres currently
  available to do a successful laryngoscopic
  intubation.

6
(No Transcript)
7
THE VARIABLES INVOLVED IN A SUCCESSFUL
LARYNGOSCOPY

• The laryngoscope
• The airway anatomy of the patient
• Neonate, child or adult.
• Head, neck, body position
• Movement of cervical spine
• Mouth opening
• External laryngeal pressure
• View of the glottic aperture
• Placement of the endotracheal tube
• Appropriate analgesia / Anesthesia
• Expertise of the anesthesiologist.

8
LARYNGOSCOPES

• Direct Rigid laryngoscopes
• Indirect Rigid laryngoscopes which use
  fibreoptics, mirrors, prisms, etc.
• Video laryngoscopes Rigid, Flexible
• Optical stylets
• Flexible fibreoptic endoscopes

9
DIRECT LARYNGOSCOPES

• Dominant modality since 1940s
• Advantages quick to use
• economical , rugged
• universally available
• Disadvantage alignment of the visual , oral
  pharyngeal axis is needed.

10

11

12
CURVED STRAIGHT BLADE LARYNGOSCOPE
13
CORMACK LEHANE SCORE
Gr I
Gr II
Gr III
Gr IV
14
INDIRECT RIGID FIBREOPTIC / OPTICAL LARYNGOSCOPES

• Airtraq
• Bullard
• Wuscope
• Upsherscope
• Truview

15
ADVANTAGES

• Blade shape conforms better to airway anatomy.
• Lesser mouth opening and neck extension needed.
• Alignment of oro-pharyngeal axis not necessary.
• Easy to learn.

16
DISADVANTAGES

• Costly.
• Secretions and blood can impair the view.
• Difference in angle of vision and glottic
  aperture.
• Intubation may be difficult though view of
  glottis is good.

17
AIRTRAQ
18
AIRTRAQ
19
BULLARD LARYNGOSCOPE
20
WUSCOPE
21
UPSHERSCOPE
22
VIDEO LARYNGOSCOPES

• Glidescope videolaryngoscopes
• Glidescope Cobalt
• Glidescope Ranger
• Angulated video intubation laryngoscope
• McGrath video laryngoscope
• Pentex airway scope
• Airtraq optical laryngoscope with video

23
ADVANTAGES

• Magnified view with a wider angle.
• The operator and assistant can see the same view
  and coordinate better.
• Lesser mouth opening and neck extension needed.
• Easy to learn and useful for teaching.

24
GLIDESCOPES
Glidescope Ranger
Glidescope cobalt
25
GLIDESCOPE COBALT
26
ANGULATED VIDEO INTUBATION LARYNGOSCOPE
27
McGRATH VIDEO LARYNGOSCOPE
28
PENTAX AIRWAY SCOPE
29
PENTAX AIRWAY SCOPE IN USE
30
OPTICAL STYLETS

• Shikani optical stylet
• Bonfil endoscope

31
SHIKANI OPTICAL STYLET (SOS)
32
SHIKANI OPTICAL STYLET (SOS)
33
BONFIL OPTICAL STYLET
34
ADVANTAGES

• Useful in routine and difficult intubations.
• Uncomplicated tools.
• Easily learned.
• Portable.
• Simple to prepare.

35
DISADVANTAGES

• Short optical depth .
• Potential for impaired visualization due to
  fogging or secretions

36
FIBREOPTIC ENDOSCOPE
37
ADVANTAGES

• Laryngoscopic intubation can be done via nasal
  route also.
• Neck extension and mouth opening not necessary.
• Anatomical variations can be overcome.
• Topical / regional anaesthesia is adequate in the
  awake patient.
• Good view of the glottis, larynx, trachea and
  bronchi .

38
DISADVANTAGES

• It is a delicate instrument and needs care.
• High cost.
• Takes a little time and practice to learn.
• Tissue oedema and blood can obscure vision.
• Cleaning / sterilization takes time.

39
SET UP
40
FOB AIDED INTUBATION UNDER LOCAL IN A PATIENT
WITH CERVICAL FRACTURES
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
FOB UNDER TOPICAL TRANSTRACHEAL INSTILLATION
50
(No Transcript)
51
PATIENT WITH STRIDOR DUE TO TRACHEAL COMPRESSION
52
FLEXIBLE FIBEROPTIC ASSISTED AWAKE INTUBATION
53
VARIATIONS IN AIRWAY ANATOMY and SIZE OF THE
PATIENT

• Overcome by selection of a appropriate
  laryngoscope .
• Use of pillows and folded sheets.

54
LIMITED MOUTH OPENING

• TM Jt ankylosis - fixed
• Fibreoptic laryngoscopy
• Pain induced Trismus
• Trial Direct laryngoscopy after paralysing the
  patient.

55
LIMITED C-SPINE MOVEMENT PATIENTS

• Direct laryngoscopy with bougie, flexible tip
  blades.
• BURP, OELM
• Indirect fibreoptic scopes
• Video endoscopes
• Optical stylets
• Flexible fibreoptic endoscopes

56
VIEW OF GLOTTIC APERTURE

• External laryngeal pressure
• Flexible tip direct laryngoscopes
• Improved immensely by all the newer optical,
  video, flexible fibreoptic laryngoscopes.

57
PASSING THE ENDOTRACHEAL TUBE

• Stylet or bougie - shape modification
• Rotation of ETT anticlockwise
• ETT tube / endoscope size

58
APPROPRIATE ANALGESIA,ANESTHESIA

• Depth of anaesthesia needed is maximum for direct
  lscopy , lesser for indirect and least for
  flexible fibreoptic laryngoscopy.
• Babies children need sedation or GA.
• Combative adults also need sedation or GA
• Flexible endoscopy can be done easily under local
  on a awake cooperative patient or a sedated
  ,spontaneously breathing child.

59
SUMMARY

• Variety of new laryngoscopes.
• Familiarization with using two other devices and
  the fibreoptic endoscope.
• Meticulous attention to detail in regard to all
  the variables.
• A difficult intubation tray.

60
THANK YOU
