Refactoring with Contracts

1
Refactoring with Contracts
2
Is Software Development a Pain??

• Of course not! It's fun!
• But the requirements are always changing
• Dan Berry (2002)
• Every development method has a fatal flaw, a pain
  that developers postpone and avoid
• In XP, this is refactoring
• For us, it is unit testing!

3
What Seems to be the Problem?

• Writing all the necessary tests is hard work
• Unit tests need to change with almost any change
  in the code
• Functionality
• Refactoring
• Test data generation needed

4
Solution

• Tests should be responsible for exercising the
  code
• The correctness is to be checked by the contract!

5
Agenda

• Introduction
• Refactoring Examples
• Crepe Recipe
• Summary

6
Agenda

• Introduction
• Refactoring Examples
• Crepe Recipe
• Summary

7
Design by Contract

• A practical methodology for evolving code
  together with its specification
• Class invariants, method preconditions and
  postconditions
• Precondition binds clients
• Postcondition obliges suppliers
• Invariant is a consistency constraint

8
Behavioral Subtyping (Liskov)

• Invariants and postconditions in subclasses
• May only be strengthened
• Computed as conjunctions (ANDed)
• Preconditions in subclasses
• May only be weakened
• Computed as disjunctions (ORed)

9
Extreme Design by Contract

• Correctness checked by contract
• Of course, contract may need to change when code
  changes
• But Contract expresses intent of code!
• Contracts can be refactored systematically
• Contract refactoring can be partially automated

Crepe Contract Refactoring Plugin for Eclipse
10
Agenda

• Introduction
• Refactoring Examples
• Crepe Recipe
• Summary

11
ReadyQueue (1)

• / _at_inv size() gt 0 /
• public class ReadyQueue
• final private List elements new LinkedList()
• public int size() / ... /
• / _at_pre job ! null
• _at_pre job.status() Job.READY
• _at_post elements.get(0) job
• _at_post size() prev(size()) 1
• /
• public void insert(Job job) / ... /

12
ReadyQueue (2)

• / _at_pre size() gt 0
• _at_post size() prev(size()) - 1
• /
• public void remove() / ... /
• / _at_post (size() 0) (ret null)
• /
• public Job top() / ... /

13
FreeJobs (1)

• / _at_inv size() gt 0 /
• public class FreeJobs
• final private List elements new LinkedList()
• public int size() / ... /
• / _at_pre job ! null
• _at_pre job.status() Job.INACTIVE
• _at_post top() job
• _at_post size() prev(size()) 1
• /
• public void insert(Job job) / ... /

READY
elements.get(0) job
14
FreeJobs (2)

• / _at_pre size() gt 0
• _at_post size() prev(size()) - 1
• /
• public void remove() / ... /
• / _at_pre size() gt 0
• _at_post ret ! null
• _at_post ret.status() Job.INACTIVE
• /
• public Job top() / ... /

15
Example Extract Superclass
16
Extract Superclass Refactoring (1)

• / _at_inv size() gt 0 /
• public abstract class JobDispenser
• protected List elements new LinkedList()
• / _at_pre false
• _at_post size() 1 prev(size())
• /
• public abstract void insert(Job job)

Contradictory preconditions in subclasses _at_pre
job.status() Job.READY _at_pre job.status()
Job.INACTIVE
17
Extract Superclass Refactoring (2)

• / _at_pre size() gt 0
• _at_post 1 size() prev(size())
• /
• public abstract void remove()
• / _at_pre size() gt 0
• /
• public abstract Job top()
• public abstract int size()

Common postconditions (Form slightly changed by
theorem-prover)
Precondition from FreeJobs, but not from
ReadyQueue
18
Changes ReadyQueue (1)

• / _at_inv size() gt 0 /
• public class ReadyQueue
• / _at_pre job ! null
• _at_pre job.status() Job.READY
• _at_post elements.get(0) job
• _at_post size() prev(size()) 1
• /
• public void insert(Job job) / ... /

19
Changes ReadyQueue (2)

• / _at_pre size() gt 0
• _at_post size() prev(size()) - 1
• /
• public void remove() / ... /
• public int size() / ... /
• / _at_pre size() 0
• _at_post (size() 0) (ret null)
• /
• public Job top() / ... /

20
Changes FreeJobs (1)

• / _at_inv size() gt 0 /
• public class FreeJobs
• / _at_pre job ! null
• _at_pre job.status() Job.INACTIVE
• _at_post top() job
• _at_post size() prev(size()) 1
• /
• public void insert(Job job) / ... /

21
Changes FreeJobs (2)

• / _at_pre size() gt 0
• _at_post size() prev(size()) - 1
• /
• public void remove() / ... /
• / _at_pre size() gt 0
• _at_post ret ! null
• _at_post ret.status() Job.INACTIVE
• /
• public Job top() / ... /
• public int size() / ... /

22
PriorityQueue

• / _at_inv size() gt 0 /
• public class PriorityQueue
• / _at_pre job ! null
• _at_pre job.status() Job.READY
• _at_pre job.priority()lt Scheduler.current_priori
  ty()
• _at_post size() prev(size()) 1
• /
• public void insert(Job job) / ... /
• // ...

23
Example Add Inheritance
ReadyQueue
ReadyQueue
PriorityQueue
PriorityQueue
24
PriorityQueue vs. ReadyQueue

• / _at_inv size() gt 0 /
• public class ReadyQueue
• / _at_pre job ! null
• _at_pre job.status() Job.READY
• _at_post elements.get(0).equals(job)
• _at_post size() prev(size()) 1 /
• public void insert(Job job) / ... /
• / _at_inv size() gt 0 /
• public class PriorityQueue
• / _at_pre job ! null
• _at_pre job.status() Job.READY
• _at_pre job.priority()lt Scheduler.current_priori
  ty()
• _at_post size() prev(size()) 1 /
• public void insert(Job job) / ... /

Extra postcondition
Extra precondition
25
Add Inheritance

• Cannot add inheritance relationship between two
  classes if, in the subclass, it causes
• Preconditions to be strengthened
• Invariants or postconditions to be weakened

26
Add Inheritance (Crepe)
27
Agenda

• Introduction
• Refactoring Examples
• Crepe Recipe
• Summary

28
The Crepe Recipe

• Use Eclipse ASTParser on assertions
• Parse the assertions in the Javadoc
• Convert to predicate form
• Use theorem prover (Mathematica) to verify
  relationships between assertions
• Find contract contradictions
• Compute the new contract
• Combine existing assertions to create new ones
• Compute contracts for arbitrary code (in
  preparation)

29
Combining Assertions

• Preconditions are conjoined and simplified
• Postconditions can be disjoined
• But, sometimes the most precise assertions are
  not best!

30
Extract Superclass - Postconditions

• class A
• / _at_post x gt 0
• _at_post x lt 10
• _at_post y gt 0
• _at_post y lt 10
• /
• void foo()

• class B
• / _at_post x gt 10
• _at_post x lt 20
• _at_post y gt 10
• _at_post y lt 20
• /
• void foo()

31
Postconditions Computation
class AB_alternative / _at_post x gt 0
_at_post x lt 20 _at_post y gt 0 _at_post y lt 20
/ void foo()
class AB_strongest / _at_post (x gt 0 x
lt 10 y gt 0 y lt 10) (x gt 10
x lt 20 y gt 10 y lt 20) / void
foo()
32
Postconditions Computation
class A extends AB_alternative / _at_post x lt
10 _at_post y lt 10 / void foo()
class B extends AB_alternative / _at_post x gt
10 _at_post y gt 10 / void foo()
20
10
A
10
20
33
Agenda

• Introduction
• Refactoring Examples
• Crepe Recipe
• Summary

34
Contracts Refactoring Statistics
35
Crepe Limitations

• Contract computation from arbitrary code
• Theorem prover (Mathematica)
• Supports only Booleans, Integers, Doubles, and
  Reals
• Fails to simplify some expressions using
  assumptions
• Not open source
• Assertions parsing
• Return type computations

36
Summary

• Design by Contract is an essential technique for
  producing high-quality code
• It is synergistic with Agile practices
• It helps develop with confidence
• Automation needed for the process of refactoring
  with contracts
• Crepe demonstrates such automating techniques

37
Questions?
38

• Thank you!
