Linking Land UseLand Cover and Ecosystem Services towards an operational approach

1
Linking Land Use/Land Cover and Ecosystem
Services towards an operational approach

• Austin Troy, Matthew A. Wilson, Kenneth Bagstad
  and Shuang Liu

2
Knowledge Transfer

• Ecosystem service-based decision making
  frequently relies on expert knowledge transfer,
  that is, using studies from other regions on
  resource types that are similar to those in the
  policy site in question.
• Economic value transfer is not the only method of
  knowledge transfer for assessing ecosystem
  services functions or models that describe
  ecosystem processes can also be transferred.

3
Overview of Talk

• A Typology
• a framework of concepts and relationships
• in order to share common understanding of the
  structure of information
• Review of ecosystem service (ES) ontology
• Current trend be operational
• Looking to the future

4
Review of ES ontology history

• Up until recently, ES are intuitively categorized
  by ecosystem functions
• 1st list in 1970, 9 services including pest
  control, insect pollination, fisheries, climate
  regulation, soil retention, flood control, soil
  formation, cycling of matter, and composition of
  the atmosphere (Mooney and Ehrlich 1997)
• 1997, Dailys book 13 services
• Costanza et al. 17 services
• Recently Millennium Assessment 21 services four
  groups.

5
ES framework in MA
Separated supporting service
6
Recent trend be operational

• Avoid double counting
• Primary vs. secondary values (Gren et al, 1994)
  separate supporting service and others (MA 2003)
• Intermediate vs. final (Boyd and Banzhaf 2006)
  (Fisher et al, in preparation)
• Deal with scale mismatch in management
• By spatial scales (e.g. Hein et al, 2006)
• By spatial pattern (Costanza et al.)
• Measure ecosystem functioning
• By production levels (Norberg 1999)
• Identify ESP ES providers (Kremen and Oftesld
  2005)

7
Avoid doubling counting
Fisher et al. in preparation
8
Deal with scale mismatch in management ES by
spatial scale
From Hein et al. 2006
9
Deal with scale mismatch in management ES by
spatial behavior

• Omni-directional flow related
• global no horizontal movement such as carbon and
  existence
• local (dispersion) such as storm protection and
  waste treatment and pollination
• directional flow related flow to point of use
  such as water supply/regulation/flood protection,
  nutrient and sediment regulation
• in site point of use such as rangeland for
  livestock, nitrogen mineralization for ag
  production, soil formation raw materials.
• Recreation/cultural related flow of people to
  unique natural features features such as
  aesthetic/recreation potential

10
Ecologists approach ES by production levels
Adapted from Norberg 1999
11
Review on coastal and nearshore ocean valuation
studies (Wilson and Liu, in review)
Looking for the future

• Significant gaps in ecosystem service research
  invites operational ontology.

Total Studies 70 Observations 155
12
Review on coastal and nearshore ocean
Total Studies 70 Observations 155 (Wilson and
Liu, in review)
13
An operational ontology should

• Build bridges between our current knowledge and
  ecosystem services
• Take into consideration of the interdisiplinary
  nature of ecosystem service research
• Ideally allow us to facilitate benefit transfers
  and to predict ecosystem services
• Here is our proposal

14
Ontology and ecosystem services

• Standards to improve value transfer

15
Lack of common language Land use/land cover

• Traditional LU/LC
• Anderson (1976) Land Use Classification System
• Hierarchical systems (e.g., urban gtgt urban
  residential gtgt urban low density residential)
• Poorly suited for ecosystem service valuation

• Past global valuation studies
• Costanza et al. 1997 11 cover types, nested
  for coastal, forests, wetlands
• Boumans et al. 2002 11 cover types

16
Limitations of value transfer

• Problems with Costanza et al. 1997, numerous
  other studies
• Forest ? forest ? forest

17
Variation in studies
18
Growth of ESV studies

19
Proposed solution superclasses modifiers
20
Important modifiers for forests
Ecological Socioeconomic

• Canopy cover
• Successional stage
• Vegetation turnover rate
• Aboveground woody biomass
• Coniferous/deciduous/mixed
• Fragmentation
• Tree age structure
• Landscape mosaic
• Soil age, type, fertility
• Fire-driven ecosystem
• Endemism level
• Riparian/non-riparian
• Native species dominance
• Climate zone
• Species diversity
• NPP
• Stage of recovery from disturbance

• Marquee status/uniqueness
• Urban-wild gradient
• Ownership status
• Size of unit area
• Human population size
• Per capita income
• Subsistence economy
• Urban pollution levels
• Watershed location
• Proximity to transportation markets
• View
• Crop type
• Legal and practical access status
• Religious and cultural value
• Wilderness area
• Congestion
• Plantation

21
GrOWL Visual Language

• The blue thick arrows denote the relation of
  subclass.
• In OWL there is a special class owlThing which
  represent the class of all things
• The oval box with math sign (For
  All)WetlandType technically represent a class of
  all things that have values of property
  WetlandType within set tidal forested, tidal
  unforested, nontidal forested, nontidal
  unforested

22
Class Hierarchy
23
What weve done so far

• Hierarchical list of ecosystem services
• List of superclasses and modifiers (started at
  NCEAS)
• Working on a Pilot study for forests
• Working paper (Troy, Wilson, Liu and Bagstad) to
  be submitted on needs and limitations of existing
  framework

24
Our vision for end of project

• Provide a Realistic basis for value transfer
• Key modifiers for different superclasses
• Identify research gaps
• Contribution and consensus-building from the ESV
  research community

25
Where you come in

• Desired outcomes, by end of week
• Important modifiers and references (where
  available) for non-forest superclasses
• Desired outcomes, outside assistance by next
  conference?

26
Translating into Ontology Language

• In ontology languages attribute, property, roles
  are interchangeable with modifiers
• It is common in the practice of Object Oriented
  programming to introduce a general superclass for
  classes that have common attributes. In LU
  ontology there is common property Wetland type
  which can be attributed to classes salt and fresh
  wetland.

27
Example Wetland , FW, SW

• In LU ontology there is common property Wetland
  type which can be attributed to classes SW and
  FW.
• We thus can introduce a class Wetland with
  property Wetland type and declare SW and FW to be
  the subclasses of Wetland.

28
GrOWL Visual Language

• The blue thick arrows denote the relation of
  subclass.
• In OWL there is a special class owlThing which
  represent the class of all things
• The oval box with math sign (For
  All)WetlandType technically represent a class of
  all things that have values of property
  WetlandType within set tidal forested, tidal
  unforested, nontidal forested, nontidal
  unforested

29
Common Superclass

• There is a set of properties that appropriate for
  all ten basic categories of land use.
• All those properties could be assigned to a
  general class which will be the top class of the
  land use ontology.
• Provisionally, let us call it EcoClass. Here is
  the diagram that show EcoClass with some common
  attributes

30
Class Hierarchy
