Whats new in chronic ulcer management

1
Whats new in chronic ulcer management ?

• Dhanakom Premprapha

2
Wound Definition

• A breach of the epidermis of skin that can lead
  to infection and sepsis

3
Classification

• Acute wound
• Chronic wound

4
Acute wound

• Mechanical force
• Healing process
• Coagulation phase
• Inflammatory phase
• Proliferative phase
• Remodeling phase

5
Chronic wound

• Fail in healing process
• Persist inflammatory phase
• Cellular senescence
• Repetitive trauma

6
Chronic wound

• Common cause
• Venous stasis
• Diabetes mellitus
• Pressure necrosis
• Other cause
• Malignancy
• Vasculitis
• Pyoderma gangrenosum

7
Type of wound healing

• Primary wound healing
• Secondary wound healing
• Epithelialization

8
Wound bed preparation

• Debridement
• Control infection
• Environment for healing
• Moist wound healing
• Dressing

9
Debridement

• Why debride?
• Wound assessment
• Infection
• Necrotic tissue delays formation of granulation
  and epithelial tissue
• Initiate healing process

10
Debridement

• Surgical debridement
• Mechanical debridement
• Wet to dry dressing
• Forceful saline irrigation

11
Debridement

• Enzymatic debridement
• Papain
• Collagenase
• Autolytic debridement
• Occlusive dressing

12
Debridement

• Biological debridement
• Maggots therapy
• Quite effective in removing necrotic debris
• Useful when antibiotic resistant

13
Topical antibiotic

• Bactericidal gt Bacteriostatic
• Broad spectrum
• Minimal tissue irritation
• Not inhibit healing process
• Minimal systemic effect
• Sustained action

14
Topical antibiotic

• Iodine the most toxic agent on fibroblast
• New agent Iodosorb
• Hydrogen peroxide
• Silver compounds
• Silver sulfadiazine
• Silvernitrate
• Noncrystalline silver compounds (Acticoat)

15
Topical antibiotic

• Mefenide
• Acetic acid
• Chlorhexidine
• Sodium Hypochlorite (Dakins solution)
• Topical antibiotic

16
Wound healing materials

• Traditional product
• Advanced product
• Moist wound healing
• Active product
• Bioactive compounds enhance healing
• Tissue engineering
• Nanotechnology gt Nanocrystalline silver

17
Dressing

• Desirable dressing characteristics
• Protect wound from bacterial and FB
• Absorb exudate
• Prevent heat and fluid loss
• Provide compression
• Be nonadherent
• Create a warm, moist occluded environment
• Be esthetically attractive

18
Dressing

• Occlusive dressing concept
• Dry wound
• Occlusive
  dressing
• Moist wound

19
Dressing

• Occlusive dressing concept
• Maintainaning an occluded environment
• Maintain mildly acidity pH
• Relative low oxygen tension on surface

20
Dressing

• Placing an occlusive dressing on an infected
  wound encourages bacterial proliferation and
  exacerbates the infection

21
Type of dressing

• Non adherent fabrics
• Absorptive
• Occlusive
• Nonbiologic
• Biologic
• Creams, ointment, solution

22
Type of dressing

• Nonadherent fabrics
• Xeroform
• Xeroflo
• Adaptic
• Meditel

23
Type of dressing

• Absorptive dressing
• Gauze gt adhere to wound
• Foams gt Absorbent and nonadherent
• gt Expand and conform to wound
• Lyofoam(Convatec), Flexzan(Dow Hickham)
• Curafoam(The kendall company), Biopatch(JJ)

24
Type of dressing

• Occlusive dressings Non biologic
• Film Transparent, Nonabsorbtive
• Tegaderm(3M), Bioclusive(JJ),
• Op-site(Smith Nephew)

25
Type of dressing

• Occlusive dressings Non biologic
• Hydrocolloids Absorbtive dressing
• Duoderm(Convatec), Cutinova(SmithNephew),
  Nuderm(JJ),

26
Type of dressing

• Occlusive dressings Non biologic
• Alginates Calcium salt of seaweed
• Utility in exudative wound
• Algosteril(JJ), Kaltostat(Convatec),

27
Type of dressing

• Occlusive dressings Non biologic
• Hydrogels 80 water
• Rehydration to dry wound
• Poor absorptive effect
• Nugel(JJ), Tegagel(3M), Flexigel(SmithNephew)

28
Type of dressing

• Occlusive dressings Non biologic

29
Type of dressing

• Occlusive dressings Non biologic
• Healing and limit pain gt Nonocclusive
• Not differ in epithelialization and healing

30
Type of dressing

• Occlusive dressings Bioactive
• Skin substitutes
• Bilayer analog
• Epidermal analog
• Dermal analog lt dermal factor

31
Type of dressing

• Occlusive dressings Bioactive
• Temporary
• Homograft Cadaver skin
• Xenograft Pig skin
• Amnion
• Transcyte(SmithNephew)
• Biobrane(Dow hickham)

32
Type of dressing

• Occlusive dressings Bioactive
• Permanent
• Apigraft (Organogenesis Inc, Novartis USA)
• Dermagraft (Advanced tissue sciences Inc, USA)
• Alloderm (Lifecell, USA)
• Integra (Integra life science corporation, USA)

33
Negative pressure wound therapy

• Mechanism
• Edema
• Blood perfusion
• Cell proliferation
• Infection
• Dressing change

34
Negative pressure wound therapy (V.A.C. system)

• Component
• Open-cell foam
• Suction tube
• Adhesive drape
• Suction and reservoir

35
Negative pressure wound therapy (V.A.C. system)
36
Negative pressure wound therapy (V.A.C. system)
37
Negative pressure wound therapy (V.A.C. system)
38
Negative pressure wound therapy (V.A.C. system)
39
Negative pressure wound therapy (V.A.C. system)
40
Negative pressure wound therapy (V.A.C. system)
41
Hyperbaric Oxygen Therapy

• The intermittent systemic administration of 100
  oxygen under pressure greater than atmospheric

42
Hyperbaric Oxygen Therapy

• Produce neo-vascularization
• Normalized PMN function
• Direct toxic to anaerobic organism
• Improved activity of ATB
• Improved epithelialization

43
Hyperbaric Oxygen Therapy
44
Diabetic ulcer

• Neuropathic ulcer
• Ischemic ulcer
• Infective ulcer

45
Diabetic ulcer Neuropathic ulcer

• Sensory function
• Pain Touch
• Motor function
• Intrinsic muscles of foot
• Autonomic function
• Sympathetic function

46
Diabetic ulcer Neuropathic ulcer

• ????????????
• ??????????????????????????
• ??????????
• ??????????????????????? (Callus)
• ?????????

47
Diabetic ulcer Neuropathic ulcer
48
Diabetic ulcer Neuropathic ulcer

• ?????
• ???????????????
• ??????????? ???? ? ??? ?
• ??????????????
• Loss of sensation
• Foot deformity (Charcot deformity)
• ??????????????

49
Diabetic ulcer Neuropathic ulcer

• Charcot deformity

50
Diabetic ulcer Ischemic ulcer

• Intermittent claudication
• Rest pain
• Dry gangrene
• Infection
• Wet gangrene

51
Diabetic ulcer Ischemic ulcer

• ????????????
• ??????????????????????????
• ???????????
• ??????????????????????

52
Diabetic ulcer Ischemic ulcer

• ?????
• ???????????????
• ?????????????
• ???????????????????????????
• ??????????????
• ??????? ???? ???
• ?????????????????
• ??????????????

53
Diabetic ulcer Infective ulcer

• Superficial abscess
• Cellulitis
• Fasciitis
• gt Necrotizing fasciitis
• Deep abscess

Septicemia
54
Diabetic ulcer Infective ulcer

• ????????????
• ?????? ??????
• ?????
• ??? ???
• ??????????????
• ???????????????????????
• ???? ??????????

55
Diabetic ulcer Infective ulcer
56
Diabetic ulcer

• Diabetic triopathy
• Neuropathy
  Infection
• Limb loss
• Ischemia

57
Diabetic ulcer

• ????????????
• X-ray
• Doppler ultrasonography
• ABPI
• Arteriography
• Culture

58
Diabetic ulcer
Calcified artery
59
Diabetic ulcer Treatment

• Neuropathic ulcer
• Rest
• Debridement
• Dressing
• Off-loading

60
Diabetic ulcer Treatment

• Ischemic ulcer Mild
• Intermittent caudication
• Risk modification
• Medication

61
Diabetic ulcer Treatment

• Ischemic ulcer Severe
• Rest pain
• ABI lt 5
• Risk modification
• Arterial bypass surgery
• Amputation

62
Diabetic ulcer Ischemic ulcer
63
Diabetic ulcer Treatment

• Ischemic ulcer Dressing
• Debridement only infective tissue
• Moist wound dressing
• Do not pressure dressing
• Re-evaluate

64
Diabetic ulcer Treatment

• Infective ulcer Mild
• OPD case
• I D - Debridement
• Oral ATB
• Control DM
• Dressing

65
Diabetic ulcer Treatment

• Infective ulcer Severe
• Fever or sepsis
• Rx IPD
• H/C, Pus C/S
• Parenteral ATB
• Control DM with insulin

66
Diabetic ulcer Treatment

• Infective ulcer Severe
• Adequate debridement and drainage
• 2-3 dressing change/day
• Amputation in severe infection

67
Diabetic ulcer Infective ulcer

• Ischemia infection

68
Diabetic ulcer Infective ulcer

• Ischemia infection

69
Diabetic ulcer Prevention

• ?????????????????????????????
• ????????????????????????????
• ?????????????????????????????????
• ?????????????????????

70
Diabetic ulcer Prevention

• ?????????????????????????????????????
• ??????????????????????????????????
• ?????????????????????????????
• ?????????????????????????????????

71
Diabetic ulcer Off-loading

• Redistribute or reduce pressure from wound
• Goal reduce pressure at ulcer while keeping the
  patient ambulatory

72
Diabetic ulcer Off-loading

• Total contact cast (TCC)

73
Diabetic ulcer Off-loading

• Walking splint/Removable cast walker (RCW)

74
Diabetic ulcer Off-loading

• Healing shoes

75
Diabetic ulcer Off-loading

• Healing shoes

76
Diabetic ulcer Coverage

• Secondary healing
• STSG
• Local flap
• Distant flap
• Free flap

77
Venous stasis ulcer

• Chronic venous insufficiency
• Abnormal peripheral venous system that reduces
  venous return

78
Venous stasis ulcer
79
Venous stasis ulcer
80
Venous stasis ulcer

• Classification CVI
• Class 0 No visible and palpable signs of
  disease

81
Venous stasis ulcer

• Classification CVI
• Class 1 Telangiectasia or Reticular vein

82
Venous stasis ulcer

• Classification CVI
• Class 2 Varicose veins

83
Venous stasis ulcer

• Classification CVI
• Class 3 Edema

84
Venous stasis ulcer

• Classification CVI
• Class 4 Skin change Hyperpigmentation

85
Venous stasis ulcer

• Classification CVI
• Class 5 Healed ulcer
• Class 6 Active ulcer

86
Venous stasis ulcer

• Prevention of CVI
• Leg support elastic bandage
• elastic support hose
• ( 30-40 mmHg at ankle )
• Leg elevation
• Skin care

87
Venous stasis ulcer

• Treatment
• General treatment
• Local treatment
• Surgery

88
Venous stasis ulcer

• Compression therapy
• Importance and effective to improve healing
• Compliance is importance

89
Venous stasis ulcer

• Compression therapy
• Tubigrip

90
Venous stasis ulcer

• Compression therapy
• Jobst

91
Venous stasis ulcer

• Compression therapy
• Contraindication in PAD
• Precaution in CHF
• Multilayer compression wraps
• Profore (Smith Nephew)
• Dynaflex (Dyna-Flex international)

92
Venous stasis ulcer

• Profore

93
Venous stasis ulcer

• Profore

94
Venous stasis ulcer

• Profore

95
Venous stasis ulcer

• Profore

96
Venous stasis ulcer

• Profore

Tricotex
Allevyn standard
97
Venous stasis ulcer

• Profore 1
• Soffban natural
• Natural wool
• Absorb exudate
• Protects bony prominences

98
Venous stasis ulcer

• Profore 2
• Soffcrepe
• Adds absorbency and smoothes the orthopaedic wool
  layer

99
Venous stasis ulcer

• Profore 3
• Litepress
• Light compression bandage
• Highly conformable

100
Venous stasis ulcer

• Profore 4
• Co-plus
• Cohesive flexible bandage
• Applied pressure

101
Venous stasis ulcer

• Prevent recurrence

102
What direction we go in the caring of out
pateint 2006

• Better patient care is the best reason to adopt
  a multidisciplinary approach to wound care.

•
  Dermatol clin21,(2003)
• Wound care clinic

103
Power by vascular unit Department of surgery
