Evolution of paralogous proteins

1
Evolution of paralogous proteins

• Level 3 Molecular Evolution and Bioinformatics
• Jim Provan

Patthy Sections 7.1 - 7.3
2
Advantagous duplications

• Duplication of a complete protein-coding gene
  results in two identical duplicons
• Encode same protein and express it in the same
  way as original
• Duplication will be advantageous if increased
  supply of gene product is advantageous (e.g
  histones or ribosomal proteins)
• Duplication by retroposition results in a
  processed duplicon
• Same protein encoded but expression likely to be
  different
• Duplication will be advantageous if change in
  expression pattern (tissue specificity,
  developmental stage) has biological advantage
• Fully redundant functions (neutral duplications)
  may be lost through drift but may persist long
  enough to acquire an advantageous function
• New proteins generally arise through modulation
  of existing ones

3
Advantageous duplication of unprocessed genes

• Duplications are advantageous and maintained by
  positive selection if having multiple genes
  performing the same function ensures enhanced
  efficiency e.g. histones
• Positive selection for advantageous gene
  duplications can be observed in
• Insects exposed to insecticides
• Tumours and protozoa exposed to drugs
• Various stomach lysozymes in ruminants
• Seven closely related mRNAs encoding lysozymes
• Multiple lysozyme genes arose through duplication
• Serial duplication of lysozyme gene was an
  adaptive response to increase the expression of
  lysozyme

4
Advantageous duplication of processed genes

• Due to changes in chromosomal environment and/or
  5 regulatory regions, processed gene may have
  altered regulatory features and may not be
  competing with its progenitor
• Lower fidelity of reverse transcription means
  that duplicon may have deleterious mutations and
  be lost
• Two examples of positive selection increasing the
  chance of survival of testis-specific processed
  genes
• Phosphoglycerate kinase retrogene
• Pyruvate dehydrrogenase E1a retrogene

5
The phosphoglycerate kinase retrogene

• Two functional PGK loci in the mammalian genome
• PGK-1 is X-linked and expressed constitutively in
  all somatic cells
• PGK-2 is a functional autosomal gene expressed in
  a tissue-specific manner exclusively in the late
  stages of spermatogenesis
• PGK-2 lacks introns and has a poly(A) tail
  processed gene
• Evolution of PGK-2 was a compensatory response to
  inactivation of the X-linked gene before meiosis
• Mature spermatozoa require PGK to metabolise
  fructose in semen
• X-inactivation called for a functional autosomal
  PGK locus
• Unequal crossing-over would not have solved this
  problem
• Processed gene had an initial advantage since it
  permitted the expression of PGK in a tissue where
  the X-linked gene was inactivated
• Subsequently evolved a testis-specific promoter

6
The pyruvate dehydrogenase E1a retrogene

• PDH E1a subunit of the PDH complex is located on
  the X chromosome and is expressed in somatic
  tissues
• Another PDH E1a locus is found on chromosome 4
• Testis-specific and expressed in postmeiotic
  spermatogenic cells
• Lacks introns, has a downstream poly(A) tract and
  is flanked by a pair of 10 bp direct repeats
• After the last meiotic division, spermatids rely
  on energy from pyruvate for the maturation
  process PDH E1a is essential
• X-chromosome is inactivated in postmeiotic
  spermatogenic cells
• Only half the cells contain an X-chromosome
• Evolution of an alternative, non-X-linked gene

7
Neutral duplications

• If there is no selective advantage from a
  duplication event, functional constraints
  protecting the new gene from deleterious
  mutations may be relaxed
• May ultimately be converted to a pseudogene
• Many clusters of duplicated genes contain
  pseudogenes
• Advantageous mutations, either in the coding
  sequence or the regulatory region, may lead to
  positive selection
• Where there is a major change of function,
  several critical sites may be involved
• New function might not be fully manifested until
  several sites have adapted
• Early mutational steps may be selectively neutral

8
Visual pigment proteins

• Old World primates have three colour-sensitive
  proteins
• Green- and red-absorbing photoreceptors are
  encoded by a pair of closely related (96
  identity), closely linked genes on the X
  chromosome - suggests very recent gene
  duplication
• Blue photoreceptor is encoded by an autosomal
  gene
• New World monkeys have only one X-linked pigment
• Duplication must have occurred in the ancestor of
  Old World monkeys after divergence from New World
  monkeys
• Humans, apes and Old World monkeys can
  discriminate three colours whereas New World
  monkeys can only distinguish two
• Prior to emergence of three pigments, rate of
  non-synonymous substitution exceeded synonymous
  rate suggests positive selection for
  three-colour vision

9
Serine proteinases and their inhibitors

• Pancreatic proteinases (trypsin, chymotrypsin and
  elastase) illustrate paralogues with minor
  modifications of function
• Strikingly similar three-dimensional structures
• Very different substrate specificities
• Elastase cleaves residues with small, non-polar
  side chains (Ala, Val etc.)
• Chymotripsin cleaves at bulky, hydrophobic
  residues (Phe-X, Tyr-X etc.)
• Trypsin cleaves only Arg-X or Lys-X
• Advantage of having multiple digestive
  proteinases is clear their combined activities
  ensure more efficient utilisation of proteins in
  foodstuffs.
• Original duplicons survived since they acquired
  advantageous mutations that diversified their
  function

10
Serine proteinases and their inhibitors

• Molecular basis of differences in substrate
  specificity can be rationalised from
  three-dimensional structure and understanding of
  the catalytic mechanism
• Specificity of trypsins for Arg or Lys residues
  is due to
• Deep substrate binding site which can accommodate
  side chains
• Asp-189 residue at the bottom of the pocket which
  neutralises the Arg / Lys residue of the
  substrate
• Specificity of chymotrypsin for bulky aromatic
  residues due to
• Large, hydrophobic substrate binding pocket
• Small, neutral (usually Ser) residue at position
  189
• Elastase has shallower binding site
• Residues 216 and 226 have small side chains in
  trypsin/chymotrypsin
• Elastase has bulkier residues (Val, Thr) at these
  positions

11
Serine proteinases and their inhibitors

• Substitution of a few, key residues can alter
  sequence specificity without eliminating enzyme
  activity
• Replacement of Asp-189 of trypsin with a Ser
  residue (to mimic chymotrypsin) greatlydiminishes
  activity towards Lys or Arg and increases
  specificity for hydrophobic substrates 10- to
  50-fold
• Lack of complete change of substrate suggests
  that other readjustments had to occur during
  divergence of trypsin and chymotrypsin from their
  common ancestor
• Supports notion that new function may emerge by
  continual improvement of function
• Correlated with functional adaptation of serine
  proteinase inhibitors
• Porcine elafin genes have 93-98 conservation in
  introns but only 60-77 similarity in exon 2,
  which encodes the inhibitor domain
• Due to accelerated mutation rate KA gtgt KS

12
UDP-glucuronosyltransferases (UDPGTs)

• UDPGTs detoxify hundreds of compounds by
  conjugation and increasing water solubility to
  facilitate excretion
• In mammals, bilirubin (by-product of haem
  turnover) must undergo detoxification by
  conjugation to glucuronic acid
• Glucuronidation is carried out by a large family
  of UDPGTs with different, but overlapping,
  substrate specificities
• Means that UDPGTs also affect levels of several
  hormones
• Overproduction (through whole-gene duplication)
  deleterious
• UDPGTs have distinct domains serving different
  functions
• N-terminal globular domain which binds toxic
  substrate
• C-terminal globular domain involved in
  UDP-glucuronic acid binding
• Substitutions in restricted regions of N-terminal
  domain led to diversification of substrate
  specificities

13
UDP-glucuronosyltransferases (UDPGTs)

• Two families of UDPGTs in mammals which differ
  markedly in evolutionary strategy used for
  functional diversification
• UDPGT2B subfamily has evolved through classic
  process of whole gene duplication resulting in
  several isoforms
• Clustered gene family on chromosome 4
• Primary substrates include 4-hydroxysterone and
  hyodeoxycholic acid
• Single UDPTG1 gene complex on chromosome 2 has
  diversified by duplication only of exon 1, which
  encodes substrate-binding domain
• Human UDPGT1 gene complex has six closely related
  exon 1 variants
• Single set of four exons that encode the
  C-terminal parts of UDPGTs
• mRNAs of different isoforms produced by
  differential splicing of one of the exon 1
  variants onto the constant C-terminal exons

14
Major change of function in paralogous genes

• Some members of the serine protease family (e.g.
  haptoglobin, hepatocyte growth factor,
  azurocidins) have lost their capacity to act as
  proteinases
• Have lost one or more of the residues in the
  catalytic triad
• Have other important biological functions
• Haptoglobin binds globin release from lysed
  erythrocytes
• Hepatocyte growth factor acts through specific
  receptor tyrosine kinases to stimulate cell
  growth
• Azurocidin has bactericidal activity
• Careful analysis sometimes indicates plausible
  pathway for transition from one function to
  another

15
Evolution of azurocidins

• Azurophil granules of neutrophils contain several
  proteins implicated in the killing of
  microorganisms
• Serine proteases that cause degradation of
  connective tissues (cathepsin G, neutrophil
  elastase, proteinase 3)
• Azurocidin is similar to these but lacks His-57
  and Ser-195 and thus has no proteolytic activity
• Bactericidal activity of azurocidin mediated by
  tight binding to anionic lipopolysaccharide, a
  component of the Gram-negative bacterial
  envelope
• Serine proteinase fold used as a scaffold for
  endotoxin binding
• Fact that azurocidins share most recent common
  ancestor with proteinases that have antibacterial
  activity suggests that this was a common function
  of the ancestor
• New function probably emerged before original
  function was lost

16
Major change of function by domain acquisition

• In proteinases involved in blood coagulation,
  very large segments are joined to the
  trypsin-homologue region
• These nonproteinase parts of plasma proteinases
  consist of multiple structural-functional domains
  that were introduced by exon shuffling
• Function modified not only by point mutations but
  also by domain insertions and duplications
• Proteinase domains retained proteolytic activity
  but point mutations led to a altered (usually
  narrower) sequence specificity
• Value of domain-acquisition mutations is that
  they can endow novel binding specificities and
  lead to dramatic changes in regulation and
  targeting

17
Modular structure of blood coagulation and
fibrinolytic proteinases
18
Domain acquisition in the evolution of plasma
proteinases

• Selective value of domains joined to proteinase
  domain illustrated by fact that they are usually
  involved in interactions with cofactors,
  substrates or inhibitors
• Vitamin K-dependent calcium-binding domains of
  prothrombin, coagulation factors VII, IX, X and
  protein C anchor proteinases to phospholipid
  membranes ensuring proper regulation of cascade
• Kringle domains of plasmin and plasminogen are
  critical for binding of proteinase to its primary
  substrate, fibrin
• Serine proteinase domain has proteinase
  specificity very similar to that of trypsin
  (Lys-X and Arg-X)
• Fibrin specificitydue to fact that kringle
  domains have specific fibrin-binding sites that
  target the enzyme to fibrin

19
Similarities and differences in the evolution of
paralogous and orthologous proteins

• Common protein folds are conserved in both
  paralogues and orthologues and structural
  elements generally accept mutations at similar
  rates between the two
• One difference is that orthologous proteins are
  likely to fulfil very similar functions in
  different species whereas paralogous proteins are
  more likely to have diversified in function
• When comparing orthologous proteins, residues
  that are critical for structure, function and
  specificity are equally likely to be conserved
• When comparing paralogous proteins that fulfil
  different functions, only residues essential for
  structure are likely to be conserved
