Decoding Algorithms for Statistical Machine Translation

1
Decoding Algorithms for Statistical Machine
Translation

• Dr. Joy Ying Zhang
• Carnegie Mellon University

2
Carnegie Mellon University Silicon Valley
3
CMU SV Campus
4
In a few years
5
Outline

• Overview
• Monotone decoder
• Decoding with reordering
• Jumping window
• Decoding with ITG
• Hierarchical decoder
• Decoder for mobile devices

6
Phrase-based SMT
7
Decoding is NP Complete

• Even the simplest decoding algorithm is
  NP-complete complexity is exponential to the
  sentence length. Just as a Travelling Salesman
  Problem (TSP) Knight et. al. 99

8
Decoding as TSP

• In a word-to-word translation model
• The order to choose the next source word to
  translate is like to choose the next city to
  visit
• To choose the target translation is like to
  choose which hotel to stay in a city
• The optimal translation corresponds to the
  optimal city/hotel choice.
• We can only afford a suboptimal solution ?
• Lets start with the simplest one

9
Monotone Decoding

• No reordering is allowed, decoding from left to
  right
• Apply translation model over the testing sentence
  to build up a lattice
• Search the lattice for a best path given all
  knowledge sources (translation model, language
  model, sentence length model )

10
Monotone Decoding

• Traverse the lattice from left to right
• Building partial translation hypotheses for each
  node (what are good translations up to this
  source positions)
• Output the best that covers the complete
  sentence as the final translation.

11
Probability/Score of a Partial Hyp

• Depends on the model used in decoder
• Translation model scores under the independent
  assumption.
• E.g. P(e1en f1fm) P(e1..e3
  f1f4)P(e4..e5 f5f6)..
• Language modelP(e1en )
• Sentence length model score(n src length)
• Distortion model
• And be creative ..

12
Sentence Length Model

• Different language have different level of
  wordiness
• Histogram over source sentence length target
  sentence length shows that distribution is rather
  flat -gt p( J I ) is not very helpful
• Very simple sentence length model the more the
  better
• i.e. give bonus for each word (not a
  probabilistic model)
• Balances shortening effect of LM
• Can be applied immediately, as absolute length is
  not important
• However this is insensitive to whats in the
  sentence
• Optimize length of translations for entire test
  set, not each sentence
• Long sentences are made longer to cover for
  sentences which are too short

13
Partial Hypotheses Recombination

• For each source word and phrase, there are t
  translation alternatives.
• If simply combine them, final node will have
  tJ hyps to be explored.
• However, many partial hyps are not
  distinguishable to decoder models
• If using TM and a 3-gram LM only
• I will come to office
• I came to office

14
Recombination of Hypotheses

• Recombination Of two hypotheses keep only the
  better one if no future information can switch
  their current ranking
• Notice this depends on the models
• Model score depends on current partial
  translation and the extension, e.g. LM
• Model score depends on global features known only
  at the sentence end, e.g. sentence length model
• The models define equivalence classes for the
  hypotheses
• Expand only best hypothesis in each equivalence
  class

15
Recombination of Hypotheses Example

• TM and n-gram LM only
• Hypotheses
• H1 I would like to go
• H2 I would not like to go
• Assume as possible expansions Eto the movies
  to the cinema and watch a film
• LMscore is identical for H1Expansion as for
  H2Expansion for bi, tri, four-gram LMs
• E.g 3-gram LMscore Expansion 1 is-logpr( to
  to go ) - logpr( the go to ) logpr( movies
  to the)
• Therefore Cost(H1) lt Cost(H2) gt Cost(H1E) lt
  Cost(H2E) for all possible expansions E

16
Beam Pruning

• Still a lot of partial hyps to explore even after
  the recombination for each node in lattice (src
  sentence up to this position)
• To a not so good partial hyp Sorry, we dont
  give you chances any more since you failed this
  mid-term
• Prune H if it is not the top B-best hyp --- Beam
  Size Pruning
• Prune H if its score is lower than factorbest
  score --- Beam Factor Pruning
• Pruning reduces number of partial hyps to
  explore faster decoding
• But it eliminates those might become good
  translations later on

17
Beam Pruning
18
Rest-Cost Estimation

• In Pruning we compare hyps, which are not
  strictly equivalent under the models
• Risk prefer hypotheses which have covered the
  easy parts
• Remedy estimate remaining cost for each
  hypothesis
• Want to know minimum expected cost (similar to A
  search)
• Gives a bound for pruning
• However, not possible with acceptable effort
• Want to include as many models as possible
• Translation model costs, word count, phrase count
• Language model costs
• Distortion model costs
• Calculate expected cost for each span (l, r)
  R(l, r)

19
Rest Cost for Translation Models

• Translation model, word count and phrase count
  features are local costs
• Depend only on current phrase pair
• Strictly additive R(l, m) R(m, r) R(l, r)
• Minimize over alternative translations
• For each source phrase span (l, r) initialize
  with cost for best translation
• Combine adjacent spans, take best combination

20
Rest Cost for Language Models

• We do not have history -gt only approximation
• For each span (l, r) calculate LM score without
  history
• Combine LM scores for adjacent spans
• Notice p(e1 em) p(em1 en) ! p(e1 en)
  beyond 1-gram LM

• Alternative fast monotone decoding with TM-best
  translations
• History available
• Then R(l,r) R(1,r) R(1,l)

21
Rest Cost for Distance-Based DM

• Distance-based DM rest cost depends on coverage
  pattern
• To many different coverage patterns, can not
  pre-calculate
• Estimate by jumping to first gap, then filling
  gaps in sequence
• Moore Quirk 2007 DM cost plus rest cost

S
S
S
Previous phrase
Gap-free initial segment
Current phrase
L(.) length of phrase, D(.,.) distance
between phrases
S adjacent S d0
S left of S d2L(S)
S subsequence of S d2(D(S,S)L(S))
Otherwise d2(D(S,S)L(S))
22
Rest Cost for Lexicalized DM

• Lexicalized DM per phrase
• DM(f,e) scores in-mon, in-swap, in-dist,
  out-mon, out-swap, out-dist
• Treat as local cost for each span (l, r)
• Minimize over alternative translations and
  different orientations in- and out-

23
Effect of Rest-Cost Estimation

• From Richard Zens 2008
• LM is important, DM is important

24
Output Best Translation

• Optimal hypothesis in the last node of the
  lattice
• We need to keep the back pointers

25
Monotone Decoding Algorithm

• Apply TM on sentence f1fJ
• For j1 to J
• Foreach incoming edge e that enters node j
• Edge e i-gtj
• Foreach partial hyp h in node I
• Extend h with edge e
• Estimate hyp prob/score for he
• Store lthe, prob/score, back pointer to hgt in
  node j
• Prune partial hyps in node j
• In node J, find out the best hyp
• Follow the backpointers and output the final
  translation

26
Output N-best List

• When traverse back from the last node, decoder
  can output the top N-best hyps for the whole
  sentence N-best list.
• Model scores do not correlate well with external
  scores such as BLEU
• In a 1000-best list, hyps with the highest BLEU
  ranks about 489.38 according to their model
  scores.

27
N-Best List
28
N-Best Rescoring

• Generate n-best list
• Use different TM and/or LM to rescore each
  translation -gt reordering of translations, i.e.
  different best translation
• Different TMs
• Use IBM1 lexicon for entire translation
• Use HMM-FB and IBM4 lexicons
• Forced alignment with HMM alignment model
• Different LMs
• Very large LM (Distributed Language Model)
• Link grammar too slow)
• Other syntax-based LMs, e.g. Charniaks parser?

29
Problem with N-Best Generation

• Duplicates from different transducers
• _at_Lex A B 0.5
• _at_ISA A B 0.7
• -gt Two identical translations with different
  scores or even same score (when rescoring all
  translations with same lexicon)
• Spurious ambiguities
• us companies and other institutions
• us companies and other institutions
• us companies and other institutions
• us companies and other institutions
• . . .
• Example run 1000 n-best -gt 400 different
  strings on average Extreme case only 10 unique
  strings
• Possible solution Checking uniqueness during
  backtracking

30
Oracle Score of N-best List
31
Using Distributed LM for Reranking Systems

• Large training data available
• Distributed computing clusters
• Distributed language modeling (Zhang and Vogel,
  2006 Emami, 2007 Brants et al, 2007)?

32
Rerank the N-Best List using LM Features
33
Rerank N-best List
34
Rerank N-best List
35
Rerank N-best List

• Considering long-distance dependencies

36
Reranking N-best List
37
Tuning the SMT System

• We use different models in SMT system
• Models have simplifications
• Trained on different amounts of data
• gt Different levels of reliability
• gt Give different weight to different ModelsQ
  c1 Q1 c2 Q2 cn Qn
• Find optimal scaling factors c1 cn
• Optimal means Highest score for chosen
  evaluation metric

38
Automatic Tuning

• Many algorithms to find (near) optimal solutions
  available
• Simplex
• Maximum entropy
• Minimum error training
• Minimum Bayes risk training
• Genetic algorithm
• Note models are not improved, only their
  combination
• Large number of fully translations required gt
  still problematic when decoding is slow

39
Automatic Tuning on N-best List

• Generate n-best lists, e.g. for each of 500
  source sentences 1000 translations
• Loop
• Changing scaling factors results in re-ranking
  the n-best lists
• Evaluate new 1-best translations
• Apply any of the standard optimization techniques
• Advantage much faster
• Can pre-calculate the counts (e.g. n-gram
  matches) for each translation to speed up
  evaluation
• For Bleu or NIST metric with global length
  penalty do local hill climbing for each
  individual n-best list

40
Minimum Error Training

• For each scaling factor we have Q ck Qk
  QRest
• For different values different hyps have lowest
  score
• Different hyps lead to different MT eval scores

41
Decoding with Reordering

• Languages are of different word orders
• 1??/Austrilia 2?/is ?/with 3??/North Korea
  4?/has 5??/diplomatic relationship 6?/of
  7??/a few 8??/countries 9??/one of
• Austrilia is one of the few countries that have
  diplomatic relationship with North Korea
• To generate the right English translation, we
  need to translate the source in order of 12967845
• Reordering either change the order to translate
  the source, or equivalently re-arrange the
  partial translations
• Knowledge sources
• Reordering models
• Language models
• Syntax

42
Reordering Strategies

• All permutations
• Any re-ordering possible
• Complexity of traveling salesman -gt only possible
  for very short sentences
• Small jumps ahead filling in the gaps pretty
  soon
• Only local word reordering
• Implemented in current decoder
• Leaving small number of gaps fill in at any
  time
• Allows for global but limited reordering
• Similar decoding complexity exponential in
  number of gaps
• IBM-style reordering (described in IBM patent)
• Merging neighboring regions with swap no gaps
  at all
• Allows for global reordering
• Complexity lower than 1, but higher than 2 and 3

43
Decoding with Reordering Window

• Word and phrase reordering within a given window
• From first un-translated source word next k
  positions
• Window length 1 monotone decoding
• Restrict total number of reordering (typically 3
  per 10 words)
• Simple Jump model
• One reordering typically includes two jumps
• Jump distance D depends on gap and also on phrase
  lengthdistance measured from center of phrase to
  center of phrase
• Simple Gaussian distribution p(D) exp( D - 1)
• Lexicalized jump model

44
Jumping ahead in the Lattice

• Hypothesis describes a partial translation
• Coverage information, Back-trace information,
  Score
• Expand hypothesis over uncovered position

I will come
to your office
I come
tomorrow
to
you
come
I
morgen
zu
dir
ich
komme
h c11000, tI will come
h c11011, tI will come to your office
h c11111, tI will come to your office tomorrow
45
Word Order Coverage Info

• Need to know which source words have already been
  translated
• Dont want to miss some words
• Dont want to translate words twice
• Can compare hypotheses which cover the same words
• Use Coverage vector to store this information
• Essentially a bit vector
• For small jumps ahead position of first gap
  plus short bit vector
• For small number of gaps array of positions of
  uncovered words
• For merging neighboring regions left and right
  position

46
Decoding with Inverted Transduction Grammar

• Translation model phrase to phrase translation
• May include lexicalized reordering probabilities
• Grammar X-gtltF1F2, E1E2gt X-gtltF1F2, E2E1gt
  X-gtltf, egt

47
Combine Adjacent Edges

• Take adjacent edges el and er and create a new
  edge e
• e.FromNode el.FromNode
• e.ToNode er.ToNode
• e.Translation el.Translation er.Translation

tomorrow I will come
I will come
to your office
I come
to
you
come
tomorrow
I
morgen
zu
dir
ich
komme
hl c(0,2), tI will come
hr c(2,3) ttomorrow
h c(0,3), tI will come tomorrow
48
And Allow For Reordering

• Create additional edge
• e.FromNode el.FromNode
• e.ToNode er.ToNode
• e.Translation er.Translation el.Translation

tomorrow I will come
I will come
to your office
I come
to
you
come
tomorrow
I
morgen
zu
dir
ich
komme
hl c(0,2), tI will come
hr c(2,3) ttomorrow
h c(0,3), ttomorrow I will come
49
Chart-Decoder for Simple ITG

• Recall Simple ITG binary tree
• Word reordering straight and inverted subtrees
• Allows long distance reordering first-gtlast
  word, last -gt first word
• Generation of partial hypotheses
• Initialize with phrase translations
• Combine adjacent areas into longer translations
• Allow for swaps
• Requires different organization of decoder

50
Chart Decoder
51
LM in Chart-Based Translation

• Language model states on both sides
• History has not been seen
• Combine h(0,2) abc with h(2,5) de to give
  h(0,5) abcde
• Calculated was p(a) p(ba) p(cab)and
  p(d) p(ed)
• But now needed p(dbc) p(fde)
• Partly undo calculation
• subtract wrong log probs p(d) p(ed)
• add correct log probs p(dbc) p(fde)
• For short extensions just extend from left
  hypothesis
• For long extensions, faster to correct LM score

52
Effect of Reordering

• Arabic devtest set (203 sentences)
• Chinese test set 2002 (878 sentences)

• Reordering mainly improves fluency, i.e. stronger
  effect for Bleu
• Improvement for Arabic 4.8 NIST and 12.7 Bleu
• Less improvement for Chinese 5 in Bleu

53
Effect of Reordering
Arabic/English translation
54
Effect of Reordering
55
Hierarchical Decoding

• Translation model phrase pairs with holes
  (phrase of phrases)
• Consider hierarchical phrase pairs as translation
  rules
• Decoding is a CYK parsing find the optimal
  synchronous parsing tree

56
Hierarchical Decoding (no LM)
57
Decoding as Parsing (Hiero)
58
SMT Decoder for Mobile Devices

• Mobile speech translators
• Fast (close to real time) speech translation
• Domain limited but should not limit to
  pre-recorded sentences
• Two-way translation
• Challenges
• Weaker CPU (e.g. iPhone 3G S 600MHz)
• Tiny RAM a few MB, up to 256 MB
• No numerical co-processors
• Pandora decoder
• Minimum on-device computing
• Intergized computation
• Compact data structure

59
Summary

• Decoder
• Generating translation lattice
• Finding best path
• Limited word reordering
• Generation of N-best list
• Esp used for tuning system
• May also be used for downstream NLP modules
• Tuning of System
• Find optimal set of scaling factors
• Done on n-best list for speed
• Direct minimization of any MT eval metric
