POND: THE OCEANSTORE PROTOTYPE

1
PONDTHE OCEANSTORE PROTOTYPE

• S. Rea, P. Eaton, D. Geels,
• H. Weatherspoon, J. Kubiatowicz
• U. C. Berkeley

2
Key Ideas

• Versioning file system
• Location independent routing
• Uses hashes instead of addresses
• Mapping is done through Tapestry
• Byzantine update commitment
• By nodes holding primary copies (inner ring)
• Proactive threshold signatures allow inner ring
  membership updates

3
Key Ideas

• Push-based update of other copies
• Through an overlay multicast network
• Copies are not permanent
• Continuous archiving in erasure-coded form
• Very reliable
• Very slow access

4
Motivation

• Find a better solution forlong-term management
  of data
• Enabling trends
• Near universal connectivity through
  high-bandwidth links
• Very fast increase of disk storage capacity per
  unit cost

5
OceanStore

• Internet-scale cooperative file system
• Will provide
• High durability
• Universal accessibility
• Will use a two-tiered storage system
• Stores data objects

6
Two-tiered organization

• Upper tier
• Powerful , well connected hosts
• Serialize changes and archive results
• Lower tier
• Less powerful hosts
• Can be user workstations
• Provide storage resources

7
Two-tiered organization
Archive
Primary replica (in inner ring)
Secondary replica
Secondary replica
Secondary replica
8
Basic requirements

• OceanStore should
• Let information be accessed fromany location
• Balance the tension between privacy and
  information sharing
• Offer an easily understandable and usable model
  of data consistency
• Guarantee data integrity

9
First basic assumption

• Infrastructure cannot be trusted , except in
  aggregate
• Host and routers can fail arbitrarily
• Must consider
• Passive failures host snooping,
• Active failures host injecting malicious
  messages,

10
Second basic assumption

• Infrastructure is continuously changing
• Performance of communication paths varies
• Resources enter and leave the network without
  warning
• System should
• Be at least self-organizing andself-repairing
• Aim to be self-tuning

11
The challenge

• Build a system that provides
• An expressive user interface
• High data availability
• High data durability
• High data privacy and integrity
• atop an untrusted and ever changing base

More ambitious than FARSITE
12
The data model

• OceanStore data object
• Similar to a traditional file
• Ordered sequence of read-only versions
• Versioning
• Simplifies consistency issues
• Allows recovery of previous versions
• Identical blocks are shared among versions

13
Data object implementation (I)

• Each data object has an AGUID(Active
  Globally-Unique Identifier)
• Secure hash of application-level name and private
  key of owner
• Each version has a VGUID (Version GUID)
• BGUID of root block of a version
• Each block has a BGUID (Block GUID)
• Secure hash of block contents

14
A data object
AGUID
VGUIDi
VGUIDi1
root block
COW
Indirect blocks
COW
Data blocks
15
Data object implementation

• AGUID, VGUID and BGUID arelocation-transparent
• OceanStore relies on a lower-level serviceto map
  GIDs into addresses

16
Application-level consistency (I)

• Updating an object means creating a new version
• Updates are
• Atomic
• Represented as an array of potential actions each
  guarded by a predicate

17
Application-level consistency (II)

• Actions can be
• Appending data
• Replacing bytes at a specific address
• Predicates can be
• Checking the latest version number of the object
• Verifying values of bytes at a specific address

18
Application-level consistency (II)

• Actions can be
• Appending data
• Replacing bytes at a specific address
• Predicates can be
• Checking the latest version number of the object
• Verifying values of bytes at a specific address

19
Application-level consistency (III)

• Predicate and action model
• Allows to implement multiple level of consistency

• Atomic transactions satisfying ACID properties
  for database applications
• Weaker consistency for mailboxes

20
A footnote

• ACID properties of atomic transactions mean that
  atomic transactions
• Are Atomic
• Bring the database from one consistent state to
  another consistent state
• Isolate their partial results until the
  transaction is completed
• Guarantee the durability of final result

21
Virtualization through Tapestry

• OceanStore messages are addressed with a GUID
• Tapestry forwards these messages to host
  containing a resource with that GUID
• Fully decentralized service
• Hosts can
• Join tapestry by supplying its GUID
• Publish the GUIDs of the resources they have

22
Replication and consistency (I)

• Each object has a single primary replica
• Primary replica
• Serializes and applies all updates
• Creates a certificate (heartbeat ) mapping AGUID
  of object to GUID of its latest version
• Controls access to the object

23
Replication and consistency (II)

• Heartbeat contains
• An AGUID
• A VGUID
• A timestamp
• A version sequence number
• Getting the most recent version of object means
  getting its most recent heartbeat

24
The inner ring

• Small set of co-operating servers that manage
  primary replicas
• Implement a Byzantine fault-tolerant protocol to
• Agree on all updates to an object
• Digitally sign the result

25
Archival storage

• Stores object versions that are not frequently
  accessed
• Uses erasure codes
• Each block
• Partitioned into m fragments
• Encoded into n gt m fragments
• Any subset of m fragments suffices to
  reconstitute the block

26
Caching of data objects

• Retrieving data from archive is slow
• OceanStore also maintains of whole blocks
• Secondary replicas
• Heartbeats always come from theprimary replica
• Updates of secondary replicas are done through a
  dissemination tree

27
Path of an OceanStore update
Archive
Primary replica in inner ring
Application
Secondary replica
Secondary replica
Secondary replica
28
Updating primary replicas (I)

• Use a Byzantine fault-tolerant protocol
• Tolerates up to f failures in a system made up
  of 3f 1 hosts
• Protocol uses digitally signed messages using
  symmetric key message authentication code
• Faster than using public keys
• Complicates the Byzantine agreement protocol

29
Updating primary replicas (II)

• Solution was to use
• Symmetric keys for all communications within the
  inner ring
• Public keys to communicate with all other machines

30
Proactive threshold signatures

• (listen to lecture)

31
Prototype software architecture
Disseminationtree/replicas
Inner ring
Clientinterface
Byzantineagreement
Application
Archive
32
The prototype

• Written in Java

33
Conclusion
