Title: COMP 206 Computer Architecture and Implementation Unit 8a: Basics of Caches


1
COMP 206Computer Architecture and
ImplementationUnit 8a Basics of Caches
  • Siddhartha Chatterjee
  • Fall 2000

2
The Big Picture Where are We Now?
  • The Five Classic Components of a Computer
  • This unit Memory System

Processor
Input
Memory
Output
3
The Motivation for Caches
  • Motivation
  • Large memories (DRAM) are slow
  • Small memories (SRAM) are fast
  • Make the average access time small by servicing
    most accesses from a small, fast memory
  • Reduce the bandwidth required of the large memory

4
The Principle of Locality
  • The Principle of Locality
  • Program access a relatively small portion of the
    address space at any instant of time
  • Example 90 of time in 10 of the code
  • Two different types of locality
  • Temporal Locality (locality in time) If an item
    is referenced, it will tend to be referenced
    again soon
  • Spatial Locality (locality in space) If an item
    is referenced, items whose addresses are close by
    tend to be referenced soon

5
Levels of the Memory Hierarchy
6
Memory Hierarchy Principles of Operation
  • At any given time, data is copied between only 2
    adjacent levels
  • Upper Level (Cache) the one closer to the
    processor
  • Smaller, faster, and uses more expensive
    technology
  • Lower Level (Memory) the one further away from
    the processor
  • Bigger, slower, and uses less expensive
    technology
  • Block
  • The minimum unit of information that can either
    be present or not present in the two-level
    hierarchy

Lower Level (Memory)
Upper Level (Cache)
To Processor
Blk X
From Processor
Blk Y
7
Memory Hierarchy Terminology
  • Hit data appears in some block in the upper
    level (example Block X in previous slide)
  • Hit Rate the fraction of memory access found in
    the upper level
  • Hit Time Time to access the upper level which
    consists of
  • RAM access time Time to determine hit/miss
  • Miss data needs to be retrieve from a block in
    the lower level (Block Y on previous slide)
  • Miss Rate 1 - (Hit Rate)
  • Miss Penalty Time to replace a block in the
    upper level
  • Time to deliver the block the processor
  • Hit Time ltlt Miss Penalty

8
Cache Addressing
  • Block/line is unit of allocation
  • Sector/sub-block is unit of transfer and
    coherence
  • Cache parameters j, k, m, n are integers, and
    generally powers of 2

9
Examples of Cache Configurations
Memory address
Block address Block offset
Tag Set Sector Byte
10
Storage Overhead of Cache
11
Basics of Cache Operation
12
Details of Simple Blocking Cache
Write Through
Write Back
13
Example 1KB, Direct-Mapped, 32B Blocks
  • For a 1024 (210) byte cache with 32-byte blocks
  • The uppermost 22 (32 - 10) address bits are the
    tag
  • The lowest 5 address bits are the Byte Select
    (Block Size 25)
  • The next 5 address bits (bit5 - bit9) are the
    Cache Index

14
Example 1a 1KB Direct Mapped Cache
15
Example 1b 1KB Direct Mapped Cache
16
Example 2 1KB Direct Mapped Cache
17
Example 3a 1KB Direct Mapped Cache
18
Example 3b 1KB Direct Mapped Cache
19
A-way Set-Associative Cache
  • A-way set associative A entries for each Cache
    Index
  • A direct-mapped caches operating in parallel
  • Example Two-way set associative cache
  • Cache Index selects a set from the cache
  • The two tags in the set are compared in parallel
  • Data is selected based on the tag result

20
Fully Associative Cache
  • Push the set-associative idea to its limit!
  • Forget about the Cache Index
  • Compare the Cache Tags of all cache tag entries
    in parallel
  • Example Block Size 32B, we need N 27-bit
    comparators

21
Cache Shapes
Direct-mapped (A 1, S 16)
2-way set-associative (A 2, S 8)
4-way set-associative (A 4, S 4)
8-way set-associative (A 8, S 2)
Fully associative (A 16, S 1)
22
Need for Block Replacement Policy
  • Direct Mapped Cache
  • Each memory location can only mapped to 1 cache
    location
  • No need to make any decision -)
  • Current item replaces previous item in that cache
    location
  • N-way Set Associative Cache
  • Each memory location have a choice of N cache
    locations
  • Fully Associative Cache
  • Each memory location can be placed in ANY cache
    location
  • Cache miss in a N-way Set Associative or Fully
    Associative Cache
  • Bring in new block from memory
  • Throw out a cache block to make room for the new
    block
  • We need to decide which block to throw out!

23
Cache Block Replacement Policies
  • Random Replacement
  • Hardware randomly selects a cache item and throw
    it out
  • Least Recently Used
  • Hardware keeps track of the access history
  • Replace the entry that has not been used for the
    longest time.
  • For two-way set-associative cache one needs one
    bit for LRU replacement
  • Example of a Simple Pseudo LRU Implementation
  • Assume 64 Fully Associative entries
  • Hardware replacement pointer points to one cache
    entry
  • Whenever an access is made to the entry the
    pointer points to
  • Move the pointer to the next entry
  • Otherwise do not move the pointer

24
Cache Write Policy
  • Cache read is much easier to handle than cache
    write
  • Instruction cache is much easier to design than
    data cache
  • Cache write
  • How do we keep data in the cache and memory
    consistent?
  • Two options (decision time again -)
  • Write Back write to cache only. Write the cache
    block to memory when that cache block is being
    replaced on a cache miss
  • Need a dirty bit for each cache block
  • Greatly reduce the memory bandwidth requirement
  • Control can be complex
  • Write Through write to cache and memory at the
    same time
  • What!!! How can this be? Isnt memory too slow
    for this?

25
Write Buffer for Write Through
  • A Write Buffer is needed between cache and main
    memory
  • Processor writes data into the cache and the
    write buffer
  • Memory controller write contents of the buffer
    to memory
  • Write buffer is just a FIFO
  • Typical number of entries 4
  • Works fine if store frequency (w.r.t. time) ltlt 1
    / DRAM write cycle
  • Memory system designers nightmare
  • Store frequency (w.r.t. time) gt 1 / DRAM write
    cycle
  • Write buffer saturation

26
Write Buffer Saturation
  • Store frequency (w.r.t. time) gt 1 / DRAM write
    cycle
  • If this condition exist for a long period of time
    (CPU cycle time too quick and/or too many store
    instructions in a row)
  • Store buffer will overflow no matter how big you
    make it
  • CPU Cycle Time ltlt DRAM Write Cycle Time
  • Solutions for write buffer saturation
  • Use a write back cache
  • Install a second level (L2) cache

27
Write Allocate versus Not Allocate
  • Assume that a 16-bit write to memory location
    0x00 causes a cache miss
  • Do we read in the block?
  • Yes Write Allocate
  • No Write No-Allocate

28
Four Questions for Memory Hierarchy
  • Where can a block be placed in the upper level?
    (Block placement)
  • How is a block found if it is in the upper level?
    (Block identification)
  • Which block should be replaced on a miss? (Block
    replacement)
  • What happens on a write? (Write strategy)
