Fusion of frequency and spatial domain information for motion analysis

1
Fusion of frequency and spatial domain
information for motion analysis

• Alexia Briasoulli, Narendra Ahuja
• Beckman Institute, Dept of ECE
• UIUC
• ICPR-2004

2
Motion Estimation Techniques

• Single motion estimation based on optical flow
  uses Brightness Constancy Constraint
• Data Conservation Constraint
• Assumes that image brightness of a region remains
  constant while its location may change
• Violated at motion and occlusion boundaries,
  specular reflections and transparency
• Spatial Coherence Constraint
• Assumes that surfaces have spatial extent and
  optical flow within the neighbourhood changes
  gradually
• Violated at surface boundaries

3
Spatial Approaches

• Detection and estimation of multiple motions is a
  segmentation problem
• Ill posed Requires simultaneous determination
  of optical flow and motion boundary
• Generalized Aperture Problem
• Aperture size must be large to detect the
  presence of motion (to constrain the solution)
• Aperture size must be small to avoid violating
  optical flow assumptions and avoid multiple
  motion
• Most spatial approaches uses iterative-EM
  techniques on parametric models

4
Spatiotemporal Energy Model

• Adelson and Bergen, 1984, Journal of the Optical
  Society of America
• Provide an optical flow analysis for single body
  motion based on spectral anaysis
• A motion sequence is a pattern in the x-y-t space
• Velocity of motion corresponds to a 3D
  orientation in this space
• Motion orientation and motion energy can be
  extracted by linear filters oriented in
  space-time and tuned in spatial frequency

5
Spectral vs. Spatial Approaches

• Yu, et al. showed that
• Spectral motion model describes both occlusion
  and transparency based discontinuities
• Spatial model is more appropriate for occlusion
  analysis because it provide finer resolution and
  requires less frames
• Spatially
• Image sequence can be decomposed into different
  layers, where each layer has a smooth optical
  flow field
• Discontinuities due to occlusion and transparency
  are different in the spatial domain
• Occlusion is a step-function at the occlusion
  boundary
• Transparency results from overlap of 2 motions in
  the window
• Cannot be unified into a single model which
  accounts for both kinds of multiple motions

6
Spectral Analysis of Occlusion

• Occlusion in spatial domain is modeled by
• where
• x 2D spatial coordinates
• U(x) Heavyside unit step function describing
  the occlusion boundary
• I1(x) Occluding 2D signal (foreground) moving
  with velocity v1(u1,v1)
• I2(x) Occluded 2D signal (background) moving
  with velocity v2(u2,v2)
• FT of the signal is
• where
• k spatial frequency (?x, ?y)T
• ?t temporal frequency
• The first term is the spectrum of the occluding
  signal along with a distortion term A(k)
• The second term is the exact spectrum of the
  occluded signal
• The third term is a convolution of a 3D spectral
  line passing through the origin and the spectrum
  of the occluded signal

7
Spectral Analysis of Transparency

• Transparency is viewed as a special case of
  occlusion by substituting the Heavyside function
  with a real constant a (0ltalt1)
• The corresponding spectrum is characterized by 2
  oriented planes without distortion
• Though in the case occlusion there is an
  additional distortion term, most of the energy is
  concentrated on the two spectral planes
• Thus both occlusion and transparency are
  characterized by multiple spectral planes passing
  through the origin
• Corresponding motion is described by the normals
  to these planes!!

8
Comparison

• With spectral analysis, multiple planes describe
  both occlusion and transparency based
  discontinuities
• Spatial analysis is able to describe only
  occlusion based motion
• However, there is a severe problem in obtaining
  the energy spectrum of an image sequence
• Due to the block effect of the DFT
• To overcome this, the LFT is used blurring of
  the spectrum reduces resolution of spectral
  model
• To increase resolution, the LFT window needs to
  be increased, but in a large spatio-temporal
  neighborhood the constant motion assumption is
  endangered
• Therefore occlusions are best analyzed in spatial
  domain

9
Why Integrated Approach?

• Spectral analysis has following advantages
• Motion estimation is based on phase changes of
  the FT, so it is robust to global illumination
  changes
• Computational cost is significantly lower
• Size and shape of moving objects do not affect
  analysis
• However spectral information suffers from
  resolution problems
• Use spatial information to improve analysis
  accuracy

10
Frequency Domain

• M Number of moving objects l, 1 l M
• luminance at pixel and velocity
• The FT of object l is
• Where
•
  is the 2D freq
• is the image size
• is FT magnitude and is
  FT phase
• Each object is displaced by after
  each frame, so its FT becomes
• Background has FT
• FT of frame k is
• Measurement noise is

11
Frequency Domain (contd)

• For frame 1
• A moving object occludes one part of the
  background and un-occludes another. FT of
  un-occluded and occluded parts of background from
  frames 1 to k are and
• FT of frame N
• Stacking the FTs of the N frames
• X Z Vnoise Vbck
• where Z is N x (M 1) data matrix
• Vnoise is additive measurement noise
• Vbck represents occluded and unoccluded
  background areas

12
Frequency Domain (contd)

• Decompose Z as Z AS
• S Sb, S1,, SMT
• A a Vandermonde matrix containing motion
  information, with rows
• We have
• is an overdetermined system
• solve in an LS sense to get S

13
Counting Number of Objects

• Rank of noiseless data correlation matrix
  RZARSAH, where is RS the correlation matrix of S
  is equal to rank of A
• Due to Vandermonde structure of A, it has M
  independent columns. Therefore rank gives number
  of independently moving objects
• For noise with RV s2I, singular values of
  sample correlation matrix RX are
• Where are the
  singular values of RZ
• In practice so M can be
  determined from them

14
Motion Estimation

• FT of the frames contains motion information in
  the form of a sum of weighted harmonics
• Authors propose a simple, computationally cheap
  method for motion estimation that is not
  restricted to constant translations
• Constant Motion
• Phase change F1,k of frames 1 k
• Its inverse FT f1,k is a weighted sum of delta
  functions
• Peaks corresponding to the harmonics
  for each object l
• Can extract motion
• In practice aliasing due neighboring peaks can
  degrade resolution
• First detect and remove strong motion components.

• Then weaker harmonics can be detected more easily

15
Time Varying Motion

• Initially estimated gives the avg velocity

• T1,k is the time from frame 1 to k
• This can be repeated for shorter subsequences,
  until velocities become similar, which results in
  constant motion
• If velocity of object l from frames 1 to k is
  and the rows of
  are
• does not have Vandermonde structure, so
  number of independent motions cannot be estimated
  beforehand
• However, displacements between frames 1 to k can
  be estimated
• From these estimates number of motions can be
  found
• S can be obtained by an LS solution of
  instead of A.

16
Difference Masks from Frequency Domain Solutions

• A accurate solution for S can be obtained from X
  X Vbck Z Vnoise, if Vbck is known
• Approximate Vbck using object mask which is
  iteratively improved
• From each LS solution and frame luminance s
  at each pixel, get
• Dmask,l closer to 1 for pixels belonging to
  object l since Dl(x,y)0 in these positions
• In pixels not on object l, Dmask,l is closer to 0
• Thus LS solution of Sl gives a measure of
  probability that a pixel (x,y) belongs to object l

17
Probability Masks from Velocity Mapping

• Frame pixels are tracked by assigning object
  velocities or background velocity 0 to each of
  them
• If a pixel is tracked with correct velocity
  its luminance remains fairly constant, i.e. it
  has small variance
• pixel is tracked with incorrect velocity, its
  variance increases
• Let Fl be the probability that tracked pixel has
  small variance i.e. the pixel belongs to object l
• This gives spatial probability mask
• that pixel (x,y) belongs to object l
• Frequency based and spatial masks are combined to
  give an optimal probability mask that helps find
  the Vbck and S

18
Results Synthetic Data

• Constant Motion
• 2 squares translating against a black background
• SVD of Rx has 2 harmonics
• Peaks of FT give correct velocities, and moving
  objects are correctly segmented

• Non-constant Translational Motion
• 2 separate motions in frames 1-5 and frames 6-16
• When all frames are used estimates between true
  values are obtained
• When analyzed as two sequences, there is a clear
  separation of time varying velocites

19
Results - Real Image Synthetic Sequences

• Motion is accurately estimated as 15,0
• There are artifacts in determination of Vbck,
  which become zero when Vbck is known
• Vertical stripes outside the motion region due to
  regularization in the LS solution

20
Results Real Sequence with Multiple Objects

• Sequence with dark car moving rightwards and
  white car moving leftwards
• Initial LS solution separates background and the
  2 moving objects
• Frequency domain results are enhanced by the
  spatial techniques (probability masks) which
  reduces error

Original sequence
Initially recovered background
Originally extracted first and second cars
Cars after spatial masking technique
21
Conclusion and Critique

• Contributions
• Authors build on work done by Yu, Sommer, et
  al. towards integrating spatial and spectral
  methods
• Propose new technique of determining number of
  objects, motion estimation and segmentation in
  frequency domain, coupled with object masks in
  spatial domain to improve robustness
• Results look good
• Limitations
• Method is restricted to translational motion only
  not obvious how it can be extended to rotations
  and shear (rotations will destroy the Vandermonde
  structure of the A matrix)
• The technique for non-constant translations is
  very hacky
• Avoid addressing the segmentation problem by
  recasting it as temporal segmentation
• I suspect it would not work very well in practice

• Paper does not address the theoretical
  foundations of the mathematics.
