Eddington artist impression

1
Eddington artist impression
2
ESA Eddington - vital statistics
3 x 0.9m co-aligned Schmidt telescopes 3
colour filters
18 x 3Kx2K E2V frame-transfer CCDs 1Mhz (2-8s)
readout
FoV25 sq deg 3 arcsec/pix defocus psf 10-30
arcsec diam
Soyuz/Fregat Launch L2 orbit 2008 June 5
(3?) year mission
Eddington UK PPRP
Birmingham 10 Oct 2003
3
Eddington Science
Discovery of Small Planets -- hot and habitable
Earths
(Albedo of hot Jupiter atmospheres)
Seismology of Stars -- ages for all major stellar
populations
thousands of stellar interior maps
1 ages, metalicities.
Mixing/rotation 10-20 fields
t1-3 mo
Exploration of time domain discovery space
Eddington UK PPRP
Birmingham 10 Oct 2003
4
Seismology of Stars

• stellar interior maps across the H-R diagram
  - age-rotation (meridional circulation)
  - low-mass stars
  (settling of H, metals)
  - high-mass stars (convective overshooting,
  .
  supernova progenitors, yield to ISM)
• 1 ages for Galactic stellar populations
• stellar evolution testbed
• properties of matter under extreme conditions
• Solar chronology in a stellar context

Eddington UK PPRP
Birmingham 10 Oct 2003
5
Solar interior rotation
Slow surface rotation at poles
Shear at base of convection zone
Near solid body rotation of core
6
Pulsating stars span the HR diagram
Eddington will allow to study all possible types
of pulsating stars
Eddington will measure stellar interior
structures across the entire HR diagram
7
Inversion of simulated Eddington data for a 1.45
Msun star
Edge of convective core to within 1
Size of convective core determined within 1!
8
Accuracy of stellar parameters
For an open cluster with moderate mass stars
(e.g. Hyades) with 1) classical observables
(UBV,parallax, Fe/H, etc)
. 2) frequency separations
.
3) detailed inversion from observed frequencies
Eddington UK PPRP
Birmingham 10 Oct 2003
9
Eddington Exoplanet Science
Discover and characterize a large number and
variety of extra-solar planets, including
habitable worlds.
Liquid water
Rocky, with atmosphere
Design to detect
habitable planets per star
Eddington UK PPRP
Birmingham 10 Oct 2003
10
HST/FOS lightcurve of HD 209458 transit
11
Mercury transiting the Sun 15 Nov 1999
12
Design Goalto detect Earth analogs
Transit probability
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Eddington history
2000 - selected as an ESA Reserve mission 2002
- fully approved for 2008 launch ESA funds ( 200
Meuro) -- Spacecraft -- Herschel bus clone --
Payload (built by industry (Alcatel or Astrium)
20
Eddington baseline payload

• Final definition ongoing!
• White light, wide field photometer
• Multiple (3x) telescopes
• Ca. 0.8 m2 collecting area
• Ca. 20 sq. deg field of view

21
Eddington data products

• Long-term, highly accurate photometric light
  curves of selected targets in the field of view
• Up to 100,000 targets in PF field, 20,000 in AS
  fields
• 30 s time resolution in AS fields, 600 s time
  resolution in PF field
• Photon-noise limited

22
Eddington baseline observing program

• 5 yr observational lifetime
• 3 yr uninterrupted planet-finding observation
• Asteroseismology also performed
• 2 yr total asteroseismic observations
• 1-3 months duration typical
• Planet-finding also performed
• Can be interleaved
• Both key science goals always on!
• Parallel and auxiliary science always ongoing

23
Eddington, status

• Proposed in early 2000 to ESA as a
  flexy-mission (176 MEur envelope, 192 Meur 2003
  value)
• Selected as reserve mission in late 2000
• Approved in May 2002 as element of ESAs Cosmic
  Visions science program for launch early 2008
• Currently in a competitive definition phase
  (phase B) with two contractors
• Ready to start the implementation phase (phase
  C/D) in May 2004 for a 2008 launch

24
Eddington development approach

• Complete mission is ESA-funded and developed
  under ESA responsibility
• S/C (Herschel bus clone)
• P/L (Built by industry)
• Launch
• Ground segment (including SOC)
• No dependence on external funding sources

25
Eddington P/L Consortium

• Key scientific role, no H/W procurement
• Defines (together with Science Team) and oversees
  instrument specs and development
• Develops flight and ground science S/W
• Definition and execution of P/L calibration
• Proposal for P/L Consortium received, involves 41
  institutions in 11 countries

26
(No Transcript)
27
Eddington Payload Consortium - organigram
28
UK role in Payload Consortium - CCD
characterisation
29
A community mission

• Fully open data policy
• No proprietary rights, data immediately available
  to complete ESA scientific community
• Fully open observing program
• 1-3 month fields program to be defined by
  community, through an AO cycle
• 3 yr field being currently being defined by
  Eddington community
• Ample space for additional science, additional
  targets

30
Eddington low-risk approach

• S/C and P/L fully scoped (cost, schedule) by
  industry
• Scientific specs very tight and clear
• High level of definition
• High technological maturity
• No development items, no hidden surprises
• As a consequence, no financial risk

31
Eddington vs Kepler

• 3 x 0.9m 2.3 sq.m
• 20 sq deg
• 3 colours
• L2 orbit

• 1 x 1.2m
• 100 sq deg
• white light
• drift-away orbit

32
Kepler, status(from the Kepler web site)

• Systems requirements review Oct. 2003
• Preliminary design review Oct. 2004
• Critical design review Aug. 2005
• Launch Oct. 2007
• 60 flight CCDs to be procured (none delivered yet)
