Distributed Data Management and Processing 2.3

1
Distributed Data Management and Processing 2.3

• Ian Fisk
• U.C. San Diego

2
Introduction to 2.3, Distributed Data Management
and Processing

• 2.3 Distributed Data Management and Processing
  develops software tools to support the CMS
  Distributed Computing Model.

Tier 01
100 MBytes/sec
Online System
PBytes/sec
US Center Fermilab
Italy Regional Center
Tier 1
France Regional Center
UK Regional Center
Tier 2
Tier 3
Institute
Institute
Institute
Institute
Physics data cache
Tier 4
3
Introduction to 2.3, Distributed Data Management
and Processing

• Supporting the CMS Distributed Computing Model is
  a daunting task.
• 1/3 Processing Capability at Tier0, 1/3 Tier1s,
  and 1/3 Tier2s
• Centers are spread globally over networks of
  variable bandwidth
• Most physicists will be performing analysis at
  remote centers that locally have only a portion
  of the raw or reconstructed data.
• Creating tools that will allow efficient access
  to data at local sites and to resources at remote
  sites is a complicated task.
• This is a larger dataset, using more computing
  power, spread over a greater distance, than HEP
  has previously attempted and it requires a more
  advanced set of tools.

4
Introduction to 2.3, Distributed Data Management
and Processing

• DDMP attempts to break the project into 5
  manageable pieces for efficient development
• 2.3.1 Distributed Process Management
• 2.3.2 Distributed Database Management
• 2.3.3 Load Balancing
• 2.3.4 Distributed Production Tools
• 2.3.5 System Simulation
• The combination of these should allow CMS to
  take full advantage of the grid of Distributed
  Computing Resources.
• CMS has immediate needs for simulation for use in
  completing TDRs (HLT, Physics, ). Wherever
  possible the project attempts to develop tools
  that are useful in production at existing
  facilities while developing more advanced tools
  for the future.

5
Introduction to 2.3 Distributed Data Management
and Processing

• Distributed Data Management and Processing
  attempts to integrate software developed
  elsewhere whenever possible. Exploiting a number
  of tools being developed for grid computing.

6
Introduction to Distributed Process Management
2.3.1

• The Goal of Distributed Process Management is to
  develop tools that enable physicists to make
  efficient use of computing resources distributed
  world wide.
• There are a number of tools available with
  similar goals (LSF, PBS, DQS, Condor, ) but at
  the moment none are judged to be adequate to meet
  long term needs of CMS.
• Important Issues
• Keeping track of long running jobs
• Support collaboration among multiple physicists
• Conserving limiting network bandwidth
• Maintaining high availability
• Tolerating partition failures that are common to
  WANs

7
Distributed Process Management Prototype
Development

• Prototype introduces the concept of a session
  which is a container for interrelated jobs. This
  allows submission, monitoring, and termination
  with a single command. Sessions can be shared
• Processors can be chosen based on data
  availability,processor type, and load.

• Replicated states are maintained so that
  computations
• will not be lost if a server fails.
• Prototype is based on functional language ML and
• Group Communications Toolkit. The Group
• Communications Toolkit aids writing
  distributed
• programs.

8
Distributed Process Management Current Status

• Working prototype exists with features described
  on previous slide.
• The system has been tested with 32 processors
  performing CMS ORCA production.
• Some scalability issues were encountered and
  repaired.
• System has been tested on 65 processors with no
  scalability problems encountered.

9
Distributed Process Management Prototype Future
Plans

• In the next few months Distributed Process
  Management will move development efforts to the
  CMS Tier2 Prototype Computation Center at
  Caltech/UCSD.
• The unique split nature of the center and large
  number of processors makes it a nearly ideal
  place to work on scalability, remote submission,
  and more complex ORCA scenarios.
• Spring 2001 there are plans for support for
  multiple users and development of a queuing
  system when resources are unavailable.
• First Prototype is expected to be complete in the
  summer of 2001.

10
Distributed Process Management Fully Functional
Development

• Milestones tied to deliverables to CMS for use in
  production.
• Program starts with algorithm development for use
  in Process Management including data aware Self
  Organizing Neural Network agents for scheduling.
• Fully Functional should be completed sometime in
  2003.

11
Introduction to Distributed Database Management
2.3.2

• Distributed Database Management develops tools
  external to the ODBMS that control replication
  and synchronization of data over the grid as well
  as monitoring and improving the performance of
  database access.
• As event production becomes less CERN centric
  there is an immediate need for tools to replicate
  data produced at remote sites. There is also a
  need to evaluate and improve the performance of
  database access.
• In the future for Distributed Production there is
  a need for tools to automatically synchronize
  some databases over all sites analyzing results
  and a need to replicate databases on demand for
  remote analysis jobs.
• Distributed Database Management attempts to meet
  both these needs.

12
Distributed Database Management Prototype
Development

• To meet the long and short term goals two paths
  were pursued an investigational prototype
  written in Perl and development with the Grid
  Data Management Pilot (GDMP) on a functional
  prototype based on Globus Middleware.
• Both require high speed transfers, secure data
  access, transfer verification, integration of the
  data upon arrival, and remote catalogue querying
  and publishing.

13
Investigational Prototype Goals

• one-way bulk replication of read-only (static)
  datafiles
• simple prototype using available software
• RFIO from HPSS to disk at CERN
• SCP from disk at CERN to disk at Fermilab
• FMSS to archive from disk at Fermilab to tape
• Objectivity tools (oodumpcatalog, oodumpschema,
  oonewfd, ooschemaupgrade, ooattachdb)
• all wrapped up in Perl with HTTP and TCP/IP
• aim for automation, not performance
• transferring 1 2GB file is easy, transferring
  1000 is not
• objective is to clone (part of) a federation from
  CERN in Fermilab.
• automated MSS ? MSS transfer via (small) disk
  pools
• use as a possible fallback solution.
• documentation at http//home.cern.ch/wildish

14
Investigational Prototype Steps

• The basic steps
• Create an empty federation with the right schema
  and pagesize.
• Get the schema directly from the source
  federation via a web-enabled ooschemadump.
• Find out what data is available.
• Use a web-enabled oodumpcatalog to list the
  source federation catalogue.
• Determine what is new w.r.t. your local
  federation.
• Use a catalogue-diff, based on DB Name or ID.
• Request the files you want from a server at the
  source site.
• Server will stage files from HPSS to a local disk
  buffer, then send them to you.
• Process files as they arrive.
• Attach them to your federation, archive them to
  MSS, purge them when your local disk buffer fills
  up.
• Repeat steps 2,3,4 as desired, and step 5 as
  desired.

15
Exporting data prototype design
http
Catalogue-server
Remote client
ooschemadump oodumpcatalog
ooschemaupgrade oonewfd
User federation
New cloned federation
(firewall?)
(firewall?)
CERN
Fermilab
16
Distributed Database Management Investigational
Prototype Exporting
http
Catalogue-server
Catalogue-diff
TCP socket
DBServer
oodumpcatalog
HPSS
Local cloned federation
rfcp
(firewall?)
MSS
disk pool
ooattachdb
scp (Secure Shell Copy)
archive
Process new DBs
(firewall?)
CERN
disk pool
Fermilab
17
Distributed Database Management Investigational
Prototype Results

• 600GB transferred in 9 days
• SHIFT20 (200GB disk) ? CMSUN1 (280GB disk)
• federation built automatically as data arrived
• data archived automatically to FMSS
• peak rate 2.7MB/sec sustainable for several hours
• performance unaffected by batch jobs running on
  Fermilab client or CERN server.
• best results with ? 40 simultaneous copies
  running
• monitored with the production-monitoring system
• monitor Fermilab client from a desktop at CERN
• Investigation Prototype development frozen, but
  parts of the code are being reused for
  Distributed Production Tools, updated monitoring
  system, and database comparisons.

18
Distributed Database Management Functional
Prototype

• Flexible, layered, and modular architecture
  designed to be able to support modifications and
  extensions using Globus as the basic Middleware.
• Data Model
• Export Catalog
• Contains information about the new files produced
  which are ready to be accessed by other sites.
• Export catalog is published to all the subscribed
  sites.
• A new export catalog is generated, every time a
  site wants to publish its files, which contains
  the newly generated files only.
• Import Catalog
• Contains the information about the files which
  have been published by other sites but not yet
  transferred locally.
• As soon as the file is transferred locally,
  validated and attached to the federation, it is
  removed from the import catalog.
• Subscription Service
• All the sites that subscribe to a particular site
  get notified whenever there is an update in its
  catalog. Supports both a push and pull
  mechanism.

19
Database Replicator Functional Prototype
Architecture

• Communication
• Control Messages
• Data Mover
• File Transfers
• Logging Incoming and Outgoing Files
• Resuming File Transfers
• Progress Meters
• Error Checks
• Security
• Authentication and authorization
• Replica Manager
• Handling Replica Catalogue
• Replica Selection and Synchronization

Application
Globus-threads
Request Manager
Globus-dc
Globus Rep. Manager
gssapi
GIS
Objy API
DB Manager
Information Service
Replica Manager
Security
Control Comm.
Data Mover
Globus-ftp
Globus_io
Layered Architecture for Distributed Data
Management
20
Database Replicator Functional Prototype
Architecture

• Information Service
• Publish data and network resources at sites.
• DB Manager
• Backend to database specific functions.
• Request Manager
• Generating Request on the client side and
  handling requests on the server side.
• Application
• Multi-threaded Server handling clients.

Application
Globus-threads
Request Manager
Globus-dc
Globus Rep. Manager
gssapi
GIS
Objy API
DB Manager
Information Service
Replica Manager
Security
Control Comm.
Data Mover
Globus-ftp
Globus_io
Layered Architecture for Distributed Data
Management
21
Integration into the CMS Environment
Site A
CMS environment
Physics software
CheckDB script
GDMP system
Write DB
DB completeness check
CMS/GDMP interface
Production federation
catalog
Site B
Purge file
Copy file to MSS
Stage Purge scripts
Stage Purge scripts
Copy file to MSS
MSS
MSS
Transfer attach
Update catalog
Purge file
User federation
User federation
catalog
catalog
wan
Stage file (opt)
trigger
trigger
trigger
read
GDMP export catalog
Subscribers list
GDMP import catalog
Replicate files
write
Generate import catalog
Publish new catalog
Generate new catalog
GDMP server
22
Database Replicator Functional Prototype Current
Status

• The decision was made to use the Functional
  Prototype in the fall ORCA production.
• This required adding some features and making it
  more fault tolerant.
• Parallel Transfers to improve performance.
• Resumption of file transfer from checkpoints to
  handle network interruptions.
• Catalogue filtering to allow more choices for
  files to import and export to remote sites.
• User Guide
• Being used at remote centers for ORCA fall
  production to handle replication of Objectivity
  files.

23
Database Replicator Prototype Future Plans

• When the GDMP tools were written they were
  tightly coupled to Objectivity applications and
  they were unable to replicate non-Objectivity
  files. With the addition of Globus Replica
  Catalogue, they should be able to perform file
  format independent replication in January of
  2001.
• In May 2001 integration and development of Grid
  Information Services should begin. At the moment
  the data replicator cannot make an intelligent
  choice as to which copy to access given choices.
  This decision should be made based on current
  network bandwidth, latency between two given
  nodes, load on the data servers, etc.

24
Fully Functional Prototype Development

• Development toward a fully functional prototype
  is foreseen starting after the summer of 2001 and
  continuing until 2003.
• This involves the testing and integration of grid
  tools currently under development
• Mobile agents that float on the network
  independently, communicate, and make intelligent
  decisions when triggered.
• Use of virtual data, the concept that all except
  irreproducible raw experimental data need exist
  only as specifications for how to derive them.

25
Request Redirection Protocol

• The second goal of Distributed Database
  Management was to evaluate and improve database
  access.
• The performance and capabilities of the
  Objectivity AMS server can be improved by writing
  plugins that conform to a well defined interface.

• To improve the availability of the database
  servers, one such plugin, the Request Redirection
  Protocol has been implemented. When the
  Federated Database has determined that an AMS has
  crashed (due to a disk failure, etc.), jobs can
  be automatically transferred to an alternate
  server. This has been implemented on the CERN
  AMS servers for a month.
• In early 2001, a security protocol plugin will be
  implemented.

26
Introduction to Load Balancing 2.3.3

• Balancing the use of resources in a distributed
  computing environment is difficult and requires
  the integration and augmentation of elements
  Distributed Process Management and Distributed
  Database Management with intelligent algorithms
  to determine the most efficient course of action.
• In a distributed computing system jobs can be
  submitted to the computing resources where the
  data is available or the data can be moved to
  available computing resources.
• Deciding between these two cases to efficiently
  complete all requests and balance the load over
  all the computing grid requires good algorithms
  and lots of information about network traffic,
  CPU loads, and data availability.

27
Load Balancing Current Status

• While there has been considerable work on
  Distributed Process Management and Distributed
  Database Management and some effort on
  information services and algorithm development,
  most of the work on Load Balancing is still to
  come.
• Preliminary Work has been done on a prototype of
  Grid Information Services using Globus
  Middleware.
• Publish outside domain resources that can be
  accessed inside domain.

• Static
• CPU Power
• Operating System Details
• Software Versions
• Available Memory

• Dynamic
• CPU Load
• Network Bandwidth
• Network Latency
• Updates every few seconds

28
Load Balancing Future Plans

• Algorithm Development should start in the summer
  of 2001 using conventional and Self Organizing
  Neural Network techniques.
• Integration of Distributed Process Management and
  Distributed Database Management should begin as
  those projects enter the fully functional
  prototype phase.

29
Introduction to Distributed Production Tools 2.3.4

• The Goal of Distributed Production Tools is to
  develop tools for immediate use to aid CMS
  production at existing computing facilities.
• Job submission
• Transferring and Archiving Results
• System Monitoring
• US-CMS until recently had no dedicated production
  facilities. Production in the US was performed
  on existing facilities with a wide variety of
  capabilities, platforms, and configurations.
• CMS has an immediate need for simulated events to
  complete the Trigger TDR and later the Physics
  TDR. This project helps to meet the immediate
  need, while lessons learned help long term goals
  as well.

30
Distributed Production Tools Current Status

• Based on the database replicator investigative
  prototype, tools have been designed to
  automatically record and archive results of
  production performed at remote sites and to
  transfer these results to the CERN mass storage
  system. This has been primarily used for
  archiving CMSIM production performed at Padua,
  Moscow, IN2P3, Caltech, Fermilab, Bristol, and
  Helsinki.
• Tools have been developed to utilize existing
  facilities in the US. The aging HP X-class
  Exemplar System has been used for CMSIM
  production and the Wisconsin Condor system, which
  is a scavenger system using spare cycles of
  Linux systems has been used for CMSIM production
  and will be used for ORCA production this fall.

31
Distributed Production Tools Current Status of
System Monitoring

• Tools have been developed to monitor production
  systems.
• This helps to evaluate and repair bottlenecks in
  the production systems.
• This provides realistic input parameters to the
  system simulation tools and improves the quality
  of simulation.
• This provides information to make intelligent
  choices about requirements of future production
  facilities.
• Monitoring uses Perl/bash scripts running on each
  node
• Information is generated in a netlogger
  inspired format.
• UDP datagrams transmit results to collection
  machines
• Numerical quantities are histogrammed every n
  minutes and put on the web.
• During Spring Production it was used to monitor
  150 nodes with 25MB ASCII logging per day.

32
Distributed Production Tools Current Status of
System Monitoring

• Goals of the project are to try to understand how
  best to arrange the data for fast access.
• Monitor standard things on data servers
• CPU, network, disk I/O, paging, swap, load
  average etc.
• Monitor the AMS.
• Which files the user reads (includes those
  already on disk).
• Number of open filehandles (also for Lockserver).
• Monitor the lockserver
• Transaction ages, hosts holding locks etc.
• Monitor the staging system
• Names of files staged in.
• Time it takes for them to arrive.
• Names of purged files.

33
System Monitoring Results

• This shows the AMS activity on 6 AMS servers by
  the simple means of counting the number of
  filehandles that each server had open at a given
  time.

34
Distributed Production Tools Future Plans

• Tools are being developed to support generic job
  submission over diverse existing computing
  facilities to improve the ease of use. The first
  of these which is based on LSF will be available
  in the spring of 2001.
• It is a relatively small extension of the system
  monitoring tools to initiate an action if the
  monitoring measures certain kinds of problems.
  Already a system exists to send e-mail to the
  appropriate people. Tools are being developed so
  that all the jobs in a batch queue should be able
  to be cleanly stopped or paused if the system
  monitoring tools determine that a server has
  crashed or that a disk has filled up.

35
Introduction to System Simulation 2.3.5

• Distributed Computing Systems of the scope and
  complexity proposed by CMS do not yet exist. The
  System Simulation project attempts to evaluate
  distributed computing plans by performing
  simulations of large scale computing systems.
• The MONARC simulation toolkit is used. The goals
  of MONARC are
• To provide realistic modeling of distributed
  computing systems, customized for specific HEP
  applications.
• To reliably model the behavior of computing
  facilities and networks, using specific
  application software and usage patterns.
• To offer a dynamic and flexible simulation
  environment.
• To provide a design framework to evaluate a range
  of possible computing systems as measured by the
  ability to provide physicists with the requested
  data within the required time.
• To narrow down a region of parameter space in
  which viable models can be chosen.
• The toolkit is Java based to take advantage of
  Javas built in support for multi-threaded for
  concurrent processing.

36
System Simulation Current Status

• MONARC is currently in its third phase and was
  recently updated to be able to handle larger
  scale simulations.
• The simulation of the spring 2000 ORCA production
  served as a nice validation of the tool kit.
  Using inputs from the system monitoring tools the
  simulation was able to accurately reproduce the
  behavior of the computing farm CPU utilization,
  network traffic and total time to complete jobs.
• As an indication of the maturity of the
  simulation tools, there is a simulation being
  performed of Distributed Process Management using
  Self Organizing Neural Networks. Since full
  scale production facilities will not be available
  for some time, it is nice to get a head start on
  algorithm development using the simulation.

37
System Simulation Current Status

• Simulation GUI

38
System Simulation Spring HLT Production
Below are simulation examples of network traffic
and CPU efficiency
Measurement
Simulation
39
System Simulation Future Plans

• Plans to update the estimated CMS computing needs
  in December.
• In early 2001 there are plans to update the
  MONARC package to have modules for Distributed
  Process Management and Distributed Database
  Management.

40
System Simulation Future Plans

• The upgraded package should allow better
  simulation of Distributed Computing Systems. Two
  are planned for Spring 2001
• A study of the role of tapes in Tier1-Tier2
  interactions, which should help describe
  interactions and evaluate storage needs.
• A complex study of Tier0-Tier1-Tier2 interactions
  to evaluate a complete CMS data processing
  scenario, including all the major tasks
  distributed among regions centers.
• During the remainder of 2001 the System
  Simulation Project will aid in the development of
  load balancing schemes.

41
Conclusions

• The CMS Distributed Computing model is complex
  and advanced software is needed to make it work.
• Tools are needed to submit, monitor and control
  groups of jobs at remote and local sites.
• Data needs to be moved over the computing grid to
  the processes that need it.
• An intelligent system needs to exist to determine
  the most efficient split of moving data and
  exporting processes.
• CMS has TDRs due which require large numbers of
  simulated events for analysis and tools are
  needed to facilitate production.
• We are trying to deliver both.
