High-Throughput Computing on Commodity Systems.

1
High-Throughput Computing on Commodity Systems.
2
The Good News

• Raw computing power is everywhere - on desk-tops,
  shelves, racks, and in your pockets. It is
• Cheap
• Plentiful
• Mass-Produced

3
The Bad News

• GFLOPS per year
• /
• GFLOPS per second
• 30,000,000 seconds/year

4
A variation on a chestnut

• What is a benchmark?

5
Answer

• The throughput which your system is
• guaranteed
• never to exceed!

6
Why?

• A community of commodity computers can be
  difficult to manage
• Dynamic State and availability change over
  time
• Evolving New hardware and software is
  continuously acquired and installed
• Heterogeneous Hardware and software
• Distributed ownership Each machine has a
  different owner with different requirements and
  preferences.

7
Why?

• Even traditionally static systems (such as
  professionally managed clusters) suffer the same
  problems when viewed at a yearly scale
• Power failures
• Hardware failures
• Software upgrades
• Load imbalance
• Network imbalance

8
How do we measure computer performance?

• High-Performance Computing
• Achieve max GFLOP per second under ideal
  circumstances.
• High-Throughput Computing
• Achieve max GFLOP per months or years in whatever
  conditions prevail.

9
High-Throughput Computing

• Focuses on maximizing
• simulations run before the paper deadline
• crystal lattices per week
• reconstructions per week
• video frames rendered per year
• without babysitting from the user.
• Cannot depend on ideal circumstances.

10
High-Throughput Computing

• Is achieved by
• Expanding the CPUs available.
• Silently adapting to inevitable changes.
• Robust software
• Is only marginally affected by
• MB, MHz, MIPS, FLOPS
• Robust hardware

11
Solution Condor

• Condor is software for creating a high-throughput
  computing environment on a community of
  workstations, ranging from commodity PCs to
  supercomputers.

12
Who are we?
13
The Condor Project (Established 85)

• Distributed systems CS research performed by a
  team that faces
• software engineering challenges in a
  UNIX/Linux/NT environment,
• active interaction with users and collaborators,
• daily maintenance and support challenges of a
  distributed production environment,
• and educating and training students.
• Funding - NSF, NASA,DoE, DoD, IBM, INTEL,
  Microsoft and the UW Graduate School
• .

14
Users and collaborators

• Scientists - Biochemistry, high energy physics,
  computer sciences, genetics,
• Engineers - Hardware design, software building
  and testing, animation, ...
• Educators - Hardware design tools, distributed
  systems, networking, ...

15
National Grid Efforts

• National Technology Grid - NCSA Alliance
  (NSF-PACI)
• Information Power Grid - IPG (NASA)
• Particle Physics Data Grid - PPDG (DoE)
• Grid Physics Network GriPhyN (NSF-ITR)

16
Condor CPUs on the UW Campus
17
Some NumbersUW-CS Pool

• 6/98-6/00 4,000,000 hours 450 years
• Real Users 1,700,000 hours 260 years
• CS-Optimization 610,000 hours
• CS-Architecture 350,000 hours
• Physics 245,000 hours
• Statistics 80,000 hours
• Engine Research Center 38,000 hours
• Math 90,000 hours
• Civil Engineering 27,000 hours
• Business 970 hours
• External Users 165,000 hours 19 years
• MIT 76,000 hours
• Cornell 38,000 hours
• UCSD 38,000 hours
• CalTech 18,000 hours

18
Start slow,but thinkBIG
19
Start slow, but think big!
1000 machines in the GRID.
100 machines in your department
1 machine on your desktop
One Personal Condor
Condor Pool
Condor-G
20
Start slow, but think big!

• Personal Condor
• Manage just your machine with Condor. Fault
  tolerance, policy control, logging. Sleep
  soundly at night.
• Condor Pool
• Take advantage of your friends and colleagues
  share cycles, gain 100x throughput.
• Condor-G
• Jobs from your pool migrate to other
  computational facilities around the world. Gain
  1000x throughput. (Record-breaking results!)

21
Key Condor User Services

• Local control - jobs are stored and managed
  locally by a personal scheduler.
• Priority scheduling - execution order controlled
  by priority ranking assigned by user.
• Job preemption - re-linked jobs can be
  checkpointed, suspended, hold and resumed.
• Local executing environment preserved - re-linked
  jobs can have their I/O re-directed to submission
  site.

22
More Condor User Services

• Powerful and flexible means for selecting
  execution site (requirements and preferences)
• Logging of job activities.
• Management of large (10K) numbers of jobs per
  user.
• Support for jobs with dependencies - DAGMan
  (Directed Acyclic Graph Manager)
• Support for dynamic MW (PVM and File)
  applications

23
How does it work?
24
Basic HTC Mechanisms

• Matchmaking - enables requests for services and
  offers to provide services find each other
  (ClassAds).
• Fault tolerance - Checkpointing enables
  preemptive resume scheduling (go ahead and use it
  as long as it is available!).
• Remote execution enables transparent access to
  resources from any machine in the world.
• Asynchronicity - enables management of dynamic
  (opportunistic) resources.

25
Every Communityneeds a Matchmaker!
26
Why? Because ...

• .. someone has to bring together community
  members who have requests for goods and services
  with members who offer them.
• Both sides are looking for each other
• Both sides have constraints
• Both sides have preferences

27
ClassAd - Properties

• Type Machine
• Activity Idle
• KbdIdle 002231
• Disk 2.1G //2.1 Gigs
• Memory 64M // 6.4 Megs
• State Unclaimed
• LoadAverage 0.042969
• Arch INTEL
• OpSys SOLARIS251

28
ClassAd - Policy

• RsrchGrp raman, miron, solomon
• Friends dilbert, wally
• Untrusted rival, riffraff, TPHB
• Tier member(RsrchGroup, other.Owner) ? 2
• ( member(Friends, other.Owner) ? 1 0 )
• Requirements !member(Untrusted, other.Owener)
• (Tier 2 ? True
• Tier 1 ? LoadAvg lt 0.3
• KbdIdle gt 0015 )
• DayTime() lt0800 DayTime()gt1800 )

29
Advantages of Matchmaking

• Hybrid (CentralizedDistributed) resource
  allocation algorithm
• End-to-end verification
• Bilateral specialization
• Weak consistency requirements
• Authentication
• Fault tolerance
• Incremental system evolution

30
Fault-Tolerance

• Condor can checkpoint a program by writing its
  image to disk.
• If a machine should fail, the program may resume
  from the last checkpoint.
• Ifa job must vacate a machine, it may resume from
  where it left off.

31
Remote Execution

• Condor might run your jobs on machines spread
  around the world not all of them will have your
  files.
• Condor provides an adapter a library which
  converts your jobs I/O operations into remote
  I/O back to your home machine.
• No matter where your job runs, it sees the same
  environment.

32
Asynchronicity

• A fact of life in a system of 1000s of machines.
• Power on/off
• Lunch breaks
• Jobs start and finish
• Condor never depends on a fixed configuration
  work with what is available.

33
Does it work?
34
An example - NUG28

• We are pleased to announce the exact solution of
  the nug28 quadratic assignment problem (QAP).
  This problem was derived from the well known
  nug30 problem using the distance matrix from a 4
  by 7 grid, and the flow matrix from nug30 with
  the last 2 facilities deleted. This is to our
  knowledge the largest instance from the nugxx
  series ever provably solved to optimality.
• The problem was solved using the branch-and-bound
  algorithm described in the paper "Solving
  quadratic assignment problems using convex
  quadratic programming relaxations," N.W. Brixius
  and K.M. Anstreicher. The computation was
  performed on a pool of workstations using the
  Condor high-throughput computing system in a
  total wall time of approximately 4 days, 8 hours.
  During this time the number of active worker
  machines averaged approximately 200. Machines
  from UW, UNM and (INFN) all participated in the
  computation.

35
NUG30 Personal Condor

• For the run we will be flocking to
• -- the main Condor pool at Wisconsin (600
  processors)
• -- the Condor pool at Georgia Tech (190 Linux
  boxes)
• -- the Condor pool at UNM (40 processors)
• -- the Condor pool at Columbia (16 processors)
• -- the Condor pool at Northwestern (12
  processors)
• -- the Condor pool at NCSA (65 processors)
• -- the Condor pool at INFN (200 processors)
• We will be using glide_in to access the Origin
  2000 (through LSF ) at NCSA.
• We will use "hobble_in" to access the Chiba City
  Linux cluster and Origin
• 2000 here at Argonne.

36
It works!!!

• Date Thu, 8 Jun 2000 224100 -0500 (CDT) From
  Jeff Linderoth ltlinderot_at_mcs.anl.govgt To Miron
  Livny ltmiron_at_cs.wisc.edugt Subject Re Priority
• This has been a great day for metacomputing!
  Everything is going wonderfully. We've had over
  900 machines (currently around 890), and all the
  pieces are working great
• Date Fri, 9 Jun 2000 114111 -0500 (CDT) From
  Jeff Linderoth ltlinderot_at_mcs.anl.govgt
• Still rolling along. Over three billion nodes in
  about 1 day!

37
Up to a Point

• Date Fri, 9 Jun 2000 143511 -0500 (CDT) From
  Jeff Linderoth ltlinderot_at_mcs.anl.govgt Hi Gang,
• The glory days of metacomputing are over. Our job
  just crashed. I watched it happen right before my
  very eyes. It was what I was afraid of -- they
  just shut down denali, and losing all of those
  machines at once caused other connections to time
  out -- and the snowball effect had bad
  repercussions for the Schedd.

38
Back in Business

• Date Fri, 9 Jun 2000 185559 -0500 (CDT) From
  Jeff Linderoth ltlinderot_at_mcs.anl.govgt
• Hi Gang,
• We are back up and running. And, yes, it took me
  all afternoon to get it going again. There was a
  (brand new) bug in the QAP "read checkpoint"
  information that was making the master coredump.
  (Only with optimization level -O4). I was nearly
  reduced to tears, but with some supportive words
  from Jean-Pierre, I made it through.

39
The First 600K seconds
40
We made it!!!

• Sender goux_at_dantec.ece.nwu.edu Subject Re Let
  the festivities begin.
• Hi dear Condor Team,
• you all have been amazing. NUG30 required 10.9
  years of Condor Time. In just seven days !
• More stats tomorrow !!! We are off celebrating !
• condor rules !
• cheers,
• JP.

41
Do not be picky, be agile!!!
